Operating & Installation Instructions
EN
Fully Automatic Washing Machine
Model SF-P90XA
Thank you for purchasing a Hitachi fully automatic washing machine.
■
Please read these operating & installation instructions carefully for proper
operation of the machine.
■
Please keep these operating & installation instructions for future reference.
Contents
2
3
5
6
8
9
14
21
22
23
24
25
30
30
Advertisement
Table of Contents
Related Manuals for Hitachi SF-P90XA
Summary of Contents for Hitachi SF-P90XA
-
Page 1: Table Of Contents
Troubleshooting Error Codes How to Install the Washing Machine Customer Service Specifi cations Thank you for purchasing a Hitachi fully automatic washing machine. ■ Please read these operating & installation instructions carefully for proper operation of the machine. ■ Please keep these operating & installation instructions for future reference. -
Page 2: Environmentally Friendly Waste Disposal
Environmentally Friendly Waste Disposal The shipping package has protected your new washing machine on its Disposing of the way to your home. All materials are ecologically harmless and recyclable. packaging Please contribute to a better environment by disposing of packaging materials in an environmentally conscious manner. -
Page 3: Safety Instructions
Safety Instructions This washing machine is designed for home use only. Before operating the washing machine, please read these safety instructions carefully. Warning Issues which could cause death or serious injury. ■ Do not dismantle, repair or modify the washing machine. General safety This could cause malfunction, fi... - Page 4 Always put detergent into the detergent dispenser when washing laundry. ■ Do not use water hotter than 50ºC. SF-P90XA ■ Do not wash items together with coins, pins, or stones. This may damage clothes or the washing machine, or cause a water leak. Check inside pockets before washing.
-
Page 5: Parts And Accessories
Parts and Accessories Softener Dispenser Liquid Detergent and Bleach Dispenser Lint Filter (cassette type) Control Panel Power Cord Adjustable Foot Pulsator Attachments Check that the followings are contained in the washer package. If not provided, please contact your retailer immediately. Drain hose assembly and Hose clamp Water supply hose x 1... -
Page 6: Control Panel And Display
Control Panel and Display Power button Press this button to switch power on and off. The washing machine automatically switches off when operations are fi nished. The washing machine also turns off automatically if it is not operated or no button is pressed for 10 minutes after the power has turned on. - Page 7 Control Panel and Display Detergent indicator The amount of detergent is shown on the display when the Detergent indicator is lit. The display shows the number of scoops of powder detergent. (Each scoop is 35g) Water Level indicator Lights the Water Level indicator and shows the amount of water to be used for washing in litters on the display.
-
Page 8: Before You Start Washing
Before You Start Washing ■ Preparation of Remove any foreign objects (coins, safety pins, etc.). ■ Put delicate clothes (knits, lingerie, etc.) in a net. the laundry ■ Remove large lumps of lint, mud, sand, hair, and pet hair from laundry. ■... -
Page 9: How To Use The Washing Machine
Laundry shall not exceed the lower part of the liquid load balancer (dotted line). Otherwise, laundry may jump out from the wash tub while spinning and it may cause damage. SF-P90XA Press the Power button to turn on the power ■... - Page 10 How to Use the Washing Machine Put detergent into the Tub and close the Lid ■ The amount of detergent is based on a single 35-gram scoop of powder detergent. Since the required amount of detergent varies depending on the type of detergent, follow the instructions on the package of detergent.
- Page 11 How to Use the Washing Machine Program ends ■ The alarm sounds when a program ends. Press the Water Level button for 3 seconds to deactivate the alarm or to change the sound in the following way. Melody Mono No alarm *initial setting ■...
- Page 12 How to Use the Washing Machine 1. Prepare the laundry. How to use ■ Fold large items, such as quilts or blankets, as follows. the Blanket They should not be taller than 25 cm after they are folded. program 25 cm About 25 cm If it exceeds 25 cm, use a laundry net, which is sold separately.
- Page 13 How to Use the Washing Machine ■ How to use Use this program separately from other washing programs. (Do not put laundry into the tub.) the Tub Dry 1. Press the Power button to turn on the power. program 2. Select the Tub Dry program. 3.
-
Page 14: List Of Programs
List of Programs : Default settings : Changeable settings (via corresponding button) FUZZY FUZZY Program Fuzzy ENERGY SAVE SMALL LOAD Maximum P90XA 9 kg 0.6 kg load 32 to 65 L 20 L (automatically) Amount P90XA of water 20 to 65 L 20 to 26 L P90XA 12 min... - Page 15 List of Programs : Default settings : Changeable settings (via corresponding button) Program POWERFUL WATER SAVE SPEEDY Maximum P90XA 9 kg 9 kg 3 kg load 32 to 65 L 32 to 60 L 41 L (automatically) (automatically) Amount P90XA of water 20 to 65 L 20 to 60 L...
