- Page 1 L2 SWITCH SWR2311P-10G Owner’s Manual Bedienungsanleitung Mode d’emploi Manual de instrucciones Manuale di istruzioni Руководство пользователя...
- Page 2 TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT normalement ou est tombé. EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. AVERTISSEMENT POUR RÉDUIRE LES RISQUES D’INCENDIE OU DE DÉCHARGE ÉLECTRIQUE, N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ. SWR2311P-10G Owner’s Manual...
- Page 3 If this product ual, meets FCC requirements. Modifica- is found to be the source of interference, tions not expressly approved by Yamaha which can be determined by turning the may void your authority, granted by the product “OFF”...
-
Page 4: Precautions
Then have the product inspected or • If you plan to connect a powered device repaired by qualified Yamaha service that complies with the IEEE802.3 at personnel. standards, use a CAT5e or higher-grade cable. - Page 5 20. Inadequate itself and not the cord. Pulling by the cord ventilation can result in overheating, can damage it. possibly causing damage to the product(s), malfunction, or even fire. SWR2311P-10G Owner’s Manual...
-
Page 6: Backup Battery
• Before moving the product, remove all product(s). connected cables. When the backup battery needs to be • Always consult qualified Yamaha service replaced, contact your Yamaha dealer personnel if the product installation and have qualified Yamaha service requires construction work, and make personnel replace the backup battery. -
Page 7: Notice
If this occurs, contact your impregnated wiping cloths. dealer or a Yamaha customer service • Be sure to earth (ground) any static center to have the backup battery electricity from your body or clothing replaced. - Page 8 About this manual Product • The illustrations as shown in this manual are for instructional purposes only. • Please refer to Yamaha Pro Audio website for the details of licensing article. • Windows is a registered trademark of http://www.yamaha.com/proaudio/ ®...
-
Page 9: Table Of Contents
Index........................38 Accessories Please ensure that you have all of the following accessories. • Owner’s Manual (this manual) • Power Cord • Power Cord Clamp (used only for the included dedicated power cord) • Leg (Rubber feet) (x4) SWR2311P-10G Owner’s Manual... -
Page 10: Introduction
• A function is provided to automatically reset a device that is being powered from this unit by turning its power supply on/off if an abnormality is detected in that device. • The PoE supply status can be checked or turned on/off via Yamaha LAN Monitor. Separately sold items •... -
Page 11: Controls And Connectors
• Fan stopped The fan that exhausts the heat dissipated by this unit has stopped. You must immediately stop using the unit, and contact a Yamaha service center listed at the end of this manual to have the unit repaired or inspected. -
Page 12: Lan Ports
LAN ports are 1000BASE-T uplink ports. They do not have power supply capability. SFP ports are for installing a separately sold SFP module (SFP-SWRG-LX or SFP- SWRG-SX). For details on installing an SFP module, refer to “Installing an SFP module” (page 28) in “Connections.” SWR2311P-10G Owner’s Manual... -
Page 13: Top Panel
Do not block the cooling vents or place objects near them. Doing so could cause fire or malfunctions. Top panel Serial number MAC address Product label This lists the model name, serial number, and MAC address etc. of this unit. SWR2311P-10G Owner’s Manual... -
Page 14: Rear Panel
Doing so could cause fire or malfunctions. Power supply inlet (three-pin connector, C14 type) Insert the included power supply cord here. Connect it to an electrical outlet of the appro- priate voltage for the unit. Side panel SWR2311P-10G Owner’s Manual... -
Page 15: Bottom Panel
If the unit is to be installed in a horizontal position, attach the included legs as shown in the illustration. Leg attachment guides Rack mount accessory attachment holes Use these holes to attach the RK-SWR rack mount accessory. Refer to “Installation in a rack” (page 20) for information on how to install the unit. SWR2311P-10G Owner’s Manual... -
Page 16: Switching The Display Mode
STATUS Lower Lit (orange) LAN port or SFP port. VLAN STATUS LED MODE Upper Unlit Turns off the indicators of the LINL/ACT Lower Unlit LAN ports and SFP ports. VLAN STATUS 1 Back to LINK/ACT SWR2311P-10G Owner’s Manual... -
Page 17: Port Indicators
SFP ports Left indicator Link status Right indicator Connection speed The link is lost. Unlit Unlit Not connected. (unavailable) A link is established. Connected by Lit (green) (available) Lit (green) 1000BASE-LX or 1000BASE-SX. Flashing (green) Data is flowing. SWR2311P-10G Owner’s Manual... -
Page 18: Poe Mode
Indicates the error status of the LAN port or SFP port. When the following errors are detected, the unit forcibly enters STATUS mode. • Loop detected • SFP optical input level abnormality detected • PoE supply stoppage or receiving device error detected SWR2311P-10G Owner’s Manual... -
Page 19: Off Mode
Flashing (orange) was detected. The right indicator is unlit. For details, refer to the page for this unit on the Yamaha Pro Audio website. http://www.yamaha.com/proaudio/ NOTE • The error causes can be determined by using the show error port-led command. -
Page 20: Installation In A Rack
This section explains how to attach the unit in the middle block of a rack mount panel. If you plan to attach the unit in the left or right block, follow the same procedure below. Notice If the supplied feet have already been attached to the unit, remove them. SWR2311P-10G Owner’s Manual... - Page 21 Using the four screws included with the 19-inch rack, attach the rack mount panel. Be sure to tighten the screws so that they will not get loosened. 19-inch rack Screws supplied with the 19-inch rack Rack mount panel You can also mount two units as shown in the figure below. SWR2311P-10G Owner’s Manual...
