- Page 1 COLOR CAMERA BLOCK EVI-370 series nstruction anual (Ver. 1.2) English...
-
Page 2: Table Of Contents
EVI-370 series Table of Contents OUTLINE ........................1 GENERAL SPECIFICATIONS ................... 2 BLOCK DIAGRAM ....................3 DIMENSIONS ......................5 LIST OF INPUT/OUTPUT PINS ................9 OUTLINE OF FUNCTIONS ..................13 FUNCTION CONTROL ....................21 CONTROL METHODS ....................22 INSTALLATION ......................25 HANDLING PRECAUTIONS .................. -
Page 3: Outline
The EVI-370D series uses the VISCA™ protocol and RS-232C interface. When using VISCA™, the computer (or other device issuing the commands) is called the controller and the EVI-370 series (or other device receiving the commands) is referred to as the peripheral device. -
Page 4: General Specifications
EVI-370 series GENERAL SPECIFICATIONS EVI-370 (NTSC) EVI-371 (PAL) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... -
Page 5: Block Diagram
EVI-370 series BLOCK DIAGRAM EVI-370/371/370D/371D Block Diagram OPD 0–9... - Page 6 EVI-370 series BLOCK DIAGRAM EVI-370DG/371DG Block Diagram HCOM OPD 0–9...
-
Page 7: Dimensions
EVI-370 series DIMENSIONS EVI-370/370D/371/371D (1/2) - Page 8 EVI-370 series DIMENSIONS EVI-370/370D/371/371D (2/2)
- Page 9 EVI-370 series DIMENSIONS EVI-370DG/371DG (1/2)
- Page 10 EVI-370 series DIMENSIONS EVI-370DG/371DG (2/2)
-
Page 11: List Of Input/Output Pins
EVI-370 series LIST OF INPUT/OUTPUT PINS VC-192 Board (EVI-370/371/370D/371D) VC-201 Board (EVI-370DG/371DG) CN001: 6P For video output Board side : JST S6B-ZR-SM3A-TF C OUT Housing : JST ZHR-6 Y OUT VIDEO OUT CN301: 2P For power input DC IN (6 to 12 V) - Page 12 EVI-370 series LIST OF INPUT/OUTPUT PINS CN104: 27P For connecting FK-69 board (Optional board) JST 27FLZ-RSM1-TB ZOOM (FAST)/FOCUS/AF ON/OFF/ 17. SHUTTER PRIORITY AE LED EXP. COMP. UP 18. POSITION RESET LED OUTDOOR LED 19. D 3.5 V INDOOR LED 20. ZOOM (SLOW)/WB INDOOR/...
- Page 13 EVI-370 series LIST OF INPUT/OUTPUT PINS IF-67 Board In this board, zoom, focus (key switch) and VISCA™/RS-232C control can be performed simply. For details, call SONY. CN206: 7P For connecting function control ZOOM WIDE Board side : JST S7B-ZR-SM3A-TF ZOOM TELE...
- Page 14 EVI-370 series LIST OF INPUT/OUTPUT PINS GN-3 Board (EVI-370DG/371DG) CN800: 5P For external sync VIDEO IN Board side : JST S5B-ZR-SM3A-TF Housing : JST 05ZR-8M CN801: 9P For GN-key board MENU ON/OFF Board side : JST S9B-ZR-SM3A-TF CURSOR UP Housing...
-
Page 15: Outline Of Functions
EVI-370 series OUTLINE OF FUNCTIONS The EVI-370 series has the following functions. Zoom A stepper motor is adopted for zoom control. The zoom range of the EVI-370/371 is 12 times. Zooming between tele (64.8 mm) and wide (5.4 mm) is possible. -
Page 16: White Balance
EVI-370 series OUTLINE OF FUNCTIONS Focus An inner focus system is employed for the EVI-370/371 series. The auto-focus control is based on high frequency components with high video signal level, that is components with high luminance and strong contrast in the measurement area. -
Page 17: Automatic Exposure Mode
EVI-370 series OUTLINE OF FUNCTIONS Automatic Exposure Mode In automatic exposure mode the following features will be active:— Auto Iris AGC (Auto Gain Control) Shutter 1/60th sec (EVI-370/370DG) 1/50th sec (EVI-371/371DG) Shutter Priority Automatic Exposure Mode In this mode the shutter speed is selected from the table below. The gain and iris are automatically adjusted accordingly. - Page 18 EVI-370 series OUTLINE OF FUNCTIONS Bright Control The bright control function adjusts brightness with both gain and iris. Exposure is controlled by gain when dark and by iris when bright. As both gain and iris are fixed, they are used when exposing at a fixed camera sensitivity. When switching from the automatic exposure mode or shutter priority automatic exposure mode to the bright mode, the state before switching is held momentary.
