Electrolux W4400H Service Manual

Clarus control
Hide thumbs Also See for W4400H:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual , User Manual

Service Manual

W4400H, W3600H, W3850H, W31100H
Clarus Control
438 9206-51
06.22

Advertisement

Table of Contents
loading

Related Manuals for Electrolux W4400H

Summary of Contents for Electrolux W4400H

  • Page 1: Service Manual

    Service Manual W4400H, W3600H, W3850H, W31100H Clarus Control 438 9206-51 06.22...

  • Page 3: Table Of Contents

    Contents Contents Technical data ....................7 Machine presentation ................. 15 Maintenance ....................17 Daily ....................... 17 Every third month .................. 17 Troubleshooting ..................19 Precautions .................... 19 Measurements ..................19 Errors with no error codes ..............20 Errors with error codes ................20 Service programme ................
  • Page 4 Contents Motor ......................157 Warnings ....................157 Description ....................158 Motor ....................158 Motor control ..................159 Function ....................160 Belt tension ..................162 Drain valve ....................16 Description ..................16 Fault-finding ..................16 Detergent dispenser ................. 165 Tilt function (Optional equipment) ............167 Installation ...................

  • Page 5: Contents

    Contents Safety This machine can only be used with water. Never use dry cleaning agents. Do not allow children to operate the machine. Do not hose down or spray the machine with water. All mechanical and electrical installation must be carried out by qualified personnel. Do not bypass the door locking device. Should the machine malfunction, please report the fault to the technician responsible for the machine. 428 429 Emergency stop When necessary measures have If the machine for some reason has been taken, the emergency button to be stopped – press emergency can be reset by pulling it out. stop button All external equipment which is connected to the machine must be CE/EMC-approved and connected using an approved shielded...

  • Page 7: Technical Data

    Technical data Technical data W4400H W3600H W3850H W31100H Innerdrum, volume litres 400 1100 diameter 1220 1220 Drum speed wash extraction max rpm Heating 6 or 54 – – steam hot water G-factor Weight, net 1095-1450* 180-1480 2200-200* 200-2400* * Precise weight depends on accessories fitted.
  • Page 8 Technical data Technical data W4400H W3600H W3850H W31100H Frequency of the dynamic force 1.8 12.7 12.0 11.1 Max floor load at extraction 16±0.75 15.9±6.4 22±7. 24±7. Sound levels Airborne sound level dB (A) re 2x10 < 70 < 70 < 70 < 70...
  • Page 9 Technical data Dimensions W4400H A 125 1450 2015 910 00 1865 270 820 420 45 425 525 660 225 950 80 70 2205 1140 45 W3600H A 190 1600 2015 970 200 1850 270 660 525 425 860 1565 420 40 2200 1120 2180 955 275 275...
  • Page 10 Technical data Dimensions W3850H A 1640 165 220 995 80 215 1070 80 65 445 1140 1660 45 820 2410 1175 2480 960 285 400 W31100H A 1640 1850 220 995 80 215 1070 80 65 445 1140 1660 45 820 2400 1160 2480 955 240 5 1 Control panel Steam connection 2 Door opening ø...
  • Page 11 Technical data W4400H Heating Voltage Total Fuse alternative alternative No heating 200 V  AC or Steam 208-240 V  AC heating 20/400 V  AC 25/16 240 V  AC 46 V  AC 80 V  AC 400 V  AC...
  • Page 12 Technical data W3600H Heating Voltage Total Fuse alternative alternative No heating 200 V  AC or Steam 20 V  AC heating 20 V  AC 240 V  AC 240 V  AC 80 V  AC 400 V  AC 415 V  AC 440 V  AC 480 V  AC...
  • Page 13 Technical data W3850H Heating Voltage Total Fuse alternative alternative No heating 200 V  AC 20 V  AC or Steam heating 240 V  AC 80 V  AC 400 V  AC 415 V  AC 440 V  AC 480 V  AC W31100H Heating...

  • Page 15: Machine Presentation

    Machine presentation Machine presentation The drum assembly on this model is of the suspended type, which means that the outer drum and its motor assembly are suspended in the machine chassis with strong coil springs in the middle and at each corner, inside the machine.
  • Page 16 Machine presentation The inner drum is driven via four V-belts by a frequency-controlled motor, which is mounted on a motor mounting plate under the drum assembly. The motor mounting plate is adjustable, so that belt tension can be regula- ted. The motor has a microprocessor-controlled control unit which allows the motor speed, acceleration and deceleration to be controlled with high precision.

  • Page 17: Maintenance

    • Check that the drain valve is not leaking and that it opens and closes normally. • Check the compressed air regulator (A). If necessary empty separated water. W4400H = 15 mm W600H = 10 mm W850H, Every third month W1100H = 2 mm •...

  • Page 19: Troubleshooting

    Troubleshooting General information about troubleshooting The troubleshooting section is used to pinpoint a fault on the machine to a specific defective component or unit. If the power supply is interrupted, the programme memory will keep the select programme in its memory for approx. -5 minutes. Within this time period, the machine automatically restarts after the power interruption.

  • Page 20: Errors With No Error Codes

    Troubleshooting Errors with no error codes This section includes troubleshooting charts for errors for which no error code is generated. Alarm text Errors with error codes Error indication Programme or machine errors are indicated by an alarm text in the display window. � � � Resetting an error indication �...
  • Page 21 Troubleshooting List of errors, functions monitored and relevant error messages displayed Error/Function Error message displayed 01 ERROR. NO WATER Water level has not reached set level within time set. NO WATER After this error message appears and the machine is reset, the machine will try again. 02 ERROR. OPEN DOOR Signal from microswitch which checks door status absent during program. After this error message appears and the machine is reset, the machine will try again.
  • Page 22 Troubleshooting List of errors, functions monitored and relevant error messages displayed, cont. Error/Function Error message displayed 15 ERROR. EMERGENCY STOP The emergency stop button has been pressed. EMERGENCY STOP 16 ERROR. WEIGHT FROM SCALE Over-/Under-load of scale or weight above limit for maximum allowed WEIGHT FROM SCALE weight at wash module start. 17 ERROR. DOOR LOCK SWITCH Even though the door lock microswitch indicates that the door is locked, the signal from the microswitch which is used to detect when the door is closed is absent.
  • Page 23 Troubleshooting List of errors, functions monitored and relevant error messages displayed, cont. Error/Function Error message displayed ERROR. ERROR CODES FROM MOTOR CONTROLLER This function includes a number of error warnings from the motor control system for frequency-controlled motors 1 DC voltage too high OVER VOLTAGE Check the mains voltage. 2 DC voltage too low UNDER VOLTAGE Check the mains voltage.

  • Page 24: Service Programme

    Troubleshooting Service programme Opening the service programme The service program The service program makes fault-finding on the machine easier, as it allows you to control the vari- ous machine functions individually: If this menu is not currently displayed: • water filling RUN A WASH PROGRAM Press repeatedly. GO TO THE MENU •...
  • Page 25 Troubleshooting Prevention of unauthorised access A button on the CPU circuit board has to be press- sed to gain access to the service program, to PRESS BUTTON ON Press the button on the prevent its unauthorised or inadvertent use. The CPU BOARD CPU circuit board. CPU circuit board is located behind the control panel.
  • Page 26 Troubleshooting To control the machine functions SERVICE PROGRAM LEVEL TEMP 22°C SPEED DRAIN CLOSED 01 COLD WATER 02 HOT WATER 0 COLD HARD WATER 04 TANK 1 WATER 05 TANK 2 WATER 06 TANK  WATER To activate the various 01 COLD WATER machine functions: 02 HOT WATER 0 COLD HARD WATER...
  • Page 27 Troubleshooting I/O card inputs Press 1. SERVICE PROGRAM Now you can check the LEVEL TEMP 22°C SPEED various input signals from I/O DRAIN CLOSED board 1. EMERGENCY STOP DOOR LOCKED TEMPORARY PAUSE DOOR CLOSED A black square in front of the REMOTE START UNBALANCE SERVICE...

