SERVICE MANUAL

MODEL
KDL-40V4000
KDL-46V4000
KDL-52V4000
MODEL
DEST
OIRT / UK / WE
OIRT / UK / WE
OIRT / UK / WE
- 1 -
EG1L-L
FLAT PANEL COLOR TV
CHASSIS
DEST
RM-ED013

Advertisement

Table of Contents
loading

Related Manuals for Sony KDL-40V4000

Summary of Contents for Sony KDL-40V4000

  • Page 1: Service Manual

    EG1L-L SERVICE MANUAL CHASSIS MODEL MODEL DEST DEST KDL-40V4000 OIRT / UK / WE KDL-46V4000 OIRT / UK / WE KDL-52V4000 OIRT / UK / WE RM-ED013 FLAT PANEL COLOR TV - 1 -...

  • Page 2: Table Of Contents

    COMPONENTS IDENTIFIED BY SHADING AND MARKED THE EXPLODED VIEWS AND IN THE PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. - 2 -...

  • Page 3: General

    Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com - 3 -...
  • Page 4 CAUTION Due to changes in the caution note for MDF-61 connector, the caution note has been placed in Appendix-A -  -...

  • Page 5: Specifications

    SPECIFICATIONS Television System Channel Coverage Colour/Video System Analogue: Analogue: VHF : E2-E12 Analogue: Depending on your country/region UHF : E21-E69 PAL, SECAM B/G/H, D/K, L, I CATV : S1-S20 NTSC 3.58/4.43 HYPER : S21-S41 (VIDEO IN) D/K: R1-R12, R21-R69 L: F2-F10, B-Q, F21-F69 Digital: I: UHF B21-B69 Digital:...

  • Page 6: Connectors

    CONNECTORS 21 Pin Connector (SCART) Pin No Signal Signal level Audio output B Standard level : 0.5V rms (right) Output impedence : Less than 1kohm* Audio input B Standard level : 0.5V rms (right) Output impedence : More than 10kohm* Audio output A Standard level : 0.5V rms (left)
  • Page 7 HDMI Connector Pin No Signal Assignment Pin No Signal Assignment TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock- TMDS Data2- TMDS Data1+ Reserved (N.C. on device) TMDS Data1 Shield TMDS Data1- TMDS Data0+ DDC/CEC Ground TMDS Data0 Shield +5V Power TMDS Data0- Hot Plug Detect...

  • Page 8: Self Diagnosis

    EG1L-L SELF DIAGNOSTIC SOFTWARE The identification of errors within the EG1L-L chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flashing LED) and then communicate with each device in turn to establish if a device is faulty.

  • Page 9: Disassembly

    SECTION 2 DISASSEMBLY 2-1. Rear Cover Removal 2-2. Stand Removal => = > => = > = > => = > = > => = > = > > => Remove the 30 rear cover fixing screws indicated and pull the rear Remove the 4 stand fixing screws as indicated.

  • Page 10: Be2 Board Removal

    2-5. BE2 Board Removal 2-6. D4 Board Removal (52 inches) Screws Screws Screws To remove the ‘BE2’ board disconnect all connectors and then remove To remove the ‘D4’ board disconnect all connectors and then remove the 6 screws circled and ease the board gently away from the back of the the 9 screws circled and ease the board gently away from the back of the TV set.

  • Page 11: H3E Board Removal

    2-9. H3E Board Removal 2-10. H4 Board Removal Clip Clips To remove the ‘H4’ board disconnect the connector and then release the To remove the ‘H3E’ board disconnect the connector and then release 1 clip circled and ease the board gently towards you and away from the the 2 clips circled and gently ease the board towards you and away from back of the TV set.

  • Page 12: Adjustments

    SECTION 3 ADJUSTMENTS • To take the Remote Commander out of ‘Service Mode’ press the 3-1. How to enter the Service Mode same buttons above together again for two seconds or remove thebatteries from the Remote Commander. Service adjustments to this model can be performed using the •...

  • Page 13: Set-Up

    3-3-1. Set-Up 3-3-4. White Balance The following menu appears on the screen when you enter the The following menu appears on the screen when you enter the ‘Set-up’ menu (See Pic.4). Be sure to check all pages. ‘White balance’ menu (See Pic.7). Pic.4 Pic.7 3-4.