-
Page 22: Installation On A Wall Or Ceiling
If these two surfaces are confused, it will not be possible to attach the mounting accessory to the SWR2311P-10G. To distinguish the surfaces, refer to the illustrations for step 1 and step 3. Place the mounting accessory against the wall, and mark the installation location. - Page 23 Installation on a wall or ceiling Wall installation methods (two types) The SWR2311P-10G can be installed on a wall in the following two ways. Warning Do not install with the LAN ports facing upward or downward. Doing so could cause fire or malfunctions.
- Page 24 If the unit falls, injury or damage might occur. Notice When installing the SWR2311P-10G, engage the mounting accessory onto the screws that you provisionally attached in step 2, and slide it either to the left or the right. [Installing in left horizontal orientation] [Installing in right horizontal orientation]...
-
Page 25: Settings
Making settings using the Web GUI Here we explain the procedure for logging in to this unit using the Web GUI. You will use Yamaha LAN Monitor to log in to the Web GUI, so install Yamaha LAN Monitor before you continue. -
Page 26: Making Settings From The Command Line Using The Console Port
• In order to use the mini-USB CONSOLE port, the USB serial driver must first be installed in the computer. • For details on installing the USB serial driver, refer to the “Yamaha Network USB Serial Driver Installation Guide.” The Yamaha Network USB Serial Driver Installation Guide and the installer can be down- loaded from the Yamaha Pro Audio website. - Page 27 Take care when making connections. • If you use the mini-USB CONSOLE port, do not use a USB hub. If multiple Yamaha switches are connected to one computer, the COM port numbers assigned to the con- nection might be inadvertently exchanged.
-
Page 28: Connections
Do not look into the optical emitter when the SFP module is installed. The separately sold SFP modules are class 1 laser devices. They may emit laser beams invisible to the eye. If the laser beam enters your eye, your eyesight might be damaged. SWR2311P-10G Owner’s Manual... -
Page 29: Removing An Sfp Module
If the laser beam enters your eye, your eyesight might be damaged. Grasp the lever and pull out the SFP module. NOTE Since this unit supports hot-swapping, an SFP module can be removed without turning the power off. SWR2311P-10G Owner’s Manual... -
Page 30: Connecting The Power Cord
• Fan stopped The fan that exhausts the heat dissipated by this unit has stopped. You must immediately stop using the unit, and contact a Yamaha service center listed at the end of this manual to have the unit repaired or inspected. -
Page 31: Initialization
• When you execute this, the settings will also return to their factory-set state. If necessary, use external memory to save the settings before you proceed with initialization. For details on how to export settings to external memory, refer to the SWR2311P-10G’s “Tech- nical Reference.”... - Page 32 Ver (see below) appears on the console screen. SWR2311P BootROM Ver.1.00 When a screen asks you whether to execute initialization, press the <y> key to execute initialization. Initialize or not ?(y/n) Initialization is executed. Ready to Initialize ....SWR2311P-10G Owner’s Manual...
-
Page 33: Appendix
Standard RS-232C, USB 2.0 CONSOLE Connector type RJ-45, USB mini-B (5-pin) port Data transmission 9600 bit/s speed Indicators POWER, microSD, LED MODE, LAN port, SFP port Ambient Operating 0–40 °C temperature environment conditions Ambient humidity 15–80%, non-condensing SWR2311P-10G Owner’s Manual... -
Page 34: Dimensional Diagram
Owner’s Manual; power cord (3-prong); power cord Accessories clamp; legs The explanations in this document use the current specifications as of the date of publica- tion. The latest version can be downloaded from the Yamaha website. http://www.yamaha.com/proaudio/ Dimensional diagram Units: mm... -
Page 35: Rj-45/Db-9 Console Cable Pin Configuration
SOFTWARE and you also shall not have any third party to do so. 1-3. You shall not modify, remove or delete a copyright notice of YAMAHA contained in the SOFTWARE. 1-4. Except as expressly provided herein, no license or right, express or implied, is hereby conveyed or granted by YAMAHA to you for any intellectual property of YAMAHA. - Page 36 SUPPORT AND UPDATE: YAMAHA, YAMAHA’s subsidiaries and affiliates, their distributors and dealers are not responsible for maintaining or helping you to use the SOFTWARE. No updates, bug-fixes or support will be made available to you for the SOFTWARE.
- Page 37 You agree that this AGREEMENT is the complete and exclusive statement of agreement between you and YAMAHA concerning the subject matter hereof and supersedes all proposals or prior agreements, verbal or written, and any other communications between you and the parties relating to the subject matter hereof.
-
Page 38: Index
Web GUI ........... 25 WK-SWR........... 22 Initialization ..........31 Yamaha LAN Monitor........ 10 LAN ports ..........12 Yamaha Network USB Serial Driver ... 10, 26 LAN/SFP combo ports ......12 Leg ............15 Leg attachment guides......15 microSD indicator........12 microSD slot.......... - Page 39 Memo SWR2311P-10G Owner’s Manual...
- Page 40 SWR2311P-10G Owner’s Manual...
- Page 41 Informations sur la mise au rebut dans d’autres pays en dehors de l’Union européenne : Ce symbole est seulement valable dans l'Union européenne. Si vous souhaitez vous débarrasser de déchets d’équipements élec- triques et électroniques, veuillez contacter les autorités locales ou votre fournisseur et demander la méthode de traitement appropriée. (weee_eu_fr_02) SWR2311P-10G Owner’s Manual...
- Page 42 Informazioni sullo smaltimento negli altri Paesi al di fuori dell’Unione europea: Questi simboli sono validi solamente nell’Unione Europea; se si desidera scartare questi articoli, si prega di contattare le autorità locali o il rivenditore e richiedere informazioni sulla corretta modalità di smaltimento. (weee_eu_it_02) SWR2311P-10G Owner’s Manual...
-
