- Page 1 C-189-100-11 (1) Digital Video Camera Module Technical Manual XCG-C30/C32/C130 XCG-C30C/C32C/C130C © 2015 Sony Corporation...
-
Page 2: Table Of Contents
Frame Rate ............25 Table of Contents Auto frame rate ..........25 Specifying frame rate ........25 Displaying frame rate ........25 Fastest frame rate for partial scanning ....26 Overview Timing Chart ............28 Features ..............3 Trigger latency ..........28 Typical CCD Phenomena ........4 Sensor Readout (Sensor Output) ......29 System Components .......... -
Page 3: Overview
Sensitivity can be doubled by combining two pixels Model name Pixel count aligned vertically, you can achieve a standard output frame rate between 1.8x and 2x. Sensitivity can be XCG-C30/C32/C30C/ 330,000-pixel CCD, compatible C32C with VGA doubled by combining two pixels align horizontally. -
Page 4: Typical Ccd Phenomena
CCD used in XCG-C130/C130C Typical CCD Phenomena Under the following operating conditions, because the construction of the CCD of this camera is different from The following effects on the monitor screen are the CCDs used in other cameras, the brightness level characteristic of CCD cameras. -
Page 5: System Components
g LAN cable System Components This cable connects to the RJ45 connector on the rear panel of the camera module. Image/control signals are transmitted via this cable. Use a LAN cable (CAT5e or higher standard) that supports 1000BASE-T (or allows 100BASE-TX when it is used). Depending on the attributes of the LAN cable, images may become less clear and the camera module may become unstable. -
Page 6: Connection
Connection LAN cable Camera module interface board Camera module C-mount lens TRIG Camera cable Camera adaptor DC-700/700CE Tripod adaptor (adopt EIAJ compliant 12-pin VCT-333I connector pin assignments) If the HUB supports PoE, the items within the dashed line are not necessary. Power supply You can supply power to the camera module using the following methods. -
Page 7: Location And Function Of Parts And Operation
Locking the camera module into these holes secures the optical axis alignment. Note Refer to XCG-C30 Demensions in page 48 for about the position/size of the Guide hole and the Reference hole. Location and Function of Parts and Operation... -
Page 8: Rear
Rear e RJ45 connector g Reset switch You can connect a LAN cable to this connector to This reformats the network settings. control the camera module from a host device to output h Status LED (Green) image to a host device. By using a PoE-compatible LAN cable and camera module interface board or hub, you When power is on, this LED lights up. -
Page 9: Connecting The Cables
Connecting the cables Controlling the camera from the host device You can control the camera from host devices such as a computer. The following table shows the major control functions. Control functions Description Operating mode Free run/Trigger Shutter speed* Free run 1/100,000 sec to 2 sec... -
Page 10: When Mounting The Camera
When mounting the camera When you operate this unit in the following conditions, heat dissipation is required depending on the usage environment because the inside of the camera becomes hot. • when using PoE system • when the partial scan is set to less than 120 lines during the power is supplied through DC IN To promote heat dissipation from the unit and maintain performance, mount the camera to a metallic heat... -
Page 11: Heat Dissipation Of The Camera
Periodic inspections are recommended if it is used for a Read value of temperature sensor = long time. Temperature around the camera + Temperature inside ◆ Contact a Sony sales representative for more the camera information about inspections. The relation between the heat dissipation plate area... -
Page 12: Connections
Packet Delay Connections The delay amount to be inserted between packets can be set when sending them to a network. By increasing the packet delay, you can reduce the network bandwidth that the camera uses for sending packets. However, as the Network Settings amount of data sent in a certain time is decreased with increased delay, the frame rate of output images of the... -
Page 13: Network Connection Speed
Notes Network connection • Any persistent IP address can be entered, but the speed camera may become unable to be detected, depending on the IP address setting. If this occurs, use a tool for issuing ForceIP and set a persistent IP address again. This unit supports the connection with 1000Base-T •... -
Page 14: Trigger Signal Input
