- Page 1 ® System Configuration and Order-information Guide BX620 S2/BX620 S3 October 2006...
-
Page 2: Front View
PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S2 PRIMERGY BX620 S3 View View Expansion Board slot Expansion Board slot DIMM Slot DIMM Slot Hard Disk Bay Hard Disk Bay PRIMERGY BX600 S2 Blade Server System Unit Front View PRIMERGY BX620 S2... - Page 3 PRIMERGY BX620 S2 / BX620 S3 Instruction This document contains basic product and configuration information that will enable you to configure your system. Only these tools will ensure a fast and proper configuration of your PRIMERGY server or your complete PRIMERGY Rack system.
-
Page 4: Data Sheet
PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S2 Data Sheet Type Dual-Processor Blade Server Base Unit Xeon® 3EGHz/2MB, 1GB PGUX6221A Frequencies 64-bit Intel® Xeon® 3.80GHz *5 / 3.40EGHz *6 / 3.20EGHz *7 / 3EGHz Second-Level-Cache Multi-Processor max. 2 (1 for standard) -
Page 5: Configuration Diagram
PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S2 Configuration Diagram Memory DIMM Slot 1 Xeon® DIMM Slot 2 3.80/3.40E/ 3.5 inch HDD Bay 1 Hard Disk 3.5inch Bay (hot plug) DIMM Slot 3 3.20E/3EGHz (hot plug) Standard Drive Cage (HDD x 1ch) - Page 6 PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S2 Memory Max: 12GB (2GB DIMM x 6) Memory Module-1GB (512MB DIMM x 2) Memory PG-RM1BC Slot Standard Memory Module: 1GB (512MB DIMM x 2) Memory Module-2GB (1GB DIMM x 2) PG-RM2BC...
- Page 7 PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S2 LAN Card/Internal backup device (PRIMERGY SX10) Max: 1 Expansion Card Twist Pair Cable (category 5e) Slot Module Connector Expansion Card Slot Module Eth. Ctrl 2x 1000-BASE-T Cu PG-CS102 PG-1862 *Dual port SCSI Ctrl U160 SCSI Cable HDCI 1.5m...
- Page 8 PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S3 Data Sheet Type Dual-Processor Blade Server Base Unit Xeon® 5050 (3GHz) PGUX6231A Frequencies Dual Core Intel® Xeon® 5080 (3.73GHz) *5 / 5060 (3.20GHz) *6 / 5050 (3GHz) Second-Level-Cache 2 x 2MB Multi-Processor max.
- Page 9 PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S3 Configuration Diagram Memory 2.5 inch HDD Bay 1 Hard Disk 2.5inch Bay (hot plug) (hot plug) Standard Drive Cage (HDD x 2ports) DIMM Slot 8 Xeon® DIMM Slot 4 5080 (3.73GHz)/ DIMM Slot 7 5060 (3.20GHz)/...
- Page 10 PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S3 Connection Table Max: 2 CPU Processor Xeon 5080 3.73GHz/2x2MB PG-FG33P CPU Slot Standard: 1 CPU PGBFG33P (for CTO) *. This option is available when CPU Conversion kit: Xeon 5050(3GHz/2x2MB) -> Xeon 5080(3.73GHz/2x2MB) (PGBFU33P) is applied.
- Page 11 PRIMERGY BX620 S2 / BX620 S3 PRIMERGY BX620 S3 Connecting Internal HDD and Internal Backup Devices Internal HDD SAS/RAID Configuration Max: 2 HDDs HDD SAS 10k 36GB hot plug 2.5inch Onboard SAS PG-HDD61A Controller PGBHDD61A (for CTO) HDD SAS 10k 73GB hot plug 2.5inch...
- Page 12 PRIMERGY BX620 S2 / BX620 S3 Switch Blade Data Sheet Type Switch Blade Base Unit PG-SW104 PG-SW105 PGBSW1040 (*1) / PGBSW1041 (*2) / PGBSW1042 (*3) / PGBSW1043 (*4) PGBSW1050 (*1) / PGBSW1051 (*2) / PGBSW1052 (*3) / PGBSW1053 (*4) CTO optional...
- Page 13 PRIMERGY BX620 S2 / BX620 S3 FC Switch Blade Data Sheet Type FC Switch Blade Base Unit PG-FCS102 CTO optional PGBFCS102 (*1) / PGBFCS1022 (*2) Fibre Channel Internal 8ports (4Gbps) ( 10ports (4Gbps when FCSW Upgrade kit:Porton Demand (PG-FCSU102) is applied )
- Page 14 PRIMERGY BX620 S2 / BX620 S3 BX600 S2 Blade Server System Unit Data Sheet Type BX600 S2 Blade Server System Unit Base Unit PGUR3SC1 Slots Server Blade 10 (hot plug) (*1) Network Blade 4 (hot plug) (LAN/Fibre Channel) Management Blade (standard)
- Page 15 PRIMERGY BX620 S2 / BX620 S3 BX600 S2 Blade Server System Unit Connection Table BX600 S2 Blade Server System Unit PGUR3SC1 Server Blade Max: 10 Server Blade BX620 S2 Slots BX620 S3 LAN Interfaces ( Use of Network Blade Slot 1,2 )
- Page 16 PRIMERGY BX620 S2 / BX620 S3 BX600 S2 Blade Server System Unit LAN/Fibre Channel Interfaces ( Use of Network Blade Slot 3,4 ) Switch Blade Network Blade PG-SW104 Twist Pair Cable (category 5e) Slots Max: 2 Blades PGBSW1042 (for CTO)
- Page 17 PRIMERGY BX620 S2 / BX620 S3 BX600 S2 Blade Server System Unit Connection between BX620 S2 / BX620 S3 and Network Blade Please refer to the following connection patterns between BX620 S2 / BX620 S3 and Network Blade. BX620 S2 / BX620 S3...
- Page 18 Specifications are subject to change without notice. For the latest detailed information, contact your local representative. All brand names and product names are trademarks and registered trademarks of their respective holders. ©2006 Fujitsu Limited. All rights reserved. Printed in Japan. Global Business Development & Marketing Business Strategy &...
