Huawei Technologies Co., Ltd. reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO...
Table of Contents 1 Getting to Know Your Phone ......3 Your Phone............ 3 Keys and Functions ........4 Screen Icons ..........7 2 Getting Started..........8 Installing the SIM Card and the Battery .... 8 ...
Page 5
Writing and Sending a Multimedia Message ..16 6 Contacts ............18 Creating a Contact ........18 Searching for a Contact ........ 18 Setting a Speed Dial Number......18 7 Multimedia ............ 19 Camera ............
Getting to Know Your Phone Your Phone The following figure shows the appearance of your phone and it is for your reference only. Charger/USB port Number keys Headset jack End/Power key...
Navigation keys Delete key Left soft key Right soft key Music key Confirm key Call/Answer key Earpiece * key Flashlight # key Keys and Functions In this guide, the following icons indicate the navigation keys of your phone: , and Press …...
Page 8
Press … To … Scroll through submenus on a menu screen or options on an option screen. Access the functions assigned to the keys as shortcuts in standby mode. To customize the functions assigned to the navigation keys, select Menu > Settings > Phone settings >...
Page 9
Press … To … Enter #. Lock the screen and the keypad in standby mode (by pressing and holding the key for about 3s). Switch between input modes when editing text.
Screen Icons Icon Indicates … Signal strength. Battery power level. New text messages. New multimedia messages. The earphone plugged in. Bluetooth enabled. Missed calls. An alarm activated. Keypad locked. A microSD card inserted. The alert type is Ring only. The alert type is Vib. only. The alert type is Vib.
Getting Started Installing the SIM Card and the Battery When installing the Subscriber Identification Module (SIM) card on the phone, ensure that the golden contact area on the SIM card is facing downward and that the beveled edge of the SIM card is properly aligned with that of the SIM card slot.
Installing a microSD Card You can expand the storage space of your phone by installing a microSD card with a capacity of up to 16 GB on your phone. When installing a microSD card, ensure that the golden contact area on the microSD card is facing downward and that the beveled edge of the microSD card is properly aligned with that of the card slot.
Phone Lock The phone lock protects your phone from unauthorized use. By default, the phone lock is disabled. You can change the default phone lock code (1234) into any numeric string of four to eight digits. To change the phone lock code, do the following: In standby mode, select Menu >...
permanently. In this case, contact your service provider for a new one. Locking the Keypad If the Auto keypad lock function is enabled and if the phone is in standby mode for a preset period, the keypad is locked automatically. To unlock the keypad, press (Unlock) and key in succession.
File manager: to manage the multimedia files stored in the phone or the microSD card. Voice Services Making a Call In standby mode, enter the phone number. To make an international call, press key twice consecutively to enter the plus sign (+). Then enter the international access code, country code or region code, area code, and phone number in sequence.
Press to reject it. Press (Silent) to mute the speaker, and then press (Reject) to reject it. If the Any key answer function is enabled, you can press any key except to answer an incoming call. Text Entry Switching Between Text Input Modes The indicator of the current text input mode is displayed in the upper left corner of the screen.
Multi-Tap Input Mode In multi-tap input mode, you can press a key labeled with the desired letter once to enter the first letter on the key, twice to enter the second letter on the key, and so on. Press consecutively to select and enter commonly used symbols.
Entering a Symbol Press to display the symbol list. Press to scroll to the desired symbol. Press to enter the symbol. Messaging Writing and Sending a Text Message Select Menu > Messaging > Write message > Text message. Edit a text message. Press (Options), and then select Send to.
Writing and Sending a Multimedia Message Select Menu > Messaging > Write message > Multimedia message. Edit the content of the message. You can add picture, sound, subject, slide, and other attachments to multimedia messages. Press (Options), select Send to, and then enter the recipient or add the contact from the phonebook.
Page 20
Contact your service provider for the availability of the Multimedia Messaging Service (MMS) and the method for subscribing to this service. Open multimedia messages with caution. Objects in multimedia messages may contain viruses that can damage your phone, such as malicious software.
Contacts Creating a Contact Select Menu > Contacts > Add new contact. Press (Options), and then select To SIM or To phone for saving the contact. Enter the name and number of the contact. Press to save the contact. Searching for a Contact Select Menu >...
Multimedia Camera Select Menu > Multimedia > Camera. Press , and then select to view the photo album or to configure relevant settings. Press to take a picture. After taking the picture, do the following: Press (Options), and then select Send to send the picture or Delete to delete the picture.
Press to pause or continue. Press (Stop) to stop playing music. All the music files are stored in My Music of the phone memory or the microSD card according to the relevant settings. You can select Menu > File manager > Phone/Memory card > My Music to access these files and perform operations such as Rename and Delete to them.
Press (Options) to configure the settings such as Background play or Loudspeaker. Flashlight Select Menu > Organizer > Flashlight and then set the status to On. In standby mode, press and hold to turn on or off the flashlight. Ebook Reader Select Menu >...
When reading an ebook, you can press turn the pages. Connectivity Bluetooth Through Bluetooth, you can synchronize data between a computer and your phone, exchange data with other Bluetooth devices, and use a Bluetooth headset. You can configure Bluetooth-related settings only after enabling the Bluetooth function.
When a Bluetooth device sets up a connection to the phone for the first time, you need to enter a pairing password for authentication. Internet Services You can access Wireless Application Protocol (WAP) sites and use WAP-based services on your phone. To access WAP sites through your phone, you need to subscribe to the corresponding service from the service provider and set the relevant parameters on your phone.
Warnings and Precautions This section contains important information pertaining to the operating instructions of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic Device Power off your device if using the device is prohibited. Do not use the device when using the device causes danger or interference with electronic devices.
Page 28
Triggering of sparks in such areas could cause an explosion or a fire, resulting in bodily injuries or even deaths. Do not power on your device at refueling points such as service stations. Comply with restrictions on the use of radio equipment in fuel depots, storage, and distribution areas, and chemical plants.
Page 29
In a motor vehicle, do not place the device over the air bag or in the air bag deployment area. Otherwise, the device may hurt you owing to the strong force when the air bag inflates. Do not use your device while flying in an aircraft. Power off your device before boarding an aircraft.
Page 30
Keep the ambient temperature between 0°C and 40°C while the device is being charged. Keep the ambient temperature between 0°C to 40°C for using the device powered by a battery. Prevention of Hearing Damage Using a headset at high volume can damage your hearing.
Page 31
Use the AC power supply defined in the specifications of the charger. An improper power voltage may cause a fire or a malfunction of the charger. Do not connect two poles of the battery with conductors, such as metal materials, keys, or jewelries.
Page 32
Cleaning and Maintenance The device, battery, and charger are not water-resistant. Keep them dry. Protect the device, battery, and charger from water or vapor. Do not touch the device or the charger with a wet hand. Otherwise, it may lead to a short circuit, a malfunction of the device, and an electric shock to the user.
Page 33
You can clean the device and the charger with a piece of damp and soft antistatic cloth. Do not dismantle the device or accessories. Otherwise, the warranty on the device and accessories is invalid and the manufacturer is not liable to pay for the damage. Emergency Call You can use your device for emergency calls in the service area.
Page 34
The SAR limit adopted by USA and Canada is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The highest SAR value reported to the FCC and IC for this device type when tested for use at the ear is 0.693 W/kg, and when properly worn on the body is 1.280 W/kg.
Page 35
Warning: Changes or modifications made to this device not expressly approved by Huawei Technologies Co., Ltd. may void the FCC authorization to operate this device. EU Regulatory Conformance Hereby, Huawei Technologies Co., Ltd. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
