Page 5
Samsung Electronics Co.,Ltd. - This Service Manual is a property of 416, Maetan-3Dong, Yeongtong-Gu, Suwon City, Samsung Electronics Co., Ltd. Gyeonggi-Do, Korea, 443-742 Any unauthorized use of Manual can be Printed in Korea punished under applicable International P/N : BN82-00145F-00 and/or domestic law.
2 Product Specifications 2 Product specifications 2-1 Fashion Feature Wise link - Accept 10 types of Memory Cards including USB (10 in 3 ) Excellent Compatibility. SD/MMC/CF/MD/MS/MSPRO/XD/SM Wide Color Gamut - More natural and vivid picture quality by UWCG (100%) High Dynamic Contrast - 6000:1 Highest dynamic Contrast Ratio Best Off-Angle Viewing...
2 Product Specifications 2-6 Option Specification Item Item Name Code.No Remark Remote Control BN59-00530A & Batteries (AAA x 2) 4301-000121 Power Cord 3903-000042 32" BN63-02535A Cover-Bottom 40" BN63-02491A 46" BN63-02624A 32" BN90-00942B Stand 40" BN90-01023A 46" BN90-01033A Cleaning Cloth BN63-01798A...
Page 12
10 Operating Instructions and Installation 10 Operating Instructions and Installation 10-1 Front - The product colour and shape may vary depending on the model. 1. SOURCE 5. SPEAKERS Toggles between all the available input sources (TV, Ext.1 , Ext.2, AV, S-Video, Component, PC, HDMI1, (POWER) HDMI2).
10 Operating Instructions and Installation 10-2 Connection Panel - Whenever you connect an external device to your TV, make sure that power on the unit is turned off. - When connecting an external device, match the colour of the connection terminal to the cable. 10-2...
Page 14
10 Operating Instructions and Installation Connecting an Aerial or Cable Television Network To view television channels correctly, a signal must be received by the set from one of the following sources: - An outdoor aerial / A cable television network / A satellite network Connecting HDMI/DVI - Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players, AV receivers and digital TVs).
10 Operating Instructions and Installation 10-3 Remote Control 1. Selects a target device to be controlled by the Samsung remote control (TV, DVD, STB, CABLE, VCR) 2. Television Standby button 3. Number buttons for direct channel access 4. One/Two-digit channel selection 5.
For detailed information on installing the wall mount, see the instructions provided with the Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.
Page 17
10 Operating Instructions and Installation Memo 10-6...
11 Disassembly and Reassembly 11 Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the TFT-LCD WARNING : This monitor contains electrostatically sensitive devices. Use caution when handling these components. 11-1 Disassembly Cautions : 1. Disconnect the monitor from the power source before disassembly. 2.
Page 19
11 Disassembly and Reassembly Description Picture Description 2. Remove screws from the rear-cover and lift up the rear-cover. 3. Disconnet cables from the main and power boards Remove screws from the side AV jack. 11-2...
Page 20
11 Disassembly and Reassembly Description Picture Description 4. Remove screws from the boards and stand BRKT. 5. Lift up the speakers. Remove screws from the BRKT. 11-3...
Page 21
11 Disassembly and Reassembly Description Picture Description 6. Lift up the Panel and remove screws. 7. Lift up the panel BRKT. 11-4...
Page 22
11 Disassembly and Reassembly 11-2 Reassembly Reassembly procedures are in the reverse order of disassembly procedures. 11-5...
Page 23
11 Disassembly and Reassembly Memo 11-6...
1 Precautions 1 Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1 Safety Precautions 1-1-1 Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC Power Jack before servicing.
1 Precautions 1-2 Servicing Precautions WARNING: An electrolytic capacitor installed with the wrong polarity might explode. Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.
1 Precautions 1-4 Installation Precautions 1. For safety reasons, more than two people are 6. Keep the antenna far away from any high-voltage required for carrying the product. cables and install it firmly. Contact with the high- voltage cable or the antenna falling over may 2.
14 Reference Infomation 14 Reference Infomation 14-1 Technical Terms - TFT-LCD - Auto Configuration(Auto adjustment) (Thin film Transistor Liquid Crystal Display) This is an algorithm to adjust monitor to optimum ADC(Analog to Digital Converter) condition by pushing one key. This is a circuit that converts from analog signal to digital signals.
Page 29
14 Reference Infomation - T.M.D.S - Interlace and Non-Interlace Methods (Transition minimized Differential Signaling) Showing the horizontal lines of the screen from the a kind of transmission method for Digital. top to the bottom in order is called the Non- It can be used from Video card to Main PBA.
Page 30
Enables high picture quality and clear sound channel to obtain the best viewing conditions. The throughout the country regardless of the location of Samsung LCD TV has both automatic and manual the viewer. channel fine-tuning features to enable the viewer to adjust their desired settings.
Page 32
14 Reference Infomation 14-2-2 Component 14-2-3 S-Video Separate RCA Green Pb (Cb) RCA Blue Pr (Cr) RCA Red Audio L 14-2-5 D-SUB RCA White Separate Audio R RCA Red Green Blue 14-2-4 A/V GND Red GND Green GND Blue RCA Yellow CVBS DDC Input power(+5V) Audio L...
