3.4 List of Commands

Below is a list of RS-232C commands.
For details on individual commands, see
Playback-related commands(*1) are only valid for BDMV, BDAV, DVD-Video, DVD VR, CD-DA and DTS-CD discs.
(*1) Playback-related commands: Stop, Play, Pause, Still, Search & Play, Current Address Request, Time Code Request,
Title/Track Number Request, Chapter Number Request and Index Number Request
Operation-related commands(*2) do not operate when any screen other than a screen displayable in the play mode(*3)
is displayed.
(*2) Operation-related commands: Stop, Play, Pause, Still, Search & Play, Menu Call, Numeric Button,
Button Select, Enter Button and Slow
(*3) Screens displayable in the play mode: Now Playing screen, play mode screen, picture quality adjustment screen,
audio adjustment screen, etc.
An address can be specified for commands for which "Address" is indicated in the command mnemonic.
The specified address operates according to the address mode.
The types of applications and address modes that can be specified are shown below.
The initial value of the address mode is "TM(Time)".
BDMV
TM (Time)
TI (Title)
CH (Chapter)
An argument can be specified for commands for which "Argument" is indicated in the command mnemonic.
For details about arguments, see the separate commands under
RS-232C Command
No. Command Name
1 Open
2 Close
3 Stop
4 Key Lock
5 Current Address Request
6 Time Code Request
7 Title/Track Number Request ?R
8 Chapter Number Request
9 Index Number Request
10 Player Active Mode Request ?P
11 Error Code Request
12 Firmware Version Request
13 Player Model Name Request ?L
14 Slow
15 Remote control Button
3.5 Command Details
BDAV DVD-Video
○ ○
○ ○
○ ○
Mnemonic
OP
CO
99RJ
(Argument)KL
?A
?T
?C
?I
?E
?Z
(Argument)SW
/(Argument)/RU
.
DVD VR CD-DA
○ ○
○ ○
○ ○
3.5 Command Details
Function
Opens the disc tray.
Closes the disc tray.
Stops playback.
Controls button and tray locking.
Returns all information on currently playing title/chapter number, etc.
Returns currently playing time.
Returns currently playing title/track number.
Returns currently playing chapter number.
Returns currently playing track number and index number.
Returns player's current operating status.
Returns the latest error code.
Returns the firmware version.
Returns the player's model name, including destination code.
Sets slow motion playback.
Conducts the same operation as the remote control buttons. For
the correspondence between the remote control buttons and
arguments, see Remote Control Button Commands and
Arguments below.
9
