Sistema receptor/reproductor de DVD LX-3000D/21L, LX-3500D/21R Modelo : 110–127V~; 50 Hz Alimentación: Consumo: 160 W Importador: Philips Mexicana, S.A. de C.V. Norte 45, # 669, Domicilio: Col. Industrial Vallejo C.P. 02300 México D.F., Localidad y Tel: Tel. 5728-4200 Exportador: Philips Electronics HK, Ltd.
Page 3
Index English -------------------------------------------------------- 8 Français ------------------------------------------------------ 27 Español ------------------------------------------------------ 46 ----------------------------------------------- 65 NDEX pg 01-26/LX3xxx/21-Eng 4/16/02, 11:20 AM...
Page 4
Trade Practices Act or other Commonwealth or State Law. Philips Consumer Electronics warrants its products to the purchaser as follows and subject to the stated conditions. 12 months free service...
Page 5
12 months prior to the date of your claim. . In the event of a failure, Philips shall be under no liability for any injury, or any loss or damage caused to property or products other than the product under guarantee.
Page 6
POLIZA DE GARANTÍA ESTA POLIZA ES GRATUITA a partir de la entrega del aparato al consumidor. Esta póliza incluye la reparación o reposición gratuita de cualquier parte o componente que eventualmente fallase y la mano de obra necesaria para su reparación reparará...
Page 7
Ciudad Calle y Nº NOTA: Los Centros que tengan (S) solo proporcionan Servicio y los que tengan (SR) venden refacciones y proporcionan Servicio. pg 01-26/LX3xxx/21-Eng Philips Mexicana, S.A. de C.V. Nº DE SERIE _____________________________ DIA _____________ CENTROS DE SERVICIO Colonia C.
Contents Introduction and General Information Features ... 9 Discs for playback ... 9 Player zone Supplied accessories ... 9 Environmental information... 9 Installation ... 9 Maintenance ... 9 Functional Overview Front and Rear panels ... 10 Remote Control ... 11 Connections Connecting antennas ...
/21S and /21H) – this instruction booklet If any item is damaged or missing, contact your retailer or Philips. Environmental information All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).
Functional Overview Front and Rear panels DVD VIDEO DIGITAL SURROUND SYSTEM STANDBY PROGRESSIVE SCAN STANDBY ON y – to switch between power on and standby modes. Disc Tray OPEN/CLOSE 0 (in Disc mode only) – to open or close the disc tray. Display screen –...
(surround) speakers’ level. CENTER +/- – to adjust the centre speaker’s level. TV VOL +/- – to adjust Philips television’s volume level. SLEEP – to set the sleep (auto-off) timer function. – to select different brightness for the display screen.
Connections COMPONENT COMPONENT Pr/Cr Pb/Cb VIDEO OUT VIDEO OUT P-SCAN CENTER CENTER AUDIO OUT AUDIO OUT AUDIO IN AUDIO IN OFF ON OFF ON LINE OUT LINE OUT DIGITAL OUT DIGITAL OUT (75 ) MW/FM MW/FM WOOFER WOOFER OPTICAL OPTICAL ANTENNA ANTENNA LINE OUT...
Connecting the speakers Connect the supplied speaker systems using the supplied speaker cables by matching the colours of the jacks and speaker cables. Press up (or down) the speaker’s jack and fully insert the stripped portion of the speaker cable into the jack, then release.
Preparations Inserting batteries into the remote control Open the battery compartment. Place the batteries in the compartment with the correct polarity as indicated by “+“ and “-“ symbols. Close the cover. CAUTION! – Remove batteries if they are exhausted or will not be used for a long time.
Changing the volume level You can change the speakers’ sound distribution to suit your surround sound needs. Press CENTER +/- to adjust the level of the centre speaker. “CNT +XX DB” is displayed. Press REAR +/- to adjust the level of the rear surround speakers.
16:9 (Wide screen) 4:3 LB (Letter Box) 4:3 PS (Pan Scan) Note: – If your DVD is not encoded to allow you to change the aspect ratio, TV shape cannot be changed. – TV System Allows you to select the colour system matching the connected TV set.
Setting the language – Audio – Subtitle – Disc Menu This is to select the audio language, subtitle language and the language used on TV screen menus or DVD menus that will always be used for every disc to be played back. The default setting is English.
Adjust VOLUME button (or press VOL +/-) to increase or decrease the volume level. “VOL XX” is displayed. “XX”denotes the volume level. For Philips TVs only Press TV VOL +/- on the remote control to adjust the TV’s volume level.
Discs information DVD-VIDEO DISC TITLE 1 CHAPTER 1 CHAPTER 2 CHAPTER 1 DVD video discs may have one or more Titles, and each Title may have one or more Chapters. Playback stops at the end of each Title. VIDEO CD TRACK 1 INDEX 1 INDEX 2...
Repeat play You can only select the repeat play mode during playback. For DVD - Repeat chapter/title/disc Press REPEAT repeatedly to select the following : “R-1” – repeat chapter. “R-A” – repeat title/disc. For VCD/CD/MP3-CD - Repeat track/disc Press REPEAT repeatedly to select the following : “R-1”...
Changing sound track language This operation works only on DVDs with multiple soundtrack language. from the menu bar and press 4 key to select Select the desired language. For VCD : Press 4 to select the desired audio channels for sound : LEFT VOCAL ™...
Zooming in This function allows you to enlarge the picture on the TV screen and to pan through the enlarged image. from the menu bar and press 4 key repeatedly Select to select a zoom factor : x1.5 ™ x2.0 ™ x4.0 ™ OFF. To pan through the enlarged image, press OK to confirm the zoom selection and use 1 2 34 keys to move the zoomed picture left, right, up and down.
Special MP3-CD features – JPEG format – Max. 12 characters – Max. nested directory is 7 levels – The max. album number is 32 – Supported VBR bit-rate – Supported sampling frequencies for MP3 disc are : 32 kHz, 44.1 kHz, 48 kHz –...
Other Functions Tuning to radio stations Press STANDBY ON to switch on the last selected source. Adjust SOURCE (or press TUNER) to select TUNER mode. Press TUNER again to select the desired band : FM or Press and hold S or T until the frequency indication starts to change, then release.
Power Supply Rating LX3000D/21L, LX3500D/21R ... 110 – 127 / 60 Hz LX3000D/21S /30S, LX3500D/21H ... 220 – 240 / 50 – 60 Hz Power Consumption ... 160 W Dimensions (w x h x d) ... 435 mm x 78 mm x 360 mm Weight ...
Troubleshooting WARNING! Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty. Do not open the system as there is a risk of electric shock. If a fault occurs, first check the points listed below before taking the system for repair. If you are unable to solve a problem by following these hints, consult your dealer or service centre.
