Summary of Contents for Asus TriplePlay
-
Page 1: User Manual
TriplePlay User Manual Version 1.0 Version Date: August 1, 2005 Document #: BD-TU0001-10... -
Page 2: Table Of Contents
UICK ETUP ..............26 DVANCED ETUP WAN ..................26 LAN Local Area Network (LAN) Setup .........31 NAT ..................32 Virtual Servers ..............32 Port Triggering ..............34 DMZ Host ..............35 Firewall.................36 IP Filtering—Outgoing ............36 IP Filtering—Incoming ............37 TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... - Page 3 Restore User Settings ...........65 Restore Default .............65 System Log ................66 Configure System Log ..........67 SNMP ...................67 Internet Time ................68 Access Control ..............69 Services ................69 IP Addresses..............69 Passwords ..............70 Update Software ..............70 Reboot Router ..............71 TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
-
Page 4: General Information
General Information The TriplePlay is a 3-in-1 router having the functions of a standard ADSL router, plus voice capabilities and wireless accessibility all in one box. Including three features adds convenience and provides increased functions for one router. Package Contents Included in the package is one of each of the following—... -
Page 5: Front Panel View
Connection established using USB. 8. USB Device The router is sending or receiving data Flashing using USB. Solid Wireless is enabled. 9. Wi-Fi No light Wireless is disabled. Blinking Presence of wireless traffic. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... - Page 6 Line2 is off-hook. 10. Phone2 No light Line2 is on-hook. Solid Line1 is off-hook. 11. Phone1 No light Line1 is on-hook. Solid Line is off-hook. 12. LINE No light Line is on-hook. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
-
Page 7: Back Panel View
9-12. LAN 1-4 Connect to PC(s) using RJ-45 cable(s). Connect to the splitter provided using an RJ-11 13. ADSL cable. Refer to the next page for complete instructions for splitter connections. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 8: Installing The Router
USB Device) on the back of the router and connect the other end to a free USB port on your PC. • The Found New Hardware Wizard will open on your PC. See USB Driver Installation below. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 9: Connect A Printer Or Server To The Router
• Then turn on and boot up your PC and any LAN devices, such as hubs or switches, and any computers connected to them. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 10: Installation Diagram
Installation Diagram TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 11: Usb Driver Installation
Found New Hardware Wizard will appear. 2. The Found New Hardware Wizard will appear shortly after, identifying that a USB driver is needed. Click on Next to continue with the installation. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... - Page 12 Yes to continue with the installation. 4. Then the Insert Disk window prompts you to insert the disk (or CD) containing the USB driver. Click OK after inserting the disk (or CD). TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
- Page 13 6. When you select the location of the disk (or CD), the required file USB8023K.SYS will automatically be updated in the filename window of this screen. Click on Open to continue with the installation process. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
- Page 14 7. The last window lets you know that the driver installation is complete. Click Finish to close the wizard. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
-
Page 15: Configuring Your Computer
Add button. 6. Select Internet Protocol (TCP/IP) from the list and then click on OK. 7. If prompted to restart your computer with the new settings, click OK. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 16: Windows Xp
192.168.1.x (where x is any number between 2 and 254) and 255.255.255.0 in the IP address field and Subnet Mask field. 5. Click on OK twice to save your changes and then close the Control Panel. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 17: Log In To The Router
The admin / admin combination can perform all functions. Passwords can be changed at any time. Please note that this user manual is based on the admin / admin login which includes all functions. ____________________________________________________ TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 18: Device Info
After completing the configurations for a WAN connection, you can return to this screen to view the information on your WAN status. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 19: Statistics
Access the LAN statistics from the router by clicking on the “LAN” item under “Statistics” WAN Statistics Access the WAN statistics from the router by clicking on the “WAN” item under “Statistics”. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 20: Atm Statistics
“Statistics”. ADSL Statistics You can view ADSL statistics by clicking on the “ADSL” item under “Statistics”. Information contained in this screen is useful for troubleshooting and diagnostics of connection problems. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 21: Adsl Ber Test
If you click on the ADSL BER Test button at the bottom of the ADSL Statistics screen, the following pop-up screen will appear allowing you to set the tested time and to begin the test. TriplePlay User Manual Version 1.0... -
Page 22: Route
Access the ARP status report from the router by clicking on the “ARP” item under “Device Info”. ARP (Address Resolution Protocol) maps the IP address to the physical address, labeled HW Address (the MAC address) and helps to identify computers on the LAN. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 23: Dhcp
If you uncheck the DSL Auto-connect box, the resulting screen is seen below. Enter the VPI / VCI as indicated by your ISP and enable Quality of Service to enable the function. To continue, click on Next. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... - Page 24 Enter the PPP username and password as given by your ISP. Then decide if you will be using any features such as dial on demand, PPP IP extension, keep alive and then click on Next. TriplePlay User Manual Version 1.0...