  • Page 28: Errors With No Error Codes

    Troubleshooting Errors with no error codes Programme unit card No indication in the display window (machine not responding or operates apart from this). If the power is on, be very careful when working on the machine. 972 Verify that: Red LED Green LED • the machine receives power. • the machine has not been emergency stop- Green LED ped. Red LED • the red LEDs on the programme unit card and the I/O card light steadily.

  • Page 29: Errors With Error Codes

    Troubleshooting Errors with error codes NO WATER The water level has not reached the selected level within the given time. Following an alarm and subsequent, the machine will make a new attempt. First verify that: • the programme unit was not incorrectly pro- grammed 97 Valve Switch Relay • the inlet filter is not blocked cold/warm X9:7 4 detergent • all water faucets are open compartment 1 dispenser •...
  • Page 30 Troubleshooting Continued from previous page 5. Activate (close) the drain valve in the service programme. Activate another of the water valves and verify the drain valve function. Drain valve OK Drain valve defective Troubleshoot the drain valve according to the instructions under error code WATER IN DRUM later in this troubleshooting section. 6. Verify that the level hose is not damaged, bent, blocked and has not come lose from the T-joint, drum, programme unit card A1 or level guard B2. Level hose connection Level hose OK Defective level hose 972 Fit the hose correctly or replace it.
  • Page 31 Troubleshooting DOOR OPEN No signal from the ”Door closed” during pro- gramme operation. If the input signal for ”Door closed” is lost during programme operation, the OPEN DOOR error code is immediately generated. If the power is on, be very careful when working on the machine. 97 1. Try to restart the machine (i.e. reset the error code) by pressing START. Error message returns No error message Temporary error (probably defective contact) SERVICE PROGRAM LEVEL TEMP 22°C SPEED 2. Exit the programme using . Enter the service DRAIN CLOSED EMERGENCY STOP DOOR LOCKED programme (unlock the door if it is locked). Verify TEMPORARY PAUSE DOOR CLOSED voltage supply is present between X5:4 - 5 when the REMOTE START...
  • Page 32 Troubleshooting Continued from previous page Switch cam 4. Disassemble the door lock and verify the function of Microswitch S S3 using an ohm meter. Correct function Incorrect function Lock solenoid and Replace S. microswitch S4 5. Inspect the cabling between X5 and S3 using an ohm meter. Cabling OK Incorrect cabling Remedy or replace the cables. Inspect the mechanical function of the door lock. Replace any defective components or replace the door lock.
  • Page 33 Troubleshooting DOOR UNLOCKED No signal from the ”Door locked” during pro- gramme operation. If the input signal for the "Door locked" is lost during programme operation, the "DOOR UN- LOCKED" error code is immediately genrera- ted. At programme start, this error code is sup- pressed for a few seconds. If the power is on, be very careful when working on the machine. 97 1. Try to restart the machine (i.e. reset the error code) by pressing START. Error message returns No error message Temporary error in the door SERVICE PROGRAM lock or programme unit LEVEL TEMP 22°C SPEED DRAIN CLOSED EMERGENCY STOP DOOR LOCKED 2. Exit the programme using . Enter the service...
  • Page 34 Troubleshooting NTC LOW TEMP The programme unit indicates an interruption with the temperature sensor or the tempera- ture is below -5 °C. Try to restart the machine (i.e. reset the error code) by pressing START. 1. Undo the temperature sensor connections and measure the resistance of the sensor. The resistance should be as in the table below: Approximate values for a fully functional Temperature sensor temperature sensor T (°C) R (ohm) 6109 5844 5204 5592 55 5124 Resistance OK Incorrect resistance...
  • Page 35 Troubleshooting NTC HIGH TEMP The programme unit indicates a short-circuit with the temperature sensor or the tempera- ture exceeds 98°C. Try to restart the machine (i.e. reset the error code) by pressing START. 1. Undo the temperature sensor connections and measure the resistance of the sensor. The resistance should be as in the table below: Approximate values for a fully functional temperature sensor Temperature sensor T (°C) R (ohm) 6109 5844 5592 5204 55 5124 Resistance OK Incorrect resistance...
  • Page 36 Troubleshooting WATER IN DRUM Level indication The water level is higher than EMPTY at programme start. SERVICE PROGRAM First verify whether: LEVEL TEMP 22°C SPEED • the same error appears again following reset- DRAIN CLOSED EMERGENCY STOP DOOR LOCKED ting of the error code TEMPORARY PAUSE DOOR CLOSED REMOTE START IMBALANCE SERVICE •...
  • Page 37 Troubleshooting MACHINE OVERFILLED Level indication The water level is above the level for OVER- FILLED MACHINE. If this function is switched off (=N) the drain valve will open instead for a SERVICE PROGRAM LEVEL short while to drain some of the water. TEMP 22°C SPEED DRAIN CLOSED EMERGENCY STOP DOOR LOCKED TEMPORARY PAUSE DOOR CLOSED REMOTE START IMBALANCE SERVICE PHASE CHECK If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START.
  • Page 38 Troubleshooting NO HEATING The temperature has not increased the number of degrees specified in the function MIN ALLO- WABLE TEMPERATURE INCREASE (see set- tings 2) during the time that is programmed in the function MAXIMUM HEATING TIME (Confi- guration 1). If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, first make sure that: • the programme module is not incorrectly pro- grammed •...
  • Page 39 Troubleshooting NOT DRAINED The water level exceeds EMPTY at wash program start. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, first verify these items: • Is the drain is blocked by fluff or foam? • Are the the level hose and air box blocked (blow into the level hose)? •...
  • Page 40 Troubleshooting UNBALANCE SENSOR FAULT The imbalance switch is closed during program start. If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, troubleshoot as follows: Verify: • the mechanical function of the imbalance switch • the resistance between the imbalance switch and the cabling. If the error remains, there is probably an internal error in the motor controller.
  • Page 41 Troubleshooting NO MOTOR COMM. Communication between the programme unit and the motor controller has been interrupted or interfered. If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns.
  • Page 42 Troubleshooting LEVEL CALIBRATION The water level system has not been correctly calibrated. Each machine has been individually level adjusted at the factory. If the calibration values are missing or outside the limits, an error is generator at programme start. The programme can, however, be started by pressing START once more. In this case the standard values are used and the level swill not be as exact.
  • Page 43 Troubleshooting WEIGHT FROM SCALE The scale is all the time sending the actual weight to the timer. If the scale is over- or under-loaded all the time the error will be indicated. The same error will also be indicated if the weight transfered from the scale to the timer at the beginning of a water filling periode, is above a certain li- mit set in the configuration system of the machine.
  • Page 44 Troubleshooting EMERGENCY STOP The emergency stop button was pressed. If the power is on, be very careful when working on the machine. Find out the reason for the emergency stop button having been pressed. Take the necessary measures. Reset the emergency stop button by turning it counter-clockwise. Restart the machine by pressing START or...
  • Page 45 Troubleshooting DOOR LOCK The signal from the ”Door locked ” switch is present although there is no signal from the ”Door closed” switch. This error code can only be generated prior to programme start. If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START. 97 If the error returns, troubleshoot as follows: 1. Undo the card connection X5 on I/O card 1, A11 Switch cam Error message returns No error message Microswitch S Troubleshoot the door lock actuator and the cabling Lock solenoid and...
  • Page 46 Troubleshooting START NOT ALLOWED The network does not allow start of the washing programme. Try to reset the error code. If the error remains, contact the responsible person for the network and have the error fixed.
  • Page 47 Troubleshooting MIS COMMUNICATION Communication between the programme unit card A1 and the network has been interrupted. If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, troubleshoot as follows: 972 Verify that the cable between the network and X7 on programme unit card A1 is connected. If the cable is properly connected, contact the person responsible for the network.
  • Page 48 Troubleshooting INTERLOCK STATUS The motor controller does not receiving an interlock signal during programme operation. If the power is on, be very careful when working on the machine. Switch off the machine for at least 0 seconds to ensure the motor controller has been comple- tely reset. Then try to start the machine again. If the error returns, troubleshoot as follows: 1. Measure the interlock signal on the motor controller XA2:16 interlock (+24V) and XA2:22 GND.
  • Page 49 Troubleshooting IO COMMUNICATION Communication between programme unit A1 and one of the I/O cards has been interfered with or interrupted, or incorrect configuration of the I/O cards. If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START. If the error returns, troubleshoot as follows: 1. Perform a communication test using the test box. Refer to the manual ”Instructions for Clarus Communication Tests”. OK LED on test box Defective LEDs on test box Troubleshoot according to the manual ”Instructions for Clarus Communication Tests”.
  • Page 50 Troubleshooting LOW OIL LEVEL Low oil level in the oil container. Applies only to machines with oil lubrication. Fill up with oil and restart the machine. Verify for any leaks.
  • Page 51 Troubleshooting PHASE Alarm from the mains monitoring equipment. An input on I/O card 1 (X16:7-8) can be connected to external equipment that monitors received mains signals in terms of voltage levels, loss of phase, etc. If this input goes high, the error message is displayed. Find out the reason for the error indication by inspecting the mains monito- ring equipment.
  • Page 52 Troubleshooting AUT. LEVEL CALIB. The pressure sensor for the water level signals Level indication a value that is so incorrect when the machine is empty that automatic level calibration of the level system is not possible. SERVICE PROGRAM LEVEL TEMP 22°C SPEED DRAIN CLOSED EMERGENCY STOP DOOR LOCKED TEMPORARY PAUSE DOOR CLOSED REMOTE START IMBALANCE SERVICE PHASE CHECK If the power is on, be very careful when working on the machine. Try to restart the machine (i.e. reset the error code) by pressing START.
  • Page 53 Troubleshooting LEVEL NOT CALIBRATED Before the machine is used filling water controlled by the pressure sensor system, the pressure sensor system must be calibrated. The pressure sen- sor system for water filling can be calibrated in the service mode. It is possible to use the machine in weight mode, filling water on weight, without calibrating the water pressure sensor system.
  • Page 54 Troubleshooting NO SCALE CONNECTED Communication between the timer and the scale is not working. Check the wire between the timer and the scale. If still not working, please contact service.
  • Page 55 Troubleshooting OVER HEAT PM The motor controller indicates too high a temperature at the heat sink. This error code appears if the external temperature has been very high. It his has been the case, lower the temperature by e.g., ventila- tion the room. If the power is on, be very careful when working on the machine. First verify that: • the machine is not overloaded • the machine is not covered • any fan for the motor controller operates correctly • the motor controller heat sink is not blocked by dust •...
  • Page 56 Troubleshooting MOTOR OVER HEAT Measure the resistance between pins 7 and 9 The motor controller indicates the thermal pro- tector of the motor has triggered. If the power is on, be very careful when working on the machine. Contactor X, female towards motor First verify that: • the machine is not overloaded 402 A • the motor fan is working • the external temperature is very high •...
  • Page 57 Internal error in the thermal sensor of the motor controller detector. 5950 5. Switch of the wall-mounted power switch. Undo the contactor at X3 on the motor. Use an ohmmeter to measure the resistance towards the motor. Measure between 1-2, 1-3, and 2-3. Correct resistance should be: W4400H W600H W850H, W1100H cold motor 0,84 ohm 0,68 ohm 0,48 ohm hot motor 1,1 ohm 0,9 ohm 0,6 ohm Correct resistance One of the resistance values is...
  • Page 58 Then try to start the machine again. If the error returns, troubleshoot as follows: 1. Switch off the machine. Undo the contactor at X3 on the motor. Use an ohmmeter to measure the resistance towards the motor. Measure between 1-2, 1-3, and 2-3. Correct resistance should be: W4400H W600H W850H, W1100H cold motor 0,84 ohm 0,68 ohm 0,48 ohm X12 hot motor 1,1 ohm 0,9 ohm 0,6 ohm...
  • Page 59 Troubleshooting INTERLOCK The motor controller indicates an error in the interlock receiving circuit. If the power is on, be very careful when working on the machine. Switch off the machine for at least 0 seconds to ensure the motor con- troller has been completely reset. Then try to start the machine again. Fault in MCU receiving circuitry for lock acknowledgement signal. The test of the MCU-interlock circuits proceeds in the following way: Before the locking of the door lock a speed command is sent from the timer to the MCU (=0 Hz).
  • Page 60 Troubleshooting UNDER VOLTAGE The motor controller indicates the DC level is too low. If the power is on, be very careful when X11 working on the machine. Switch off the machine for at least 0 seconds to ensure the motor controller has been comple- tely reset. Then try to start the machine again. If the error returns, troubleshoot as follows: 5950 1. Verify the voltage supply (230/400 V) to the motor controller at the contactor X311.
  • Page 61 Troubleshooting OVER VOLTAGE The motor controller indicates the DC level is too high. If the power is on, be very careful when X11 working on the machine. Switch off the machine for at least 0 seconds to ensure the motor controller has been completely reset. Then try to start the machine again. If the error returns, troubleshoot as follows: 5950 1. Verify the voltage supply (230/400 V) to the motor controller at the contactor X311.
  • Page 62 Troubleshooting PHASE MISSING The DC voltage level fluctuates too much. If the power is on, be very careful when wor- king on the machine. X11 Switch off the machine for at least 0 seconds to ensure the motor controller has been completely reset. Then try to start the machine again. If the error returns, troubleshoot as follows: 5950 1. Verify the voltage supply (400 V) to the motor controller at the contactor X311.

