Summary of Contents for Electrolux EYL85066BT
- Page 1 EYL85066BT WATER HEATER USER MANUAL EYL95066BT EYL10566BT...
-
Page 2: Table Of Contents
9. TROUBLESHOOTING..................23 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. - Page 3 In the user manual and on our web site, www.electrolux.co.uk you will nd some useful information on how to deal with minor faults and how to take care of your product. When contacting us for...
-
Page 4: Safety Information
1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. - Page 5 ENGLISH The pressure relief device must be tted during installation, unless it is incorporated in the appliance. The appliance must be permanently connected to xed wiring. The appliance must be earthed. Do not install the appliance in locations where freezing can occur.
-
Page 6: Safety Instructions
Do not let the electricity mains cable tangle. All products manufactured and supplied by Electrolux are safe provided they are Make sure the appliance is installed installed, used correctly and receive regular correctly. Loose and incorrect electricity... - Page 7 Turn off at the mains electrical supply and refer to the Troubleshooting section (see page 23) or contact Electrolux Customer Services (see page 3). Do not crush or kink the shower hose, this could damage the hose, cause leaks and activate the pressure relief device.
-
Page 8: Electrical Requirements
3. Electrical Requirements Double pole switch Shower unit For cable capacity see cable current carrying capacity table on page 9 Consumer unit Mains electrical supply supply company. WARNING! This appliance MUST be earthed! The shower must be connected to its own independent electrical supply. - Page 9 ENGLISH Where shower cubicles are located in any For close circuit protection DO NOT use a rooms other than bathrooms, all socket rewireable fuse. Instead use a suitably rated Miniature Circuit Breaker (MCB) or cartridge outlets in those rooms must be protected by fuse (see Circuit protection table).
-
Page 10: Water Requirements
4. Water Requirements Isolating stop valve Mains water Shower unit supply Hose retainer 1m minimum height from shower unit to floor Minimum 25mm between showerhead Bath spillover and spillover level If the shower is to be installed in a hard water... -
Page 11: Installation
ENGLISH 5. INSTALLATION WARNING! Water entry position: Before installation, make sure Bottom right inlet entry you read through the electrical requirements and water requirements section. Select the location and hang up the shower While planning your shower installation, make sure you allow suf cient clearance between the ceiling and walls to allow any future maintenance (cleaning the lter etc.) to be performed. - Page 12 Top right inlet entry Left inlet entry Top left inlet entry Bottom left inlet entry To mark the drilling position Rear left inlet entry Using the installation template supplied, mark the positions of the three xing holes. NOTE: Ensure that there are suf cent...
- Page 13 ENGLISH Hook the backplate over the top screw and To remove the front cover t the bottom screws into position, but Unscrew the screws that xing the front DO NOT fully tighten the screws at this stage. cover (Fig. 2a), and pull out the front cover lightly, then disconnect the cable between The xing holes are elongated to allow for front cover and the chassis (Fig.
- Page 14 To select the wiring terminal position NOTE: This Electrolux shower heater has 2 wiring It is essential that all pipe work is ushed terminals and 2 earthing terminals shown through to remove debris and swarf that as Fig.
- Page 15 ENGLISH Fixing the front cover Fig. 8b 1. Before xing the front cover to the shower, tighten the 3 screws to x the shower on the wall rmly. 2. Adjust the spline spindle and the control knob to the correct position before replacing the cover Fig.
- Page 16 5.5 Install the bracket NOTE: Use the exible hose to locate the proper position for the bracket if necessary. Bracket parts Put the wall plugs on the holes, then Sliding rail remove the sliding rail holder covers from Wall plug...
-
Page 17: Operation Instruction
ENGLISH b. Assemble the soap tray holder from the Fig. 13 bottom of the sliding rail as Fig. 12 shown. Fig. 12 The larger hole should Point the open be pointed outside gap upward c. Assemble the soap tay on the soap tray holder. - Page 18 Before rst use Fig. 15 CAUTION! Rotate the temperature adjuster fully Before normal operation of the shower, it is anti-clockwise to the essential that the following commissioning “ ” position. procedure is completed correctly. The following operation is intended to ush...
- Page 19 ENGLISH 6. When a smooth ow of water is obtained, NOTE: It will take a few seconds for the rotate the temperature control from Min to temperature to stabilise after changing the Max several times to release any trapped air setting temperature.
- Page 20 Shower head setting Massage Setting Water ow Description Concentrated spray impact, with pulse effects, suitable for part pulse massage on muscle. Setting Water ow Description Shower spray with massage feeling. Spray Setting Water ow Description Have a broader area, suitable for large area shower.
-
Page 21: Maintenance
ENGLISH 7. MAINTENANCE WARNING! Inspect the ‘O’ ring for damage when the lter cap is removed. Before maintenance work, you must When cleaning the lter, DO NOT use a switch off the power at the isolating switch. sharp object, as it will cause damage. It is preferable to use an old toothbrush or similar. -
Page 22: Helpful Hints And Tips
8. HELPFUL HINTS AND TIPS Cut off the power while not in use avoid block of internal water pipe and lime scale. In normal use, it is in order to leave the water supply permanently on to the shower unit,... -
Page 23: Troubleshooting
(see rating label). shower is in use. Fit pump to give minimum pressure (see rating label). Electrolux Contact Customer Service for advice. Water too cool or cold. Reduction in ambient Select a higher water temperature via water temperature. - Page 24 9. TROUBLESHOOTING Problem/Symptom Cause Action/Cure Shower varies from Water pressure has Wait until the water pressure resumes to normal temperature dropped below minimum normal. to cold during use. required. Clean or replace blocked sprayplate in Blocked showerhead. showerhead and then t new PRD.
- Page 25 www.electrolux.com/shop...