  • Page 14: Tt Mode

    3-5. TT MODE Ver 4.0 TT mode is available by setting the TV and Remote Commander for operation in Service Mode [ As shown on Page 12 ]. The functions described below are then available by selecting the two numbers. To release the ‘TT mode’ press 00. To release the TT menu press the menu key.

  • Page 15: Block Diagrams

    Ver 2.0 4-1. BLOCK DIAGRAMS KDL-40V4000/42xx CTRL_KEY UNIT INDICATOR SIRCS CN101 CN301 CN401 CN5500 HDMI1 HDMI2 HDMI3_S PC_Audio BALANCER MAIN BOARD I P 5 ( 4 0 ) Hs/Vs NAND POWER MS_JIG IC7100 IC4701 C I _ B u ff e r s...

  • Page 16: Circuit Board Location

    4-2. CIRCUIT BOARD LOCATION 5-2. CIRCUIT BOARD LOCATION Reference Information RESISTOR : METAL FILM : SOLID FPRD : NON FLAMMABLE CARBON FUSE : NON FLAMMABLE FUSIBLE : NON FLAMMABLE METAL OXIDE : NON FLAMMABLE CEMENT : NON FLAMMABLE WIREWOUND CVM Board S1 Board : ADJUSTMENT RESISTOR COIL...