  • Page 63: Troubleshooting The Keypad In The Display Unit

    Troubleshooting Troubleshooting the keypad in the display unit When a key is pressed on the keypad of the programme unit, two of the outputs on the keypad close. By disconnected the flat cable from the display card, pressing a key and the measuring the resistance between the outputs that should close, it is possible to determine correct operation of any one key.

  • Page 65: Control Unit

    Control unit Control unit A11-1 I/O-board Control unit, door lock Card for tilting functions (option) Level control, safety monitoring for control unit, door lock B41, 42 Pressure guard for tilting Level control, overfilling E20, M20 Oil lubrication F11, F12 Fuses, 1.25 AT, protection of 20 V power supply to I/O board, CPU board, display unit and control unit, door lock Motor interlock Motor fan relay...
  • Page 66 Control unit X149 X148 X146 X145 � � � � � � � � � � � � � � � � � �������� �� � � � � � � � � � �� � � � � � � �...
  • Page 67 Control unit X110 1 2 3 4 1 2 3 4 8 9 10111213 1 2 3 4 8 9 10 1 2 3 4 1 2 3 4 8 9 10111213 1 2 3 4 8 9 10 1 2 3 4 8 9 10111213 1 2 3 4 1 2 3 4...
  • Page 68 Control unit Connectors X100 Connector, 7 pole, CPU board X101 Connector, 14 pole, door lock X102 Connector, 14 pole, control unit and sensor(s) for tilt function (optional equipment) X10 Connector, 4 pole, speed sensor on motor X104 Connector, 4 pole, unbalance X105 Connector, 14 pole, water supply X106...

  • Page 69: Clarus Control Unit

    Control unit Clarus control unit A200-1 CPU circuit board X200 Connector, 7 pole, operator unit X201 Connector, 4 pole, sensor(s) thermostat A200- Card reader A200-2 Display circuit board Connection terminals X202 Connector, 4 pole, weighing equipment DMIS/CMIS (optional equipment) 4660...

  • Page 70: Program Control Unit

    Control unit Program control unit This chapter describes the components which are specific to this washer extractor. For a general description of the CPU board, display board and I/ O board(s), consult the service manual for the Clarus Program Control Unit. System structure CPU board The machine's wash programs are stored in the CPU board memory.
  • Page 71 Control unit Feed, -phase system voltage Display unit Motor control unit Motor Speed detector CPU board Control unit, door lock Level sensing Temperature sensing Level sensing System voltage Door lock Emergency stop I/O board 1 ± 12V Outputs and inputs to and from various washer extractor func- tions I/O board 2...

  • Page 73: Programme Unit

    Programme unit • I/O cards A11 and A12 The I/O cards are controlled by the CPU card via a serial interface. The I/O cards feature outputs, which, via the communication cards in the rear electric box, control various machine functions, such as the wa- ter valves, heater connection and drain valve. On the input connection blocks, it is possible to connect signals for control of e.g.

