WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity should be serviced or repaired only by experienced professional technicians.
SAFETY PRECAUTIONS GENERAL GUIDELINES ELECTROSTATICALLY SENSITIVE (ES) DEVICES 1. When servicing, observe the original lead dress. If a Some semiconductor (solid state) devices can be damaged short circuit is found, replace all parts, which have been easily by static electricity. Such components commonly are over-heated or damaged by the short circuit.
SERVICE INFORMATION AG-AC7P Model No. : CONTENTS 1. Location of Controls and Components..................INF-1 2. How to Replace the Lithium Battery.................... INF-7 2-1. Replacement Procedure ..................... INF-7 3. Service Mode..........................INF-8 3-1. Lock Search History Indication ................... INF-9 3-2. Power ON Self Check Result Display................. INF-9 4.
The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not recharge, disassemble, heat above 100C (212F), or incinerate. Replace battery with Panasonic part number ML-614S/ZTK only. Use of another battery may present a risk of fire or explosion.
3. Service Mode 1. Indication method of the service menu Set the mode switch “Motion Picture Recording” mode. 2. Turn the power on, and then while keep pressing the “Zoom lever” to W side, “Focus” switch and “Menu” button for more than 3 seconds until the top screen of the Service Mode Menu being displayed. ( Service mode menu ) NOTE: Do not using service mode except above table of Service Menu.
3-1. Lock Search History Indication Touch the [ 4 ] of LCD, select Lock search history indication. < Operation specifications > < Indication contents > • Lock search history indication. Display the camera system error cord for three histories saved in EEPROM. •...
4. Service Fixture & Tools 4-1. When Replacing the Main P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. Please refer to the section 3 (ELECTRICAL ADJUSTMENT) about adjustment procedure. 4-2. Service Position This Service Position is used for checking and replacing parts. (Extension cable is not use.) INF-10...
5. Factory Setting 5-1. How To Turn On The Factory Settings? 1. Set the mode switch “Motion Picture Recording” mode. 2. Turn the power on, and then while keep pressing the “Zoom lever” to W side, “Focus” switch and “Menu” button for more than3 seconds until the top screen of the Service Mode Menu being displayed.
Page 23
DISASSEMBLY PROCEDURES AG-AC7P Model No. : CONTENTS Disassembly and Assembly Instructions..................DIS-1 1.1. Disassembly Flow Chart ....................DIS-1 1.2. PCB Location........................DIS-1 1.3. Disassembly Procedure....................DIS-2 1.3.1. Removal of the Face Panel and Shoulder Pad ..........DIS-3 1.3.2. Removal of the Hood ND Case Unit and Focus Ring ........DIS-4 1.3.3.
1 Disassembly and Assembly Instructions 1.1. Disassembly Flow Chart This is a disassembling chart. When assembling, perform this chart conversely. 1.2. PCB Location DIS-1...
1.3. Disassembly Procedure Item Removal Batt Power P.C.B. Unit Fig. D15 2 Screws (U) Item Removal Battery Catcher Unit P6751 (Connector) Face Panel Fig. D1 8 Screws (A) FP6752 (Flex) Shoulder Pad Face Panel 2 Locking tabs Shoulder Pad Batt Power P.C.B. Unit Hood ND Case Unit Fig.
Item Removal Front P.C.B. Unit Fig. D31 2 Screws (n) FP6801(Connector) Remote Controller Window Fig. D32 2 Screws (o) P.C.B. Angle Front P.C.B. Unit LCD Case Unit Fig. D33 3 Screws (p) Fig. D34 2 Screws (q) 6 Locking tabs LCD Case Top Unit FP901 (Flex) LCD Case Unit...
1.3.11. Removal of the Batt Power P.C.B. 1.3.12. Removal of the Handle Mic Unit Unit and Battery Catcher Unit Fig. D16 1.3.13. Removal of the Mic Case Unit and Ext Mic P.C.B. Unit Fig. D15 Fig. D17 DIS-9...
1.3.18. Removal of the Grip Cover Unit Fig. D26 1.3.19. Removal of the Zoom Photo P.C.B. Unit Fig. D28 1.3.20. Removal of the SS GYRO P.C.B. Unit Fig. D27 Fig. D29 DIS-13...
< Part Number of jig > NOTE: Only a necessary jig mentions for the setup of electrical adjustment in the table below. Please confirm the content that has been described to “How to use PC EVR software for AG-AC7P” in detail.
Page 43
X: Adjustment required Replacement part Adjustment item ● Hall amplifier / PWM bias / OIS Hall amplifier adjustment (automatic) ● Zoom tracking adjustment (automatic) ● White balance adjustment (manual) Camera Part ● Gain adjustment between channels (automatic) ● Blemish compensation (automatic) ●...
1. Overall Block Diagram : VIDEO SIGNAL NOTE : AUDIO SIGNAL : CLK or CONTROL LINE LENS(F1.8-2.6 16.8x) IC201 ZOOM/ MOS IMAGE FOCUS IRIS/ SENSOR MOTOR/ IC851 COLOR EVF EVF COLOR PANEL DRIVER Analog COLOR LCD PANEL X301 (72MHz) IC701 Analog LENS/OIS DRIVE COMPONENT...
