Page 1: Quick Reference Guide
HITACHI INVERTER NE-S1 SERIES Quick Reference Guide Read through this Quick Reference Guide, and keep it handy for future reference. NT3411DX...
Page 2 Thank you for purchasing the Hitachi NE-S1 Series Inverter. This Quick Reference Guide describes how to handle and maintain the Hitachi NE-S1 Series Inverter. Read this Quick Reference Guide carefully before using the inverter, and then keep it handy for those who operate, maintain, and inspect the inverter.
Page 3: Table Of Contents
Contents Chapter 1 Safety Instructions Safety Instructions ······························································································· 1 - 1 Precautions Concerning Electromagnetic Compatibility (EMC) ······································ 1 - 5 Precautions Concerning Compliance with UL and cUL Standards ·································· 1 - 10 Chapter 2 Inspection of the Purchased Product Inspection of the Purchased Product ······································································· 2 - 1 Method of Inquiry and Product Warranty ···································································...
Page 4 Contents Chapter 7 Explanation of Functions Monitoring the data ······························································································ 7 - 1 7.1.1 Output frequency monitoring (d001) ······························································ 7 - 1 7.1.2 Output current monitoring (d002) ·································································· 7 - 1 7.1.3 Rotation direction monitoring (d003) ······························································ 7 - 1 7.1.4 Process variable (PV), PID feedback monitoring (d004,A071,A075) ·····················...
Page 5 Contents To drive the motor ································································································ 7 - 20 7.5.1 V/f characteristic curve selection (A044/A244,b100 to b113) ······························ 7 - 20 7.5.2 Torque boost setting (A041/A241,A042/A242, A043/A243,H003/H203,b H004/H204) ·························· 7 - 22 7.5.3 3-wire interface operation function (STA, STP, and F/R) (C001 to C005) ··············· 7 - 23 7.5.4 Start frequency setting (b082) ······································································...
Page 6 Contents Set functions related to protection and warning, each output signal ································ 7 - 60 7.8.1 Trip signal (AL) ························································································· 7 - 60 7.8.2 Electronic thermal protection (b012/b212,b013/b213,b015 to b020,C021,C026,C061) ···································· 7 - 61 7.8.3 Overload restriction/overload notice (b021 to b026,C001 to C005,C021,C026,C040,C041) ······································· 7 - 63 7.8.4 Overcurrent restraint (b027) ········································································...
Page 7 Contents Warning Codes for Digital operator ·········································································· 9 - 5 Other Display for Digital operator ············································································ 9 - 6 Chapter 10 Troubleshooting Troubleshoong tips ······························································································ 10 - 1 Chapter 11 Maintenance and Inspection 11.1 Precautions for Maintenance and Inspection ····························································· 11 - 1 11.2 Daily and Periodic Inspections ················································································...
Page 8: Chapter 1 Safety Instructions
Chapter 1 Safety Instructions This chapter describes the Safety instructions. Safety Instructions ·····································1 - 1 Precautions Concerning Electromagnetic Compatibility (EMC) ···································1 - 5 Precautions Concerning Compliance with UL and cUL Standards ·······························1 - 10...
Page 10 Chapter 1 Safety Instructions 1.1 Safety Instructions Be sure to read this Quick Reference Guide and appended documents thoroughly before installing, operating, maintaining, or inspecting the inverter. In this Quick Reference Guide, safety instructions are classified into two levels, namely WARNING and CAUTION.
Page 11 Chapter 1 Safety Instructions 2. Wiring ！ WARNING - Be sure to ground the inverter. Otherwise, you run the risk of electric shock or fire. - Commit wiring work to a qualified electrician. Otherwise, you run the risk of electric shock or fire. - Before wiring, make sure that the power supply is off.
Page 12 Chapter 1 Safety Instructions 3. Operation ！ WARNING - While power is supplied to the inverter, do not touch any terminal or internal part of the inverter, check signals, or connect or disconnect any wire or connector. Otherwise, you run the risk of electric shock or fire.
Page 13 Chapter 1 Safety Instructions 4. Maintenance and inspection ！ WARNING - Before inspecting the inverter, be sure to turn off the power supply and wait for 10 minutes or more. Otherwise, you run the risk of electric shock. (Before inspection, confirm that the Charge lamp on the inverter is off.) In case the power indication of the operator does not turn ON after power-up, inverter may be damaged.
Page 14: Precautions Concerning Electromagnetic Compatibility (Emc)
3-ph. 200V class 2kHz 20m (Shielded) 3-ph. 400V class 2kHz 20m (Shielded) Table 2. Applicable EMC filter Input class Inverter model Filter model (Schaffner) NES1-002SB FS24828-8-07 NES1-004SB NES1-007SB 1-ph. 200V class NES1-015SB FS24828-27-07 NES1-022SB NES1-002LB NES1-004LB FS24829-8-07 3-ph. 200V class NES1-007LB...
Page 15 Chapter 1 Safety Instructions Important notes 1. Input choke or other equipment is required if necessary to comply with EMC directive from the harmonic distortion point of view (IEC 61000-3-2 and 4). 2. If the motor cable length exceeds 20m, use output choke to avoid unexpected problem due to the leakage current from the motor cable (such as malfunction of the thermal relay, vibration of the motor, etc..).
Page 16 Chapter 1 Safety Instructions 7. Minimize the distance between an interference source and an interference sink (interference- threatened device), thereby decreasing the effect of the emitted interference on the interference sink.  You should use only interference-free devices and maintain a minimum distance of 0.25 m from the adjustable frequency inverter.
Page 17 Chapter 1 Safety Instructions Installation for NE-S1 series (example of SB models) Model LB (3-ph. 200V class) and HB(3-ph. 400V class) are the same concept for the installation. Power supply 1-ph. 200V Metal plate (earth) The filter is a footprint type, so it is located between the inverter and the metal plate.
Page 18 Chapter 1 Safety Instructions Hitachi EMC Recommendations ！ WARNING - This equipment should be installed, adjusted, and serviced by qualified personal familiar with construction and operation of the equipment and the hazards involved. Failure to observe this precaution could result in bodily injury.
Page 19: Precautions Concerning Compliance With Ul And Cul Standards
Chapter 1 Safety Instructions 1.3 Precautions Concerning Compliance with UL and cUL Standards (Standard to comply with : UL508C,CSA C22.2 No.14-05) Wiring diagram of inverter DC link choke Circuit breaker or Fuse Power Motor supply Inverter a) Maximum surrounding air temperature rating of 50ºC. b) Solid State motor overload protection reacts with max.
Page 20: Chapter 2 Inspection Of The Purchased Product
Chapter 2 Inspection of the Purchased Product This chapter describes the inspection of the purchased product, the product warranty. Inspection of the Purchased Product ·············2 - 1 Method of Inquiry and Product Warranty ········2 - 2...
Page 22 2.1 Inspection of the Purchased Product (A) Inspecting the product Please check the followings after unpacking. Please contact your supplier or local Hitachi Distributor if there are any problems like below on the product. (1) Any damage during transportation? (2) Basic manual (English and Japanese) are packed together with the product? (3) The product is the one you ordered.
Page 23: Method Of Inquiry And Product Warranty
Chapter 2 Inspection of the Purchased Product 2.2 Method of Inquiry and Product Warranty (A) Method of inquiry In case of contacting to the store you bought the product or Hitachi, please inform the following information. (1) Model name of the inverter (2) Manufacturing number (MFG No.)
Page 24: Chapter 3 Exterior Views
Chapter 3 Exterior Views This chapter describes the exterior views and the names of parts. Exterior Views and Names of Parts ···············3 - 1 Name of each portion (removing the front cover) ···························3 - 2...
Page 26: Exterior Views And Names Of Parts
Chapter 3 Exterior Views 3.1 Exterior Views and Names of Parts The figure below shows an exterior view of the inverter - model : NES1 – 002*,004*SB/LB , 007*LB - model : NES1 – 007*SB , 015,022SB , 004*,007,015,022HB,040HB *)002-007SB/LB and 004HB : without Cooling Fan a) Cooling Fan Cover d) Case b) Cooling Fan...
Page 27: Name Of Each Portion (Removing The Front Cover)
Chapter 3 Exterior Views 3.2 Name of each portion (removing the front cover) Note1) 5) Switch for termination resistor SW4 Note5) (Default) 1) Connector of dedicated  section 5.4, 8.3 operator for NES1-OP 6) Switch for RS485/OPE SW5 RS485 (Default) 2) RUN/STOP/RESET key →section 5.4, 8.3 7) RS422/RS485 port Note3) Note4)
Page 28 Chapter 3 Exterior Views 3 - 3...
Page 29: Chapter 4 Installation
Chapter 4 Installation This chapter describes how to install the inverter. Precautions for installation ··························4 - 1...
Page 31: Precautions For Installation
Chapter 4 Installation 4.1 Precautions for installation ！ CAUTION - Install the inverter on a non-flammable surface, e.g., metal. Otherwise, you run the risk of fire. - Do not place flammable materials near the installed inverter. Otherwise, you run the risk of fire. - When carrying the inverter, do not hold its top cover.
Page 32 Chapter 4 Installation (1)Caution during transportation Please pay attention when carrying the product because it is covered by plastic case. Especially, do not put pressure onto the front cover and terminal cover. Otherwise there is a risk of falling down the product. Please do not use products having damage, and/or lacking components. (2)Ensure Adequate Ventilation To summarize the caution messages –...
Page 33 Chapter 4 Installation (6)Cautions for installation direction Surface of the installation must be no vibration, and should be capable of holding the weight of the product. And the product must be fixed to the surface with a proper screws with vertical direction. Be sure to screw using all the screw holes for the installation.
Page 34: Chapter 5 Wiring
Chapter 5 Wiring This chapter describes the wiring of main circuit and control signal terminals. Precautions for Wiring ······························5 - 1 How to attach and remove the front cover ·······5 - 2 How to attach the Exclusive operator (NES1-OP) ··············································5 - 3 Wiring and terminal description ····················5 - 4 Mains wiring ·············································5 - 7 Wiring of the control circuit ··························5 - 12...
Page 36: Precautions For Wiring
Chapter 5 Wiring 5.1 Precautions for Wiring ！ WARNING - In order to prevent damage caused by static electricity, Please remove the static electricity of the body touch the nearby metal before touching this product. - Be sure to ground the inverter. Otherwise, you run the risk of electric shock or fire. - Commit wiring work to a qualified electrician.
Page 37: How To Attach And Remove The
Chapter 5 Wiring 5.2 How to attach and remove the front cover (1) How to remove 1) Loosen up the screw 2) remove the cover by pressing the bottom side of 3) Move the wiring plate like shown below the cover to the direction shown below. in case of wiring.