  • Page 74: Function

    Programme unit Function CPU card A1 The CPU card controls all functions of the washing machine using various control programmes in the CPU card memory. The CPU card communi- cates with the I/O card, display card and motor controller using a serial interface. The following functions are controlled: •...
  • Page 75 Programme unit The two pins in switch X7 are shorted to confirm changes made in Configuration 1 and 2. (Not for FOM71 CLS). Pushbutton SW1: used as an acknow- P1, P2 Used for factory ledgement button when in the Service calibration of the pres- programme mode (the same function sure sensor.

  • Page 76: Display Card A2

    Programme unit Display card A2 The display card communicates with the CPU card through a serial interface. The CPU card informs what should be displayed in the display window and the display card converts these messages to information that controls the alphanumeric display window. The display card also detects which buttons are pressed on the con- trol panel and sends these signals to the CPU card.

  • Page 77: I/O Cards

    Programme unit I/O cards The I/O cards are controlled by the CPU card and communicate via a serial interface. Depending on the need for inputs and outputs, one programme unit may have one or two I/O cards. All inputs and outputs are switched from the I/O card to the various functions via the communication cards in the rear electric module.
  • Page 78 Programme unit Input and outputs on I/O cards 1 and 2 Card switch I/O-card 1 A11 I/O-card 2 A12 Serial interface and voltage supply X1: 1- Serial interface to card 2 16 V+ supply to card 2 0 V– supply to card 2 X2: 1 0 V– supply to CPU 12 V- from card 1 16 V+ supply to CPU 12 V+ supply from card 1 Serial interface to CPU...
  • Page 79 Programme unit Outputs on I/O cards I/O-card I/O-card 1 A11 Connection block No. Switch No. Function Outputs X4: 1 Neutral Door lock relay, phase (normally open) Neutral Door lock relay, phase (normally open) X7: 1 Drain 1 (Y1), phase (normally open) Common neutral Drain 1 (D1), phase (normally closed) X8: 1 Heater relay (K21) Neutral...
  • Page 80 Programme unit Outputs on I/O card 1 and 2 I/O-card I/O-card 2 A12 Connection block No. Switch No. Function Outputs X4: 1 Flashlight, phase X7: 1 Cold, hard water (Y5)/Flushing detergent dispenser N (neutral) X8: 1 Neutral X9: 1 Inlet C (Y65) Inlet B (Y55) Inlet A (Y45) Drain C (Y4) Drain B (Y) Drain A (Y2)
  • Page 81 Programme unit I/O-card I/O-card 1 A11 Connection block No. Opto-coupler Function Inputs X5: 1 Door lock micro-switch S4/N, Com Door lock micro-switch S4/N, No Door lock position micro-switch S/N Door lock micro-switch S4/Phase X15:1 External start/stop signal, phase External start/stop signal, neutral External pause signal, phase External pause signal, neutral X16:1-2...
  • Page 82 Programme unit I/O-card I/O-card 2 A12 Connection block No. Opto-coupler Function Inputs X5: 1 X15:1 X16:1-2 I/O-card I/O-card  A1 Connection block No. Opto-coupler Function Inputs X5: 1 Neutral S44A No Neutral S44A COM Neutral S44A COM Neutral (COM) Phase Phase S44B/COM X15: 1 Neutral Phase K41 COM...

  • Page 83: Control System Transformer T10

    Programme unit Control system transformer T10 The control system transformer is used to provide the voltage feed for the CPU board, I/O boards and display board. The transformer supplies 12 V on its secondary side, and can be adapted to suit any of four different primary voltages by moving a bridge. The transformer should normally be connected for a primary voltage of 20 V.

  • Page 84: The Service Program

    Programme unit The service program The service programme facilitates troubleshooting on the machine by enabling control of all machine functions. Input signals to the various I/O cards that are active are also indicated. The following functions can be controlled: COLD WATER LOW EXTRACT HOT WATER MEDIUM EXTRACT COLD HARD WATER HIGH EXTRACT TANK 1 WATER TURBO EXTRACT...

  • Page 85: To Select The "Service Program" Function

    Programme unit To select the ”Service Program” function The service program The service program makes fault-finding on the machine easier, as it allows you to control the vari- ous machine functions individually: If this menu is not currently displayed: • water filling RUN A WASH PROGRAM Press repeatedly. GO TO THE MENU •...
  • Page 86 Programme unit Prevention of unauthorised access A button on the CPU circuit board has to be press- sed to gain access to the service program, to PRESS BUTTON ON Press the button on the prevent its unauthorised or inadvertent use. The CPU BOARD CPU circuit board. CPU circuit board is located behind the control panel.

  • Page 87: To Control The Machine Functions

    Programme unit To control the machine functions SERVICE PROGRAM LEVEL TEMP 22°C SPEED DRAIN CLOSED 01 COLD WATER 02 HOT WATER 0 COLD HARD WATER 04 TANK 1 WATER 05 TANK 2 WATER 06 TANK  WATER To activate the various 01 COLD WATER machine functions: 02 HOT WATER 0 COLD HARD WATER Use or to highlight...

  • Page 88: I/O Card Inputs

    Programme unit I/O card inputs Press 1. Now you can check the SERVICE PROGRAM various input signals from I/O LEVEL TEMP 22°C SPEED board 1. DRAIN CLOSED EMERGENCY STOP DOOR LOCKED TEMPORARY PAUSE DOOR CLOSED REMOTE START UNBALANCE A black square in front of the SERVICE PHASE CHECK name indicates that the input...

  • Page 89: Settings 1

    Programme unit Settings 1 In the Configuration 1 mode, the variables can be changed without requesting a special password from the supplier: ADJUST TIME ALLOWED LEVEL HIGH MIDDEL TEMPERATURE COOL-DOWN ADJUST TEMPERATURE ALLOWED DEFAULT MOTOR ON TIME RAPID ADVANCE ALLOWED SHOW WEIGHT ALLOWED DEFAULT MOTOR OFF TIME FLUSH DELAY TIME WATER REDUCTION NOT ALLOWED...

  • Page 90: To Select The "Settings 1" Function

    Programme unit To select the ”SETTINGS 1” function If this menu is not currently RUN A WASH PROGRAM displayed: GO TO THE MENU Press repeatedly. MAKE YOUR CHOICE WITH AND PRESS SELECT WEIGHT, KG 000,0 SELECT Press to highlight ”GO TO THE MENU”. RUN A WASH PROGRAM GO TO THE MENU SELECT Press SELECT. MENU MAKE A CHOICE: WASH PROGRAM LIBRARY PROGRAMMING MODE SETTINGS 1 MEMORY CARD...

  • Page 91: Password

    Programme unit Password Password protection or not? It is for you to decide whether or not the functions To open the function without a password SETTINGS 1 and PROGRAMMING will be pass- word-protected. Please note that if you do decide to implement password protection for either of SETTINGS 1 them, then access to both these functions will be by means of the same password.
  • Page 92 Programme unit To change the password SETTINGS 1 PLEASE ENTER YOUR PASSWORD: ENTER NEW PASSWORD: Enter your four-digit pass- word. Once the correct password has been entered, the display will show and SELECT. Press . Enter the new four-digit password. SELECT Press SELECT. To remove the password protection SETTINGS 1 PLEASE ENTER YOUR PASSWORD: ENTER NEW PASSWORD: SELECT Enter your four-digit pass- word.