3-2. Video/Audio Signal Process Block Diagram (2) IC3701 SD YLEVEL (AVIO) (To IC3401-AF12) HD YLEVEL (To IC3401-AE11) JK4503 (D JACK) V OUT PBOUT HDY OUT HDYOUT G HDYSDY CLAMP HD/SD LPF JK4901 D PLUGIN L D PLUG DET EXT MIC L Q4901-4904 (To IC2006-C12) C PB IN...
SCHEMATIC DIAGRAMS AG-AC7P 品番/Model No .: NOTE: BE SURE TO MAKE YOUR ORDERS OF REPLACEMENT PARTS ACCORDING TO PARTS LIST SECTION. The positions of parts on the schematic diagrams can be searched. When the search function of Adobe Acrobat is used, the character of specified...
Page 59
2. Video Schematic Diagram Video Section TO POWER (Main P.C.B. (2/10)) PW_UNP1R1V Schematic Diagram PW_REG1R2V PW_REG1R8V PW_REG3V PW_3R2V R3420 R3401 POWER $[15] TO CAMERA CAMERA I/F $[18] TO CAMERA D_GND CLK74_CAM BUS37_DTY1_0 BUS37_REFYC0 BUS37_DTY1_1 BUS37_REFYC1 C3403 BUS37_DTY1_2 BUS37_REFYC2 4R7[18] BUS37_DTY1_3 BUS37_REFYC3 BUS37_DTY1_4 BUS37_REFYC4...
2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. 2-1.
PRINTED CIRCUIT BOARD プリント基板図 AG-AC7P 品番/Model No. : 基板図上の部品位置を検索することが出来ます。 PDF の検索機能を使用すると、 指定した REF No.がハイライト表示されます。 The positions of parts on the circuit board diagrams can be searched. When the search function of Adobe Acrobat is used, the character of specified part is displays as highlight.
Page 98
CONTENTS 1. Main P.C.B..........................PCB-1 1-1. Main P.C.B. (Component Side) ..................PCB-1 1-2. Main P.C.B. (Foil Side)..................... PCB-2 1-3. Main P.C.B. Address Information..................PCB-3 2. EVF BL P.C.B..........................PCB-4 3. SD Holder P.C.B......................... PCB-5 3-1. SD Holder P.C.B. (Component Side) ................PCB-5 3-2.
EXPLODED VIEWS & REPLACEMENT PARTS LIST AG-AC7P Model No. : Note: *Be sure to make your orders of replacement parts according to this list. Unless otherwise specified, all resistors are in OHMS, K=1,000 OHMS, all capacitors are in MICROFARADS (F) P=F.
Page 130
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks VEP06G55A SIDE-R INT P.C.B. UNIT 1 (RTL) E.S.D. VEP002E8A SIDE-R OP P.C.B. UNIT 1 (RTL) E.S.D. VEP27227A MF SENS P.C.B. UNIT 1 (RTL) E.S.D. VYQ5819 ND CASE UNIT VFC4129...
Page 132
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks VEP03H99B MAIN P.C.B. UNIT 1 (RTL) E.S.D. VEP03J00A SD HOLDER P.C.B. UNIT 1 (RTL) E.S.D. VEP04969B JACK P.C.B. UNIT 1 (RTL) E.S.D. VEP01A42A BATT POWER P.C.B. UNIT 1 (RTL) E.S.D.
Page 134
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks VEP04970A EXT MIC P.C.B. UNIT 1 (RTL) E.S.D. VEP06G54A HANDLE ZOOM P.C.B. UNIT 1 (RTL) E.S.D. VYK1Q65 HANDLE UNIT VKF4044 HANDLE COVER VJF0804 LENS CABLE CLAMPER J0KG00000100 CLAMPER VMP2407 SHOE HOLD PLATE...
Page 136
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks VEP06G57A SS GYRO P.C.B. UNIT 1 (RTL) E.S.D. VEP06G58A ZOOM PHOTO P.C.B. UNIT 1 (RTL) E.S.D. VEP06G56A FRONT P.C.B. UNIT 1 (RTL) E.S.D. VGU0H08 PHOTO BUTTON VGQ0Q47 ZOOM SW HOLD FRAME...
Page 140
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks VEP26334A MONITOR P.C.B. UNIT 1 (RTL) E.S.D. L5BDDXM00034 LCD VYK5F30 LCD CASE TOP UNIT VSC6282 LCD FRAME K0RE00100033 LCD FRAME (W/PANEL SW) VGQ0K73 LENS HOLDER VGL1330 PRISM SHEET-A VGL1331...
Components identified with the mark have the special characteristics for safety. When replacing any of these components, use only the same type. S7.7. Packing Parts and Accessories Section...
Page 142
Components identified with the mark have the special characteristics for safety. When replacing any of these components, use only the same type. Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks VPK0825 ACCESSORY BOX ...
ELECTRICAL REPLACEMENT PARTS LIST Components identified with the mark have the special characteristics for safety. When replacing any of these components, use only the same type. Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks VEP03H99B MAIN P.C.B.