- Page 16 List of Programs : Default settings : Changeable settings (via corresponding button) SOAK Program DELICATE BLANKET 1 hr 3 hrs 5 hrs Maximum P90XA 2 kg 3 kg 9 kg load 41 L 65 L 65 L Amount P90XA of water 20 to 65 L 20 to 65 L 20 to 65 L...
- Page 17 Amount of detergent is indicated according to following table as a guide. Load (guide) Water Level Detergent (guide) Amount of detergent 6~9 kg 50~65 L 1.0~1.2 cup 33~43 g (SF-P90XA) 4~6 kg 41~65 L 0.8~1.2 cup 27~43 g 2~4 kg 35~50 L 0.7~1.0 cup 23~35 g...
-
Page 18: Partial Operations Using The Fuzzy Program
Partial Operations Using the Fuzzy Program To not spin the To reuse the wash To customize laundry because you If you want... water and separate the wash program are worried about your laundry wrinkles Wash ⇒ Rinse ⇒ Spin Wash ⇒ Rinse Operations Wash only Setting method... - Page 19 Partial Operations Using the Fuzzy Program If you want... To rinse only To rinse and spin To drain and spin Rinse ⇒ Spin Drain ⇒ Spin Operations Rinse only Setting method Turn on the power. Select the Fuzzy program. Set the amount of water. If the amount of water is not set, then maximum Cannot be used.
- Page 20 26 L 3 Min 44 L 20 L (No washing) No rinsing SF-P90XA ■ You can set the spin time each time you press the Spin button in a range of 1 to 9 minutes and no spinning. 9 Min...
-
Page 21: In Case Of Power Outage
In Case of Power Outage If there is a The washing machine is equipped with a restart function. If a power outage occurs while the washing machine is operating, the power outage cycle (i.e., wash, rinse, or spin) at that time is saved, and when the power is restored, automatically restart from the interrupted cycle. -
Page 22: Care And Maintenance
Care and Maintenance 1. Close the tap. Cleaning 2. Disconnect the water supply hose from the top of the washing the water machine. (Water in the hose may be drained when you disconnect supply inlet the hose.) 3. Use a brush or something to clean the water supply inlet of the washing machine. -
Page 23: Troubleshooting
Troubleshooting Problem Possible cause ● Does not operate The power plug is not inserted in the power outlet. ● There is a power outage. ● The Delay Timer has been set. ● It is wet, even though it is There may be moisture or water left in the tub or hoses from the the fi... -
Page 24: Error Codes
Error Codes Error Description Things to check Solution code ● Water is not Is the tap open? Check the tap, water supplied supply inlet fi lter, water ● Has dirt collected in the water supply inlet pipes, and water supply fi... -
Page 25: How To Install The Washing Machine
How to Install the Washing Machine ■ Do not use a damaged power plug, doing so is dangerous. Contact a Safety repair center that is certifi ed by the manufacturer to replace the plug. precautions ■ If the outlet you are using is a 2-pin outlet, use an adapter to change from three pins to two pins. - Page 26 How to Install the Washing Machine Connecting the Main unit ● Screw the union nut to arrow direction to fi rmly attach the water supply water supply opening. hose Precautions Make sure that the union nut between water supply hose and main unit is tightly screwed.
- Page 27 How to Install the Washing Machine Water supply hose Connecting ● to the tap ■ The optimum water pressure is 0.03 to 0.8 MPa. ■ Use a horizontal tap. Horizontal tap Extension tap Square tap Connect the water supply hose to the water supply inlet on the washing machine.
-
Page 28: Water Supply
How to Install the Washing Machine Connecting If the water supply hose installs, tighten the water ● supply hose to water tap. water supply hose to the tap Water supply hose ■ Dismantling 1. Turn off water tap. 2. Press start button and run for 10 seconds. ●... - Page 29 How to Install the Washing Machine ■ Connecting Connect the washing machine correctly to a grounded AC power supply. the power ■ The voltage of the power supply must match the voltage rating of the washing machine. ■ Do not use extension cords or overload the power outlet by using power strips.
-
Page 30: Customer Service
Specifi cations Model SF-P90XA Power supply See the rating plate on the back of the washing machine. Standard water level 65 L (maximum water level) - Page 31 Memo...
- Page 32 3WPL115531...