  • Page 17: Be2 Board Schematic Diagram

    BE2 - EG1L NOTE RESISTORS R7153..R7158 ARE 0.5% TOLERANCE NOTE SYMBOL IS WRONG R7156 0.5% 0.5% 6.3V R7160 C7116 6.3V R7159 RB7130 R7153 C7141 R7121 0.5% C7142 C7118 4 . 7 k C7100 R7122 0 . 1 0 . 1 4 .
  • Page 18 BE2 - EG1L FE_2.5V_DDR PLACE THESE CAPACITORS CLOSE TO IC PINS. PLACE THESE CAPACITORS CLOSE TO IC PINS. C7219 FE_3.3V C7228 C7227 C7226 C7225 C7224 C7213 C7214 C7215 C7216 C7217 C7218 C7220 100p 100p 100p 100p 100p 4 . 7 0 .
  • Page 19 BE2 - EG1L FE_NCI_EN FE_CI1_CE1B FE_FOEB FE_IORDB FE_D_IOWRB FE_IOWRB FE_FWEB FE_CI1_RSTB FE_REGB 3/16 R7306 R7308 FE_3.3V C7303 0.001 R7309 TS from CAM C7304 0 . 1 TC74LCX14FT(EKJ) FE_3.3V TS to CAM FE_3.3V R7310 FE_IOWRB_FWEB C7305 R7307 0.001 C7306 FE_CI1_INPACKB 0 . 1 FE_CI1_INPACKB 179376922 FE_CI1_IREQB...
  • Page 20 - 20 -...
  • Page 21 BE2 - EG1L AC_ON/OFF_NEG R8206 C8259 R8239 R8207 3 . 3 k C8215 D8203 C8212 R8238 MAIN_SP_FAULT AU_9V_GND L8203 10uH GNDSCART R8222 R8227 SHORTED AT PWB R8222 Q8200 RT3XBBM-T111-1 GNDHP R8223 SHORTED AT PWB LINE_OUT_L R8223 C8208 RB8201 R8228 GNDREC Q8202 C8224 R8224...
  • Page 22 BE2 - EG1L P ANEL_VCC_SW 9V_AUDIO 12V_REG PS6401 L6402 10uH C6430 3.15A 0 . 2 2 JL6465 JL6415 1608 R6521 3.3V_STBY R6422 C6419 R6430 JL6461 R6423 TK11190CSCL-G AU_9V_GND 3.3V_STBY IC6401 R6445 P ANEL_VCC JL6446 1608 L6410 R6414 Q6404 10uH TR RT3DL1M-T111A-1F C6487 D6419 R6508...
  • Page 23 BE2 - EG1L 3.3V_STBY_UC 3.3V_MAIN R5534 R5540 C5510 M24C32-WMN6T(B) IC5503 6.3V 2012 R5541 C5509 0 . 1 C5534 JL5508 R5680 JL5530 3.3V_STBY RB5003 JL5506 JL5531 T AUX3 T AUX3 JL5507 JL5532 TMODE TMODE NVM_WP JL5533 T AUX Q5508 T AUX JL5534 RT1N441M-TP-1 /TICS...
  • Page 24 BE2 - EG1L 3.3V_MAIN VH_DDH_3.3 FB4504 VH_DDH_3.3 C4533 C4532 C4534 VH_DDH_3.3 0 . 1 C4535 6.3V 6.3V 0 . 1 2012 2012 VD4513 220k R4541 HPD2 HDMI2_D1- HDMI4_B_D1- VH_DDH_3.3 Q4502 R4502 VD4519 INK0003AC1 R4500 HDMI2_D1+ HDMI4_B_D1+ RB4511 HDMI2_B_SDA HDMI2_B_SCL HDMI2_D2- HDMI4_B_D2- VH_DDH_3.3 JL4500...
  • Page 25 BE2 - EG1L LINE OUT LATERAL A/V CONNECTOR JL3054 LINE_OUT_L CVBS_FRONT AUDIO OUT R3112 VD3000 R3113 R3114 D3055 RB3024 PZU10.B2 C3000 D3000 R3109 1000p UMZ12KTR 470k 1608 GND_1 JL3055 10/16 JL3056 LINE_OUT_R FRONT_L RB3023 RB3022 C3078 C3075 C3001 C3072 R3110 100p 1000p 470k...
  • Page 26 BE2 - EG1L 1.2v DVB 2.5V_V 11/16 R2260 MM3141CNRE IC2202 C2244 FB2213 1.2V_DVB_SW R2270 1608 JL2229 C2275 R2253 0 . 1 Q2212 0 . 0 1 C2272 2SC4154TP-1EF 1608 5V_FE L2207 FB2215 10uH 0 . 4 7 0 . 0 0 1 C2255 C2223 C2236...
  • Page 27 BE2 - EG1L HYB18TC256160BF-3S IC4001 PLACE A PAIR OF THESE CAPS CLOSE TO EACH VDD, VDDQ PIN VCT_1.8V VDDQ VSSQ C4007 C4013 C4017 C4021 C4025 C4030 C4033 C4038 C4042 C4049 C4053 C4057 C4046 C4061 C4065 VDDQ VSSQ 0 . 1 0 .
  • Page 28 BE2 - EG1L RB4707 Audio,Analog Video input & DDR C4747 0 . 1 I n t e r f a c e CL4704 VCTY_RAMD5 VCTY_RAMD5 C4713 AGND1234 DRAM_DQ0 VCTY_RAMD0 C4750 0 . 1 AGND5678 DRAM_DQ1 VCTY_RAMD7 DRAM_DQ2 R4728 CL4701 VCTY_RAMD3 C4727 0 .
  • Page 29 BE2 - EG1L Power Supply(1/2) ET5001 AC18 Vsense_1.08V VSENSE VSS_HDMI1 5V_MAIN ET5002 SEAL VSS_HDMI1 R5004 SEAL VSS_HDMI1 ET5003 IC5002 SEAL VSS_HDMI1 R5012 Power Supply ET5004 SEAL VSS_HDMI1 ( 2 / 2 ) JL5004 C5004 FL5000 C5005 VCT_1.8V VDD_DRAM VSS_HDMI2 3.3V_AFE R5005 2012 2012...
  • Page 30 BE2 - EG1L L VDSA_0N CL8030 VSYNC R8105 LVDSA_0P L VDSA_1N L8000 BUS_RELEASE LVDSA_1P SINGLE MACRO AT PWB C o n t r o l a n d D i g i t a l V i d e o I / O RB8007 AF18 L VDSA_2N...
  • Page 31 BE2 - EG1L SCART2 SCART1 RB1006 JL1010 SCART1_OUT_L RB1012 JL1023 R1027 SCART2_OUT_L RB1010 470k C1025 1608 0 . 0 2 2 R1047 470k 1608 JL1008 1608 SCART1_OUT_R JL1024 RB1002 SCART2_OUT_R R1023 C1026 R1043 C1010 C1012 470k 1608 0 . 0 2 2 470k 0 .

  • Page 32: D4 Board Schematic Diagram (52 Inches)

    D4 - EG1L t @ X g ƒ “ *EY6704 CN6707 JW6601 EY6600 EY6601 L6600 EY6656 EY6658 68uH ET6702 CN6600 JL6600 JW6602 *EY6705 EY6653 FB6600 FB6602 C6787 0 . 0 1 EY6652 0.45uH 0.45uH 25V B 1608 EY6622 EY6659 C6603 C6600 EY6657 R6915...

