Sony ICF-CD1000 Operating Instructions

3-810-942-52 (1)
FM/AM CD Clock Radio
Operating Instructions
XXXXXXX
ICF-CD1000
Sony Corporation © 1997
Printed in Malaysia
Display
CLOCK/TRACK TIME
ENTER
ALARM
WORLD/ D.S.T.
LOCAL SUMMER T. –
TUNING TIME SET
1
TRACK PRESET
3
Telescopic antenna
5
LIFT OPEN
DC IN 6V
2
VOLUME MEGA BASS
NORM
B
A
Bottom Bottom
1
1
2
Coin, etc.
2
3
LR6 (AA) x 4
English
• When operating the unit with house currents,
WARNING
do not remove the lithium battery which serve
as a backup of the memory.
To prevent fire or shock hazard, do not expose • When operating the unit with the batteries,
the unit to rain or moisture. remove the AC power adaptor in the following
order: 1 disconnect from the wall outlet and
To avoid electrical shock, do not open the 2 disconnect from the DC IN 6V jack of the
cabinet. Refer servicing to qualified personnel unit.
only.
Setting the Clock
CAUTION
The use of optical instruments with this
The display will flash "0:00" when the batteries
product will increase eye hazard.
are first installed. Set the time when the CD or
radio is turned off.
For Customers in Europe and Saudi Arabia
To Set Local Time
1.
2.
This Compact Disc player is
classified as a CLASS 1
LASER product.
The CLASS 1 LASER • 24-hour system: "0:00" = midnight. "12:00" =
noon
PRODUCT label is located on
• To set the current time rapidly, keep pressing
the bottom exterior. the + or – button while holding down CLOCK/
TRACK•ENTER.
• To set the current time from zero seconds, at
step 2, release CLOCK/TRACK•ENTER with the
Before You Begin
time signal.
Thank you for choosing the Sony CD clock radio!
To Set World Time
The CD clock radio will give you many hours of
To set WORLD time, press WORLD/LOCAL to
reliable service and listening pleasure.
display "WORLD", then set it, upon calculating
Before operating the CD clock radio, please read
the parallel time with the time-zone map, using
these instructions thoroughly and retain them for
CLOCK/TRACK•ENTER and TUNING TIME
future reference.
SET + or –, until the desired time appears.
Features If you change either of Local Time or
World Time
• You can wake up to any track of a CD, radio
The two clock's are not linked, adjust the time to
and buzzer with the snooze function. either one.
• The digital tuner with 5 random memory
presets.
To change the display to the day-
• A powerful bass is produced with the MEGA
light saving time (summer time)
BASS sound system.
indication
• You can enjoy stereo sound both by speakers
Press D.S.T.•SUMMER T.
and by headphones.
"
• Summer time calculation (one-hour skip
changes to summer time.
function).
• World time calculation (parallel time- To cancel the summer time indication, press
difference setting).
D.S.T.
Notes on AM Channel Step
The AM channel step differs depending on areas.
The channel step of this unit is factory-set to
Changing AM
9 kHz.
Channel Step
ALARM MODE
Area Channel step
North and South 10 kHz The channel step of this unit is factory-set to
American countries
9 kHz or 10 kHz to match the frequency
+
allocation system of the country as listed.
Other countries 9 kHz
BAND
WAKE UP When needed, change the channel step before
TRACK
listening to the radio.
2
Power Sources
Area
Installing Batteries
North and South
4
American countries
(Fig. A)
Other countries
Use alkaline batteries.
1.
1.
Lift up the telescopic antenna. 2.
2.
Push and slide up the battery cover
toward the direction of the arrow.
3.
Install four LR6 (size AA) batteries with
correct polarity.
• When the AM channel step is changed, the
Battery Life
(Approx. hours)
preset stations will be erased.
Listening by speakers
CD RADIO
Playing a Disc
Sony LR6 (size AA) 9 26
Listening by headphones
An 8 cm (3-inch) CD can be played without an
CD RADIO
adaptor.
1.
Sony LR6 (size AA) 11 40
Replacing Batteries
When the batteries become weak, "i"will
appear in the display and the CD and Radio
functions will stop. Replace all the dry batteries.
When the batteries are exhausted, "i" will flash
and only the clock is displayed.