Page 33
14 Reference Infomation 14-2-7 Scart 1 Signal Signal Audio output R Audio input R Video GND (RGB red) Audio output L Audio common GND RGB red input Video GND (RGB blue) Fast Blanking signal (RGB switching) Audio input L Video output GND RGB blue input Video input GND Switching voltage...
14 Reference Infomation 14-3 Timing Chart This section of the service manual describes the timing that the computer industry recognizes as standard for computer- generated video signals. 14-3-1 LCD Panel Mode1 mode 14-7...
3 Alignments and Adjustments 3 Alignments and Adjustments 3-1 Service Instruction 1. Usually, a color TV-VCR needs only slight touch-up adjustment upon installation. Check the basic characteristics such as height, horizontal and vertical sync. 2. Use the specified test equipment or its equivalent. 3.
3 Alignments and Adjustments 3-2 How to Access Service Mode 3-2-1 Entering Factory Mode " " - If you have Factory remote - control - The buttons are active in the service mode. 1. Remote - Control Key : Power, Arrow Up, Arrow Down, Arrow Left Arrow Right, Menu, Enter, Number Key(0~9) 2.
3 Alignments and Adjustments 3-4 Service Adjustment 3-4-1 White Balance - Calibration If picture color is wrong, do calibration first. Equipment : CA210, Patten : chess pattern Execute calibration in Factory Mode Source AV : PAL composite, Component : 1280*720/60Hz PC : 1024*768/60Hz ( chess patten ) 3-4-2 White Balance - Adjustment...
Page 50
3 Alignments and Adjustments 3-4-3 Conditions for Measurement 1. On the basis of toshiba ABL pattern : High Light level (57 IRE) - INPUT SIGNAL GENERATOR : MSPG-925LTH * Mode 2 : 744X484@60 Hz 6 : 1280X720@60 Hz NO 21 : 1024X768@60 Hz * Pattern NO 36 : 16 Color Pattern NO 16 : Toshiba ABL Pattern 2.
Page 51
3 Alignments and Adjustments d) Adjust the high light. (Refer to table 1, 2 in adjustment position by mode) - Adjust red gain ('x') and blue gain ('y') to the color coordinates. * Do not adjust the green gain and sub-contrast (Y) data. Picture 4-3 Toshiba ABL Pattern High light Measurement point...
3 Alignments and Adjustments 3-5 Software Upgrade 3-5-1 How to Update Flash ROM 1. Installthe Flash Downloader ConnectSet(Service Jack)and Jig Cable to execute Program Update. 2. Flash Downloader program update -Before Turning on the set,Click "connect"which is under of OSD Screen! -Turn on the Set.
4 Troubleshooting 4 Troubleshooting 4-1 First Checklist for Troubleshooting 1. Check the various cable connections first. - Check to see if there is a burnt or damaged cable. - Check to see if there is a disconnected cable connection or a connection is too loose. - Check to see if the cables are connected according to the connection diagram.
4 Troubleshooting 4-2 Checkpoints by Error Mode 4-2-1 No Power LAMP off, power indicator Check a connection a power cable. LED blue color? Does proper DC 12V Change a Assy PCB Power. appear at CM801? Does proper DC A3.3V, Check a IC1008, IC1004. A5V appear at Change a main PCB ass'y.
Page 56
Change a main PCB ass'y. LBE (RA4016~18)? Does the digital data appear Check IC4003 at the output of IC4003 Change a main PCB ass'y. (RA4014,15_1CH, R4132,33_1CH)? Check a LVDS cable? Please, Call to Samsung Co. LTD. Replace a lcd panel?
Page 57
4 Troubleshooting WAVEFORMS R,G,B Output Signal of IC500...
Page 58
IC4001 Change a main PCB ass'y. LVDS(RA4016~18)? Does the digital data appear at the output of IC4003 Check IC4003 (RA4014,15_1CH, Change a main PCB ass'y. R4132,33_1CH)? Check a LVDS cable? Please, Call to Samsung Co. LTD. Replace a lcd panel?
Page 59
4 Troubleshooting Digital Output Data of IC500 Signal of HDMI(Data)
Page 60
RA4016~18? Change a main PCB ass'y. Does the digital data appear Check IC4003 at the output of IC4003 Change a main PCB ass'y. (RA4014,15_1CH, R4132,33_1CH)? Check a LVDS cable? Please, Call to Samsung Co. LTD. Replace a lcd panel?
Page 62
Out of IC4001, RA4016~18? Change a main PCB ass'y Does the digital data appear Check IC4003 at the output of IC4003 Change a main PCB ass'y. (RA4014,15_1CH, R4132,33_1CH)? Check a LVDS cable? Please, Call to Samsung Co. LTD. Replace a lcd panel?