Trigger Signal Input Trigger signals can be input via the 2nd, 3rd, 4th pins of the DC IN connector, or the software command. Switchover of the trigger signal can be changed via the TriggerSource register. Register Parameter Setting TriggerSource Line1 (0) DC IN connector 2nd pin (GPI1) Line2 (1) DC IN connector 3rd pin (GPI2) *... -
Page 15: Gpio Connector
GPIO Connector The 2nd DC IN connector is the GPI connector and the 3rd and 4th are connectors that can set to either GPI or GPO. The trigger reset pin is the DC IN connector 2nd pin (GPI1). If you are connecting an external device to the GPI or GPO connector, refer to the circuit specifications below. -
Page 16: Functions
Partial scan can be used Width Height concurrently and horizontal and vertical can be set at the same time. XCG-C30/C 16 to 640 to 658 32 to 480 to 494 XCG-C32/C 16 to 640 to 658... -
Page 17: Output Format
Output format Register Parameter Setting GainAutoMode Off (0) Manual gain Monochrome cameras can switch between 8 bits, 10 Once (1) One-push AGC bits, and 12 bits. Color cameras can switch between Raw Continuous (2) Continuous AGC output 8 bits, 10 bits, 12 bits, RGB output 24 bits, and GainAutoLevel 0 to 11264 to 16383 AGC target level YUV output 24 bits, 16 bits. -
Page 18: Shutter (Exposure)
Bright Dark Register Parameter ExposureTime 10 to 60000000 Exposure Time [us] Rate [fps] XCG-C30/C 7674 XCG-C32/C 9593 XCG-C130C 32169 Auto exposure (AE) The shutter is set automatically by detecting the output level. The target level is the same as the value of GainAutoLevel. -
Page 19: Trigger Control
Trigger Control Free run/trigger mode Free run The camera operates without a trigger signal and performs the video output operation continuously after the shutter (exposure) is finished. The horizontal and vertical timing signals are generated within the camera. During the free-run operation, image pickup timing cannot be controlled. -
Page 20: Special Trigger
Special trigger When operating in trigger mode and performing image pickup in different conditions (such as the shutter, gain, and image pickup area), the setting has to be changed in advance for each trigger input. However, if the special trigger operation is enabled, the setting does not have to be changed and continuous image pick up in different conditions is facilitated. -
Page 21: Trigger Source
Sequential SpecialTriggerMode=2, SpecialTriggerActivation=0 in the figure. Trigger signal Exposure Sensor output Setting 1 Setting 2 Setting 3 5ms or longer Trigger states Free run Bulk Sequential Trigger mode Trigger edge detection Trigger width detection Trigger source This can be input via the DC IN connector or software command (TriggerSoftware). Refer to “Trigger Signal Input” (page 14) for details. -
Page 22: Trigger Shift
Trigger shift This device can accept exposure by the next trigger even while a video is output (except for the special trigger operation). In this case, trigger shift should be enabled since the trigger signal can become a noise source. When trigger shift is enabled, adjustment is made automatically for operations from trigger input to exposure to prevent noise contamination. -
Page 23: Trigger Delay
Trigger delay The camera can delay the trigger signal. Trigger signal Exposure Sensor output Register Parameter Setting TriggerDelay 0 to 4000000 Trigger delay [µs] Trigger counter Accepted triggers by which video output is performed are counted. Triggers are counted up by the internal counter even in the free-run operation. -
Page 24: Trigger Control
Trigger range operation example ExposureTime=300, TriggerAcceptanceRangeLowerLimit=100, TriggerAcceptanceRangeUpperLimit=200 in the figure. Trigger signal Exposure Sensor output ExposureTime=300, TriggerAcceptanceRangeLowerLimit=100, TriggerAcceptanceRangeUpperLimit=1000 in the figure. Trigger signal Trigger not disabled Exposure Sensor output Trigger control Since detection of the trigger width time requires a certain time during the trigger width detection operation, the exposure time will be slightly longer than the input trigger width time. -
Page 25: Frame Rate
Frame Rate Auto frame rate The reading cycle is set to allow the frame rate to be the maximum value automatically according to the current shutter setting and the partial scan setting in the free-run operation (Shutter has priority). The next exposure is performed while outputting a video and the next video output is started immediately after finishing all video outputs. -
Page 26: Fastest Frame Rate For Partial Scanning
Fastest frame rate for partial scanning The fastest frame rate varies depending on Height for partial scanning. XCG-C30/C XCG-C32/C Frame Rate... - Page 27 XCG-C130/C Note The VBIN=2 setting is not available on color models. Frame Rate...