  • Page 93: Variables Under "Settings 1

    Programme unit Variables under ”SETTINGS 1” When the top line of a menu SETTINGS 1 is highlighted you have the option of scrolling down ADJUST TIME ALLOWED ADJUST TEMPERATURE ALLOWED through the menu faster by RAPID ADVANCE ALLOWED MANUAL FUNCTIONS ALLOWED pressing . When you PAUSE ALLOWED FREE TEXT ALLOWED do, the next portion of the menu is displayed, with its...
  • Page 94 Programme unit Altering ”step time” allowed ADJUST TIME ALLOWED Here you determine if manual adjustment of the ADJUST TEMPERATURE ALLOWED remaining ”step time” (by using to move to RAPID ADVANCE ALLOWED the line for ”STEP TIME” then entering a new time) SHOW WEIGHT ALLOWED will be allowed. WATER REDUCTION NOT ALLOWED MANUAL FUNCTIONS ALLOWED 991 NORMAL 95°C...
  • Page 95 Programme unit Rapid advance allowed ADJUST TIME ALLOWED Here you determine whether it is allowed to use ADJUST TEMPERATURE ALLOWED rapid advance forwards or backwards through the RAPID ADVANCE ALLOWED wash program during program operation. SHOW WEIGHT ALLOWED WATER REDUCTION NOT ALLOWED 991 NORMAL 95°C STD MANUAL FUNCTIONS ALLOWED PROGRAM STEP: MAIN WASH STEP TIME:...
  • Page 96 Programme unit For machines with weight measurement installed only! Water reduction not allowed ADJUST TIME ALLOWED If the weight measurement function is installed, ADJUST TEMPERATURE ALLOWED the water level will be reduced automatically if the RAPID ADVANCE ALLOWED machine does not have a full load. SHOW WEIGHT ALLOWED Here you determine whether it will be possible to WATER REDUCTION NOT ALLOWED switch off the water level reduction during a wash MANUAL FUNCTIONS ALLOWED...
  • Page 97 Programme unit ADJUST TIME ALLOWED ADJUST TEMPERATURE ALLOWED Pause allowed RAPID ADVANCE ALLOWED Here you determine whether it is allowed to use SHOW WEIGHT ALLOWED the pause function during the wash program. This WATER REDUCTION NOT ALLOWED function will not work until the second time the MANUAL FUNCTIONS ALLOWED program is run.
  • Page 98 Programme unit Changing wash program allowed ADJUST TIME ALLOWED ADJUST TEMPERATURE ALLOWED Here you determine whether it is allowed to chan- RAPID ADVANCE ALLOWED ge to a different wash program during program SHOW WEIGHT ALLOWED operation. WATER REDUCTION NOT ALLOWED MANUAL FUNCTIONS ALLOWED 991 NORMAL 95°C STD PAUSE ALLOWED PROGRAM STEP: MAIN WASH FREE TEXT ALLOWED...
  • Page 99 Programme unit Altering extraction speed allowed RAPID ADVANCE ALLOWED SHOW WEIGHT ALLOWED Here you determine whether it is allowed to alter the WATER REDUCTION NOT ALLOWED extraction speed during the current extraction se- MANUAL FUNCTIONS ALLOWED quence by using to move to the DRUM SPEED PAUSE ALLOWED line and entering a new value.
  • Page 100 Programme unit MANUAL FUNCTIONS ALLOWED Display actual temperature FREE TEXT ALLOWED Here you determine whether the actual water tempe- CHANGE WASH PROGRAM ALLOWED rature will be displayed during the program. AUTO RESTART ALLOWED ADJUST SPIN SPEED ALLOWED. DISPLAY REMAINING TIME 991 NORMAL 95°C STD DISPLAY ACTUAL TEMPERATURE PROGRAM STEP: MAIN WASH DISPLAY ACTUAL SPEED...
  • Page 101 Programme unit Machine not heated Here you determine if the machine is to heat the water to the required temperature before the time CHANGE WASH PROGRAM ALLOWED the wash sequence starts, or if the wash time of AUTO RESTART ALLOWED the sequence is to begin directly after water filling. ADJUST SPIN SPEED ALLOWED.
  • Page 102 Programme unit ADJUST SPIN SPEED ALLOWED. DISPLAY REMAINING TIME DISPLAY ACTUAL TEMPERATURE Temperature in °C DISPLAY ACTUAL SPEED Here you determine if all temperatures are to be MACHINE NOT HEATED shown in °C or °F. TEMPERATURE CONTROL OF WATER If you answer Yes (Y): TEMPERATURE IN °C All temperatures will be shown in °C.
  • Page 103 Programme unit DISPLAY ACTUAL TEMPERATURE DISPLAY ACTUAL SPEED MACHINE NOT HEATED No access to standard programs TEMPERATURE CONTROL OF WATER Here you determine whether the user will have ac- TEMPERATURE IN °C cess to the machine’s standard programs (numbe- REPEAT PROGR. MODE QUESTION red 991-999) or not. LOCKED STANDARD WASH PROGRAMS N If you answer Yes (Y): LEVEL QUICK COOL-DOWN...
  • Page 104 Programme unit MACHINE NOT HEATED TEMPERATURE CONTROL OF WATER TEMPERATURE IN °C Water level after unbalance halt REPEAT PROGR. MODE QUESTION Here you determine the water level to which LOCKED STANDARD WASH PROGRAMS N the machine fills after a halt in extraction due to LEVEL QUICK COOL-DOWN unbalance.
  • Page 105 Programme unit Middle temperature cool-down Here you determine the middle temperature for LEVEL QUICK COOL-DOWN cool-down. LEVEL UNBALANCE LEVEL LOW When creating a new wash program you can, to LEVEL MEDIUM prevent creasing of the load, use the COOL-DOWN LEVEL HIGH module to achieve controlled cool-down of the wa- ter in the drum.
  • Page 106 Programme unit LEVEL UNBALANCE LEVEL LOW LEVEL MEDIUM LEVEL HIGH MIDDLE TEMPERATURE COOL-DOWN 70 °C DEFAULT MOTOR ON TIME 0:12 Flush times DEFAULT MOTOR OFF TIME 0:0 Here you determine times relating to flushing clean FLUSH DELAY TIME 0:06 the supply lines of an external system for liquid FLUSH ON TIME 0:10 detergent: the delay time and the length of time...
  • Page 107 Programme unit Maximum filling time BUZZER ON BUTTON MAX FILLING TIME 10:00 Here you determine the maximum time to be al- MAX HEATING TIME 10:00 lowed for filling the machine with water to the level SHOW WEIGHT TIMEOUT 0:20 set. PC5 BLOCKING OF HEATING If the correct level has not been reached within this PC5 BLOCKING OF SPINNING time, the error message ”NO WATER”...
  • Page 108 Programme unit Show weight timeout BUZZER ON BUTTON Here you determine the length of time the weight MAX FILLING TIME 10:00 will be displayed, before the normal display is MAX HEATING TIME 10:00 restored. SHOW WEIGHT TIMEOUT 0:20 PC5 BLOCKING OF HEATING �������������� PC5 BLOCKING OF SPINNING �����������...
  • Page 109 Programme unit BUZZER ON BUTTON MAX FILLING TIME 10:00 MAX HEATING TIME 10:00 SHOW WEIGHT TIMEOUT 0:20 Relay for steam as standard PC5 BLOCKING OF HEATING PC5 BLOCKING OF SPINNING Here you decide if the machine should heat with HEAT 2 AS STANDARD steam or el. Yes (Y) the machine will heat with SERVICE ALARM HOURS steam (standard) and No (N) the machine will heat BUZZER TIMEOUT AT END...
  • Page 110 Programme unit Buzzer length at programme end Here you determine for how long the buzzer should sound at the end of the programme unless BUZZER TIMEOUT AT END 0:20 it is not turned off manually. When programming the main data for a washing programme, it is possible to select whether or not to sound the buzzer at the programme end.
  • Page 111 Programme unit Password active Here you determine whether or not to set a pass- PASSWORD ACTIVE word according to the explanations. CMIS address Here you can give the machine a unique address CMIS ADDRESS when connected to the CMIS system. 0 = inactive Allowed values = 1-127. Level in mm active Y(es) = Pressure sensor system for water LEVEL IN MM ACTIVE...
  • Page 112 Programme unit Start slow filling, hg When filling on weight, detergent valve  will be START SLOW FILLING, HG used to finalize the washer filling. Detergent valve  will be opened given value before the final level is reached. Offset level, hg Gives value will be subtracted from programing OFFSET LEVEL, HG water level before water filling starts.
  • Page 113 Programme unit To conclude making changes in variables Prevention of unauthorised access under ”SETTINGS 1” A button on the CPU circuit board has to be press- sed to gain access to the service program, to prevent its unauthorised or inadvertent use. The CPU circuit board is located behind the control SETTINGS 1 panel.
  • Page 114 Programme unit Settings 2 In Configuration 2, there are variables that, in case of carelessness or lack of knowledge, may affect the safety systems or operating safety of the machine. Because of this, these variables are protected by a code system. Each time a variable needs to be changed, it is neces- sary to obtain a new code from the manufacturer.