  • Page 33: D5 Board Schematic Diagram (52 Inches)

    D5 - EG1L JW6900 CN6900 JW6902 JW6901 EY6900 JL6900 PFC_OUT EY6904 EY6905 JW6903 L6900 PRI_GND JL6901 68uH EY6901 EY6970 EY6966 EY6967 EY6972 EY6938 0.45uH 0.45uH C6900 FB6904 FB6906 C6902 C6910 JW6911 450V EY6971 EY6973 450V EY6919 FB6909 EY6937 EY6968 EY6969 D6912 T6951 FSF03B60...

  • Page 34: G5 Board Schematic Diagram (52 Inches)

    G5 - EG1L C6526 C6524 R6511 470p 470p D6150 SG10SC6-F5 C6517 C6516 R6516 12V @4.4A 470p 470p L6504 L6505 240uH 240uH L6151 4.7uH JL6156 R6500 EY6512 0 . 4 7 REG_12V REG12V EY6532 1/2W L6100 EY6520 JL6500 EY6507 EY6500 EY6501 001:3F REG12V D6502...

  • Page 35: Ip5 Board Schematic Diagram (40/46 Inches)

    IP5 - EG1L L6552 Mount Mecha A6001 263406611 D6000 380uH L6551 380uH C6568 C6570 R6576 470p 470p 6 . 8 EY6103 EY6558 EY6559 R6013 EY6552 EY6553 12V @6.9A REG_12V C6023 R6500 L6550 EY6560 0 . 1 EY6150 260uH 1/2W L6151 001:17E S3K60 C6551...
  • Page 36 IP5 - EG1L 001:8B JW6601 EY6600 EY6601 PFC_OUT2 PFC_OUT L6600 100uH JW6602 EY6652 EY6653 FB6600 FB6602 0.45uH 0.45uH *EY6704 L6601 C6600 *EY6705 450V EY6714 C6797 *EY6622 *EY6706 TO-220 450V EY6654 EY6655 001:17E;002:17F FSF03B60 EY6604 *EY6623 *EY6707 JW6603 001:8B JL6719 *D6604 *T6601 VCC_12V MA2DF600001S0...

  • Page 37: Be2 Printed Wiring Board

    Text Search ~ BE2 Printed Wiring Board Side A ~ C N 5 5 00 J A E 2 4 0 2 - 3 2 2 C N 6 4 0 2 P S 6 4 0 0 A - 1 5 4 5 - 5 9 9 - A C N 2 2 0 0 C N 5 5 0 2...
  • Page 38 ~ BE2 Printed Wiring Board Side B ~ W 2 4 1 C N 7 5 0 3 F 7 2 0 1 0 . 5 A 5 0 V Text Search F 7 1 0 0 F 7 1 0 0 : 2 . 0 A 3 6 V I C 7 2 0 1 I C 8 2 0 0 - 38 -...

  • Page 39: D4 Printed Wiring Board (52 Inches)

    ~ D4 Printed Wiring Board ~ E Y 6 7 1 8 E Y 6 7 1 9 Q6601 D 6 6 0 7 D 6 6 0 7 H V 2 D 6 6 0 9 H V 1 D 6 6 0 9 E Y 6 7 1 5 E Y 6 6 1 6...

  • Page 40: D5 Printed Wiring Board (52 Inches)

    ~ H4 Printed Wiring Board Side A ~ ~ H4 Printed Wiring Board Side B ~ Text Search C N 4 0 1 ~ H3E Printed Wiring Board Side A ~ ~ H3E Printed Wiring Board Side B ~ PICOFF (172963611) DATA TREC...

  • Page 41: G5 Printed Wiring Board (52 Inches)

    Text Search ~ G5 Printed Wiring Board Side A ~ A 6 0 0 3 E Y 6 0 2 1 E Y 6 0 1 6 C N 6 1 5 3 E T 6 0 0 0 E T 6 0 0 3 E Y 6 5 2 7 E Y 6 5 1 4 E Y 6 5 1 5...
  • Page 42 Text Search ~ G5 Printed Wiring Board Side B ~ C N 6 1 5 3 A 6 0 0 3 J L 6 1 1 0 J L 6 1 1 4 J L 6 1 1 2 C 6 1 1 7 C 6 1 1 5 C 6 1 1 6 E T 6 0 0 0...