Page 38: How To Attach The Exclusive Operator (Nes1-Op)
Chapter 5 Wiring 5.3 How to attach the Exclusive operator (NES1-OP) Cut (6 points) 2) Cut the standard operator panel by in thin–blade-nipper and 1) Remove the front cover from main body take it off. 3) The connector of the exclusive operator (NES1-OP) 5) Figure of installation (NES1-OP) connect to the connector on the circuit board.
Page 39: Wiring And Terminal Description
Chapter 5 Wiring 5.4 Wiring and terminal description Single phase Power source, U/T1 (L1) R/L1 3-phase or S/L2 1-phase, per V/T2 inverter model (Ｎ) T/L3 W/T3 Short circuit bar DC24V Motor Refer to P5-13 when using external Short circuit bar equipment for source logic output PD/+1 and/or external power supply.
Page 40 Chapter 5 Wiring (1) Mains terminal description Symbol Name Description R/L1(L1) Connect power supply Power input S/L2 terminals - Use [L1] and [N] terminal in case of 1-ph. 200V power supply T/L3(N) U/T1 Power output V/T2 Connect 3-ph. motor terminals W/T3 DC link choke First, remove the short circuit bar between PD/+1 and P/+ terminal.
Page 41 Chapter 5 Wiring Category Symbol Name Description Electrical characteristics 5 functions from 35 Voltage between each input and PLC Intelligent functions can be assigned - V(ON) = min.18V input to terminal 1 to 5. Sink or - V(OFF) = MAX.3V terminals source logic can be - Max.
Page 42: Mains Wiring
Chapter 5 Wiring 5.5 Mains wiring (1) Cautions on wiring Be sure to confirm that the charge lamp is turned OFF before the wiring work. Once it is powered up, there will be a remaining voltage at the DC bus capacitor for a certain period regardless the motor operation.
Page 43 A special filter to suppress the surge voltage is available. If you need this filter, contact your supplier or local Hitachi Distributor. ・ When connecting multiple motors to the inverter, connect a thermal relay to the inverter output circuit for each motor.
Page 44 Chapter 5 Wiring (2) Layout of main circuit terminals The figures below show the terminal layout on the main circuit terminal block of the inverter. The main circuit terminal block opens a faceplate and wires it. Single-phase 200V 0.2 to 0.4kW Three-phase 200V 0.2 to 0.75kW Single-phase type...
Page 45 Power Note 1: The peripheral equipment described here is applicable when the inverter supply connects a standard Hitachi 3-phase, 4-pole squirrel-cage motor. Note 2: Select breakers that have proper capacity. (Use breakers that comply with inverters.) Note 3: Use earth-leakage breakers (ELB) to ensure safety.
Page 46 (2.0) (10) Note 1） The peripheral equipment described here is applicable when the inverter connects a standard Hitachi 3-phase, 4-pole squirrel-cage motor. Note 2） Select breakers that have proper capacity. (Use breakers that comply with inverters.) Select above proper ELB capacity following above table for the 1pc inverter.1pc inveter must be supplied by the above proper 1pc ELB.
Page 47: Wiring Of The Control Circuit
Chapter 5 Wiring 5.6 Wiring of the control circuit (1) Wiring instructions 1) Terminals L and CM2 are common to I/O signals and isolated from each other. Do not connect these common terminals to each other or ground them. Do not ground these terminals via any external devices. (Check that the external devices connected to these terminals are not grounded.) 2) Use a shielded, twisted-pair cable (recommended gauge: 0.14-0.75 mm ) for connection to control...
Page 48 Chapter 5 Wiring [example] (sink logic) (27Vdc 50mA max.) Note2) O/OI Short circuit bar (sink logic) Variable Resistor (1k~2k) Frequency meter Note1)The above is a method to perform analog input(O/OI) by voltage input. It is necessary for SW6 on the board to be set for voltage input(default). Note2) If you want to connect a relay to an intelligent output terminal, please connect a surge absorbing diode in parallel with the relay.
Page 49: Connection With The Programmable Controller (Plc)
Chapter 5 Wiring 5.7 Connection with the programmable controller (PLC) (1) Connecting a programmable controller to intelligent input terminals When using an external power supply When using the internal interface power supply (Remove the short circuit bar from the control circuit terminal block.) Short circuit...
Page 50: Notes On Using Multiple Inverters
Chapter 5 Wiring 5.8 Notes on using multiple inverters A plurality of inverter uses the common input and when inverter is timing of different power-on, as shown in the figure below the current flowing around. The input may be recognized as ON in spite of OFF. In this case, please put a diode(rated 50V/0.1A) as shown in the figure to prevent.
Page 51 Chapter 5 Wiring (2) Souce logic Power-ON Power-ON short circuit bar Input Input Additional diode Power-OFF Power-OFF short circuit bar SW OFF SW OFF The input is recognized Providing a diode instead of the short circuit as ON in spite of OFF without Diode. bar, so that the current flowing is prevented.
Page 52: Chapter 6 Operation
Chapter 6 Operation This chapter describes typical methods of operating the inverter, how to operate the digital operator. Precautions of Operation ····························6 - 1 Confirmation before power up the inverter ······6 - 2 Changing parameters ·································6 - 2 Power up the inverter ·································6 - 3 How To Operate the Digtal Operator ··············6 - 4 Motor Operation ········································6 - 11 Conduct a test run of the motor ····················6 - 17...
Page 54: Precautions Of Operation
Chapter 6 Operation 6.1 Precautions of Operation ！ WARNING - Please do not rotate suddenly. Check the direction of rotation at low frequencies. Otherwise, there is a danger of injury. - While power is supplied to the inverter, do not touch any terminal or internal part of the inverter, check signals, or connect or disconnect any wire or connector.
Page 55: Confirmation Before Power Up The Inverter
Chapter 6 Operation 6.2 Confirmation before power up the inverter Please confirm the followings before operation. (1) Connection of the power input (R(L1)/L1,S(L2),T(L3)/N) and motor (U(T1), V(T2), W(T3)) is correctly connected. Otherwise there is a risk of inverter failure. (2) There must be no mis-connection of the control wiring. Otherwise there is a risk of inverter failure. (3) Earth grounding is properly connected.
Page 56: Power Up The Inverter
Chapter 6 Operation 6.4 Power up the inverter (1) Power up the inverter after confirming the items shown in above section 6.2. (2) Confirm the LED is emitting like shown below. - Standard panel : Confirm that both PWR lamp and Key valid lamp are emitting - Dedicated operator (NES1-OP) : Confirm that the 7-SEG LED is emitting.
Page 57: How To Operate The Inverter
Chapter 6 Operation 6.5 How To Operate the Inverter (A) Names and functions of components Standard panel 4) Key valid lamp 1) POWER LED 2) Run command LED 6) RS422/RS485 port 3) ALARM LED 5) RUN/STOP/RESET key Name Description 1) POWER LED - Turns on (red) during inverter is powered up - Turns on (green) during inverter operation.
Page 58 Chapter 6 Operation (B) Dedicated operator (NES1-OP) *same applies to external Operator 4) RUN LED 1) POWER LED 6) 7-SEG LED  2) ALARM LED 13) Volume for frequency setting 5) Run command LED 3) Program LED 7) RUN key 14) RS422/RS485port (RJ45) 9) Escape key 8) STOP/RESETkey...
Page 59 Chapter 6 Operation - This is a port for external operator, Modbus connection, or ProDrioveNext (RS485/operator changeover switch must be operated) before Power ON. In 14) RS422/RS485port case of Modbus communication, it is necessary to set the changeover switch and (RJ45) parameter (C070).
Page 60 Chapter 6 Operation (C) Key operations : This section shows the key operations of the digital operator and Dedicated operator (NES1-OP). Func. code display : Moves to data display Group "d" Func. code display  .    Func. code display : Jumps to the next group ...
Page 61 Chapter 6 Operation [Single-Digit Edit Mode] If a target function code or data is far from current data, using the single-digit edit mode makes it quicker. Pressing the up key and down key at the same time leads you to go into the digit-to-digit changing mode.
Page 62 Chapter 6 Operation [Setting example] After power ON, changing from . display to change the  (carrier frequency) data. 1) Data of  will be shown on the display 2) Press [ESC] key to show after the first power ON the function code ....
Page 63 Chapter 6 Operation [ Connection of the operator for another model] NES1 can operate even (OPE-S/SR/SBK, OPE-SR mini). STR key and FUNC key are different from the behavior of conventional key operation system. In order to transition from the func code display to the data display is the STR key, not the FUNC key.
Page 64: Motor Operation
Chapter 6 Operation 6.6 Motor Operation Both “Run command” and “frequency command” is necessary to run the motor. Motor does not run if one of each is missing. For example, motor will not run when a run command is given, but a frequency command is 0Hz.
Page 65 Chapter 6 Operation (2) Method to perform driving in RUN/STOP/RESET key and perform frequency setting in volume resistor This is the operation method using Run command is given by "RUN/STOP/RESET key" & Frequency setting is given by analog input such as O-L voltage, Accel&Decel time is 10 seconds. (If you don't need to change such as Accel&Decel time, optional Operator is not required.) Below diagram is to set the external Freq.
Page 66 Chapter 6 Operation (3) Method to perform driving in FW/RV teraminal and perform frequency setting in volume resistor This is the operation method using Run command is given by intelligent input terminal such as FW(RV) function & Frequency setting is given by analog input such as O-L voltage. If you don't need to change such as Accel&Decel time, optional Operator is not required.) Below diagram is to set the external Freq.
Page 67 Chapter 6 Operation (B) Method to perform driving with the dedicated operator (NES1-OP) *same applies to external Operator (OPE-S/SR/SBK,OPE-SR mini) (1) Setting the operation command and Frequency command by operator (*Must be set by the operator.) How to drive by key operation of the Dedicated operator. ■Setup Function Name Code...
Page 68 Chapter 6 Operation (2) Carried out in 3-wire input to operation / stop. Carried out in the frequency setting analog current signal(0 to 20mA). (Setting must be changed by the operator.) Setup ■ Code Data Note Function Name Frequency source A001 01(The control circuit terminal) Initial value...
Page 69 Chapter 6 Operation * This wiring diagram is an example of using the built-in power inverter. Refer to Section 5.6, when you use an external power supply. ■Operation Please be operated in accordance with section 6.7. 6 - 16...
Page 70: Test Run With The Motor
Chapter 6 Operation 6.7 Test Run with the motor The following figure shows an example of basic connection is basic. Please refer to section 6.6 wiring for operation command and frequency command from the control circuit terminal block. On how to operate the parameter settings, please refer to section 6.5.
Page 71 Chapter 6 Operation Set to "operator" run command source setting. (A002=02) Set the output frequency. (F001) It is recommended to first slow and for the safety of about 10Hz. Set the operation direction. (F004) Set “Frequency output” to the monitor display on the operator. Displays the (d001). Then press the SET key. Checking the "0.00"(Hz).
Page 72: When Tripping Occurs
Chapter 6 Operation 6.8 When tripping occurs During operation, If any abnormalities (overcurrent, overload, etc.) is detected, and in order to protect the motor and inverter, the inverter output is shut off to the motor. ALARM lamp is lit at the same time. Then, it displays an error code.