Page 63
4 Troubleshooting WAVEFORMS CVBS Output Signal 4-10...
Page 64
Change a main PCB ass'y. RA4016~18? Does the digital data appear at the output of IC4003 Check IC4003 (RA4014,15_1CH, Change a main PCB ass'y. R4132,33_1CH)? Check a LVDS cable? Please, Call to Samsung Co. LTD. Replace a lcd panel? 4-11...
Page 65
4 Troubleshooting WAVEFORMS Digital Output Data of IC500 Analog Signal(Y,C) to IC500 4-12...
Page 66
4 Troubleshooting 4-2-7 No Sound Connect a sound cable. Picture is display, no sound. control a volume. Does the signal appear at Pin #10, #16(CH1_L, R Sound) Check a connection harness and and Pin #3, #9 headphone jack / Side AV. (CH2_L, R Sound) of IC1015? Check the DC 12V...
Page 67
4 Troubleshooting WAVEFORMS The Signal are Inputed to IC1015 DC +12V 4-14...
13 Circuit Descriptions 13 Circuit Descriptions 13-1 Block description Mosel consists of three main blocks 1. Main board : Video signal processing 2. IP board : Power supply & Inverter 3. T-con board : LCD Panel control 13-1...
Page 71
13 Circuit Descriptions I I NVERTER SMPS Mosel consists of three main blocks 1. Main board : Video signal processing 2. SMPS : Power supply 3. T-con board : LCD Panel control 13-2...
Page 83
8 Wiring Diagrams 8-2 Main Board Layout...
Page 84
8 Wiring Diagrams 8-3 PIN characteristic CN800 - Main Board power supply NAME SW GND GND GND GND GND B12VS B12VS GND POWER NAME GND GND GND B12V B12V B12V B12V GND Function Define - B12V B12V_CHN, B9V, B8V, B5V_VCCT - B5V B33V, B5V_VCCA, B3.3VD, B2.5V_VDD, B1.8VD, PX_VD1.8, PX_VA1.8, PX_VL1.8, B1.2VD - B12VS...
Page 85
8 Wiring Diagrams CN221 - Front control NAME SDA-T SCL-T GND GND IDENT HP-L HP-R INPUT1 INPUT1 INPUT2 Function Define - A5V Front control board poewr supply - KEY INPUT1,2 Key control, from the memu, change up/down Etc. - IR Remote control signal - LED Control the timing and stand by LED color...
Page 86
8 Wiring Diagrams LVDS Signal NAME NAME TXOUTO4+ TXOUTO0- TXOUTO0+ TXOUTO1- TXOUTO1+ TXOUTO2- TXOUTO2+ TXOUTOC- TXOUTOC+ TXOUTO3- TXOUTO3+ TXOUTO4-...
Page 87
8 Wiring Diagrams 8-4 Power Board Layout...
Page 88
8 Wiring Diagrams CN801 - AC Input NAME Live Netural VOLTAGE Functing Define - Refer to : AC Input CN801 - Main Board power supply NAME 13V GND 5.4V 5.4V 5.4V GND GND GND GND ST7V PWR Functing Define - ST7V Stand-By Output - PWR Power On/Off Control - Refer to : CN801 function define CNM804 - Panel control...
Page 89
8 Wiring Diagrams CN802 - Inverter power supply NAME 24V GND GND GND GND Functing Define - AMLCD Panel Inverter Power - 24V LAMP INVERTER Voltage - B/L Brightness sensor power - A_D ANA_DIMMING - P_D PWM_DIMMING CN803 - Inverter power supply NAME 24V GND GND GND GND...
Page 91
8 Wiring Diagrams CN801 - AC Input NAME Live Netural VOLTAGE Functing Define - Refer to : AC Input CN801 - Main Board power supply NAME 13V GND 5.4V 5.4V 5.4V GND GND GND GND ST7V PWR Functing Define - ST7V Stand-By Output - PWR Power On/Off Control - Refer to : CN801 function define CNM804 - Panel control...
Page 92
8 Wiring Diagrams CN803 - Inverter power supply NAME 24V GND GND GND GND Functing Define - AMLCD Panel Inverter Power - 24V LAMP INVERTER Voltage - B/L Brightness sensor power - A_D ANA_DIMMING - P_D PWM_DIMMING CN804 - Inverter power supply NAME 24V GND GND GND GND...
Page 96
5 Exploded View & Parts List 5 Exploded View and Parts List - You can search for updated part codes through ITSELF web site. URL : http://itself.sec.samsung.co.kr/ 5-1 LE32N71B Exploded View M0014 M0059 M0013 T0175 T0447 M0215 T0175 T0003 M0013...
Page 102
6 Electrical Parts List 6 Electrical Parts List You can search for updated part codes through ITSELF web site. URL : http://itself.sec.samsung.co.kr/ 6-1 LE32N71B Parts List Level Loc. No. Code No. Description & Specification Q'ty SA/SNA LE32N71BX/XEC LE32N71B,Q56A/32M70-GNM,32,LCD-TV,SPAIN M0001 BN90-00936B ASSY COVER FRONT;32N71,EO(NEO),-,ABS+PMM...