  • Page 43: Ip5 Printed Wiring Board (40/46 Inches)

    Text Search ~ IP5 Printed Wiring Board Side A ~ E T 6 0 0 0 R 6 9 1 9 D I M M E R B A C K - L I G H T - O N / O F F P H 6 3 0 1 P H 6 1 0 0 I N V - E R R...
  • Page 44 Text Search ~ IP5 Printed Wiring Board Side B ~ C N 6 1 5 4 D I M M E R B A C K - L I G H T - O N / O F F I N V - E R R R 6 1 5 5 E T 6 0 0 0 G N D...

  • Page 45: Exploded Views

    SECTION 5 EXPLODED VIEWS NOTE : Non-serviceable items with no part number and no Items marked “*” are not stocked since they are seldom required for description are not stocked because they are not required for routine service. routine service. Some delay should The construction parts of an assembled part are indicated be anticipated when ordering these with a collation number in the remarks column.
  • Page 46 5-1. CHASSIS Cont. REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK 3-298-014-01 COVER, UNDER (L2) 40/46 inches 23 Ver 2.0 1-857-046-11 ETC-INVERTER MT BOARD 40 inches 3-298-229-02 COVER, UNDER (LL) 52 inches Ver 2.0 1-857-047-11 ETC-INVERTER MT BOARD 46 inches 3-298-013-01 BAR, UNDER (ML) 40 inches Ver 2.0 1-857-048-11 ETC-INVERTER MT BOARD (LU) 52 inches 3-298-029-01 BAR, UNDER (L) 46/52 inches Ver 2.0 1-857-049-11 ETC-INVERTER MT BOARD (LL) 52 inches 3-874-982-01 GUIDE, LED 40 inches 24 Ver 2.0 1-857-050-11 ETC-INVERTER MT BOARD (RU) 52 inches 3-874-982-11 GUIDE, LED 46 inches Ver 2.0 1-857-051-11 ETC-INVERTER MT BOARD (RL) 52 inches 3-874-982-21 GUIDE, LED 52 inches *A-1543-850-A H3E BOARD, COMPLETE 20 *A-1510-351-A H4 BOARD, COMPLETE 1-826-938-21 LOUDSPEAKER ASSY (5.8X12.6CM) 40 inches 1-826-939-22 LOUDSPEAKER (6.5X15CM) 46/52 inches...

  • Page 47: Bezel

    5-2. BEZEL REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK X-2190-821-1 BEZEL (40NW) ASSY 40 inches X-2190-819-1 BEZEL (46NW) ASSY 46 inches X-2190-824-1 BEZEL (52NW) ASSY 52 inches - 47 -...

  • Page 48: Rear Cover & Power Supply Cords

    5-3. REAR COVER & POWER SUPPLY CORDS UK MODELS ONLY REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK 3-293-590-01 REAR COVER (40) 40 inches 3-293-584-01 REAR COVER (46) 46 inches 3-293-622-01 REAR COVER (52) 52 inches *3-298-011-01 LABEL, REAR TERMINAL 3-106-546-01 COVER,ECS £...