Page 73 Chapter 6 Operation Overview of the operation at the time of trip Trip occurs Run command FW，RV free-run Motor rotation speed RS (reset) input AL output (trip signal) 6 - 20...
Page 74 Chapter 7 Explanation of Functions This chapter describes the functions of the inverter. To change a parameter setting or monitoring the parameters, you must have operator(NES1-OP,OPE-SRmini,OPE-S/SR/SBK,WOP). Parameter settings can be changed using the ProDriveNext. Monitoring the data ......7-1 Using the basic functions ....7-6 Setting the intelligent I/O terminal function ..............
Page 76: Chapter 7 Explanation Of Functions
Chapter 7 Explanation of Functions 7.1 Monitoring the data 7.1.1 Output frequency monitoring When the output frequency monitoring function (d001) is selected, the inverter displays the output frequency. The inverter displays "0.00" when the frequency output is stopped. The Hz monitor lamp lights up while the inverter is displaying the output frequency. (Display) 0.00 to 99.99 in steps of 0.01 Hz 100.0 to 400.0 in steps of 0.1 Hz...
Page 77 Chapter 7 Explanation of Functions 7.1.5 Intelligent input terminal status When the intelligent input terminal status function (d005) is selected, the inverter displays the states of the inputs to the intelligent input terminals. The internal CPU of the inverter checks each intelligent input for significance, and the inverter displays active inputs as those in the ON state.
Page 78: Output Voltage Monitoring (D013)
Chapter 7 Explanation of Functions 7.1.8 Output voltage monitoring When the output voltage monitoring function (d013) is selected, the inverter displays the voltage output from the inverter. (Display) 0.0 to 600.0 in steps of 0.1 V (remark) Displayed value may not be accurate when the output voltage is differ from input voltage. 7.1.9 Input power monitoring When the power monitoring function (d014) is selected, the inverter displays the electric power (momentary value) input to the inverter.
Page 79: Dual Monitoring (D050,B160,B161)
Chapter 7 Explanation of Functions 7.1.14 Dual monitoring Displays two different data configured in  and . Item Func. code Range of data Description Dual monitor d050 Setting data of  and . － 1st parameter of Dual Monitor b160 001～018 d001～d018 (*1)
Page 80: Warning Monitoring (D090)
Chapter 7 Explanation of Functions 7.1.17 Warning monitoring If an attempt is made to set the data conflicting with other data on the inverter, the inverter displays a warning in the operator. The PRG (program) lamp lights up while the warning is displayed (until the data is rewritten forcibly or corrected). For details on the programming error monitoring function, see Chapter 9.3 Warning Codes 7.1.18 DC voltage monitoring When the DC voltage monitoring is selected, the inverter displays the DC voltage of the inverter.
Page 81: Using The Basic Functions
Chapter 7 Explanation of Functions 7.2 Using the basic functions 7.2.1 Frequency source setting and Output frequency setting (1) Frequency source setting The frequency source setting function allows you to select the method to input the frequency-setting command. Item Function code Data Description (Valid only when the NES1-OP, OPE-SR/SRmini is used)
Page 82: Run Command Source Setting (A002/A202,C001 To C005,F004)
Chapter 7 Explanation of Functions 7.2.2 Run command source setting The run command source setting function allows you to select the method to input operation commands (to start and stop the motor). As the operation commands via control circuit terminals, turn the FW signal (for forward operation) or RV signal (for reverse operation) on and off to start and stop the motor, respectively.
Page 83: Stop Mode Selection (B091,F003/F203,B003,B007,B008)
Chapter 7 Explanation of Functions 7.2.5 Stop mode selection The stop mode selection function allows you to select one of two methods of stopping the motor when a stop command is input from the digital operator or via the control circuit terminal block. One is to decelerate the motor according to the specified deceleration time and then stop it;...
Page 84: Base Frequency Setting (A003/A203, A082/A282)
Chapter 7 Explanation of Functions 7.2.7 Base frequency setting (1) Base frequency and motor voltage Output - With the base frequency setting and AVR voltage select voltage functions, adjust the inverter outputs (frequency and voltage) to the motor ratings. AVR voltage - The base frequency is the nominal frequency of the motor.
Page 85 Chapter 7 Explanation of Functions Function Item Data Description code The AVR function is always enabled. The AVR function is always disabled. AVR function select A081/A281 The AVR function is disabled at deceleration. (*1) 200/215/220/230/240 Selectable on 200 V class inverter models AVR voltage select A082/A282 380/400/415/440/460/480...
Page 86: Maximum Frequency Setting (A004/A204)
Chapter 7 Explanation of Functions 7.2.9 Maximum frequency setting The maximum frequency setting function allows you to set the Output maximum frequency of the motor driven by the inverter. voltage The maximum frequency set here corresponds to the maximum level of each external analog input (for example, 10 V of the input of 0 to 10 voltage select...
Page 87: Setting The Intelligent I/O Terminal Function
Chapter 7 Explanation of Functions 7.3 Setting the intelligent I/O terminal function 7.3.1 Intelligent input terminal setting You can assign the functions described below to intelligent in put terminals [1] to [5]. To assign the desired functions to the terminals, specify the desired data listed in the table below for terminal settings "C001" to "C005".
Page 88: Input Terminal Response Time (C160 To C164)
Chapter 7 Explanation of Functions 7.3.3 Input terminal response time - The input terminal response time function allows you to specify a sampling time for each of intelligent input terminals 1 to 5. You can use this function effectively to remove noise (e.g., chattering). - If chattering hinders constant input from an input terminal, increase the response time setting for the input terminal.
Page 89 Chapter 7 Explanation of Functions 7.3. 5 Intelligent output terminal a/b (NO/NC) selection The intelligent output terminal a/b (NO/NC) selection function allows you to specify a-contact or b-contact output for each of the intelligent output terminal [11] and the alarm relay terminal. The intelligent output terminal [11] are used for open-collector output, and the alarm relay terminal is used for relay output.
Page 90 Chapter 7 Explanation of Functions 7.3.6 Output signal delay/hold function The output signal delay/hold function allows you to set on-delay and off-delay times for each output terminal. Since every output signal is turned on or off immediately when the relevant condition is satisfied, signal chattering may occur if signal outputs conflict with each other.
Page 91: Using The Analog Terminal
Chapter 7 Explanation of Functions 7.4 Using the analog terminal 7.4.1 Analog input (O/OI) This inverter has an external analog input terminal. If you want to switch the voltage and current inputs, use the switch on the board(SW6). Voltage input : 0 to 10V (Variable resistor is a voltage input.) Current input : 0 to 20mA (Please set the case of “4 to 20mA”to “A013=20%”) The analog input signal can be assigned the following functions.
Page 92: Analog Command Holding Function (Ahd) (C101,C001 To C005)
Chapter 7 Explanation of Functions 7.4.3 Analog command holding function (AHD) - The analog command holding function allows you to make the inverter hold the analog command input via the external analog input terminal when the AHD terminal is on. - While the AHD terminal is on, the up/down function can be used based on the analog signal held by this function as reference data.
Page 93: Analog Input Adjustment (C081)
Chapter 7 Explanation of Functions 7.4.5 Start/end frequency setting for external analog input The start/end frequency setting function allows you to set the inverter output frequency in relation to the external analog inputs (frequency commands) via the following terminals: - O/OI-L terminal: 0 to 10 V or 0 to 20mA - VR : volume of NES1-OP, OPE-SR/SRmini (1) Start/end frequency settings for the O/OI-L terminals Function...
Page 94: Fm Terminal (C027,C030,C105,B081)
Chapter 7 Explanation of Functions 7.4.6 FM terminal [C027] You can monitor the inverter output frequency and output current via the FM terminal on the control circuit terminal block. The FM terminal is a pulse output terminal. (1) FM siginal selection Select the signal to be output from the FM terminal among those shown below.
Page 95: To Drive The Motor
Chapter 7 Explanation of Functions 7.5 To drive the motor 7.5.1 V/f characteristic curve selection [A044/A244] The V/F characteristic curve selection function allows you to set the output voltage/output frequency (V/f) characteristic. To switch the V/F characteristic curve selection among the 1st and 2nd settings, assign function "08" (SET) to intelligent input terminals.
Page 96 Chapter 7 Explanation of Functions (3) Free V/f characteristic setting The free V/f characteristic setting function allows you to set an arbitrary V/f characteristic by specifying the voltages and frequencies (b100 to b113) for the seven points on the V/f characteristic curve. The free V/f frequencies (1 to 7) set by this function must always be in the collating sequence of "1 ≤...
Page 97: Torque Boost Setting (A041/A241,A042/A242, A043/A243,H003/H203,B H004/H204)
Chapter 7 Explanation of Functions 7.5.2 Torque boost setting The torque boost setting function allows you to compensate for the voltage drop due to wiring and the primary resistance of the motor so as to improve the motor torque at low speeds. When you select automatic torque boost by the torque boost selection (A041/A241), adjust the settings of the motor capacity selection (H003/H203) and motor pole selection (H004/H204) based on the motor to be driven.
Page 98 Chapter 7 Explanation of Functions (2) Automatic torque boost When automatic torque boost (data "01") is selected by the torque boost selection (A041/A241), the inverter automatically adjusts the output frequency and voltage according to the load on the motor. (During actual operation, the automatic torque boost is usually combined with the manual torque boost.) When you select the automatic torque boost, adjust the settings of the motor capacity selection (H003/H203) and motor pole selection (H004/H204) according to the motor to be driven.
Page 99: Start Frequency Setting (B082)
Chapter 7 Explanation of Functions 7.5.4 Start frequency setting The start frequency setting function allows you to specify the inverter output frequency that the inverter initially outputs when an operation command is input. Use this function mainly to adjust the start torque. If the start frequency (b082) is set too high, the inverter will start the motor with a full voltage, which will increase the start current.
Page 100 Chapter 7 Explanation of Functions 7.5.6 Jogging (JG) command setting The jogging command setting function allows you to set and finely tune the motor-stopping position. To use this function, assign function "06" (JG) to an intelligent input terminal. (1) Jog frequency setting Output frequency A038 Since the inverter operates the motor with a full voltage for the jogging operation, the inverter can easily...
Page 101: Frequency Upper Limit Setting (A061/A261,A062/A262)
Chapter 7 Explanation of Functions 7.5.7 Frequency upper limit setting The frequency upper limit setting function allows you to place upper and lower limits on the inverter set frequency. This function restricts the input of frequency commands that specify any frequencies outside the upper and lower limits.
Page 102: Acceleration/Deceleration Hold Frequency Setting (A069,A070,A154,A155)
Chapter 7 Explanation of Functions 7.5.9 Acceleration/Deceleration hold frequency setting The acceleration/deceleration hold frequency setting function allows you to make the inverter wait, upon starting the motor, until the slipping of the motor becomes less when the load on the motor causes a large moment of inertia.
