    3 VCD CHANGER MINI MINI COMPONENT MAX-WL69/ZL65/L68/L65/L67 SERVICE Manual MIMI MIMI COMPONENT SYSTEM CONTENTS 1. Alignment and Adjustments 2. Exploded Views and Parts List 3. Electrical Parts List -- Disc Selection / Direct Play -- 4. Block Diagrams Disc 1...

  • Page 2: Alignment And Adjustments

    SSG FREQ. 450 kHz AM IF Frequency 522 kHz AM ANT MAIN Adjustment TESTER AM IF point Speaker Terminal AM SSG 450KHZ Maximum output (Figure 1-3) OUTPUT INPUT VTVM Oscilloscope Figure1-3 AM I.F Adjustment Fig 1-4 OSC Voltage Samsung Electronics...
  • Page 3 2)MAIN PCB JCW3, connectted to VTVM Recording /Play head VTVM (MAIN PCB) Oscilloscope Oscilloscope Audio OSC. VTVM Cassette Deck LINE OUT SPK OUT (GND) AUX IN JCW3 In Out IN OUT Figure 1-7 AZIMUTH control screw Figure 1-8 Figure 1-6 Samsung Electronics...

  • Page 4: Electrical Parts List

    2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m FR28 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm FR20 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m JR10 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm JR12 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m JR11 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm JR23L 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m JR18L 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm JR23R 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m Samsung Electronics...
  • Page 5 220uF,20%,16V,GP,8*12,5MM,TP 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS JC14 2401-001465 C-AL 47uF,20%,10V,GP,5*11,5mm,TP 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS JC21L 2401-001465 C-AL 47uF,20%,10V,GP,5*11,5mm,TP UQ20 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA, JC21R 2401-001465 C-AL 47uF,20%,10V,GP,5*11,5mm,TP UQ21 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA, JC34 2401-001465 C-AL 47uF,20%,10V,GP,5*11,5mm,TP UQ14 0501-000610 TR-SMALL SIGNAL KSA928A,PNP,-30V,-30V,-2A,1W Samsung Electronics...
  • Page 6 C-AL 100uF,20%,10V,GP,5*11mm,5mm,TP UR30 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2401-000240 C-AL 100uF,20%,10V,GP,5*11mm,5mm,TP UR31 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm UC13 2401-000419 C-AL 10UF,20%,16V,GP,5*11,5MM,TP UR32 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2401-000475 C-AL 10uF,20%,50V,GP,5*11,5mm,TP UR33 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2401-000475 C-AL 10uF,20%,50V,GP,5*11,5mm,TP UR34 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2401-000759 C-AL 220NF,20%,50V,GP,5X11MM,5MM,TP Samsung Electronics...
  • Page 7 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 AC1L 2201-000557 C-CERAMIC,DISC 470pF,10%,50V,SL,10.0X4.0mm,5m 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 AC1R 2201-000557 C-CERAMIC,DISC 470pF,10%,50V,SL,10.0X4.0mm,5m 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 AC4L 2201-000629 C-CERAMIC,DISC 5pF,5%,50V,SL,5.0*3.0,2.5mm,TP 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 AC4R 2201-000629 C-CERAMIC,DISC 5pF,5%,50V,SL,5.0*3.0,2.5mm,TP 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 AC7L 2301-000375 C-FILM,PEF 100nF,10%,50V,11x12.5x6.5,TP R201 2007-000074 R-CHIP 100OHM,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 8 2203-001063 C-CERAMIC,CHIP 56nF,10%,16V,X7R,1608,-,TP C215 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 C106 2203-001140 C-CERAMIC,CHIP 68nF,10%,16V,X7R,TP,1608,- C217 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 C122 2203-001140 C-CERAMIC,CHIP 68nF,10%,16V,X7R,TP,1608,- C302 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 C203 2203-001222 C-CERAMIC,CHIP 820pF,10%,50V,X7R,TP,1608,- C303 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 C125 2203-001640 C-CERAMIC,CHIP 390PF,10%,50V,X7R,TP,1608 C603 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 C131 2203-005005 C-CERAMIC,CHIP 100NF,10%,16C,X7R,TP,1608 Samsung Electronics...