  • Page 49: Electrical Parts List

    Note: To ensure safety and reliability it is Sony policy that power supply boards should not be repaired at component level in the field as a result... The D4, D5, G5 and IP5 boards are regarded as non service items...
  • Page 50 Note : The components identified by mark contain confidential information. Strictly follow the instructions when ever the components are repaired and/or replaced. REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C2227 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V * A-1561-860-A BE2 Board, Complete C2228 1-135-366-11 ELECT CHIP...
  • Page 51 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C3418 1-112-781-11 CERAMIC CHIP 1UF C4042 1-100-916-11 CERAMIC CHIP 0.1UF C3419 1-112-781-11 CERAMIC CHIP 1UF C4043 1-100-916-11 CERAMIC CHIP 0.1UF C3420 1-112-781-11 CERAMIC CHIP 1UF C4046 1-100-916-11 CERAMIC CHIP 0.1UF C3426 1-100-916-11 CERAMIC CHIP 0.1UF C4047 1-100-916-11...
  • Page 52 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4726 1-100-905-11 CERAMIC CHIP 0.001UF C5031 1-100-909-11 CERAMIC CHIP 10UF 6.3V C4727 1-100-916-11 CERAMIC CHIP 0.1UF C5032 1-100-916-11 CERAMIC CHIP 0.1UF C4728 1-100-916-11 CERAMIC CHIP 0.1UF C5033 1-100-916-11 CERAMIC CHIP 0.1UF C4729 1-100-916-11 CERAMIC CHIP 0.1UF C5034...
  • Page 53 F4 ABE2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C5101 1-100-916-11 CERAMIC CHIP 0.1UF C6423 1-112-777-11 CERAMIC CHIP 0.01UF C5102 1-100-916-11 CERAMIC CHIP 0.1UF C6424 1-100-912-11 CERAMIC CHIP 1UF C5103 1-112-064-11 CERAMIC CHIP 2.2UF C6426 1-100-905-11 CERAMIC CHIP 0.001UF C5104 1-100-916-11 CERAMIC CHIP 0.1UF...
  • Page 54 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C6617 1-100-909-11 CERAMIC CHIP 10UF 6.3V C7142 1-100-916-11 CERAMIC CHIP 0.1UF C6618 1-112-775-11 CERAMIC CHIP 0.0022UF C7143 1-100-916-11 CERAMIC CHIP 0.1UF C6619 1-164-245-11 CERAMIC CHIP 0.015UF 10.00% 25V C7144 1-100-916-11 CERAMIC CHIP 0.1UF C6622 1-100-909-11 CERAMIC CHIP 10UF...
  • Page 55 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C7314 1-114-331-11 CERAMIC CHIP 4.7UF C8262 1-100-831-91 CERAMIC CHIP 0.001UF C7315 1-100-916-11 CERAMIC CHIP 0.1UF C8030 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V < CONNECTOR > C8031 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V C8032 1-114-320-11 CERAMIC CHIP 0.22UF...
  • Page 56 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D3405 6-501-817-01 DIODE MA2J1110GLS0 F7100 1-576-415-11 FUSE D3406 6-501-619-01 DIODE PZU9.1B2 F7200 1-576-415-11 FUSE D3407 6-502-172-01 DI UMZ5.6KTL F7201 1-576-646-11 FUSE 0.5A D4502 6-500-335-01 DIODE MC2838-T112-1 D4505 6-500-335-01 DIODE MC2838-T112-1 < FERRITE BEAD > D4506 6-500-335-01 DIODE MC2838-T112-1...
  • Page 57 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK FB7101 1-469-869-21 FERRITE IC4001 6-711-262-01 IC HYB18TC256160BF-3S FB7102 1-469-869-21 FERRITE IC4002 6-711-262-01 IC HYB18TC256160BF-3S FB7103 1-469-869-21 FERRITE IC4500 6-704-600-01 IC M24C02-WMN6T(B) FB7104 1-469-869-21 FERRITE IC4504 6-704-600-01 IC M24C02-WMN6T(B) FB7105 1-400-244-11 FERRITE IC4505 6-704-600-01 IC M24C02-WMN6T(B) FB7106...
  • Page 58 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < COIL > < TRANSISTOR > Q1000 8-729-028-28 TRANSISTOR 2SK2036(TE85L) L2200 1-412-058-11 INDUCTOR 10UH L2201 1-469-549-21 INDUCTOR Q1001 8-729-029-14 TRANSISTOR DTC144EUA-T106 Q1002 6-551-775-01 TR 2SA2122G0LS0 L2202 1-412-058-11 INDUCTOR 10UH L2203 1-412-058-11 INDUCTOR 10UH Q1003 6-551-776-01...