After replacing the batteries or when the AC
MID MAX power adaptor is connected, the "i" indicator
will stop flashing and then start the unit
operations.
Note
When the unit is not being used for long period
of time, remove the batteries to avoid damage
from battery leakage and corrosion.
Installing Lithium Battery
for Clock Backup
(Fig. B)
1.
The lithium battery compartment lid is
at the bottom of the unit. Open the lid
with a coin, turning it towards OPEN.
2.
Install the lithium battery CR 2025 with
the ' facing upwards, close the lid
turning it towards CLOSE.
2.
Replacing Lithium battery
CR2025
Replace the lithium battery when the LCD
display becomes weak. Keep the dry batteries
installed or the AC power adaptor connected to
keep the memeory from being erased. Replace
the lithium battery regularly once a year. 3.
Notes on batteries
Listening to the built-in speakers
• Keep the lithium battery out of reach of
The built-in speakers are located inside the lid of
children. Should the battery be swallowed,
the unit. Open the lid to use the built-in speakers.
immediately consult a doctor.
• Wipe the battery with a dry cloth to assure
good contact.
To
• Be sure to install the battery in the correct
Pause
polarity position.
• Do not hold the battery with metallic tweezers,
Resume play after
as doing so may casue a short-circuit.
pause
• Do not break up the battery or throw it into a
Locate the beginning
fire, which might cause it to explode.
of the current
Carefully dispose of the used battery.
track (AMS*)
Locate the next
CAUTION
track (AMS)
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
Go back at high speed
equivalent type recommended by the equipment
Go ahead at high
manufacturer. Discard used batteries according
speed
to manufacturer's instructions.
Locate the previous
track (AMS)
Using House Current
Locate the succeeding
(Mains) track (AMS)
Stop play
Connect the supplied AC power adaptor (except
for UK model) to DC IN 6V, and plug it into a Change the clock
wall outlet. The batteries are automatically mode or track mode
disconnected then the display will continuously
*AMS = Automatic Music Sensor
light up and then operate the unit.
**These operations are possible during both play
Notes and pause.
• When the AC power adaptor is not used for a
long period of time, be sure to unplug it both
•To handle compact discs
from the DC IN 6V jack and from a wall outlet.
• Use the recommended Sony AC power adaptor
This way
only. The polarity of the plugs of other
manufacturers may be different. Failure not to
use the recommended AC power adaptor may
lead to the malfunction of the unit.
Polarity of the plug
Not this way
the
surface.
Do not stick paper or
anything on the
surface.
Notes
• Do not open the CD compartment lid during
playing, otherwise, the disc will be damaged.
Be sure to stop the disc first.
• When you press CD ^, if there is no disc in
the CD compartment, the "00" indication
Press WORLD/LOCAL to display
flashes for about 3 seconds and the unit will
" LOCAL ".
be turned off.
While holding down CLOCK/
• If the CD alarm times comes during listening
TRACK•ENTER, press either TUNING to the CD, the track changes to that preset by
pressing BAND•WAKE UP TRACK.
TIME SET + or – till the correct time
appears in the display.
When you release CLOCK/
Operating the Radio
TRACK•ENTER, the clock begins to
operate and ":" flashes.
Manual Tuning
1.
Press RADIO SLEEP.
2.
Press BAND•WAKE UP TRACK to
select the band, FM or AM.
Each press of BAND•WAKE UP
TRACK changes the band.
3.
Tune in a station by pressing TUNING
TIME SET + or – .
4.
Adjust VOLUME.
Listening to the built-in speakers
The built-in speakers are located inside the lid of
the unit. Open the lid to use the built-in speakers.
When tuning in FM
The FM frequency is raised or lowered by a step
of 0.05 MHz, but the display is raised or lowered
by a step of 0.1 MHz. There may be a same
station on several frequencies, choose the best
recepted frequency.
(Example: Frequency 88.00 MHz and 88.05 MHz
is displayed as "88.0 MHz".)
• To turn off the radio, press OFF ALARM
RESET.
" is displayed and the time indication
• To improve radio reception
FM: Extend the telescopic antenna to improve
FM reception.
•
SUMMER T. again.
AM: Rotate the unit horizontally for optimum
reception. A ferrite bar antenna is built
into the unit. Do not operate over a steel
desk or surface, as this may lead to an
interference of the reception.