-
Page 28: Timing Chart
The time from the trigger acceptance to the exposure start (trigger latency) varies depending on various conditions. In the trigger width detection operation, the value is changed by TriggerControl. Trigger signal Exposure Exposure time Sensor output Trigger latency XCG-C30/C ExposureMode TriggerControl TriggerShift Trigger latency Exposure time Approx. 0.7 µs... -
Page 29: Sensor Readout (Sensor Output)
When a trigger signal is input, Exposure signal noise may occur in an image. Sensor readout signal (Sensor output) CCD video output Effective pixel XCG-C30/C 32 µs* XCG-C32/C 40 µs* XCG-C130/C 60 µs * When VBIN=2, increase of approximately 3 µs. -
Page 30: White Balance
White Balance The white balance can be automatically adjusted when Five types of presets are provided. Specify using a 12 bit the BalanceWhiteAuto command is executed. The value. Binarization, 5-point interpolation, and arbitrary detection area is set to the screen center by default. The setting can be changed. -
Page 31: Arbitrary Setting
Setting example: Arbitrary setting The output values 0 through 4095 that correspond to input values 0 through 4095 can be changed. Register Parameter Setting LUTIndex 0 to 4095 Input LUTValue 0 to 4095 Output Output Setting example: LUTIndex = 0 LUTValue = 3 LUTIndex = 1 LUTValue = 10... -
Page 32: 3 × 3 Filter
3 × 3 filter Test Chart Output Monochrome model and color model apply a 3 × 3 area For monochrome model, monochrome chart can be set. filter for RAW output. The brightness of the central pixel For color model, monochrome chart or color chart can and the eight pixels around it, and the parameter of each be set. -
Page 33: Gpio
GPIO The signal level which is input in the 2nd, 3rd, and 4th DC IN connector can be detected. After selecting a connector by LineSelector register, the signal level is acquired from LineStatus register. Various signals can be output from the 3rd and 4th DC IN connector. - Page 34 GPO output system diagram (example of GPO1) Trigger signal Exposure Sensor output Trigger through signal Exposure signal Sensor readout signal GPO2 GPO3 Pulse signal StrobeActiveDelay Strobe control signal (GPO1) StrobeActiveTime User definition 1 User definition 2 User definition 3 LineSource LineInverter GPIO...
-
Page 35: Pulse Train Generator
Pulse Train Generator Sensitivity Control Pulse waveforms can be output from the GPO2/3 The VSUB (substrate bias voltage) in the CCD can be connector. Available range is 0.5Hz to 100kHz. changed* . VSUB adjustment allows you to change the Qs (saturation signal charge) value. Increasing the VSUB has the effect of improving the sensitivity* Register Parameter... -
Page 36: User Id
Startup with the setting saved in the user set channel 3. For example: UserSetDefaultSelector=3 The frame rate of XCG-C30 in normal mode is 130 fps (Restart or CameraReboot command) and in low speed mode is 31 fps (12/50 times of the normal mode). -
Page 37: Command List
Command List Command List... - Page 38 Command List...
- Page 39 Command List...
- Page 40 Command List...
- Page 41 Command List...
- Page 42 Command List...
- Page 43 Command List...
- Page 44 Command List...
-
Page 45: Specifications
Sensitivity XCG-C30/C32/C130: Specifications F5.6 (gain control at 0 dB, 400 lx) (only when shutter speed at 1/90 sec for XCG-C30, 1/60 sec for XCG- C32) XCG-C30C/C32C/C130C: Specifications F5.6 (gain control at 0 dB, 2,000 lx) (only when shutter speed at 1/90 sec... -
Page 46: Spectral Sensitivity Characteristics (Typical Values)
25 days per month). If usage exceeds the above normal usage frequency, the life expectancy may be reduced correspondingly. SONY WILL NOT BE LIABLE FOR DAMAGES OF ANY KIND RESULTING FROM A FAILURE TO IMPLEMENT PROPER SECURITY MEASURES ON TRANSMISSION... - Page 47 XCG-C30C XCG-C32C XCG-C130C Spectral Sensitivity Characteristics (Typical Values)
-
Page 48: Dimensions
Dimensions 14.5 ( 2 -M2 Depth 3 11.2 ( 29 (1 4.9 ( 12 ( 42 (1 15 ( 23.7 ( 4 -M2 Depth 3 3 -M3 Depth 3 16.5 ( 22 ( Unit: mm (inches) Dimensions... - Page 49 Technical information contained herein is for reference only and does not convey any license by any implication or otherwise under any intellectual property right or other right of Sony or third parties. Sony cannot assume responsibility for any right infringements arising out of the use of this information. Sony Corporation...
