D-Link DWL-AG530 Quick Installation Manual page 4

Installing the DWL-AG530 Wireless
PCI Adapter in Your Computer
A.
Make sure to turn off your computer
and unplug the power cord before
you begin. Remove the back or side
cover of the computer.
B.
Carefully guide the DWL-AG530
antenna through the PCI bracket
opening adjacent to the PCI slot you
intend to use for the DWL-AG530.
C.
Install the DWL-AG530 carefully,
and firmly set it into the available
PCI slot (which is typically white or
cream-colored).
D.
Secure the DWL-AG530 back panel
bracket with its mounting screw.
E.
Replace the computer cover.
To avoid damage caused by
static electricity, make sure to
properly ground yourself by first
touching a metal part of your
computer to discharge any static
electricity before working with
the DWL-AG530.
4
