Alternatively, wear a discharging Wrist-strap device. (Be sure to remove it prior to applying power--this is an electric shock precaution.) Samsung Electronics...
Page 3
Always inspect for pinched, out- of-place, or frayed wiring. Do not change the spacing between components and the printed circuit board. Check the AC power cord for damage. Make sure that leads and components do not touch thermally hot parts. Samsung Electronics...
P C B D T B D 7 0 0 F Fig. 3-1 Œ Prepare PC and DTB-D700F as aboveFigure. ´ Open DTB.TRM file while executing HYPERTERMINAL of PC. Port : Select to COM1 port currently used. Baudrate : 115200 ˇ...
Page 23
Software Upgrade and Installation MEMO Samsung Electronics...
C501 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 EC13 2401-002300 C-AL;47uF,20%,50V,GP,TP,6.3x11,5 C502 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 EC14 2401-002300 C-AL;47uF,20%,50V,GP,TP,6.3x11,5 C503 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C504 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 EC401 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5 C505 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 EC402 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,- Samsung Electronics This Document can not be used without Samsung’s authorization...
Page 37
2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R603 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R113 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 R604 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608 R114 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R605 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R115 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R606 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608 R117 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 R608 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608 This Document can not be used without Samsung’s authorization Samsung Electronics...
Page 38
U104 0801-001090 IC-CMOS LOGIC;74HC14,SCHMITT INVERTER,SO RES - RD/CF 10K 1/2W J MF40-00133A TUNER-NIM;TDTE9251DV01B,-,DVB-T,133CH,NO RES - RD/CF 330K 1/2W J U201 1107-001415 IC-FLASH MEMORY;M29W320DT70N6T,4MX8/2MX1 RES - RD/CF 2.2kߟ 1/2W J Samsung Electronics This Document can not be used without Samsung’s authorization...
Page 39
ZENER - DIODE 1N5232 [500mW 5.6V] MF92-00062A ASSY PCB-KEY SUB;DTB-D700F,- J902 3708-000313 CONNECTOR-FPC/FFC/PIC;8P,1.25mm,ANGLE-F, SW901 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW903 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW904 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW905 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW906 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW907 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST This Document can not be used without Samsung’s authorization Samsung Electronics...
Schematic Diagrams 8-2 Key J902 CON8 SW901 SW903 CH_UP CH_DOWN SW904 SW905 SW906 SW907 OPEN/CLOSE VOL_UP VOL_DOWN STB/DVD Samsung Electronics This Document can not be used without Samsung’s authorization...