  • Page 115: Settings 2

    Programme unit To select the ”SETTINGS 2” function If this menu is not currently RUN A WASH PROGRAM displayed: GO TO THE MENU Press repeatedly. MAKE YOUR COICHE WITH AND PRESS SELECT WEIGHT, KG 000,0 SELECT Press to highlight ”GO TO THE MENU”. RUN A WASH PROGRAM GO TO THE MENU SELECT Press SELECT. MENU MAKE A CHOICE: WASH PROGRAM LIBRARY PROGRAMMING MODE SETTINGS 1 MEMORY CARD...

  • Page 116: Variables Under "Settings 1

    Programme unit Variables under "SETTINGS 2" SETTINGS 2 When the top line of a menu HEATING RELAY ON WHEN NOT HEATED TEMPERATURE INCREASE ALLOWED is highlighted you have the LEVEL EMPTY option of scrolling down LEVEL OVERFILL PAUSE TEST LEVEL PAUSE TEST TEMPERATURE -18°C through the menu faster by pressing .
  • Page 117 Programme unit Heating relay on HEATING RELAY ON IF NOT HEATED Here you determine whether the heating relay will TEMPERATURE INCREASE ALLOWED switch on when heating begins. LEVEL EMPTY Note that the heating relay switches on even if the LEVEL OVERFILL answer ”Yes” is in place for the function ”MACHI- PAUSE TEST LEVEL NE NOT HEATED”...
  • Page 118 Programme unit Level empty HEATING RELAY ON IF NOT HEATED Here you determine the water level at which the TEMPERATURE INCREASE ALLOWED drum will be regarded as empty. LEVEL EMPTY It is advisable to set this level so that the inner LEVEL OVERFILL drum will have emptied, but so that some water PAUSE TEST LEVEL remains in the outer drum.
  • Page 119 Programme unit Test values for pause HEATING RELAY ON IF NOT HEATED Here you determine whether, and if relevant, the TEMPERATURE INCREASE ALLOWED conditions under which it will be allowed for the LEVEL EMPTY user to open the door during a wash program, for LEVEL OVERFILL example to take samples of the water.
  • Page 120 Programme unit HEATING RELAY ON IF NOT HEATED Temperature step in cool-down TEMPERATURE INCREASE ALLOWED Here you determine the maximum reduction in LEVEL EMPTY temperature per minute during the first stage of LEVEL OVERFILL cool-down. PAUSE TEST LEVEL How does cool-down work? PAUSE TEST TEMPERATURE -18 °C When creating a new wash program you can, DEFAULT TEMPERATURE HYSTERIS 4 °C...
  • Page 121 Programme unit PAUSE TEST LEVEL PAUSE TEST TEMPERATURE -18 °C DEFAULT TEMPERATURE HYSTERIS 4 °C TEMPERATURE STEP IN COOL-DOWN 4 °C DEFAULT LOW EXTRACT TIME 00:00 DEFAULT MEDIUM EXTRACT TIME 00:00 Default values for re-start after unbalance DEFAULT HIGH EXTRACT TIME 00:00 Here you determine the drain time and distribu- DEFAULT DRAIN TIME 00:00 tion time the machine will use if it cannot find the...
  • Page 122 Programme unit Drain open delay Here you determine whether you want a delay be- fore the drain valve opens, for example if you want the drum to have time to gather speed first, before the valve opens. TEMPERATURE STEP IN COOL-DOWN 4 °C The drain module DEFAULT LOW EXTRACT TIME 00:10...
  • Page 123 Programme unit Rollout time Here you determine whether you want a time delay after each extraction before the machine starts to fill with water, to give the motor time to slow down. This function is useful if the motor is not a frequen- cy-controlled one.
  • Page 124 Programme unit DEFAULT HIGH EXTRACT TIME 00:20 DEFAULT DRAIN TIME 00:40 DEFAULT DISTR. TIME 00:0 DO UNBALANCE MEASUREMENT DRAIN OPEN DELAY 0:1 START EXTRACT TIME 00:0 Pay per wash ROLLOUT TIME 00:01 This question is for special installations with pay PAY PER WASH ALARM systems. How to use it is described in the docu- LOCK TEST DELAY 0:10 mentation supplied with these systems.
  • Page 125 Programme unit DO UNBALANCE MEASUREMENT Lock test delay DRAIN OPEN DELAY 0:1 Here you determine the length of time between START EXTRACT TIME 00:0 when the door is locked and when the check ROLLOUT TIME 00:01 should be made of the lock’s microswitch. PAY PER WASH ALARM LOCK TEST DELAY 0:10...
  • Page 126 Programme unit Time drain to open after over-filling DRAIN OPEN DELAY 0:1 Here you determine how long the drain valve START EXTRACT TIME 00:0 should open for if the machine has over-filled, ROLLOUT TIME 00:01 provided you ensure that the parameter (response) PAY PER WASH ALARM stored for the function ERROR OVER-FILLED is LOCK TEST DELAY 0:10...
  • Page 127 Programme unit PAY PER WASH ALARM LOCK TEST DELAY 0:10 DRAIN TIME WHEN OVERFILL 0:05 OIL LUBRICATION HOURS PULSE TIME OIL LUBR. SEC 0:01 Oil lubrication AMOUNT OF I/O MODULES (1-) Here you determine the lubrication interval and DELAY CLEAR DOOR TEXT 04:00 pulse time for the oil lubrication systems used on MAX DRAIN TIME 4:00 larger washer extractors.
  • Page 128 Programme unit DRAIN TIME WHEN OVERFILL 0:05 Delay clear door text OIL LUBRICATION HOURS Here you determine how long the text ”WAITING PULSE TIME OIL LUBR. SEC 0:01 FOR DOOR TO UNLOCK” will remain visible if, for AMOUNT OF I/O MODULES (1-) some reason, the door is not unlocked at the right DELAY CLEAR DOOR TEXT 04:00 time.
  • Page 129 Programme unit Timeout during pause OIL LUBRICATION HOURS PULSE TIME OIL LUBR. SEC 0:01 Here you determine the maximum time for a AMOUNT OF I/O MODULES (1-) pause in the program, if it is to be available for use in calculating the average length of the program. DELAY CLEAR DOOR TEXT 04:00 MAX DRAIN TIME...
  • Page 130 Programme unit AMOUNT OF I/O MODULES (1-) Door open delay for ”motor lost” DELAY CLEAR DOOR TEXT 04:00 Here you determine the length of time during MAX DRAIN TIME 4:00 which the door will be prevented from opening TIMEOUT DURING PAUSE 1:00 if, (in machines with frequency control) the MCU MINIMUM TEMPERATURE INCREASE 5°C loses control of braking at the end of extraction.
  • Page 131 Programme unit List of errors, functions monitored and relevant error messages displayed, cont. Error/Function Error message displayed ERROR. ERROR CODES FROM MOTOR This function includes a number of error warnings from the motor control system for frequency-controlled motors (EWD) 1 Temperature of MCU control circuits too high HEAT SINK TOO HOT 2 Motor thermal protection has tripped MOTOR TOO HOT  The motor has received a start command from the PCU without receiving an interlock signal from the door lock.
  • Page 132 Programme unit ERROR, EWD INTERLOCK ERROR, I/O COMMUNICATION ERROR, LOW OIL LEVEL ERROR, LOW OR HIGH VOLTAGE ERROR, ERROR CODES FROM MOTOR ERROR, PRESS SENSOR TILT Time delay before door opening ERROR, PRESSURE SENSOR TIMEOUT Here you determine the length of time during which ERROR, DOOR SWITCH TILT the door will be prevented from opening if the ERROR, LEVEL OFFSET machine has detected a fault-error and is dis-...
  • Page 133 Programme unit Upper limit for manual temperature ERROR, I/O COMMUNICATION adjustment (”Max adjust temperature”) ERROR, LOW OIL LEVEL Here you determine the highest temperature the ERROR, LOW OR HIGH VOLTAGE user may alter the wash temperature to manually ERROR, ERROR CODES FROM MOTOR (by using to move to the line for ”SET TEM- ERROR, PRESS SENSOR TILT PERATURE”...
  • Page 134 Programme unit ERROR, PRESS SENSOR TILT ERROR, PRESSURE SENSOR TIMEOUT ERROR, DOOR SWITCH TILT ERROR, LEVEL OFFSET ERROR, LEVEL SYSTEM NOT CALIB. TIME DELAY BEFORE DOOR OPENING 0:0 UPPER TEMPERATURE FOR ERROR 98°C LOWER TEMPERATURE FOR ERROR -9°C Default wash speed MAX ADJUST TEMPERATURE 97°C Here you determine the wash speed the machine MAXIMUM EXTRACT SPEED...
  • Page 135 Programme unit TIME DELAY BEFORE DOOR OPENING 0:0 UPPER TEMPERATURE FOR ERROR 98°C Default value, extraction time LOWER TEMPERATURE FOR ERROR -9°C Here you determine the various speeds (low, me- MAX ADJUST TEMPERATURE 97°C dium and high) for extraction. The instructions for MAXIMUM EXTRACT SPEED 1200 determining the length of extraction times are to DEFAULT WASH SPEED...
  • Page 136 Programme unit START EXTRACT SPEED 1000 Default wash acceleration DEFAULT WASH ACCELERATION Here you determine the acceleration rate (rpm/se- DISTRIBUTION ACCELERATION cond) which the machine can use to reach wash RETARDATION ACCELERATION speed when it cannot find this value elsewhere, EXTRACT ACCELERATION e.g. in the event of manual operation of the drain START EXTRACT ACCELERATION sequence in machines with suspended drum.
  • Page 137 Programme unit START EXTRACT SPEED 1000 DEFAULT WASH ACCELERATION Extraction acceleration DISTRIBUTION ACCELERATION RETARDATION ACCELERATION Here you determine the acceleration rate (rpm/ EXTRACT ACCELERATION second) the machine will use to reach extraction speed. This value is not programmable when START EXTRACT ACCELERATION you create a wash program. Instead the machine EXTRACT RETARDATION always uses the value you set here.
  • Page 138 Programme unit START EXTRACT SPEED 1000 DEFAULT WASH ACCELERATION DISTRIBUTION ACCELERATION RETARDATION ACCELERATION Extract retardation (i.e. Deceleration rate EXTRACT ACCELERATION after extraction) START EXTRACT ACCELERATION Here you determine the deceleration rate (rpm/ EXTRACT RETARDATION second) at which the drum will slow down after MAX SPEED DURING FILLING extraction speed.
  • Page 139 Programme unit START EXTRACT SPEED 1000 DEFAULT WASH ACCELERATION DISTRIBUTION ACCELERATION RETERDATION ACCELERATION EXTRACT ACCELERATION START EXTRACT ACCELERATION EXTRACT RETARDATION MAX SPEED DURING FILLING Max level offs. for aut. calib. MAX LEVEL OFFS. FOR AUT. CALIB. Maximum level in SKD for automatic calibration. TIME AT DISTRIBUTION SPEED 2 NUMBER OF REDIST LOW 1 UNB. NUMBER OF REDIST LOW 2 UNB.
  • Page 140 Programme unit NUMBER OF REDIST LOW 1 UNB. NUMBER OF REDIST LOW 2 UNB. NUMBER OF REDIST MEDIUM UNB. NUMBER OF REDIST HIGH UNB. NUMBER OF REDIST EXTREME UNB. Drain time at progr. end DRAIN TIME AT PROGR. START Drain time at program end after that the level is DRAIN TIME AT PROGR. END below level empty.
  • Page 141 Programme unit To conclude making changes in variables Prevention of unauthorised access under ”SETTINGS 2” A button on the CPU circuit board has to be press- sed to gain access to the service program, to prevent its unauthorised or inadvertent use. The CPU circuit board is located behind the control SETTINGS 2 panel.