Page 103: Multispeed Select Setting (Cf1 To Cf3 And Sf1 To Sf3)
Chapter 7 Explanation of Functions 7.5.11 Multispeed select setting (CF1 to CF3 and SF1 to SF3) The multispeed select setting function allows you to set multiple motor speeds and switch among them by way of signal input via specified terminals. Multispeed operation can be performed in two modes: binary operation mode (with up to 8 speeds) using three input terminals and bit operation mode (with up to 4 speeds) using three input terminals.
Page 104 Chapter 7 Explanation of Functions 7.5.12 Two-stage acceleration/deceleration function (2CH) The two-stage acceleration/deceleration function allows you to change the acceleration or deceleration time while the inverter is accelerating or decelerating the motor. Select one of the following three methods of changing the acceleration or deceleration time: 1) Changing the time by the signal input to an intelligent input terminal 2) Automatically changing the time when the output frequency reaches a specified frequency 3) Automatically changing the time only when switching the motor operation from forward rotation to...
Page 105: Acceleration/Deceleration Curve Selection (A097,A098,A131,A132)
Chapter 7 Explanation of Functions 7.5.13 Acceleration/deceleration curve selection You can set different patterns of motor acceleration and deceleration according to the type of system to be driven by the inverter. Use functions "A097" and "A098" to select acceleration and deceleration patterns, respectively. You can individually set an acceleration pattern for acceleration and a deceleration pattern for deceleration.
Page 106: Frequency Operation Function (A141,A142,A143,A001,A076)
Chapter 7 Explanation of Functions (2) Curve constant (swelling degree) Specify the swelling degree of the acceleration curve with reference to the following graphs: Output frequency (Hz) Output frequency (Hz) Output frequency (Hz) Target Target Target frequency frequency frequency (100%) (100%) (100%) 99.6...
Page 107: Frequency Addition Function (A145,A146,C001 To C005)
Chapter 7 Explanation of Functions 7.5.15 Frequency addition function The frequency addition function allows you to add or subtract the value specified as the frequency to be added (A145) to or from the frequency value of a selected frequency command. To use this function, assign function "50"...
Page 108: V/F Gain Setting (A045/A245,A082/A282)
Chapter 7 Explanation of Functions 7.5.17 V/f gain setting [A045/A245] The V/f gain setting function allows you to change the inverter output voltage by specifying the rate of the output voltage to the voltage (100%) selected with the AVR voltage select function (A082). If the motor operation is cranky, try to decrease the gain setting.
Page 109: Pid Function (A071 To A078,C044,C052,C053)
Chapter 7 Explanation of Functions 7.5.18 PID function The PID function allows you to use the inverter for the process control on fluid flow, airflow, and pressure. To enable this function, specify "01 enabled" or "02 inverted data output enabled" for function "A071". You can disable the PID function with an external signal during the PID operation.
Page 110 Chapter 7 Explanation of Functions (2) PID operation 1) P operation The proportional (P) operation stands for the operation in which the change in operation quantity is in proportion to the change in target value. Change in steps Linear change Target value Large Large...
Page 111 Chapter 7 Explanation of Functions (5) Output of inverted PID deviation Some sensor characteristics may cause the polarity of the deviation of feedback data from the target value to be inconsistent with the inverter operation command. If the inconsistency occurs, specify "01" for function "A077"...
Page 112 Chapter 7 Explanation of Functions (7) Output of inverted PID deviation If the inverter is under the normal PID control and the PID operation result is a negative value, the frequency command to the inverter will be limited to 0 Hz. However, when "02" (enabling the inverted output) is set for the PID Function Enable (A071), the PID operation result to be output to the inverter is inverted if the result is a negative value.
Page 113 Chapter 7 Explanation of Functions (13) PID sleep function If PID command is below the (A156), it stop the output after the (A157). If PID command is above the (A156), it start the output after the (A157). If it returns within (A157), PID sleep function doesn't work. (A158) should set higher than (A156).
Page 114: Energy-Saver Operation (A085,A086)
Chapter 7 Explanation of Functions 7.5.19 Energy-saver operation [A085/A086] The energy-saver operation function allows you to automatically minimize the inverter output power while the inverter is driving the motor at constant speed. This function is suited to operating a fan, pump, or other load that has a reduced-torque characteristic.
Page 115: Nd Motor Control Function (Set) (C001 To C005)
Chapter 7 Explanation of Functions 7.5.21 2 motor control function (SET) This motor control function allows you to switch the inverter settings to control two different types of motors. To use this function, assign function "08" (SET) to the terminal [1] to [5] functions (C001 to C005). Turn the SET terminal on and off for switching.
Page 116 Chapter 7 Explanation of Functions 7.5.22 DC braking (DB) setting The DC braking function allows you to apply DC braking to the motor according to the load on the motor. You can control DC braking in two ways: the external control through signal input to intelligent input terminals and the internal control to be performed automatically when the motor is started and stopped.
Page 117 Chapter 7 Explanation of Functions (2) External DC braking Assign function "07" (DB) to terminal function (C001 to C005). Direct braking control by ON/OFF of DB terminal when the setting of DC braking enable (A051) is 00(Invalid) and 01(Valid). Adjust the braking force by adjusting the DC braking force setting (A054). When you set the DC braking wait time (A053), the inverter output will be shut off for the set period of delay, and the motor will run freely during the period.
Page 118 Chapter 7 Explanation of Functions (3) Internal DC braking (A051: 01) You can apply DC braking to the motor even without entering braking signals via the DB terminal when the inverter starts and stops. To use the internal DC braking function, specify "01" for the DC braking enable (A051).
Page 119 Chapter 7 Explanation of Functions (4) Internal DC braking (triggered only when the output frequency reaches a set frequency) (A051: 02) You can also operate the internal DC braking function so that DC braking is applied to the motor when the inverter output frequency falls to the DC braking frequency setting (A052) or below.
Page 120: Functions Related To The Operator Display
Chapter 7 Explanation of Functions 7.6 Functions related to the operator display 7.6.1 STOP key enable [b087] When the control circuit terminal block is selected as the device to input operation commands, the STOP key enable function allows you to enable or disable the motor-stopping and trip reset functions of the STOP key of the digital operator.
Page 121: Forcible-Operation From Terminal (F-Tm) Function
Chapter 7 Explanation of Functions 7.6.4 Forcible-operation from terminal (F-TM) function The forcible-operation function allows you to forcibly enable the inverter operation via control circuit terminals when the control circuit terminal block is not selected as the device to input frequency and operation commands.
Page 122: Select Automatic Return To The Initial Display (B164)
Chapter 7 Explanation of Functions 7.6.7 Select automatic return to the initial display [b164] If you do not manipulate the operator for 10 minutes, the operator screen automatically changes to the screen that you set in the (b038). This function is enabled by setting the b164 = 01. Item Function code Data...
Page 123: Function Code Display Restriction (B037)
Chapter 7 Explanation of Functions 7.6.11 Function code display restriction [b037] The function code display restriction function allows you to arbitrarily switch the display mode or the display content on the digital operator. Item Function code Data Description Full display Function-specific display Function code display restriction b037...
Page 124: Button Sensitivity Selection (C151)
Chapter 7 Explanation of Functions (3) Basic display mode The monitor displays basic parameters. The following table lists the parameters that can be displayed in basic display mode: Code displayed Item d001 to d104 Monitoring indication F001 Output frequency setting F002 Acceleration (1) time setting F003...
Page 125: Scroll Sensitivity Selection (C152)
Chapter 7 Explanation of Functions 7.6.13 Scroll sensitivity selection [C152] When the display data of the operator, press and hold the UP or DOWN key. Then, the data update rate is faster. Update rate can be adjusted by (C152). Item Function code Data Description...
Page 126: Functions About Restarting
Chapter 7 Explanation of Functions 7.7 Functions about restarting 7.7.1 Retry (Under Voltage , Over Current / Over Voltage) (1) Retry (restart) after under voltage / Over Current / Over Voltage You can select tripping or retrying (restarting) the motor operation as the inverter operation to be performed at the occurrence of undervoltage.
Page 127 Chapter 7 Explanation of Functions *1 If the inverter trips because of overvoltage or overcurrent while decelerating the motor, the inverter will display error code "E09" (undervoltage), and the motor will start free-running. If this error occurs, prolong the deceleration time. *2 The inverter may start the motor with 0 Hz if: 1) the output frequency is not more than half the base frequency or 2) the voltage induced on the motor is attenuated quickly.
Page 128 Chapter 7 Explanation of Functions (2) Output of the alarms for undervoltage in the stopped state Use function "b004" to specify whether to output an alarm when undervoltage occurs. The inverter outputs the alarm providing the control power remains in the inverter. Output of the alarms for undervoltage in the stopped state: Examples 5 to 7 show the alarm output operations with standard settings.
Page 129 Chapter 7 Explanation of Functions (3) Restarting methods - Restart with an active matching frequency The inverter starts the output with the frequency specified for the start frequency selection (b030), searches for the point where the frequency and voltage are balanced while keeping the current at the restart current level (b028), and then restarts the motor.
Page 130 Chapter 7 Explanation of Functions 7.7.2 Reset (RS) function The reset function allows you to recover the inverter from a tripped state. To perform resetting, press the STOP/RESET key of the digital operator or turn the RS terminal ON. To use the control circuit terminal for resetting, assign function "18" (RS) to an intelligent input terminal. You can select the restart mode to apply after resetting with the restart mode after reset (C103).
Page 131 Chapter 7 Explanation of Functions 7.7.3 Free-run stop (FRS) function The free-run stop (FRS) function allows you to shut off the inverter output to let the motor start free-running. You can effectively use this function when stopping the motor with a mechanical brake (e.g., electromagnetic brake).
Page 132 Chapter 7 Explanation of Functions 7.7.4 Unattended start protection (USP) function The unattended start protection function allows you to make the inverter trip with error code "E13" displayed if the inverter power is turned on when an operation command has been turned on. You can recover the inverter from tripping by performing the reset operation or turning the operation command off.
Page 133: Deceleration And Stopping At Power Failure (Nonstop Deceleration At Instantaneous Power Failure) (B050 To B054)
