Thank you for purchasing a Panasonic product.
This document explains how to install the backup battery properly.
For details about how to use the system, refer to the User's Guide
(page 15).
Please read this document before using the unit and save it for future
reference.
Home Network System
KX-HNP100FX
Model No.
Installation Guide
Backup Battery
Advertisement
Table of Contents
Related Manuals for Panasonic KX-HNP100FX
Summary of Contents for Panasonic KX-HNP100FX
-
Page 1: Installation Guide
Home Network System Backup Battery KX-HNP100FX Model No. Thank you for purchasing a Panasonic product. This document explains how to install the backup battery properly. For details about how to use the system, refer to the User’s Guide (page 15). -
Page 2: Table Of Contents
Table of Contents Introduction Accessory information ....3 Other information .......3 Important Information About this system ......4 For your safety ......4 Important safety instructions ..6 For best performance ....6 Other information .......7 General product information General information about the backup battery ......8 Power outage notification by phone .........8 Power outage notification to your... -
Page 3: Accessory Information
Accessory information Supplied accessories Accessory item/Part number Quantity Rechargeable battery See page 3 for replacement battery information. Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information. Accessory item Model no./Specifications Rechargeable KX-PRA10EX battery R Lithium Ion (Li-Ion) type battery Other information R Design and specifications are subject to change without notice. -
Page 4: Important Information
R Do not connect non-specified protection from property loss. devices. Panasonic will not be held R Do not leave the power cable responsible in the event that exposed outdoors. property loss occurs while this system is in operation. - Page 5 Important Information Medical CAUTION R Consult the manufacturer of any personal medical devices, such as Installation and location pacemakers or hearing aids, to R Never install wiring during a lightning determine if they are adequately storm. shielded from external RF (radio R The AC adaptor is used as the main frequency) energy.
-
Page 6: Important Safety Instructions
R Operating the product near electrical Hub location/avoiding noise appliances may cause interference. The hub and other compatible Move away from the electrical Panasonic devices use radio waves to appliances. communicate with each other. R For maximum coverage and noise-free communications, place your hub: –... -
Page 7: Other Information
Important Information For more information about collection and recycling, please contact your local Other information municipality. Penalties may be applicable for CAUTION: Risk of explosion if battery incorrect disposal of this waste, in is replaced by an incorrect type. accordance with national legislation. Dispose of used batteries according to the instructions. -
Page 8: General Product Information
General product information Compatible Operating time General information devices Indoor about the backup Camera 2.0 hours (standby) battery (KX-HNC200) 1.5 hours (standby, when night vision Outdoor The backup battery can provide power mode is active) Camera to your Home Network System devices (KX-HNC600) (one device per backup battery), allowing your devices to continue to... -
Page 9: Power Outage Notification To Your Mobile Device
General product information service provided by cable company, Internet service provider, VoIP Wireless service provider, etc.), and if that communication device does not contain its own backup battery, the hub will not be range able to make calls in the event of a power outage. -
Page 10: Setup
Setup Part names and LED indicator functions You can use the LED indicator to confirm the backup battery’s status. Indicator Status The battery is fully charged Green, lit Battery power is being consumed Green, Registration mode blinking slowly (you pressed and held M Red, lit Backup battery is... -
Page 11: Setup Overview
Setup Setup overview Inserting the battery R USE ONLY the specified battery. Initial setup R Wipe the battery ends ( ) with Make sure you can access the system using your mobile device. a dry cloth. For details, refer to the System R Avoid touching the battery ends ( Setup Guide included with your ) or the unit contacts. -
Page 12: Connections
Setup Connections Indoor Camera Outdoor Camera Indoor Siren Insert the backup battery’s DC plug firmly into the device’s DC jack, DC cable plug, or DC extension cord. Insert the DC plug completely. (This example illustration applies to the KX-HNB600 and KX-HNC200.) Connect the AC adaptor plug to the backup battery. - Page 13 Setup Note about power connections AC adaptor connection R The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) R The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet.
-
Page 14: Registering The Backup Battery
Setup Using the app Registering the When you register the backup battery backup battery by using the [Home Network] app, you can assign a name to the backup This procedure is not required for battery and turn its power outage devices that were included as part of notification feature on and off. -
Page 15: Appendix
Some of the features that are available when using the [Home Network] app are listed below. For more information, refer to the User’s Guide. – Device management www.panasonic.net/pcc/support/tel/ You can use the app to change the homenetwork/manual/ backup battery’s name. – Notifications... -
Page 16: Specifications
Appendix Specifications R Standards DECT (Digital Enhanced Cordless Telecommunications) R Frequency range 1.88 GHz – 1.90 GHz R RF transmission power Approx. 10 mW (average power per channel) 250 mW (max.) R Power source 220 – 240 V AC, 50/60 Hz Lithium Ion (Li-Ion) type battery (1 ´... - Page 17 Notes...