- Page 25 DHCP server and enter the range of IP addresses that the DHCP server can assign to your computers. Disable the DHCP server if you would like to manually assign IP addresses. Click on Next to continue. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
- Page 26 Setup Summary screen displays all WAN settings that you have made. Check that the settings are correct before clicking on the Save / Reboot button. Clicking on Save / Reboot will save your settings and restart your router. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
-
Page 27: Advanced Setup
WAN interface. The ATM PVC Configuration screen is seen below. The ATM PVC Configuration screen allows you to configure an ATM PVC identifier (VPI and VCI) and select a service category. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... - Page 28 It is commonly used for uncompressed audio and video information such as videoconferencing, interactive audio (telephony), audio / video distribution (e.g. television, distance learning, and pay-per-view), and audio / video retrieval (e.g. video-on-demand and audio library). TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
- Page 29 • PPP over Ethernet (PPPoE) • MAC Encapsulation Routing (MER) • IP over ATM (IpoA) • Bridging Select the mode that your ISP has instructed you to use and click on Next. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
- Page 30 After making your selections, click on Next to go on to the next page. When the settings are complete, the next screen shows a WAN Setup – Summary screen displaying the WAN configurations made. Click on Save to save the settings. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
- Page 31 Remove any of the connections that you have made. When satisfied with the settings click on the Finish button. After selecting the Finish button, the below screen will appear. At this point, the router will reboot to save the changes made. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
-
Page 32: Lan Local Area Network (Lan) Setup
Next to continue. The Save button only saves the LAN configuration data, but does not apply the configurations. Select the Save/Reboot button to save the LAN configuration data and reboot the router and apply the new configurations. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 33: Nat
IP address on the LAN side. Click on Add to configure a virtual server. Select the virtual server from the drop-down list and complete the server IP address, then click on the Save / Apply button. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... - Page 34 The following screen appears after you save your selection. To add additional virtual servers, click on the Add button. If you need to remove any of the server names, select the check box and click on the Remove button. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
-
Page 35: Port Triggering
After a selection has been made, click on the Save / Apply button. The below screen appears after you save your selections. You will be able to add or remove selections made, by clicking on the Add and Remove buttons. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 36: Dmz Host
DMZ Host You can define the IP address of the DMZ Host on this screen. Enter the IP address and click on Save / Apply. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 37: Firewall
The following screen appears when you Save / Apply the IP filter. The screen lists the IP filters that were added from the previous screen. To change your settings, click on the Add or Remove buttons. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 38: Ip Filtering-Incoming
Enter a filter name, information about the source address (from the WAN side), and information about the destination address (to the LAN side). Select the protocol and WAN interface, then click on Save/Apply to add the setting. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 39: Mac Filtering
MAC Filtering MAC filtering can forward or block traffic by MAC address. You can change the policy or add settings to the MAC filtering table using the MAC Filtering Setup screen. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 40: Parental Control
On this screen you will be able to view and delete MAC filtering rules. Parental Control In a home setting, parents can also restrict the day of the week certain computers can access the router. Click on Add to set up the restrictions. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 41: Quality Of Service
When completed, click on Save / Apply. Quality of Service You can configure the Quality of Service to apply different priorities to traffic on the router. Click on Add to configure network traffic classes. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... - Page 42 (6) – Internetwork Control o (7) – Network Control • Mark IP Type of Service— select from the following choices— o Normal Service o Minimize Cost o Maximize Reliability o Maximize Throughput o Minimize Delay TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
- Page 43 UDP / TCP Destination Port (port or port:port)— if TCP or UDP was selected , then enter the port number SET-2 • 802.1p Priority— if 802.1q was enabled on WAN, then select a value between 0-7. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
-
Page 44: Routing
Click on Save / Apply to continue. Static Route The Static Route screen can be used to add a routing table (a maximum of 32 entries can be configured). Click on Next to add. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 45: Rip
If RIP is enabled, the router operation can be configured as active or passive. DNS Server Use the DNS Server screen to enable automatic assignment of a DNS or to specify a primary and secondary DNS. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 46: Dynamic Dns
DDNS server. Select the Dynamic DNS provider from the list—DynDNS.org or TZO. Enter the hostname and the ADSL interface and the username / password provided by the DNS server site. Note that you will need to register first at DynDNS.org. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 47: Adsl
Consult with your ISP to select the correct settings for each. Then click on Save / Apply if you are finished or click on Advanced Settings if you want to configure more advanced settings. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 48: Dsl Advanced Settings
256 separate modems were running in parallel. The tone range is from 0 to 31 for upstream and from 32 to 255 for downstream. Do not change these settings unless so directed by your ISP. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10... -
Page 49: Port Mapping
Click on the Add button as displayed below. After clicking the Add button, the below configuration screen appears, allowing you to enter the groups and the interfaces they are associated with. TriplePlay User Manual Version 1.0 Document #: BD-TU0001-10...