Chapter 7 Explanation of Functions 7.7.5 Deceleration and stopping at power failure (nonstop deceleration at instantaneous power failure) The nonstop deceleration at instantaneous power failure is the function making the inverter decelerate and stop the motor while maintaining the voltage below the overvoltage level when an instantaneous power failure occurs during the inverter operation.
Page 134 Chapter 7 Explanation of Functions <2> DC voltage constant control during nonstop operation at momentary power failure (b050 = 02: no restoration, b050 = 03: restoration to be done) - If momentary power failure occurs or the main circuit DC voltage drops during inverter operation, the inverter decelerates the motor while maintaining the main circuit DC voltage at the level specified as the target nonstop operation voltage at momentary power failure (0V-LAD stop level) (b052).
Page 135: Set Functions Related To Protection And Warning, Each Output Signal
Chapter 7 Explanation of Functions 7.8 Set functions related to protection and warning, each output signal 7.8.1 Trip signal (AL) When it detects an anomaly, the inverter output is shut off, the inverter outputs a trip signal. This is called a trip. If you reset, the inverter deactivate trip state.
Page 136 The frequency characteristic set as the electronic thermal characteristic is integrated with the value of "b012" or "b212". The cooling-fan performance of a general-purpose motor lowers when the motor speed is low. So load (current) is decreased. The reduced-torque characteristic is designed to match the heat generation by Hitachi's general-purpose motors. Item Function code...
Page 137 Chapter 7 Explanation of Functions (b) Constant-torque characteristic Make this setting when driving a constant-torque motor with the inverter. (Example) 015L**, Base frequency60Hz,（rated current7.1A = b012） 60Hz （Reduction scale：x1.0） 1.5Hz （Reduction scale：x0.9） Reduction scale Trip time (s) Trip time (s) X1.0 X0.9 X0.8...
Page 138: Overload Restriction/Overload Notice (B021 To B026,C001 To C005,C021,C026,C040,C041)
Chapter 7 Explanation of Functions 7.8.3 Overload restriction/overload notice (1) Overload restriction function - The overload restriction function allows you to make the inverter monitor the motor current during acceleration or constant-speed operation and automatically reduce the output frequency according to the deceleration rate at overload restriction when the motor current reaches the overload restriction level.
Page 139: Overcurrent Restraint (B027)
Chapter 7 Explanation of Functions (2) Overload nitice function The overload notice function allows you to make the inverter output an overload notice signal before tripping because of overload. You can use this function effectively to prevent the machine (e.g., a conveyor)driven by the inverter from being overloaded and prevent the conveyor from being stopped by the overload protection of the inverter.
Page 140: Over Voltage Supression During Deceleration (B130 To B134)
Chapter 7 Explanation of Functions 7.8.5 Over voltage supression during deceleration - The over voltage supression function allows you to prevent the inverter from tripping because of the overvoltage that can be caused by the energy regenerated by the motor during deceleration. - You can enable or disable the function by setting the overvoltage suppression enable (b130).
Page 141 Chapter 7 Explanation of Functions 7.8.6 External trip (EXT) function The external trip function allows you to make the inverter trip according to the error (trip) signal generated by an external system. To use this function, assign function "12" (EXT) to one of the terminal [1] to [5] functions (C001 to C005). When the EXT terminal is turned on, the inverter trips with error code "E12"...
Page 142: Automatic Carrier Frequency Reduction (B083,B089)
Chapter 7 Explanation of Functions 7.8.7 Automatic carrier frequency reduction [b089] - The automatic carrier frequency reduction function automatically reduces the carrier frequency according to the increase in output current. - To enable this function, specify "01" for automatic carrier frequency reduction selection (b089). Item Function code Range of data...
Page 143: Running Signal (Run) (C021)
Chapter 7 Explanation of Functions 7.8.8 Running signal (RUN) While the inverter is operating, it outputs the running (RUN) signal via an intelligent output terminal ([11]) or the alarm relay terminal. To use this signal function, assign function "00" (RUN) to one of the intelligent output terminals [11] (C021) and the alarm relay terminal (C026).
Page 144 Chapter 7 Explanation of Functions (1) Signal output when the constant-speed frequency is reached (01: FA1) The inverter outputs the signal when the output frequency reaches the frequency specified by a frequency setting (F001, A020, A220) or multispeed setting (A021 to A027). fon: 1% of maximum frequency Set frequency foff: 2% of maximum frequency...
Page 145: Running Time Over And Power-On Time Over Signals (Rnt And Ont)
Chapter 7 Explanation of Functions 7.8.10 Running time over and power-on time over signals (RNT and ONT) [b034] The inverter outputs the operation time over (RNT) signal or the plug-in time over (ONT) signal when the time specified as the run/power-on warning time (b034) is exceeded. Item Function code Range of data...
Page 146 Chapter 7 Explanation of Functions 7.8.12 Logical output signal operation function (LOG1) The logical output signal operation function allows you to make the inverter internally perform a logical operation of output signals. This function applies to all output signals, except to logical operation results (LOG1) and allocation none (NO).
Page 147: Communication Line Disconnection Signal (Ndc) (C021,C026,C077)
Chapter 7 Explanation of Functions 7.8.13 Communication line disconnection signal (NDc) This signal function is enabled when ModBus-RTU has been selected for the RS485 communication. If a reception timeout occurs, the inverter continues to output the communication line disconnection signal until it receives the next data.
Page 148: Low-Current Indication (Loc) Signal (C021,C026,C038,C039)
Chapter 7 Explanation of Functions 7.8.16 Low-current indication (LOC) signal The inverter outputs the low-current indication (LOC) signal when the inverter output current falls to the low-current indication signal detection level (C039) or less. You can select one of the two signal output modes with the low-current indication signal output mode selection (C038).
Page 149: Forward Rotation Signal (Fwr) (C021,C026)
Chapter 7 Explanation of Functions 7.8.19 Reverse rotation signal (RVR) The inverter continues to output the forward rotation (RVR) signal while it is driving the motor for reverse operation. The RVR signal is turned off while the inverter is driving the motor for forward operation or stopping the motor.
Page 150: Window Comparators (Wc) (Detection Of Terminal Disconnection:dc)
Chapter 7 Explanation of Functions 7.8.21 Window comparators (WC) (detection of terminal disconnection:Dc) - The window comparator function outputs signals when the values of analog inputs O/OI is within the maximum and minimum limits specified for the window comparator. You can monitor analog inputs with reference to arbitrary levels (to find input terminal disconnection and other errors).
Page 151: Frequency Command Source (Fref)
Chapter 7 Explanation of Functions 7.8.22 Frequency command source (FREF) This function outputs a signal when the (A001 = 02). However, this function is disabled when the second control mode. The rest of the time (A001 = 02) the signal is turned OFF. Item Function code Data...
Page 152 Chapter 7 Explanation of Functions 7.8.21 Window comparators (WC) (detection of terminal disconnection:Dc) - The window comparator function outputs signals when the values of analog inputs O/OI is within the maximum and minimum limits specified for the window comparator. You can monitor analog inputs with reference to arbitrary levels (to find input terminal disconnection and other errors).
Page 153: Chapter 8 Communication Functions
Chapter 8 Communication Functions This chapter describes the Communication functions. (Modbus-RTU) Communication Specification ·······················8 - 1 Connecting the Inverter to Modbus ···············8 - 2 Modbus setting procedure ···························8 - 3 Modbus Communication parameter ···············8 - 4 Modbus Protocol Reference ························8 - 5 Explanation of function codes ······················8 - 9 Re-calculate the internal variable ··················8 - 18 Modbus Data Listing ··································8 - 19...
Page 155: Communication Specification
Chapter 8 Communication Functions 8.1 Communication Specification NE-S1 Series inverters have built-in RS-485 serial communications, featuring the Modbus RTU protocol. The inverters can connect directly to existing factory networks or work with new networked applications, without any extra interface equipment. The specifications are in the following table.
Page 156: Connecting The Inverter To Modbus
Chapter 8 Communication Functions 8.2 Connecting the Inverter to Modbus The Modbus communication uses a pin of RJ45 as below. The the RJ45 connector is used for the external operator and Modbus communication. Signal Description Symbol DC+5V For Operator. Do not connect. ―...
Page 157: Modbus Setting Procedure
Chapter 8 Communication Functions 8.3 Modbus setting procedure 1. Changes from an operator mode to Modbus 1) Set a parameter (cf. 8.4) for Modbus communication by the exclusive operator (NES1-OP), remote operator (OPE-S/SR/SBK/SRmini,WOP), or ProDriveNext. (It is necessary to be set the operator side (OFF, right side ) in RS485 communication / operator switch (SW5) when use the remote operator (OPE-S/SR/SBK/SRmini,WOP) or ProDriveNext.
Page 158: Modbus Communication Parameter
Chapter 8 Communication Functions 8.4 Modbus Communication parameter Inverter Parameter Setup - The inverter has several settings related to Modbus communications. The table below lists them together. The Required column indicates which parameters must be set properly to allow communications. You may need to refer to the host computer documentation in order to match some of its settings.
Page 159: Modbus Protocol Reference
Chapter 8 Communication Functions 8.5 Modbus Protocol Reference Transmission procedure The transmission between the external control equipment and the inverter takes the procedure below.  Query - A frame sent from the external control equipment to the inverter  Response - A frame returned from inverter to the external control equipment The inverter returns the response only after the inverter receives a query from the external control equipment and does not output the response positively.
Page 160 Chapter 8 Communication Functions Message Configuration: Query Slave address:  This is a number of 1 to 247 assigned to each inverter (slave). (Only the inverter having the address given as a slave address in the query can receive the query.) ...
Page 161 Chapter 8 Communication Functions Message Configuration: Response Transmission time required:  A time period between reception of a query from the master and transmission of a response from the inverter is the sum of the silent interval (3.5 characters long) + C078 (transmission latency time).
Page 162 Chapter 8 Communication Functions No response occurs: In the cases below, the inverter ignores a query and returns no response.  When receiving a broadcasting query  When detecting a transmission error in reception of a query  When the slave address set in the query is not equal to the slave address of the inverter ...
Page 163: Explanation Of Function Codes
Chapter 8 Communication Functions 8.6 Explanation of function codes (A) Read Coil Status [01h] This function reads the status (ON/OFF) of selected coils. An example follows below.  Read intelligent input terminals [1] to [5] of an inverter having a slave address “8.” ...
