Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com
P/NO.: MFL62883329

Advertisement

loading

Related Manuals for LG GB6140PZQV

Summary of Contents for LG GB6140PZQV

  • Page 1 Please read this manual carefully before operating your set and retain it for future reference. www.lg.com P/NO.: MFL62883329...
  • Page 3 (In the UK Only) Important The wires in this mains lead are coloured in accordance with the following code: GREEN AND YELLOW:EARTH BLUE:NEUTRAL BROWN:LIVE This appliance must be earthed As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:...

  • Page 4: Table Of Contents

    Refrigerator compartment Door in Door Use Skills (Only apply for some Models) Use Skills for Multi-use Compartment Use Skills for Freezer Compartment (lower) Energy-Saving Method Smart Diagnosis Smart Diagnosis (Only apply for some Models)
  • Page 6 The dedicated outlet should be used. • Using several devices at one outlet may cause fire. • The electric leakage breaker may damage food and the dispenser may be leaked. Do not allow the power plug to face upward or to be squeezed at the back of the refrigerator.
  • Page 7 Do not allow the power cord bent or pressed by the heavy object to be damaged. It may damage the power cord to cause fire or electric shock. Do not extend or modify the length of the power plug. It causes electric shock or fire by the electric damage of the power cord or others.
  • Page 8 When the power cord or the power plug is damaged or the holes of the outlet are loosed, do not use them. It may cause electric shock or short circuit to make fire. Wait for 5 minutes or longer when reconnecting the plug.
  • Page 9 Do not place the lit candle within the fridge-freezer to deodorize. Do not use drier to dry the inside, nor light a candle to remove odor. It may cause explosion or fire. Don’t insert the hands into the automatic ice maker. (Only for the model with the automatic ice maker) It may cause injury.
  • Page 10 Use the submerged refrigerator after checking it. It may cause electric shock or fir. In case of thunder and lightning, or not in use for a long period of time, detach the power plug. There is a danger of electric shock or fire. When gas is leaked, do not touch the refrigerator or the outlet and ventilate the room immediately.
  • Page 11 Do not use the refrigerator for non-domestic purpose (storing medicine or testing material, using at the ship, etc.). It may cause an unexpected risk such as fire, electric shock, deterioration of stored material or chemical reaction. When disposing the refrigerator, remove the packing material from the door or take off the doors but leave the shelves in place so that children may not easily climb inside.
  • Page 12 Violating this direction may cause injury or damage house or furniture. Always be careful, please. Do not touch food or containers at the freezer with wet hands. It may cause frostbite. When the electricity is off for long time, remove ice from the ice box.
  • Page 14 Type-1 General shelf Pure N Fresh Air vent Air vent Door Rack Door Rack Egg Tray Temperature Sensor Rotating plate Vegetabel drawer Door rack Door rack Multi-use Compartment Small Drawer in Freezer Compartment ice maker Ice box Freezer Compartment (Top) Freezer Compartment (Bottom) Leveling screw...
  • Page 15 Type-2 Pure N Fresh General shelf Fresh room Air vent Air vent Door Rack Egg Tray Sliding Shelft Temperature Sensor Rotating plate Vegetable Drawer Turnable door rack Multi-use Compartment Small Drawer in Freezer Compartment ice maker Ice box Freezer Compartment (Top) Freezer Compartment (Bottom)
  • Page 16 1. Select a good location.Place your fridge-freezer where it is easy to use. 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5cm) from the rear wall.
  • Page 17 Function display board Temperature adjustment button for Refrigerator compartment Temperature Adjustment button for Multi-use compartment Temperature Adjustment button for freezer compartment Air Purification Lock Unlock Press for 3 seconds...
  • Page 18 You can adjust temperature of the freezer compartment, refrigerator compartment and multi-use compartment. How to adjust the Refrigerator compartment temperature adjustment temperature in the refrigerator When you press” “ button, the temperature of Fridge compartment refrigerator compartment is repeated in the following Fridge order: 4°C →...
  • Page 19 Refrigerator In order to save electricity when no food needs to be stored in the refrigerator “ECO” compartment, you can select the Refrigerator ECO function, that is, to turn off the refrigerator compartment. To put the refrigerator in the stop state, press “ ”...
  • Page 20 When you need to clean the air please select this function. Pure N Fresh (Optional) Auto Power Replace ※ Potent air purification Setting: Press “Pure N Fresh” key. “ ” pattern and “Power” light will be on. It enters power mode. Cancel: Press “Pure N Fresh”...

  • Page 21: Ice Making

    Self-diagnosis function operates when a problem occurs in the unit. When an error occurs in the unit. Immediately contact the service center without turning the power OFF. If the power is OFF, it will take the engineer longer to find out where the fault occurs.