• To check the station you are listening to,
press RADIO SLEEP. The band and frequency
appear for five seconds.
Preset Tuning
You can preset up to five FM/AM stations (one
station for each memory preset button 1 to 5).
Note
Channel step
When you use the radio alarm, preset the station
10 kHz
you want for the alarm in memory preset button
1, as the memory preset 1 station is the wake up
9 kHz
station.
Example: To set AM 1260 kHz in memory
Press OFF ALARM RESET to turn off the
presets button 2.
power.
While holding down CLOCK/TRACK•ENTER,
1.
Tune in the AM 1260 kHz (See "Manual
keep pressing OFF ALARM RESET until a
beep sounds.
Tuning").
The AM channel step will be changed.
2.
While holding down CLOCK/TRACK •
If you proceed to step 2 again, the channel
ENTER, press the desired preset button.
step changes again.
The preset number appears in the
display and station is preset.
While "P" are flashing, press the preset
button.
Lift open the CD compartment lid and
.
place a disc.
LIFT OPEN
After presetting the indication become
the current time.
• To change the preset station, preset a new
station in the number of which you want to
change the station. The previous station is
cancelled.
Tuning in a Preset Station
Label surface up
1.
Press RADIO SLEEP.
2.
Press memory presets number button
of the station you want to tune in.
3.
Adjust VOLUME.
Setting the Alarm
Close the lid
You can set the CD, radio and buzzer alarms at
Press CD ^ and the display lights
the preset time. Before setting the alarm, be sure
"01." And the current number (01 to
to set the clock. (See "Setting the Clock.")
99) appears in the display window. After setting the alarm time, then set the type of
alarm.
After 10 seconds, the indication
Setting the Alarm Time
becomes the current time, but the
"CD ( " indication remains.
To set the CD alarm
Adjust VOLUME.
1.
While holding down TIME-ALARM,
press TUNING TIME SET + or – till the
desired time appears in the display.
Press
CD ^
When you release TIME-ALARM,
CD ^ again
the alarm time is set and the indication
becomes the current time.
=**
2. While holding down BAND•WAKE
UP TRACK, set the desired track by
pressing TUNING TIME SET + or – .
+**
When you release BAND•WAKE UP
TRACK, The track is preset and the
Hold down =**
indication becomes the current time.
Hold down +**
= repeatedly**
+ repeatedly**
Note
OFF ALARM RESET
The CD player is preset to start with any track
numbers, it will always start with the chosen
CLOCK/TRACK•ENTER
track even though you change the CD, unless
you change BAND•WAKE UP TRACK.
To set the RADIO/BUZZER alarm
1.
While holding down TIME-ALARM,
press either TUNING TIME SET + or –
till the desired time appears in the
display.
When you release TIME-ALARM, the
Handle the disc
alarm time is set and the indication
by its edge.
becomes the current time.
Specifications
Setting the Alarm Mode
Do not touch
Before setting alarm-mode, be sure to set the CD player section
alarm time. (See "Setting the Alarm Time.")
System: Compact disc digital audio system
1. Laser diode properties: Material: GaAlAs
Press ALARM-MODE till the alarm you
Wavelength: 780 nm
want appears in the display.
Emission duration: Continuous
tape nor write
Each time you press ALARM-MODE,
Laser output: Less than 44.6 µW
the alarm indication changes as follows. (This output is the value measured at a
distance of about 200 mm from the objective
No alarm
lens surface on the optical pick-up block with
indication CD RADIO BUZZER
7mm aperture.)
Frequency response: 20-20,000 Hz
The selected alarm sounds at the time you set,
Wow and flutter: Below measurable limit
and automatically turns off after 60 minutes.
Radio section
• To stop the alarm, press OFF ALARM RESET.
The alarm will sound at the same time the Frequency range:
next day.
Band
• To cancel the alarm, press ALARM-MODE
FM
repeatedly until CD, RADIO, or BUZZER
AM
indication does not appear.
• To check the alarm time you set, press the
FM
TIME-ALARM.
AM
* The frequency display is raised or lowered by
Notes
steps of 0.1 MHz.
• When you set the CD alarm, if there is no disc
(Example: Frequency 88.05 MHz is displayed
in the CD player, the buzzer will sound at the
as "88.0 MHz.")
time you set.
• The buzzer sound level is fixed, and
General
independent of volume.