Page 164 Chapter 8 Communication Functions (B) Read Holding Register [03h] This function reads the contents of the specified number of consecutive holding registers (of specified register addresses). An example follows below.  Reading Trip monitor 1 factor and trip frequency, current, and voltage from an inverter having a slave address “1”...
Page 165 Chapter 8 Communication Functions The data set in the response is as follows: Response Buffer Register Number 12+0 (high 12+0 12+1 12+1 (low 12+2 12+2 (low order) (low (high order) (high order) order) order) order) Register Data 0003h 0000h Trip data Trip factor (E03) Status Frequency (9.9Hz)
Page 166 Chapter 8 Communication Functions (D) Write in Holding Register [06h] This function writes data in a specified holding register. An example follows:  Write “50Hz” as the first Multi-speed 0 (A020) in an inverter having slave address “5.”  This example uses change data “500(1F4h)” to set “50Hz” as the data resolution of the register “1019h”...
Page 167 Chapter 8 Communication Functions (E) Loopback Test [08h] This function checks a master-slave transmission using any test data. An example follows:  Send test data to an inverter having slave address “1” and receiving the test data from the inverter (as a loopback test). Query: Response: Example...
Page 168 Chapter 8 Communication Functions (F) Write in Coils [0Fh] This function writes data in consecutive coils. An example follows:  Change the state of intelligent input terminal [1] to [5] of an inverter having a slave address “8.”  This example assumes the intelligent input terminals have terminal states listed below. Item Data Intelligent input terminal...
Page 169 Chapter 8 Communication Functions (G) Write in Holding Registers [10h] This function writes data in consecutive holding registers. An example follows:  Write “3000 seconds” as the first acceleration time 1 (F002) in an inverter having a slave address “8.” ...
Page 170 Chapter 8 Communication Functions (H) Write in Holding Registers [17h] This function is to read and write data in consecutive holding registers. An example follows:  Write “50.0Hz” as the set frequency (F001) in an inverter having a slave address “1” and then to read out the output frequency (d001).
Page 171 Chapter 8 Communication Functions (I) Exception Response When sending a query (excluding a broadcasting query) to an inverter, the master always requests a response from the inverter. Usually, the inverter returns a response according to the query. However, when finding an error in the query, the inverter returns an exception response. The exception response consists of the fields shown below.
Page 172: Re-Calculate The Internal Variable
Chapter 8 Communication Functions 8.7 Re-calculate the internal variable There are necessary data of the recomputation. In this case,use the ENTER command. (A) ENTER Command When recalculate the internal value, Set 0000h to the register(0900h) by the Write in Holding Register command [06h].
Page 173: Modbus Data Listing
Chapter 8 Communication Functions 8.8 Modbus Data Listing (A) Modbus Coil List The following tables list the primary coils for the inverter interface to the network. The table legend is given below.  Coil No. - The network register address offset for the coil. The coil data is a single bit (binary) value.
Page 174 Chapter 8 Communication Functions Coil Item Setting 002Eh Odc: Analog O disconnection detection 1: ON, 0: OFF 002Fh to (Reserved) 0031h 0032h FBV (PID feedback comparison) 1: ON, 0: OFF NDc (communication train 0033h 1: ON, 0: OFF disconnection) 0034h LOG1 (logical operation result 1) 1: ON, 0: OFF 0035h to...
Page 175 Chapter 8 Communication Functions (B) Modbus Holding Registers The following tables list the holding registers for the inverter interface to the network. The table legend is given below.  Function name - The standard functional name of the parameter or function for the inverter ...
Page 176 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 0011h Trip Counter d080 0 to 65530 1 [time] 0012h Trip info. 1 (factor) See the list of inverter trip factors below 0013h Trip info. 1 (inverter status) See the list of inverter trip factors below 0014h Trip info.
Page 177 Chapter 8 Communication Functions i) List of inverter trip factors Upper part of trip factor code (indicating the factor) Lower part of trip factor code (indicating the inverter status) Name Code Name Code No trip factor Resetting Over-current event while at constant speed Stopping Over-current event during deceleration Decelerating...
Page 178 Chapter 8 Communication Functions ii) List of warning data Modbus Operator Condition data display     Frequency upper limit setting (A061) Maximum frequency setting (A004) ＞     Frequency lower limit setting (A062) Maximum frequency setting (A004) ＞...
Page 179 Chapter 8 Communication Functions (2) Registers (monitoring group d) Register Function Data Function name Monitoring and setting items code resolution 1001h d001 (high) Output frequency monitor 0 to 40000 0.01 [Hz] 1002h d001 (low) 1003h Output current monitor d002 0 to 65530 0.01 [A] 0: Stopping, 1: Forward rotation, 2: 1004h...
Page 180 Chapter 8 Communication Functions (3) Registers (group A) Register Function Data Function name Monitoring and setting items code resolution 0 (keypad potentiometer), 1 (control circuit terminal block), 2 (digital 1201h Frequency source A001 operator), 3 (Modbus), 10 (operation function result) 1 (control circuit terminal block), 2 1202h Run command source (*)
Page 181 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 1226h to (Reserved) 1237h 1238h Jog frequency A038 R/W "Start frequency" to 999 0.01 [Hz] 0 (free-running after jogging stops [disabled during operation]) 1 (deceleration and stop after jogging stops [disabled during operation]) 2 (DC braking after jogging stops [disabled during operation])
Page 182 Chapter 8 Communication Functions Register Data Function name Function code R/W Monitoring and setting items resolution 124Fh (Reserved) 0 or "maximum frequency limit" to 1250h Frequency upper limit A061 0.01 [Hz] "maximum frequency" 1251h (Reserved) 0 or "maximum frequency limit" to 1252h Frequency lower limit A062...
Page 183 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 126Fh to (Reserved) 1273h 1274h A092 (high) Acceleration time (2) 0 to 360000 0.01 [s] 1275h A092 (low) 1276h A093 (high) Deceleration time (2) 0 to 360000 0.01 [s] 1277h A093 (low)
Page 184 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 0 (digital operator), 1 (keypad Operation-target frequency 12B0h A142 potentiometer), 2 (input via O/OI), 4 selection 2 (external communication) 0 (addition: A141 + A142), 12B1h Operator selection A143 1 (subtraction: A141 - A142), 2 (multiplication: A141 x A142)
Page 185 Chapter 8 Communication Functions (4) Registers (group B) Register Function Data Function name Monitoring and setting items code resolution 0 (tripping), 1 (starting with 0 Hz), 2 Restart mode on power failure / (starting with matching frequency), 3 1301h b001 under-voltage trip (tripping after deceleration and stopping with matching frequency)
Page 186 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 0 (frequency at the last shutoff), 1 Start freq. of active frequency 131Fh b030 (maximum frequency), 2 (set matching frequency) 0 (disabling change of data other than "b031"...
Page 187 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 1342h to (Reserved) 1348h Operation level at O 1349h b070 1 [%] 0. to 100. (%) or "no" (ignore) disconnection 134Ah to (reserved) 1350h Cumulative input power data 1351h b078 R/W Clearance by setting "1"...
Page 188 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 1375h to (Reserved) 1384h Deceleration over voltage 0 (disabling), 1 (enabling), 2 (enabling 1385h b130 suppression enable with acceleration), 3(when Const/Dec) 200 V class: 330 to 390 (V) 1386h Decel.
Page 189 Chapter 8 Communication Functions (5) Registers (group C) Register Function Data Function name Monitoring and setting items code resolution 0 (Forward Run), 1 (RV: Reverse RUN), 2 (CF1: Multispeed 1 setting), 3 (CF2: 1401h Input [1] function C001 Multispeed 2 setting), 4 (CF3: Multispeed 3 setting), 6 (JG: Jogging), 7 (DB: external DC braking), 8 (SET: Set 2nd motor data), 9 (2CH: 2-stage...
Page 190 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 0 (RUN: running), 1 (FA1: constant-speed reached), 2 (FA2: set frequency overreached), 3 (OL: overload notice advance signal (1)), 4 (OD: output deviation for PID control), 5 1415h Output [11] function C021...
Page 191 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 142Ah (Reserved) Frequency arrival setting for 142Bh C042 R/W 0 to 40000 0.01 [Hz] accel. 142Ch (Reserved) Frequency arrival setting for 142Dh C043 R/W 0 to 40000 0.01 [Hz] decel.
Page 192 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 0 (not storing the frequency data), 1 1469h Up/Down memory mode selection C101 (storing the frequency data) 0 (resetting the trip when RS is on), 1 (resetting the trip when RS is off), 2 146Ah Reset mode selection C102...
Page 193 Chapter 8 Communication Functions (7) Registers (2 control settings F group) Register Function Data Function name Monitoring and setting items code resolution 2103h F202 (high) Acceleration time (1), 0 to 360000 0.01 [s] 2nd motor 2104h F202 (low) 2105h F203 (high) Deceleration time (1), 0 to 360000 0.01 [s]...
Page 194 Chapter 8 Communication Functions Register Function Data Function name Monitoring and setting items code resolution 226Fh A292 (high) Acceleration time (2), 0 to 360000 0.01 [s] 2270h 2nd motor A292 (low) 2271h A293 (high) Deceleration time (2), 0 to 360000 0.01 [s] 2nd motor 2272h...
Page 195: Chapter 9 Error Codes
Chapter 9 Error Codes This chapter describes the error codes of the inverter, error indications by the functions, and troubleshooting methods. Indication of the error ·································9 - 1 Error Codes and Troubleshooting ·················9 - 3 Warning Codes for Digital operator ···············9 - 5 Other Display for Digital operator ··················9 - 6...
Page 197: Indication Of The Error
Chapter 9 Error Codes 9.1 Indication of the error The microprocessor in the inverter detects a variety of fault STOP conditions and captures the event, recording it in a history table. The STOP inverter output turns OFF, or “trips” similar to the way a circuit breaker trips due to an over-current condition.
Page 198 Chapter 9 Error Codes [Digital Operator (NES1-OP, OPE-S/SR/SBK/SRmini)] Trip History and Inverter Status We recommend that you first find the cause of the fault before clearing it. When a fault occurs, the inverter stores important performance data at the moment of the fault. To access the data, use the monitor function (xxx) and select ...
Page 199: Error Codes And Troubleshooting
Chapter 9 Error Codes 9.2 Error Codes and Troubleshooting It is not displayed with the standard panel. Display on digital Reference Name Description Troubleshooting and corrective action operator page If the motor is constrained or Check whether the load has fluctuated sharply. suddenly accelerated or During (Eliminate the load fluctuation.)
Page 200 Chapter 9 Error Codes Display on digital Reference Name Description Troubleshooting and corrective action operator page If an error occurs in the external equipment or Check whether an error has occurred in the external device connected to the inverter, the inverter will equipment (when the external trip function has been External trip fetch the error signal and shut off its output.
Page 201: Warning Codes For Digital Operator
Chapter 9 Error Codes 9.3 Warning Codes for Digital operator The warning code for Digital operator is follows. It is not displayed with the standard panel. The inverter displays a warning code when the data set as a target function code satisfies the condition (specified in the Condition column) in relation to the data set as the corresponding basic function code.
