F-Maintenance
Cleaning Air Outlet Filter and Biomimetic Fiber
(EA100CV)
F-9 Take off the air outlet cover.
F-10Take out the air outlet cover and biomimetic
fiber(EA100CV) and wash the filter by gently
pressing it in water, and leave it dry at a
shaded place..
F-11 Set the air outlet filter and biomimetic
fiber(EA100CV).
F-12 Set the air outlet cover.
•
To maintain the guaranteed performance and
quality, do not wash with detergent, bleach or
washing machine, and
•
do not dry with heater or dryer. They may
damage the filter.
•
After cleaning, fully dry dust bag/filter before
use. Using wet dust bag/filter may weaken
the suction power, or
•
may cause bad smell or malfunction.
•
To dry dust bag/filter, leave them at a shaded
and well-ventilated place for approx. 1 day (24
hours).
Cleaning Floor Brush
F-13 If dust is stuck, vacuum clean with crevice
nozzle.
Cleaning Main Unit and Accessory Parts
F-14 To clean the main unit and accessory parts,
wipe with a cloth moistened with water or
neutral detergent
-Do not wash the motor Protection Filter
CAUTION
Deformation occurs, dust may leak through,
and the motor may be damaged as result.
CAUTION
Do not use alcohol, benzine, or other chemicals.
F-9
F-10
F-13
6
G-Repair Hose
In case the hose close to the swivel connector is
torn, take the following steps;
G-1 Unhook the 4 ridges and separate the swivel
connector from the hose.
G-2 Screw the hose joint and separate from the
hose.
G-3 Cut off the torn hose end with scissors or else.
G-4 Remove the torn part and attach the hose joint
to the hose end by screwing.
G-5 Assemble the hose joint and the swivel
connectors by setting the 4 ridges in place.
TROUBLESHOOTING
1.
When the main unit is abnormally heated and the protector is activated operation stops.
•
Turn off the power by pressing ON/OFF power switch and unplug.
•
Throw away dust and clean the dust bag and filter.
•
Check if the hose and extension tube are clogged with dust.
•
Leave the main unit at a cool place for 1 hour and press the switch again.
2.
When the power cord is not rewound.
•
Press the cord rewind button and «rewind» and «pull out» the cord for 2 ~ 3 times.
G-1
G-2
G-3
G-4
G-5
7
