Whirlpool AWZ 8596 Quick Reference Manual

AWZ 8596
GB
Options
Drying Times
Cupboard dry plus
Cotton
Cupboard dry
Max. 6 kg
Iron dry
Cupboard dry plus
Easy care
Cupboard dry
Max. 2.5 kg
Iron dry
Airing
Laundry is aired for 9 minutes without
heating.
• Recommended drying times are based on spinning speeds of 800, 1000 and 1200 rpm.
• For reduced spinning speed a longer drying time should be selected.
• Drying times may be longer for towelling and heavier items.
Gentle Buzzer
Reduces drying Signals/Sounds
intensity end of drying
(recommended for cycle at intervals
delicate items)
-
Recommended
Time Selection
Start Delay Spin speed
Delays the drying
Washing Machine
cycle start
rpm rpm rpm
800 1000 1200
105' 80'
-
140' 115'
85' 70'
-
140' 100'
70' 60'
-
120' 85'
-
70' 40'
-
60' 30'
-
50' 20'
- - -
QUICK REFERENCE GUIDE
Please also carefully read the
Instructions for Use and Installation
Manual.
Start
Starts the drying cycle.
On
The indicator lamp lights up
when the dryer is on.
Delays the drying cycle start
from 1 to 8 hours.
Start delay
To select the start delay:
turn the time selector knob
Max
clockwise to the desired drying
Load
time (select the option, when
necessary) and turn the start
delay knob to the desired delay
time. Press the Start button.
To cancel or change the
previously set time delay: turn
the time selector knob to "0".
The indicator lamp lights up
Kg
Filter
when the filter needs cleaning.
Clean the filter at the end of
every cycle.
3.5
The indicator lamp lights up
6.0
when the water container
needs to be emptied. The
3.5
drying cycle is automatically
interrupted. Empty the water
6.0
container. Open the door and
Water Container check how damp the laundry
3.5
is. Close the door. Re-set the
6.0
drying time if necessary and
press the Start button.
(The water container light
2.5
will remain on for about 2
min. even after having
emptied the water
2.5 container.)
DRYING CYCLE SEQUENCE INDICATORS
Drying
2.5
The selector knob shows the
Airing
progress of the cycle after
Anti-
-
drying start.
crease
End
5019 307 00636