  • Page 9 KSR1003TA,NPN,300MW,22K-22KOHM C205 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608, 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM C211 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608, 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM C403 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608, 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9 C604 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608, ULD1 0601-001232 LTL-1CHKES-UA,GRN,555NM,2.5MM C606 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608, ULD10 0601-001232 LTL-1CHKES-UA,GRN,555NM,2.5MM C607 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608, ULD11 0601-001232 LTL-1CHKES-UA,GRN,555NM,2.5MM Samsung Electronics...
  • Page 10 SWITCH-TACT 12V,50mA,160gf,SKHV10910A 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm USW25 3404-000165 SWITCH-TACT 12V,50mA,160gf,SKHV10910A UR62 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm USW26 3404-000165 SWITCH-TACT 12V,50mA,160gf,SKHV10910A 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm USW27 3404-000165 SWITCH-TACT 12V,50mA,160gf,SKHV10910A 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm USW28 3404-000165 SWITCH-TACT 12V,50mA,160gf,SKHV10910A 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm USW29 3404-000165 SWITCH-TACT 12V,50mA,160gf,SKHV10910A Samsung Electronics...
  • Page 11 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm JQ9R 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA, AR16L 2001-000221 R-CARBON 1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m JQ4L 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP AR16R 2001-000221 R-CARBON 1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m JQ4R 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP AR27 2001-000273 R-CARBON 100Kohm,5%,1/8W,AA,TP,1.8x3.2m JQ6L 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP Samsung Electronics...
  • Page 12 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m JC9L 2301-000407 C-FILM,PEF 2.7nF,10%,50V,5.5x12x3,TP JR29R 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m JC9R 2301-000407 C-FILM,PEF 2.7nF,10%,50V,5.5x12x3,TP JR36L 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m JC11L 2301-000412 C-FILM,PEF 22nF,10%,50V,8x12x4,TP JR36R 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m JC11R 2301-000412 C-FILM,PEF 22nF,10%,50V,8x12x4,TP JR38 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m JC25L 2301-000412 C-FILM,PEF 22nF,10%,50V,8x12x4,TP Samsung Electronics...
  • Page 13 C-CERAMIC,DISC 10nF,+80-20%,500V,Y5V,10x4mm,5 R102 2007-000098 R-CHIP 56Kohm,5%,1/16W,DA,TP,1608 RC14 2201-000546 C-CERAMIC,DISC 4.7nF,20%,400V,Y5U,16.0*7.0,10 R103 2007-000098 R-CHIP 56Kohm,5%,1/16W,DA,TP,1608 RC15 2201-000546 C-CERAMIC,DISC 4.7nF,20%,400V,Y5U,16.0*7.0,10 R104 2007-000098 R-CHIP 56Kohm,5%,1/16W,DA,TP,1608 JC108 2401-000129 C-AL 1000uF,20%,16V,GP,10x16mm,-, R120 2007-000098 R-CHIP 56Kohm,5%,1/16W,DA,TP,1608 2401-000230 C-AL 100uF,20%,100V,GP,10x20mm,5mm, R126 2007-000098 R-CHIP 56Kohm,5%,1/16W,DA,TP,1608 3-10 Samsung Electronics...