  • Page 142: To Replace The Cpu Board

    Programme unit To replace the CPU board If the CPU board is faulty and has to be replaced, the correct software for the particular washer extractor will have to be downloaded onto the new CPU board. For this you need: 1. A new CPU circuit board. 2.
  • Page 143 Programme unit 6. Switch off the machine’s main power switch. Install the new CPU board and connect all the PCB connectors. Connect the correct cable between the computer (COM1 port) and the interface connector X7 on the CPU board. Switch the machine’s main power switch back on.

  • Page 144: To Replace An I/O Board

    Programme unit To replace an I/O board The procedure described here is for machi- nes with more than one I/O board. On 5 4  machines with only one I/O board, that board can be replaced without any need for this procedure. If there is more than one I/O circuit board, the processor must know whether the new circuit CPU circuit board board is I/O board 1, I/O board 2 or I/O board . For this programming you need: 1.
  • Page 145 Programme unit 5. Start “CMM G000”. 6. A menu where various service interventions Pushbutton for can be made is displayed. programming 7. Click "Service". 8. "Service menu" is shown. 9. Click I/O-board address. 10. Click I/O-board to be configured. Press the button on I/O board 1. A confirmation will be shown on the PC- screen.

  • Page 147: Imbalance Switch

    Imbalance switch Imbalance switch (emergency switch) Note! Imbalance detection is primarily done in the motor control. Description The imbalance switch is a safety feature which protects the machine from damage during ex- traction caused by uneven distribution of the Sensor wash load. Switch arm Microswitch The imbalance switch consists of a microswitch and a switch arm mounted on the outer frame, plus a sensor mounted on the inner frame.

  • Page 148: Instructions For Repair

    Imbalance switch Instructions for repair Checking imbalance switch adjustment • Check, when the machine is empty, that the switch arm for the micros- witch is located in the centre of the sensor. If necessary adjust as follows: - release the screws securing the sensor and move the sensor sideways.

  • Page 149: Door And Door Lock

    Door and door lock Description General Switch cam Microswitch S The door lock part consists of the following: • Door lock A41 that contains Lock solenoid and microswitch S4 - an actuator that locks the door lock and which also has two built-in micro switches, S4a and S4b. The actuator is bi-stable, i.e., it has two stable positions: locked door and unlocked door.

  • Page 150: Door Lock Function

    Door and door lock Door lock function The door is locked by means of an electrome- I/O board 1 chanical, bistable locking device. The lock has two stable states; one when the lock pin which Phase to I/O outputs locks the door handle is extended (the door Closed door status lock is locked), the other when the lock pin is re- indication...

  • Page 151: The Door Lock Locks The Door

    Door and door lock The door lock locks the door When the door is closed (closed door lock switch S), the programme unit may request door locking by applying a voltage of 200- 240 V on door lock controller A1 input X92. Programme unit The following check is made by the A1 card prior to locking of the door: Door lock control A1...

  • Page 152: The Door Lock Unlocks The Door

    Door and door lock The door lock unlocks the door The programme unit requests door unlocking by applying 0 V on input X92 of the door lock controller. Programme unit The following check is made prior to unlocking of the door: Door lock • No water in drum - input X9 from level gu- I/O card 1 control A1 ard B2 is closed = 0 V...

  • Page 153: Error Codes

    Door and door lock Error codes The door lock control has three LEDs that show whether the door lock operates normally or Resetbutton whether an error has been detected. During normal operation, the LEDs blink when the drum is not turning and are off when the drum rotates. In case of an error, the three LEDs will show the error condition according to the table below.

  • Page 154: Reset Button

    Door and door lock Reset button The door lock control features a reset button used to reset the programme routines stored in Door lock control A1 the computer. When pressed, any error codes 200- are erased; 240 V Voltage Door lock control inputs/outputs supply to A1 X90: AC 200-240 V feed Level guard X91: Transfer of voltage supply Feeds the voltage to programme unit A1.
  • Page 155 Door and door lock X93: Input from level guard If the input indicates “Water in drum” when the door is not locked, the door cannot be locked. Door lock control A The LEDs then show the error code ● ● ❍. 200- 240 V Input voltage Function 5 V DC: Water in drum (level guard open) Voltage...
  • Page 156 Door and door lock X95: Input from rotation sensor on motor shaft When the motor is operating, a pulse train is applied on the input. Door lock control A1 Rotation sensor Input Function Pin 1: DC 4-10 V feed Pin 2: Pin : DC 4-10 V pulse input Frequency > 0.4 Hz: drum is rotating Unlocks + Frequency <...