Time display:
To Doze for a Few More 24-hour system
Speaker: Full range: 4 cm + 4 cm (1
Minutes
inches) 8 ohms
Output:
1.
Press SNOOZE. The CD, radio or
2 jack (stereo minijack)
buzzer will shut off but will
Power outputs: 300mW + 300mW (at 10%
automatically come on again after
harmonic distortion)
Power requirements:
about 8 minutes. You can repeat this
6V DC, four LR6 (size AA) batteries
process as many times as you want to.
Backup for Clock:
• While SNOOZE function is 3V DC, one CR 2025 lithium battery
operating, the alarm indication flashes. External power source:
DC IN 6V
Dimensions: Approx. 166.5×46 ×162 mm
(w/h/d)
(Approx. 6
Setting the Sleep
projecting parts and controls
Mass: Approx. 705.5g (1lb 9oz) incl. batteries
Timer
Supplied accessory: Stereo headphones (1)
AC power adaptor (1)
By setting the sleep timer, you can fall asleep to
Sony CR 2025 Lithium battery (1)
the radio sound. The radio turns off after the
selected time.
Design and specifications are subject to change
1. without notice.
Turn on the radio .
2.
Press RADIO SLEEP repeatedly until
the desired operating time is displayed.
Each time you press RADIO SLEEP, the
sleep timer indication changes as
follows.
90 60 30 15 OFF
Frequency indication
The sleep timer is set and it will go off
after the selected minutes.
• To turn off the sleep timer before the selected
time has elapsed, press SLEEP OFF/LIGHT.
Useful Functions
To Obtain Powerful Bass
Set MEGA BASS to MID or MAX.
The "MEGA BASS" system produces a powerful
bass with the use of a bass reflex system added
to a normal speaker system.
To Light the Display-
Light Function
Press SLEEP OFF/LIGHT, the display will light
up for 10 seconds.
When using house currents, the display will light
up always.
Precautions
• Operate the unit on the power sources
specified in "Specifications."
• The nameplate indicating voltage, etc. is
located at the bottom.
• Disconnect the mains lead by grasping the
plug. Never pull it by the cord.
• Do not leave the unit in a location near a heat
source such as a radiator or airduct, or in a
place subject to direct sunlight, excessive dust,
mechanical vibration, or shock.
• Allow adequate air circulation to prevent
internal heat build-up. Do not place the unit
on a surface (a rug, a blanket, etc.) or near
materials (a curtain) which might block the
ventilation holes.
• Should any liquid or solid object fall into the
unit, unplug (or remove batteries from) the
unit and have it checked by a qualified
personnel before operating it further.
• When the casing becomes soiled, clean it with
a soft cloth dampened with a mild detergent
solution. Never use abrasive cleansers or
chemical solvents, as they may mar the casing.
• The unit is not disconnected from the AC
power source (mains) as long as it is
connected to the wall outlet, even if the unit
itself has been turned off.
If you have any question, please consult your
nearest Sony dealer.
Troubleshooting
Should any problem occur with the unit, make
the following checks to determine whether or not
servicing is required. If the problem persists,
consult the nearest Sony dealer.
The CD player does not operate.
• If "i" appears in the display, replace all four
batteries.
• Did you close the compartment lid
completely?
• Did you place a disc corrxectly?
The disc should be placed with the labelled
surface up.
• Dusty or defective disc—Clean the disc with
an optional cleaning cloth. Wipe the disc from
the center out.
Skipping of sound in CD operation
• Dusty or defective disc—Clean the disc.
• Dirty lens—Clean the lens with a
commercially available blower.
• Strong vibration
The CD, radio or buzzer alarm does not come
on at the preset time.
• Did you set the current time correctly?
• Did you set the alarm time correctly?
• Did you place a disc?
• Did you close the CD compartment lid
completely?
• Did you preset the station you want for the
wake up station in preset button 1?
• Did you adjust the volume?
If the volume is turned down completely, the
CD or radio alarm is not heard.
+1 dB
–1.5
Frequency Channel Step
87.5-108 MHz 0.1 MHz
530-1,610 kHz 10 kHz
87.5-108 MHz 0.05 MHz *
531-1,602 kHz 9 kHz
× 2
5
/
8
× 1 × 6
5 / 13 / 1 / inches) incl.
8 16 2