  • Page 14 10UF,20%,16V,GP,5*11,5MM,TP UR82 2001-000221 R-CARBON 1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m C801 2401-000795 C-AL 220uF,20%,16V,GP,8*12,5MM,TP UR93 2001-000221 R-CARBON 1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m C301 2401-001102 C-AL 330uF,20%,16V,GP,8*11.5,5MM,TP UR103 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m C114 2401-001625 C-AL 6.8uF,20%,50V,GP,TP,5x11,5 UR81 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m C501L 2401-001954 C-AL 4.7UF,20%,50V,GP,5*11,5MM,TP UR92 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m Samsung Electronics 3-11...
  • Page 15 FCW4 3708-001131 CONNECTOR-FPC/FC/PIC SCB-1105-00-02,5P,1.25MM,STRAI UR123 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m FCW4-1 3708-001164 CONNECTOR-FPC/FC/PIC 5P,1.25mm,ANGLE,SN 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m FCW1-1 3708-001488 CONNECTOR-FPC/FC/PIC 30P,1.25mm,ANGLE,SN52492-3020 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m OCW1 3711-000907 CONNECTOR-HEADER BOX,3P,1R,2mm,STRAIGHT,SN UR63 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m 3722-001588 JACK-PHONE 7P,3.6PI,AG,BLK,- UR64 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m 3-12 Samsung Electronics...
  • Page 16 Code no. Description Specifiation Remarks Code no. Description Specifiation Remarks Location no Location no AH92-00896A ASSY PCB-POWER AMP MAX-WL69 SC22 2301-000404 C-FILM,PEF 2.2nF,10%,50V,5.5x12x3,TP SC23 2301-000404 C-FILM,PEF 2.2nF,10%,50V,5.5x12x3,TP 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS SC10 2401-000240 C-AL 100uF,20%,10V,GP,5*11mm,5mm,TP RZD10 0403-000379 DIODE-ZENER UZP12B,12V,11.4-12.6V,1W,DO SC11 2401-000385 C-AL 10UF,20%,100V,GP,-,6.3X11...
  • Page 17 Code no. Description Specifiation Remarks Code no. Description Specifiation Remarks Location no Location no AH92-00898A ASSY PCB-MAIN MAX-WL69 JR24L 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm JR24R 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS JR32L 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS JR32R 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm...
  • Page 18 4.7UF,20%,50V,GP,5*11,5MM,TP WIC401 1003-001162 IC-MOTOR DRIVER KA3082,SIP,10PIN,25MIL,D JC8L 2401-001954 C-AL 4.7UF,20%,50V,GP,5*11,5MM,TP WIC402 1003-001162 IC-MOTOR DRIVER KA3082,SIP,10PIN,25MIL,D JC8R 2401-001954 C-AL 4.7UF,20%,50V,GP,5*11,5MM,TP DSPIC 18PIN 2202-000797 C-CERAMIC,MLC-AXIAL 10nF,30%,16V,Y5R,3.5x19mm,-,TP RC16 2401-001954 C-AL 4.7UF,20%,50V,GP,5*11,5MM,TP DSPIC 17PIN 2202-000807 C-CERAMIC,MLC-AXIAL 22nF,+80-20%,25V,Y5V,3.5x19mm, FC12 2401-001975 C-AL 47uF,20%,16V,GP,5*11,5mm,TP Samsung Electronics 3-15...
  • Page 19 10NF,10%,50V,X7R,TP,1608 C134 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C207 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C209 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C213 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C214 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C216 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C218 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C304 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 C305 2203-000257 C-CERAMIC,CHIP 10NF,10%,50V,X7R,TP,1608 3-16 Samsung Electronics...

  • Page 20: Block Diagrams

    4. Block Diagram 4-1 MAIN Samsung Electronics...
  • Page 21 4-2 CD Samsung Electronics...

  • Page 22: Wiring Diagram

    6. Wiring Diagram(COMMON) Samsung Electronics...

  • Page 23: Schematic Diagrams

    7. Schematic Diagram 7-1 CD/MP3 Parts(COMMON) Samsung Electronics...
  • Page 24 7-2 MAIN Part (COMMON) Samsung Electronics...
  • Page 25 FRONT(COMMON) Samsung Electronics...
  • Page 26 7-4 TUNER(EURO) Samsung Electronics...
  • Page 27 7-5 TUNER(RUSIA) Samsung Electronics...
  • Page 28 7-6 TUNER(2BAND) Samsung Electronics...
  • Page 29 ELECTRONICS © Samsung Electronics Co.,Ltd. MAY. 2001 Printed in Korea Code no. AH68-00664G...