  • Page 157: Motor

    Motor Warnings DANGER Be careful when measuring the electric components in the motor control. All components have a potential difference of approx. 300 V in relation to protective earth and neutral. When the red LED on the motor control card is lit, the components carry dangerous voltages. The motor control lose all voltage about 10-30 seconds after the voltage has been disconnected and the motor has stopped.

  • Page 158: Description

    The motor winding is protected against overlo- ads using a thermal overheating protector that is automatically reset. 6058 W4400H, W3600H 10258 OP ������...

  • Page 159: Motor Control

    The cable harness is directly connected to the motor control, voltage supply input and the voltage supply to the motor using connectors. W3600H, W3850H, W31100H W4400H 1 2 3 4 1 2 3 4 8 9 10111213 1 2 3 4...

  • Page 160: Function

    Motor Function DANGER Be careful when measuring the electric components in the motor control. All components have a potential difference of approx. 300 V in relation to protective earth and neutral. When the green LED on the motor control card is lit, the compo- nents carry dangerous voltages. The motor control lose all voltage about 10-30 seconds after the voltage has been disconnected and the motor has stopped. The motor control communicates with the programme unit via a serial two- way interface. With the help of the motor control, the programme unit can control not only the instantaneous motor rpm, but also with high precision the acceleration and retardation of the motor in order to reach the target rpm.
  • Page 161 Motor The motor control is also able to deliver various instantaneous and output values during constant speed, acceleration and retardation. These values are used to calculate the weight of the loaded laundry and to detect any load imbalances. A separate imbalance breaker can also be connected to the motor control.

  • Page 162: Belt Tension

    Motor Belt tension The belt tension of new machines is preset at the factory. W4400H W600H W850H W1100H 15 mm 10 mm 2 mm 2 mm To check the belt tension, or to reset it after repla- cing components which affect the tension, follow the instructions in the illustrations.

  • Page 163: Drain Valve

    Drain valve Drain valve Description The drain valve uses compressed air to close. A control valve opens and supplies pressure to a piston located beneath the rubber diaphragm of the drain valve. Fault-finding May only be carried out by authorized per- sonnel. The drain valve will not close Check that: •...

  • Page 165: Detergent Dispenser

    Detergent dispenser Detergent dispenser The detergent dispenser has five compartments. Each compartment is connected to a water valve and can be flushed with hot or cold water. There is also a separate cleaning (water flushing) function for all compart- ments in the detergent dispenser, connected to cold water. If the water pressure is low (<1 bar) the cleaning effect may be less satis- factory.

  • Page 167: Tilt Function (Optional Equipment)

    Tilt function (Optional equipment) Tilt function Installation Remove the machine’s side panels, lower front panel and rear covers. 449 For machines with tilt both forwards and back- wards: Insert the two cylinder units from the side of the machine underneath the machine frame. If there is vinyl floor-covering on the floor: To protect the floor from wear, a sheet of stain- less steel should be laid beneath each cylinder Cylinder units...
  • Page 168 Tilt function (Optional equipment) Secure the cylinder units using four bolts and nuts. It is important to fit four washers (each 5 mm thick) between each cylinder unit and the machine frame (see illustration). 4 washers 4 washers 45 Fit the four corner posts, one for each corner of the machine, using the bolts which secure the machine feet to the floor. Adjust the clearance between the upper part of each corner post and the machine so it is 14 mm.
  • Page 169 Tilt function (Optional equipment) For machines with tilt both forwards and back- wards: The compressed air lines which are to be con- nected to the air bellows and position sensors are supplied bundled on the machine rear. Connect the lines to the air bellows and pressure sensors according to the table below.
  • Page 170 Tilt function (Optional equipment) For machines with forward tilt only: The compressed air line to be connected to the air bellows is supplied bundled on the machine rear. Connect this line to the connection nipple on the top of the bellows. 6049...
  • Page 171 Tilt function (Optional equipment) Test the tilt function: • Switch on the machine electrical switch(es) and turn on the compressed air supply. • Open the door and lock it open. • The uppermost switch on the tilt control unit tilts the machine either backwards (turn switch anticlockwise) or forwards (turn switch clockwise).
  • Page 172 Tilt function (Optional equipment) Position and fasten the side panel strips. 486 Fit the two counterweights to the front panel strip. The bolt heads should be at the bottom. Counterweights 487 Hang the front panel strip on the two sleeves you fitted to the side strips. Protective plates are mounted on the front and rear.

  • Page 173: Weighing Equipment (Optional Equipment)

    Weighing equipment (Optional equipment) Weighing equipment Description The weighing equipment comprises the following Scale unit units: • A scale unit located inside the machine’s left- hand rear side panel • Four load cells, one in each corner of the frame • Wiring The weight of the wash load is registered by the four load cells, which send analogue signals to the scale unit.

  • Page 174: Water Level Reduction

    Weighing equipment (Optional equipment) Water level reduction To achieve optimum load volumes, the weight Normal mode of the load can be seen on the display while the machine is being loaded. If the machine does not have a full load, the water level will be redu- ������������������...

  • Page 175: Calibrating The Weighing Equipment

    Weighing equipment (Optional equipment) Calibrating the weighing equipment The “Zero calibration” function is used to increase the accuracy of the weighing equipment. This should be done once a month. See the section headed “Zero calibration” under “Machine operation”. If a new scale unit is installed, it must be calibrated as described in the section ”Calibrate the scale”...

  • Page 176: The Dead Load Selector

    For this machine the selector should be set to 1000-1400 kg for W4400H, 2100-2550 kg for W850H, W1100H and 1200-1600 kg for W600H. If calibration of the weighing equipment should fail, one possible cause can be that this selector is incorrectly set.

  • Page 177: To Replace A Load Cell

    Weighing equipment (Optional equipment) To replace a load cell • Machines without tilt function: Remove nut + bolt (A). • Use a suitable jack to lift under the frame at the corner where the load cell is to be replaced. • Insert a suitable object as a chock beneath the frame, to remove risk of injury and machine damage.

  • Page 178: To Replace The Scale Unit

    • Take the scale unit off its mounting plate. • Install the new scale unit, assembly in reverse order of disassembly. • Check that the dead load selector is set to 1000-1400 kg for W4400H, 2100-2550 kg for W850H, W1100H and 1200-1600 kg for W600H.

  • Page 179: Component Locations

    Weighing equipment (Optional equipment) Component locations X401 X402 X410 X41 X411 X412 B90-9 6050 Scale unit B90-9 Load cells Connectors X401 Voltage feed X402 Communication with CPU board X410-41 Load cells...

  • Page 180: Fault-Finding, Weighing Display

    Board connectors Board connectors that the dead load selector is set to 1000-1400 kg for W4400H, 2100-2550 kg for W850H, W1100H and 1200-1600 kg for W600H. If it is not, set it correctly and calibrate the weig- hing equipment according to “Calibrate the scale”...
  • Page 181 Weighing equipment (Optional equipment) • If more than one load cell is faulty, the faulty cells can be identified using a multimeter on the scale unit weight-totalling board to check each cell in turn, as follows: - Remove the four screws on the scale unit cover. - Check that the four load cell cables are connected to the scale unit.
  • Page 182 Weighing equipment (Optional equipment) Menu line which should show actual weight not displayed. Possible causes: The option “DISPLAY WEIGHT ALLOWED” may be switched off (have the answer “No” alongside) in “Settings 1”. Possible fault in communication with CPU board or display. The fault can also be in the scale unit. Fault-finding procedure: •...
  • Page 183 Fault-finding procedure: • Check that the dead load selector is set correctly. It should be set to 1000-1400 kg for W4400H, 2100-2550 kg for W850H, W1100H and 1200-1600 kg for W600H. • If you are or have recently been calibrating the weighing equipment, the calibration switch may be incorrectly set, or an incorrect calibration weight may have been used for calibration.
  • Page 184 Weighing equipment (Optional equipment) Information in display: Function not allowed. Probable cause: A function has been selected in the program which cannot be carried out. Fault-finding procedure: • Check that the function in question is switched on under “Settings”. • Check that the cables for CPU communication, power supply and load cells are connected.
  • Page 186 Share more of our thinking at www.electrolux.com...

This manual is also suitable for:

W3600hW3850hW31100h

Table of Contents
