  • Page 1 KTI8500BE User Manual...

  • Page 2: Table Of Contents

    10. ENERGY EFFICIENCY.................. 20 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3 ENGLISH result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a...

  • Page 4: Safety Instructions

    CAUTION: The cooking process has to be supervised. • A short term cooking process has to be supervised continuously. WARNING: Danger of fire: Do not store items on the • cooking surfaces. Metallic objects such as knives, forks, spoons and lids •...

  • Page 5: Electrical Connection

    ENGLISH • Make sure that the ventilation space access to the mains plug after the of 2 mm, between the worktop and installation. the front of the below unit, is free. The • If the mains socket is loose, do not warranty does not cover damages connect the mains plug.
  • Page 6 • This appliance is for cooking WARNING! purposes only. It must not be used for Risk of fire and explosion other purposes, for example room heating. • Fats and oil when heated can release flammable vapours. Keep flames or 2.4 Care and cleaning...

  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION 3.1 Cooking surface layout Induction cooking zone Control panel 240 mm 145 mm 3.2 Control panel layout Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sen‐ Function Comment field ON / OFF...

  • Page 8: Daily Use

    Sen‐ Function Comment field To select the cooking zone. To increase or decrease the time. Power function To activate and deactivate the function. Control bar To set a heat setting. 3.3 Heat setting displays Display Description The cooking zone is deactivated.

  • Page 9: Automatic Switch Off

    ENGLISH 4.1 Activating and deactivating Touch for 1 second to activate or deactivate the hob. 4.2 Automatic Switch Off The function deactivates the hob 4.4 Cooking zone indication automatically if: The horizontal line shows the maximum • all cooking zones are deactivated, size of the cookware.
  • Page 10 Immediately touch a desired heat setting. When the time comes to an After 3 seconds comes on. end, the sound operates and 00 flashes. The cooking To deactivate the function: change the zone deactivates. heat setting. 4.7 Power function...

  • Page 11: The Child Safety Device

    ENGLISH 4.12 OffSound Control When the function operates, you cannot change the heat setting. (Deactivating and activating the The function does not stop the timer sounds) functions. Deactivate the hob. Touch for 3 To activate the function: touch seconds. The display comes on and comes on.

  • Page 12: Hints And Tips

    CAUTION! Make sure that the selected power fits to the house installation fuses. 4.14 Power management function • Cooking zones are grouped according to the location and number of the phases in the hob. See the illustration. • Each phase has a maximum electricity loading of 3700 W.
  • Page 13 ENGLISH Induction cooking zones adapt to the The noises are normal and do not dimension of the bottom of the cookware refer to hob malfunction. automatically to some limit. 5.3 Öko Timer (Eco Timer) The cooking zone efficiency is related to the diameter of the cookware.

  • Page 14: Care And Cleaning

    Heat setting Use to: Time Hints (min) 9 - 12 Gentle fry: escalope, veal as nec‐ Turn halfway through. cordon bleu, cutlets, rissoles, essary sausages, liver, roux, eggs, pancakes, doughnuts. 12 - 13 Heavy fry, hash browns, loin 5 - 15 Turn halfway through.
  • Page 15 ENGLISH Problem Possible cause Remedy The fuse is blown. Make sure that the fuse is the cause of the malfunc‐ tion. If the fuse is blown again and again, contact a qualified electrician. Activate the hob again and set the heat setting in less than 10 seconds.

  • Page 16: Installation

    Problem Possible cause Remedy The Child Safety Device or Refer to "Daily use" chap‐ comes on. the Lock function operates. ter. There is no cookware on Put cookware on the zone. comes on. the zone. The cookware is incorrect.
  • Page 17 ENGLISH 8.1 Before the installation CAUTION! Do not drill or solder the wire Before you install the hob, write down the ends. This is strictly information bellow from the rating plate. forbidden! The rating plate is on the bottom of the hob.
  • Page 18 8.4 Assembly min. 500mm min. 50mm min. min. 2 mm min. 2 mm < 20 mm > 20 mm min. 500 mm min. 500 mm 30 mm 12 mm 57 mm 12 mm 57 mm 28 mm 41 mm...

  • Page 19: Technical Data

    You can not use the protection box if you install the hob above an oven. 9. TECHNICAL DATA 9.1 Rating plate Model KTI8500BE PNC 949 596 511 01 Typ 60 GBD CB AT 220 - 240 V 50 - 60 Hz Induction 7.2 kW Made in Germany Ser.Nr.

  • Page 20: Energy Efficiency

    It changes with the the table. material and dimensions of the cookware. 10. ENERGY EFFICIENCY 10.1 Product information according to EU 66/2014 Model identification KTI8500BE Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cook‐...
  • Page 21 ENGLISH • Use the residual heat to keep the food warm or to melt it. 11. ENVIRONMENTAL CONCERNS Recycle the materials with the symbol marked with the symbol with the household waste. Return the product to . Put the packaging in applicable your local recycling facility or contact containers to recycle it.
  • Page 22 www.electrolux.com...
  • Page 23 ENGLISH...
  • Page 24 www.electrolux.com/shop...