  • Page 22: Refrigerator Compartment

    Refrigerator compartment Sliding Shelf (Optional) Note Remove all items form the rear half shelf and the front sliding shelf. CAUTION Caution should be taken when adjusting the shelf as it can fall out if not handled correctly. Do not lift up the rear half shelf and keep it in the lifted position. CAUTION Tall items are not to be stored at the rear of the shelf.

  • Page 23: Door In Door Use Skills (Only Apply For Some Models)

    Refrigerator compartment Rotatable partition The door can not be closed The door can be closed when when the rotating plate is in the rotating plate is in this this position. position. The door can not be closed when the rotating plate is in the raised position. It must be put back to its original position to close the door.

  • Page 24: Use Skills For Multi-Use Compartment

    Use Skills for Multi-use Compartment When store vegetables and fruits, set the multi-use compartment temperature to 1-7°C; When store fish and meat for a short time, set the temperature to below 0℃. Therefore, always check the temperature setting before store food. Use Skills for Freezer Compartment (lower) Transparent Shallow Drawer of Freezer Compartment (lower)
  • Page 25 Suggestion on food storage Location on foods Refrigerator Compartment Multi-use Compartment Freezer Compartment TYPE-1 TYPE-2 Suggestions Door rack Bottle door rack on refrigerator Store small packages storage Store water and of milk or spices. beverage. General self Removable Shelf (optional) Store refrigerated food For instructions on (The foods should be...
  • Page 26 Suggestion on food storage Suggestions Drawer on multi-use compartment Store refrigerated or frozen foods. Suggestions Ice maker Small drawer on freezer Store frozen foods of For instructions on compartment small size. how to make ice, refer to the user guide. Drawer (top) Drawer (bottom) Store frozen foods...

  • Page 27: Energy-Saving Method

    Suggestion on food storage Note Energy-Saving Method Install the fridge in a shady,cool and well-ventilated place. • • Do not open and close the door frequently if not necessary. • Please do not keep the door open for a long time, close door in the shortest time. •...
  • Page 28 Note General shelf • Lift the inside of the shelf and pull it out to remove the shelf; • Install the shelf in the reverse order. Removable Shelf Slightly raise the front half of the removable • (only apply to some types) shelf and slide inward.
  • Page 29 Care and maintenance Vegetable drawer Pull out the vegetable drawer till it cannot move. Raise outer side of the vegetable drawer and pull out the vegetable drawer; Wash the vegetable drawer with water and dry it with soft cloth; Install the vegetable drawer in the reverse order. The drawer of 1.
  • Page 30 The drawer 1. Pull the drawer of the freezer (lower) all the way out; (bottom) 2. Remove the transparent shallow drawer. 3. Lift the whole set of drawer and pull out to remove it; of freezer compartment 4. Install the whole set of drawer, keeping the rollers of the drawer underneath the rollers of the compartment;...
  • Page 31 Care and maintenance Be sure to unplug the power. For products with a stainless steel exterior, use a clean sponge or soft cloth and a mild Detergent in warm water. Do not use abrasive or harsh cleaners. Dry thoroughly with a Soft cloth. Do not use appliance wax, bleach, or other products containing chlorine on stainless steel.

  • Page 32: Disposal Of Your Old Appliance

    When the ice • Discard the water in the water tank; maker is not to • Remove the ice cubes and water in the ice bin; be used for a long time In case the lamp is damaged, contact service center to replace it. Never replace it by yourself.
  • Page 33 Care and maintenance Trouble shooting Refrigerator does not run Wait for a while until the refrigerator compartment, multi-use compartment and freezer compartment reach the set temperature. Gaps may be formed on the refrigerator compartment door, multi-use compartment drawer or freezer compartment drawer The gaskets of the refrigerator compartment door, multi-use compartment drawer or freezer...
  • Page 34 Trouble shooting The freezer compartment Freezer temperature is set too is too cold but the cold. temperatures in other compartments are normal The refrigerator compartment Refigerator temperature is set too is too cold but the cold. temperatures in other compartments are normal The multi-use compartment is too cold but the temperatures Multi-use compartment temperature...
  • Page 35 Trouble shooting...
  • Page 36 Trouble shooting The door or drawer is closed with so Close the door or drawer gently. The door or drawer much force that other drawers and door are opened. is not closed tightly The drawer is stuck by packing bag or Remove the food that blocks the drawer The drawer is hard the food in the drawer is too heavy.

  • Page 37: Smart Diagnosis

    If you experience problems with your refrigerator, call to the LG service center. Only use the Smart Diagnosis feature when instructed to do so by the LG call center agent. The transmission sounds that you will hear are normal and sound similar to a fax machine.
