- Page 1 CBT6800 10-bit bus switch with precharged outputs for live insertion Product data Supersedes data of 1999 Oct 28 Philips Semiconductors INTEGRATED CIRCUITS 2003 Sep 12...
- Page 2 The device also precharges the B port to a user-selectable bias voltage (BIASV) to minimize live-insertion noise. The CBT6800 is organized as one 10-bit switch with a single enable (ON) input. When ON is low, the switch is on and port A is connected to port B.
-
Page 3: Function Table
Philips Semiconductors 10-bit bus switch with precharged outputs for live insertion LOGIC SYMBOL 1, 2 ABSOLUTE MAXIMUM RATINGS SYMBOL PARAMETER DC supply voltage DC input diode current DC input voltage DC clamp diode current Storage temperature range BiasV DC voltage range NOTES: 1. -
Page 4: Dc Electrical Characteristics
2. This is the increase in supply current for each input that is at the specified TTL voltage level rather than V 3. Measured by the voltage drop between the A and the B terminals at the indicated current through the switch. On-state resistance is determined by the lowest voltage of the two (A or B) terminals. - Page 5 1. This parameter is warranted but not production tested. The propagation delay is based on the RC time constant of the typical on-state resistance of the switch and a load capacitance of 50 pF, when driven by an ideal voltage source (zero output impedance).
- Page 6 Philips Semiconductors 10-bit bus switch with precharged outputs for live insertion TSSOP24: plastic thin shrink small outline package; 24 leads; body width 4.4 mm 2003 Sep 12 Product data CBT6800 SOT355-1...
-
Page 7: Revision History
Philips Semiconductors 10-bit bus switch with precharged outputs for live insertion REVISION HISTORY Date Description 20030912 Product data (9397 750 12059); ECN 853-2182 30126 dated 18 July 2003. Supersedes data of 28 October 1999 (9397 750 06552). Modifications: • 19991028 Product data (9397 750 06552);... -
Page 8: Data Sheet Status
Life support — These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury. Philips Semiconductors customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips Semiconductors for any damages resulting from such application.
