Professional Sampler
TORAIZ SP-16
TSP-16
http://pioneerdj.com/support/
The Pioneer DJ site shown above offers FAQs, information on software, and various other types of information
and services to allow you to use your product in greater comfort.
Operating Instructions (Quick Start Guide)

Advertisement

Table of Contents
loading

Related Manuals for Pioneer TORAIZ SP-16

Summary of Contents for Pioneer TORAIZ SP-16

  • Page 1 Professional Sampler TORAIZ SP-16 TSP-16 http://pioneerdj.com/support/ The Pioneer DJ site shown above offers FAQs, information on software, and various other types of information and services to allow you to use your product in greater comfort. Operating Instructions (Quick Start Guide)
  • Page 2 IMPORTANT CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol, The exclamation point within an equilateral CAUTION: TO PREVENT THE RISK OF ELECTRIC within an equilateral triangle, is intended to triangle is intended to alert the user to the SHOCK, DO NOT REMOVE COVER (OR alert the user to the presence of uninsulated presence of important operating and...
  • Page 3 (2) this device must accept any interference received, including interference that may cause undesired operation. Product Name: Professional Sampler Model Number: TSP-16 Responsible Party Name: PIONEER ELECTRONICS (USA) INC. SERVICE SUPPORT DIVISION Address: 1925 E. DOMINGUEZ ST. LONG BEACH, CA 90810-1003, U.S.A. Phone: 1-800-421-1404 URL: http://www.pioneerelectronics.com...

  • Page 4: Operating Environment

    Operating Environment Milieu de fonctionnement Operating environment temperature and humidity: Température et humidité du milieu de fonctionnement : +5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH De +5 °C à +35 °C (de +41 °F à +95 °F) ; Humidité (cooling vents not blocked) relative inférieure à...
  • Page 5 The Safety of Your Ears is in Your Hands La protection de votre ouïe est entre vos Get the most out of your equipment by playing it at a mains safe level – a level that lets the sound come through Pour assurer le rendement optimal de votre matériel clearly without annoying blaring or distortion and, most et –...

  • Page 6: Table Of Contents

    Thank you for buying this Pioneer DJ product. Be sure to read this manual and the Operating Instructions that is avail- able on the Pioneer DJ site. Both contain important information that you should understand before using this product. After you have finished reading the instructions, put them away in a safe place for future reference.

  • Page 7: Before Start

    Pioneer DJ site below. http://www.pioneerdj.com/ 2 Click [Support]. 3 Click the [FIND TUTORIALS & MANUALS] icon. 4 Click the [TORAIZ SP-16] icon in the [PRODUCTION] category. 5 Click on the required language on the download page. What’s in the box...

  • Page 8: Names Of Parts

    Names of Parts For more information, please refer to the Operating Instructions of this product published on the Pioneer DJ website. Top panel 1 MAIN OUT control k d button 2 DRIVE control l g button 3 OVER indicator m k button...

  • Page 9: Connections

    Connections Be sure to turn off the power and unplug the power cord from the power Refer to the operating instructions for the component to be connected. outlet whenever making or changing connections. ! When using a LAN cable for connection, be sure to use either the Connect the power cord after all the connections between devices have LAN cable included with this product or an STP (shielded twisted been completed.

  • Page 10: Example Of Connections

    1 Cord hook 3 Turn the tip of the power cord so that it is facing towards you, then turn it back to create a ring as shown in the diagram and insert it into Hook the AC adapters’ power cord here. the [DC IN] terminal of this unit.
  • Page 11 Starting up and preparing the unit 1 Connect the unit as described in Connections (p. 9 ). 2 Press the [u] switch on the rear panel of the unit. This unit’s indicators light up and the power turns on.

  • Page 12: Operation

    4 Tap [OK]. Tap [OK] to load the project. Operation The following explanations starts from the home screen. To go to the home screen, press the [HOME] button. Playing a demo project Loading a project 1 Tap the [PROJECT] button. The PROJECT screen appears on the touch display.

  • Page 13: Changing The Demo Project Sound

    2 Tap [ARRANGEMENT]. 2 Tap [PLAYBACK] and tap again in the selected state. [ARRANGEMENT] lights. In this state, patterns are played in the order in The playback screen appears. which they were sorted in this screen. ! You can also go to the track menu screen by turning the rotary selec- tor to select [PLAYBACK] and then pressing the rotary selector.

  • Page 14: Creating A New Project

    4 Enter the project name with the on-screen keyboard Creating a new project and tap [OK]. A new project is created and the main screen appears. 1 Tap the [PROJECT] button. The PROJECT screen appears on the touch display. In the project screen, you can perform operations such as loading and saving projects.

  • Page 15: Creating A Pattern

    3 Tap [FILTER TYPE] and select [FOLDER]. Programming triggers (step recording) The internal memory and USB device details are displayed as a tree on the right-hand side of the touch display. 1 Tap a track for step recording. The sequence of the selected track is indicated on the 16-step keys. ! A track can also be selected by turning the rotary selector.

  • Page 16: Connecting Usb Devices

    Connecting USB devices 1 Press the [u] switch to turn the unit’s power on. 2 Connect the USB device to the USB device insertion slot. Disconnecting USB devices 1 Press and hold the [USB STOP] button until the USB indicator stops flashing. Do not remove the USB device or turn Off the power of the unit while the USB indicator is flashing.

  • Page 17: Additional Information

    Changing the settings For more information, please refer to the Operating Instructions of this product published on the Pioneer DJ website. Cleaning the touch display Do not use organic solvents, acids or alkalis for cleaning the surface of the touch display.