  • Page 59 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R1047 1-216-853-11 METAL CHIP 470K 5% 1/10W Q6419 8-729-028-96 TRANSISTOR DTC114EUA-T106 R1048 1-216-853-11 METAL CHIP 470K 5% 1/10W Q6421 6-551-690-01 TRANSISTOR RT3N11M-TP-1 R1049 1-216-811-11 METAL CHIP 1/10W Q6423 8-729-028-96 TRANSISTOR DTC114EUA-T106 R1050 1-216-853-11 METAL CHIP 470K 5%...
  • Page 60 H5 D2BE2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4502 1-218-967-11 RES-CHIP 1/16W R3041 1-216-853-11 METAL CHIP 470K 5% 1/10W R4512 1-218-953-11 RES-CHIP 1/16W R3042 1-216-853-11 METAL CHIP 470K 5% 1/10W R4513 1-218-953-11 RES-CHIP 1/16W R3043 1-216-853-11 METAL CHIP 470K 5% 1/10W R4514...
  • Page 61 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R5570 1-218-957-11 RES-CHIP 2.2K 5% 1/16W R6424 1-208-911-11 METAL CHIP 0.5% 1/16W R5571 1-218-941-81 RES-CHIP 1/16W R6426 1-218-970-11 RES-CHIP 1/16W R5572 1-218-933-11 RES-CHIP 1/16W R6427 1-218-978-11 RES-CHIP 120K 5% 1/16W R5574 1-218-965-11 RES-CHIP 1/16W R6428...
  • Page 62 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R7101 1-218-937-11 RES-CHIP 1/16W R7306 1-218-941-81 RES-CHIP 1/16W R7107 1-218-941-81 RES-CHIP 1/16W R7307 1-218-945-11 RES-CHIP 1/16W R7110 1-218-941-81 RES-CHIP 1/16W R7309 1-218-941-81 RES-CHIP 1/16W R7113 1-218-937-11 RES-CHIP 1/16W R7310 1-218-965-11 RES-CHIP 1/16W R7114 1-218-937-11 RES-CHIP...
  • Page 63 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R8207 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W RB4702 1-239-674-81 RESISTOR, NETWORK 100 R8208 1-218-941-81 RES-CHIP 1/16W RB4703 1-239-674-81 RESISTOR, NETWORK 100 R8215 1-218-949-11 RES-CHIP 1/16W RB4704 1-239-701-81 RESISTOR, NETWORK 18K R8216 1-218-949-11 RES-CHIP 1/16W RB4705...
  • Page 64 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK RB7200 1-234-878-21 RES, CHIP NETWORK 1KX8 (3816) < TUNER > RB7202 1-234-878-21 RES, CHIP NETWORK 1KX8 (3816) RB7204 1-234-375-21 RES, NETWORK 1K (1005X4) TU2200 8-597-641-00 TUNER UNIT, DIGITAL BTD-HF411T RB7205 1-234-702-11 RES, NETWORK 68 (1005X4) RB7206 1-234-702-11...
  • Page 65 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK Q305 6-551-815-01 TR UNR52A1G0LS0 ACCESSORIES AND CONNECTORS *1-835-146-11 CONNECTOR ASSY, MDF61 (CN6700(D4)- < RESISTOR > BALANCER) (52 inches) *1-835-147-11 CONNECTOR ASSY, MDF61 (CN6700(IP5)- R301 1-208-871-81 METAL CHIP 0.5% 1/16W BALANCER) (40 inches) R302 1-208-885-11 METAL CHIP...
  • Page 66 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK *3-298-969-11 INSTRUCTION MANUAL (UK) ENGLISH *3-298-969-21 INSTRUCTION MANUAL (WE) GERMAN/SPANISH/ FRENCH/GREEK/ITALIAN/DUTCH/PORTUGUESE *3-298-969-31 INSTRUCTION MANUAL (OIRT) DANISH/FINNISH/ ENGLISH/NORWEGIAN/POLISH/RUSSIAN/SWEDISH *3-298-969-41 INSTRUCTION MANUAL (OIRT) CZECH/HUNGARIAN/ SLOVAK/TURKISH *3-298-969-51 INSTRUCTION MANUAL (OIRT) ENGLISH/RUSSIAN REMOTE COMMANDER 1-480-798-11 REMOTE COMMANDER (RM-ED013) - 66 -...
  • Page 67 English Sony Corporation 09DP7100-1 Sony UK Printed in U.K. Service Promotions Dept. © 2009.04 9-883-400-05...
  • Page 68 VER 5.0 Appendix-A - Caution Notes 1. MDF-61 Connector (Removal) Slide the slider to release slider Press the centre lock tab to Remove connector lock. release the lock and pull the connector up 2. MDF-61 Connector (Refiitting) Hold the centre of connector Press centre of connector to insert Slide the slider to lock connector...
  • Page 69 Appendix-A - Caution Notes 3. The harness must not be crossed or twisted 4. Wire Dressing at connector The harness must not bend more than 45 degrees from the direction of the connector base to avoid crossing or twisting. 5. Wire distance at connector The distance between each wire must be wider than 4mm to ensure isolation from lamp voltage.
