Setting up the scanner

Connecting the cable

1. Connect the interface cable to the bottom of the scanner.
2. Connect the other end of the interface cable to a USB connector on the host device.
To disconnect the cable from the scanner, insert a paper clip into the hole in the front of scanner and remove
the cable from the scanner as shown below.
Connecting the cable 1
