Contents 1 Notice 2 Important 3 Your TV Side controls and indicators Sockets Remote Control Functions Use your TV Switching on Switching off Menu Introduction Automatic Channel Set-up Smart Channel Set-up Manual Channel Set-up Fine Tuning a Channel Channel Edit 5 Use more of your TV Adjusting the Picture Adjusting the Sound...
No components are user serviceable. Do not open or remove covers to the inside of the product. Repairs may only be done by Philips Service Centres and official repair shops. Failure to do so shall void any warranty, stated or implied.
TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips Consumer Care to have the TV checked before use. Never place the TV, remote control or batteries near naked flames or other heat sources, including direct sunlight.
When you disconnect the power cord, always pull the plug, never the cable. Disconnect the TV from the power outlet and antenna before lightning storms. Dur ing lightning storms, never touch any par t of the TV, power cord or antenna cable.
3 Your TV Side controls and indicators 1. CHANNEL UP/DOWN button Scans up/down through the channel list. In the menu system. They act like the up/down direction buttons on the remote and adjust menu controls. . VOLUME UP/DOWN button Increases/decreases the volume. In the menu system, they act like the right/left direction buttons on the remote and adjust menu controls MENU button Brings up the menu system.
Page 7
Headphone socket (output) at the side This socket can be used to connect headphones or stereo earphones. Note: When connecting headphones, you can press the control to mute the sound coming from the speakers. In MUTE condition, Pressing the VOL+ and VOL- could change the volume of earphone. And you need to press the MUTE button on the remote to release the mute of speaker Warning: Excessive sound pressure from earphones and headphones can cause hearing loss.
Remote Control Functions Note: -Remote Control ( Depending on the models) and operation of remote control may be affected by bright artifical light near to the TV. SCENEA FREEZE EXIT Most of your television's functions are available via the menus that appear on the screen.
4 Use your TV Switching on Follow the instructions on this page on how to switch on your TV set and the remote control before going on to following pages describing how to use the channel set-up procedure. Switching off To put the TV set into standby mode, press the The TV set remains powered up, but with low energy consumption.
Menu Introduction SOURCE: Selecting a Signal Source PICTURE: Adjusting the Picture. SOUND: Adjusting the Sound FUNCTION: Function Settings. CHANNEL: Chanel Search and Edit . MEDIA: USB Functions. Automatic Channel Set-up Channel set-up involves selecting all the settings required to be able to search for and store all the channels you can receive.
Channel Edit You can use this function to swap two channels or skip a channel. 1. Activate the CHANNEL menu and p direction button to select the CHANNEL EDIT option. 2. Press the right direction or OK button to enter the CHANNEL EDIT menu.
SHARPNESS: adjusts the crispness of the edges in the picture. HUE: adjusts the balance between the red and green levels. Note: Hue is available to be adjusted only when the system of the video signal is NTSC. COLOR TONE. : adjusts the color temperature of the picture.
COLOR SYSTEM: use the right direction or OK button to display the selectable options, then press the up or down direction button to select your desired color system and press OK to confirm. (Note: The available color system might differ depending on the model.
Geometry Settings Display the menu by pressing the MENU button. Press the left or right direction button to select the GEOMETRY icon and press the or down direction or OK button to display the GEOMETRY menu. Note: This function is only available in PC mode. AUTO ADJUST H POSITION V POSITION...
Attention and Frequently Asked Questions: Attention: 1. Some non-standard mobile storage device maybe cannot be recognized. Please change to use the standard device.The USB should be cleaned from virus before using this function. This system only supports the following file formats: Picture format: .jpg Audio format: .mp3 All file in the storage device cannot be edited...
Other Information Troubleshooting Most problems you encounter with your TV can be corrected by consulting the following troubleshooting list. No picture, no sound 1. Check if the fuse or circuit breaker is working. 2. Plug another electrical device into the outlet to make sure it is working or turned on.
8 Product information Product information is subject to change without notice. For detailed product information, go to www.philips.com/support. Supported display resolutions Computer formats (HDMI) Resolution - refresh rate : 640 x 480 - 6 0Hz, 72Hz, 75Hz 720 x 400 - 70 Hz...
Supported TV mounts To mount the TV, purchase a Philips TV mount or a VESA-compatible TV mount. T o prevent damage to cables and connectors, be sure to leave a clearance of at least 2.2 inches or 5.5cm from the back of the TV.
Page 19
Logon to www.Philips.com Contact Philips Consumer Care Centre 3. In the unlikely event of a defect developing in the TV set contact the Philips Customer Care Centre for obtaining warranty service and inform of the defect observed in the set, the type no.and serial no.of the set.
Page 20
The TV set is not used according to instructions given in the 'Direction for use' Defects are caused by improper or reckless use. Any repair work carried out by persons other than a Philips dealer or Authorised Service Center. Any modification or alteration of any nature made in the electrical circuitry of the est.