- Page 19 EVI-370 series OUTLINE OF FUNCTIONS Iris Priority Mode In this mode the Iris position is selected from the table below. The gain and shutter speed is automatically adjusted accordingly. CLOSE F6.8 F5.6 F4.8 F3.4 F2.8 F2.4 F9.6 F2.0 F1.8 Camera Manual Mode In this mode the gain is manually selectable from the table below.
- Page 20 EVI-370 series OUTLINE OF FUNCTIONS Position Preset All products within the EVI-370/371 series incorporate 6 presets each of which can be programmed with specific camera settings. Using this function, zoom position, focus (auto/manual position), white balance, shutter speed, and bright control (iris/gain) can be stored.
- Page 21 Zoom Encode Output The EVI-370 series features an analogue zoom encode output which indicates the zoom position in DC voltage. Pin 2 and pin 3 of CN107 of the MD-71/73 board provide the digital and optical zoom encode output respectively.
- Page 22 EVI-370 series OUTLINE OF FUNCTIONS Gen Lock System (EVI-370DG/371DG) The EVI-370DG/371DG has VBS Gen Lock function. Input the VBS signal to CN800 of the GN-3 board. (Color video signal) NOTE : Be sure to perform the following adjustment when using Gen Lock.
-
Page 23: Function Control
EVI-370 series FUNCTION CONTROL Functions that can be controlled differ according to the control method used. Control method GN-3 VISCA™/ (EVI-370DG/ IF-67 FK-69 RS-232C Controllable functions 371DG) Zoom standard Tele/Wide Zoom fast Tele/Wide Zoom position (Set/Detect) Focus Auto/Manual selection Focus Far/Near... -
Page 24: Control Methods
EVI-370 series CONTROL METHODS Camera Control Methods Power supply Supply 6.0 to 12.0 V to CN301 (VC-192/201 board) using the harness provided. Red (No.1) is +. Video signal output Composite video and Y/C video are output to CN001 (VC-192/201 board). - Page 25 EVI-370 series CONTROL METHODS FK-69 board (optional board) control The following functions can be controlled by connecting the FK-69 board. CN104 of the MD-71/73 board (27P) is used. CN104: 27P ZOOM (FAST)/FOCUS/ 17. SHUTTER PRIORITY AE LED AF ON/OFF/EXP. COMP. UP 18.
- Page 26 EVI-370 series CONTROL METHODS FK-69 Board Reference Circuit D118 CL-170UR-CD-T AF LED R141 150 POWER LED D101 CL-170G-CD-T LED01 R142 270 D102 CL-170UR-CD-T R143 270 D103 CL-170UR-CD-T LED02 LED03 R144 270 D104 CL-170UR-CD-T R145 270 D105 CL-170UR-CD-T LED24 LED05 R146 270...
-
Page 27: Installation
EVI-370 series INSTALLATION Use the screws for the tripod at the bottom or M2 screws of the chassis. The plate for attaching the tripod on the bottom can be removed. When designing the housing, etc., refer to the dimensional allowance as shown in the figure below. -
Page 28: Handling Precautions
When touching the board, prevent electrostatic discharge failure, by using the ground-band. When packaging, use the anti- electrostatic packaging. When transporting the unit, place it in the carton box in which it was shipped from Sony. When adjustments are performed or factory preset are changed, the camera will be out of warranty. - Page 29 EVI-370 series MEMO...
- Page 30 EVI-370 series MEMO...
- Page 31 Sony reserves the right to change specifications of the products and discontinue products without notice.