Page 202: Other Display For Digital Operator
Chapter 9 Error Codes 9.4 Other Display for Digital operator The other display for Digital operator is follows. It is not displayed with the standard panel. Name Description Display on digital operator Rotating Reset RS input is ON or STOP/RESET key is pressed. If the input voltage falls, the inverter will shut off its output, display the code shown on the right, and wait for the recovery of Waiting in...
Page 203: Chapter 10 Troubleshooting
Chapter 10 Troubleshooting This chapter describes the troubleshooting methods.
Page 205: Troubleshooting Tips
Chapter 10 Troubleshooting Troubleshooting Tips The table below lists typical symptoms and the corresponding solution(s). 1. Inverter does not power up. Possible Cause(s) Corrective Action Power cable is incorrectly wired. Check input wiring Short bar or DCL between [P] and [PD] is Install short bar or DCL between [P] and [PD] terminal.
Page 206 Chapter 10 Troubleshooting 3. Motor does not accelerate to command speed. Possible Cause(s) Corrective Action Bad connection of analog wiring. Check the wiring. In case of analog voltage or variable resistor input, check voltage between [O/OI] and [L] terminal. In case of analog current, check current between current source and [O/OI] terminal.
Page 207 Chapter 10 Troubleshooting 10. .Overcurrent trip (E03) Possible Cause(s) Corrective Action Acceleration time is short. Change acceleration time (F002/A092/A292). Enable "acceleration hold" function (A069,A070) Excess load. Remove excess load. Enable torque boost function. Set free V/f in V/F characteristic curve selection (A044/A244=02) Overload restriction (b021) is disabled (00).
Page 208 Chapter 10 Troubleshooting 16. Output torque is not sufficient. Possible Cause(s) Corrective Action Improper parameters [Acceleration] Increase torque boost (A042/A242-A043/A243) Reduce carrier frequency (b083). Change torque boost select (A041/A241) to automatic. Improper parameters [Deceleration] Increase deceleration time (F003/F203/A093/A293). Disable AVR function (A081/A281). 17.
Page 209 Chapter 10 Troubleshooting NES1-OP does not appear. NES1-OP display is abnormal. Possible Cause(s) Corrective Action Poor contact of the inverter connector and Please reconnect the NES1-OP after power-off. NES1-OP. Output phase loss protection(E34) is occur. Possible Cause(s) Corrective Action Motor cable is disconnected or not Check the wiring.
Page 210 Chapter 11 Maintenance and Inspection This chapter describes the precautions and procedures for the maintenance and inspection of the inverter. 11.1 Precautions for Maintenance and Inspection ··········································11 - 1 11.2 Daily and Periodic Inspections ·····················11 - 2 11.3 Ground Resistance Test with a Megger ··········11 - 3 11.4 Withstand Voltage Test ·······························11 - 3 11.5 Methods of Measuring the Input/Output Voltages, Current, and Power ···································11 - 4...
Page 212: Precautions For Maintenance And Inspection
Check those inverter sections and parts which are accessible only while the inverter is power off and which should be inspected regularly. When you intend to carry out a periodic inspection, contact your local Hitachi Distributor. During a periodic inspection, perform the following: 1) Check that the cooling system is normal.
Page 213: Daily And Periodic Inspections
Chapter 11 Maintenance and Inspection 11.2 Daily and Periodic Inspections Inspection Inspection Item Inspected Check for… Criteria Cycle Method Daily Year Ambient Extreme  Thermometer, Ambient temperature between environment temperatures & hygrometer –10 to 50C, humidity Humidity 90% or less non-condensing Major Abnormal noise &...
Page 214: Ground Resistance Test With A Megger
Chapter 11 Maintenance and Inspection 11.3 Ground Resistance Test with a Megger When testing an external circuit with a megger, disconnect all the external circuit cables from the inverter to prevent it from being exposed to the test voltage. Use a tester (in high-resistance range mode) for a conduction test on the control circuit. Do not use a megger or buzzer for that purpose.
Page 215: Methods Of Measuring The Input/Output Voltages, Current, And Power
Chapter 11 Maintenance and Inspection 11.5 Methods of Measuring the Input/Output Voltages, Current, and Power This section describes the measuring instruments generally used to measure the input and output voltages, output current, and output power of the inverter. Power supply Motor Measurement Measuring point...
Page 216: Capacitor Life Curves
Chapter 11 Maintenance and Inspection 11.6 Capacitor Life Curves Ambient Temperature ( C) Operation 12hours/day, 80% load Capacitor Life (year) Capacitor Life Note 1: The ambient temperature indicates the temperature measured at a position about 5 cm distant from the bottom center of the inverter body. If the inverter is mounted in an enclosure, the ambient temperature is the temperature within the enclosure.
Page 217 (2) years from the date of manufacture, or one (1) year from the date of installation, whichever occurs first. The warranty shall cover the repair or replacement, at Hitachi's sole discretion, of ONLY the inverter that was installed.
Page 218: Chapter 12 Specifications
Chapter 12 Specifications This chapter describes the specifications and external dimensions of the inverter. 12.1 Specifications ........... 12-1 12.2 Dimensions ............12-3 12.3 Derating Curves ..........12-5...
Page 220 Chapter 12 Specifications 12.1 Specifications 200V Class Item Three-phase 200V class Specifications Single-phase 200V class Specifications NES1 inverters, 200V models 002L* 004L* 007L* 015L* 022L* 002S* 004S* 007S* 015S* 022S* Note8) 0.75 0.75 Applicable motor size Note1） 200V Rated capacity（kVA） 240V Three-phase: 200V-15% to 240V +10%, Single-phase: 200V-15% to 240V +10%,...
Page 221 Standards Compliance UL、CE、c-UL、c-tick Note1） The applicable motor refers to Hitachi standard 3-phase motor (4p). When using other motors, care must be taken to prevent the rated motor current (50/60Hz) from exceeding the rated output current of the inverter. Note2） The output voltage decreases as the main supply voltage decreases (except when using the AVR function). In any case, the output voltage cannot exceed the input power supply voltage.
Page 222: Dimensions
Chapter 12 Specifications 12.2 Dimensions Model Note) (mm) (mm) (mm) (mm) NES1-002S* NES1-004S* 21.5 NES1-002L* NES1-004L* 21.5 NES1-007L* Note) "*" changes by Restricted Distribution 12 - 3...
Page 223 Chapter 12 Specifications 007S 004H Model Note) (mm) (mm) (mm) NES1-007S* NES1-004H* Note) "*" changes by Restricted Distribution Model Note) (mm) (mm) (mm) NES1-015S* NES1-022S* NES1-015L* NES1-022L* NES1-007H* NES1-015H* NES1-022H* NES1-040H* ote) "*" changes by Restricted Distribution 12 - 4...
Page 224: Derating Curves
Ambient temperature 50℃ max. Rated output current (A) Production:after August, 2012 NES1-002LB NES1-002SB Ambient 40℃ Ambient 40℃ Ambient 50℃ Ambient 50℃ Carrier frequency(kHz) Carrier frequency(kHz) NES1-004LB NES1-004SB Ambient 40℃ Ambient 40℃ Ambient 50℃ Ambient 50℃ Carrier frequency(kHz) Carrier frequency(kHz) 12 - 5...
Page 225 Chapter 12 Specifications Ambient 30℃ NES1-022LB NES1-022SB Note)FFM installation. Ambient Ambient 50℃ temperature 50℃ Ambient 40℃ Ambient 50℃ Carrier frequency(kHz) Carrier frequency(kHz) Note) If I attach optional FFM to the inverter, show that it becomes derating-free. NES1-004HB NES1-040HB Ambient 40℃ Ambient 30℃...
Page 226 NES1-002SB NES1-002LB Ambient 30℃ Ambient 30℃ Ambient 50℃ Ambient 50℃ Ambient 40℃ Ambient 40℃ Carrier frequency(kHz) Carrier frequency(kHz) NES1-004LB NES1-004SB Ambient 30℃ Ambient 30℃ Ambient 40℃ Ambient 40℃ Ambient 50℃ Ambient 50℃ Carrier frequency(kHz) Carrier frequency(kHz) NES1-007LB NES1-007SB Ambient 30℃...
Page 227 Chapter 12 Specifications NES1-015LB NES1-015SB Ambient 30℃, 40℃ Ambient 30℃ Ambient 50℃ Ambient 50℃ Ambient 40℃ Carrier frequency(kHz) Carrier frequency(kHz) NES1-022LB NES1-022SB Ambient 30℃ Ambient 30℃ Ambient 40℃ Ambient 50℃ Ambient 40℃ Ambient 50℃ Carrier frequency(kHz) Carrier frequency(kHz) Legend for Graphs: Ambient temperature 30℃...
Page 228: Chapter 13 Option
Chapter 13 Option This chapter lists the data settings for the various functions of the inverter. Illustrate by this chapter about options of NES1.
Page 230 Chapter 13 Option 13.1 Digital Operetor Digital Operator prepares NES1-OP,OPE-S/SR/SBK/SRmini and WOP. NES1-OP can be attached to the NES1 inverter.Other than it,be the connection with the cable. 13.1.1 Attention at the time of the data setting ･When Function code display restriction(b037) are set other than "00" (all indication), some functions are not displayed.
Page 231 Chapter 13 Option “d” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Dual display the monitoring data selected by d050      Monitoring b160, b161 0. to 9999./1000 to 6553 d080 ...
Page 232 Chapter 13 Option 13.1.3Function mode (Display of NES1-OP,OPE-S/SR/SBK/SRmini) Note) Mark “” in [ Run Mode Edit] shows the accessible parameters when b031 is set “10”, high level access. “F” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units...
Page 233 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Edit Code 200/400 200/400 200/400 Five options; select codes: Frequency A001   01 00 POT on ext. operator ← ← source 01 Control terminal 02 Function F001 setting Frequency...
Page 234 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Defines the first speed of a multi-speed Multi-speed profile or a 2nd motor, range is 0.00 / start A220 ...
Page 235 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Voltage compensati on gain for A046   100. ← ← automatic torque boost Sets voltage compensation gain under Voltage automatic torque boost, range is 0.
Page 236 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Sets a limit on output frequency less than the maximum frequency (A004). Frequency Range is from frequency lower limit A061 ...
Page 237 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Selects source of Process Variable (PV), option codes: A076  PV source 01[O/OI] terminal  01 ← ←...
Page 238 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Acc1 to Acc2 A095  frequency 0.00 ← ← transition point Output frequency at which Accel1 switches to Accel2, range is 0.00 to Acc1 to Acc2 400.00 Hz...
Page 239 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Two options: 00Plus (adds A145 value to the output  A146 direction frequency setting) 00  ← ←...
Page 240 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Select inverter restart method, Four option codes: Restart 00Alarm output after trip, no automatic restart mode on 01Restart at 0Hz power ...
Page 241 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Retry wait time on over  b011 voltage / Range is 0.3 to 100.0 sec. ← ← over current trip...
Page 242 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Overload Rated b022  restriction current ← ← level Sets the level of overload restriction, between x 1.50 20% and 200% of the rated current of the Overload Rated...
Page 243 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Prevents parameter changes, in five options, option codes: 00all parameters except b031 are locked when [SFT] terminal is ON 01all parameters except b031 and output Software frequency F001 are locked...
Page 244 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Decelerat ion time b053 Range is 0.10 to 300.00 seconds.  1.00 ← ← of ctrl. decel. Initial freq.
Page 245 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Selects how the inverter resumes operation when free-run stop (FRS) is cancelled, Restart two options: b088  mode ...
Page 246 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Free V/F b112  setting, Set range, b110 ~ 400 ← ← freq.7 Free V/F Setrange,0.0to300.0V(200Vclass), b113 ...
Page 247 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Data 00 Read/Write OK b166  Read/Wri  ← ← 01 Protected te select This is to perform initialization by parameter input with b084, b085 and b094.
Page 248 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Edit Code 200/400 200/400 200/400 Select input terminal [1] function, 34 C001  Input [1] function  ← ← options (see next section) [FW] Select input terminal [2] function, 34 C002...
Page 249 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Rated Overload warning C241  current ← ← level, 2 motor x 1.15 Sets the frequency arrival setting Frequency arrival threshold for the output frequency during C042...
Page 250 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Scale factor between the external frequency command on terminals L–O O/OI input span C081  /OI(voltage/current input) and the 100.0 ←...
Page 251 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Mode Name Description standard Units Code Edit 200/400 200/400 200/400 Scroll sensitivity C152  1 to 20  ← ← selection Ground fault C155  00(OFF) / 01(ON) ...
Page 252 Chapter 13 Option 13.1.4 Monitoring mode (Display of WOP) ･The initial state displays (d001) at the time of power activation by all means. When you fix it by any display, please change setting of (b038). “d” Function Defaults Initial data Initial data Initial data Func.
Page 253 Chapter 13 Option “d” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 d081  Trip monitoring 1     (ERR1) d082      Trip monitoring 2 (ERR2) Factor,...
Page 254 Chapter 13 Option Note) Mark “” in [ Run Mode Edit] shows the accessible parameters when b031 is set “10”, high level access. “F” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400...
Page 255 Chapter 13 Option [Function mode (A Group)] “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 A001 Five options; select codes: (Frequency  Frequency source  ← ← 00 POT on ext.
Page 256 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 The output frequency A012 corresponding to the [O/OI] input active ([O/OI] end  analog input range 0.00 ←...
Page 257 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 Defines limited A038 speed for jog, range (Jog  Jog frequency is from start 6.00 ← ←...
Page 258 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 A045  V/f gain 100. ← ← (V/F gain) Sets voltage gain of the inverter, range is A245 20 to 100% ...
Page 259 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 Sets the duration for A058 DC braking, range is  DC braking time at start ← ←...
Page 260 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 A063 Up to 3 output (Jump FQ1 frequencies can be Center) defined for the 0.00 A065 output to jump past Jump freq.
Page 261 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 Selects source of Process Variable (PV), option codes: A076 01[O/OI] terminal (PV source  PV source ...
Page 262 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 acceleration, range A292 Acceleration time (2),  (Accel.time2- 10.00 ← ← 0.00 to 3600.00 motor seconds. A093 Duration of 2 ...
Page 263 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 Seven options: 00Operator A141 A input select for 01VR (A-input   ← ← calculate function 02Terminal [O/OI] calc.FQ) input...
Page 264 Chapter 13 Option “A” Function Defaults Initial data Initial data Initial data Func. Mode Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 Sets the delay time A157 PID sleep function for the action, set  (PID sleep ← ←...
Page 265 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 Select inverter restart method, Four option codes: 00Alarm output after trip, no automatic restart b001 Restart mode on 01Restart at 0Hz (Restart ...
Page 266 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 Select inverter restart method, Four option codes: 00Alarm output after trip, no automatic restart b008 Restart mode on 01Restart at 0Hz (Restart ...
Page 267 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 b019 Free setting (Free  electronic thermal Range is b017 to 400Hz ← ← E.Thermal ~freq.3 FQ-3) b020 Free setting...
Page 268 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 b027 Two option codes: OC suppression  00Disabled  ← ← suppress selection * 01Enabled select) Sets the current level of active freq.
Page 269: Digital Operator
Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 b036 Set range, 0 (disabling Reduced voltage (Reduced V  the function), 1 (approx.  ← ←...
Page 270 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 b070 Operation level at Set range, 0 to 100%, or (Discon  ← ← O/OI disconnection “no”...
Page 271 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 Three option codes: 00Disabled b089 01Enabled, depending Automatic carrier (Auto.Carrier  on the output current  ←...
Page 272 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 b112 Free V/F setting, (Free V/F  Set range, b110~ 400 ← ← freq.7 -F7) b113 Free V/F setting, (Free V/F ...
Page 273 Chapter 13 Option “b” Function Defaults Initial data Initial data Initial data Func. Mode Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 Five option codes: 00Trip b165 01Trip after (Ex.ope Ex. operator com.  deceleration to a stop ...
Page 274 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 Select input terminal C001 [1] function, 34  Input [1] function  ← ← (Input [1] Function) options (see next [FW] section)
Page 275 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 9 programmable functions: 00Output frequency (PWM) 01Output current (PWM) 03Output frequency (Pulse train) [FM] terminal 04Output voltage C027 selection (PWM)
Page 276 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 200% (from 0 to two C241 Rated Overload warning time the rated  (Overload warn current ← ←...
Page 277 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 Three option codes: C074 00No parity Communication   ← ← (Parity) parity 01Even parity 02Odd parity Two option codes: C075 Communication stop...
Page 278 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 Controls speed setpoint for the inverter after power cycle. Two option codes: C101 Up/Down memory 00Clear last (UP/DWN memory ...
Page 279 Chapter 13 Option “C” Function Defaults Initial data Initial data Initial data Func. Unit Code Name Description standard Edit (WOP) 200/400 200/400 200/400 C140 Relay output on (Alarm-RLY ON  ← ← delay delay) Set range is 0.0 to C141 100.0 seconds.
Page 280 Chapter 13 Option Input Function Summary Table – This table shows all thirty-four intelligent input functions at a glance. Detailed description of these functions, related parameters and settings, and example wiring diagrams are in “Using Intelligent Input Terminals” on page 4-8. Input Function Summary Table Option Terminal...
Page 281 Chapter 13 Option Input Function Summary Table Option Terminal Function Name Description Code Symbol Temporarily disables PID loop control. Inverter output turns OFF as long as PID Enable is active PID Disable Has no effect on PID loop operation, which operates normally if PID Enable is active ( Resets the PID loop controller.
Page 282 Chapter 13 Option Output Function Summary Table – This table shows all functions for the logical outputs (terminals [11] and [AL]) at a glance. Detailed descriptions of these functions, related parameters and settings, and example wiring diagrams are in “Using Intelligent Output Terminals” in chapter 4. Output Function Summary Table Termina Option...
Page 283 Chapter 13 Option Output Function Summary Table Termina Option Function Name Description Code Symbol Mode to Stop Mode Network Disconnect When the communications watchdog timer (period Detection specified by ) has time out When the communications watchdog timer is satisfied by regular communications activity Logic Output When the Boolean operation specified by...
Page 284: Top Cover For Exclusive Use Of Ne-S1Series : Nes1-Ffm-M
Chapter 13 Option “H” Function Defaults Initial data Initial data Initial data Func. Code Name Description standard Units Edit (WOP) 200/400 200/400 200/400 H003 Specifie Twelve selections: Motor capacity  ← ← d by the (Motor capacity) 0.10/0.20/0.40/0.5 capacity H203 5/0.75/1.10/1.50/2 Motor capacity, of each...
Page 285 Chapter 13 Option FFM（Back side） Figure1 Mounting method of FFM Figure 2 Part (shaded area) to remove surgically FFM（Back side） Figure3 Part (shaded area) to remove surgically Figure 4 After part (shaded area) to remove surgically 13 - 56...
Page 286 Chapter 13 Option 13.2.2 Improvement of the derating ・Derating properties are improved by attaching optional FFM to an applicable model. Neither applicable model needs the derating of the carrier frequency and the current derating at ambient temperature 50℃. The detail refers to figure 5 ,6 and figure 7 Ambient Temp30℃...
Page 287 Chapter 13 Option 13.2.4 Reduction of the dust invades ・Because a top opening becomes the window shade construction as for the inverter of the NE-S1 series, it is in the structure that direct, the dust from the top is hard to invade the products inside. The dust from the top becomes hard to invade the inverter inside more by attaching optional FFM to an applicable model.
Page 288 Chapter 13 Option 13.2.5 Reduction of the inverter installation space area ・At the time of the inverter installation, space more than above or the below 10cm is necessary not to disturb ventilation. However, please secure only 2cm that is measure of FFM because be exhausted by the front when optional FFM to an applicable model is attached.（Refer to Figure 10）...
Page 289: Appendix
Appendix Appendix A ·········································· Appendix A- 1...
Page 291 Appendix Appendix-A Disassembly method of NES1-OP (1)After having removed a Front Cover, remove two places of screws. Remove two places of screws. (2) Pick up the side of the operator cover, and remove a NES1-OP.. *Take it off the inverter right side by all means if I exclude a NES1-OP. Pick up the point that I ordered in a figure, and flatter PCB, and take off two places of nails of the operator to open it outside of inverter (cf.
Page 292 Appendix Appendix - 2...
Page 293: Index
Index deceleration overvoltage restraint ..... 7-65 derating ............12-4 acceleration/deceleration patterns ....7-30 detection of terminal disconnection ....7-75 acceleration/deceleration times......7-8 digital current monitoring ........7-19 acceleration curve constant ......7-30 digital current monitor reference value ..... 7-19 acceleration time ..........7-8 digital output frequency ........
Page 294 Index current trip ..........7-51 H terminal ............5-5 heat sink overheat warning ....... 7-72 O/OI terminal ..........5-5, 7-16 heat sink temperature monitoring ....... 7-3 OD ..............7-37 HLD ..............7-27 OHF ..............7-72 hold down ..........6-5, 6-10 OL ..............
Page 295 Index RUN / STOP / RESET key ........6-4 run command source setting ....... 7-7 warning display ........... 9-5 run command LED ..........6-5 warning monitoring ..........7-5 Run Mode Edit ..........7-45 WC ..............7-75 RV ............... 7-7 window comparator .......... 7-75 RVR ..............

This manual is also suitable for:

Nes1-002sb Nes1-015sb Nes1-007sb Nes1-004lb Nes1-002lb Nes1-015lb ... Show all

Hitachi NES1-004SB Quick Reference Manual

Chapter 1 Safety Instructions

Chapter 2 Inspection of the Purchased Product

Chapter 3 Exterior Views

Chapter 4 Installation

Chapter 5 Wiring

Chapter 6 Operation

Chapter 7 Explanation of Functions

Chapter 8 Communication Functions

Chapter 9 Error Codes

Chapter 10 Troubleshooting

Chapter 11 Maintenance and Inspection

Chapter 12 Specifications

Chapter 13 Option

Appendix

Index

Quick Links

Quick Reference Guide

Troubleshooting

Related Manuals for Hitachi NES1-004SB

Summary of Contents for Hitachi NES1-004SB

This manual is also suitable for:

Table of Contents
