Page 1
HT-J5500K HT-J5530K HT-J5550K HT-J5550WK User manual 5.1CH Blu-ray™ Home Entertainment System imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register...
Safety Information CAUTION This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any RISK OF ELECTRIC SHOCK. DO NOT OPEN internal part of this product. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO This symbol indicates that important NOT REMOVE THE COVER (OR BACK).
Page 3
3D Precautions ~ Do not allow children to hang on the product. ~ Store the accessories (battery, etc.) in a location safely out of the reach of children. IMPORTANT HEALTH AND SAFETY INFORMATION FOR ~ Do not install the product in an unstable location such 3D PICTURES.
Contents GETTING STARTED NETWORK SERVICES 37 Using BD-LIVE™ Accessories 37 Using DLNA Speaker Components 37 Apps Front Panel 38 Using Opera TV Store Rear Panel 39 Screen Mirroring Remote Control CONNECTIONS APPENDIX 40 Additional Information Connecting the Speakers 13 Connecting to a TV and External Devices 41 Disk and Format Compatibility 14 Connecting to a Network Router 46 Troubleshooting...
Getting Started Speaker Components HT-J5500K Front x 2 Surround x 2 Subwoofer Speaker Cable x 6 Center HT-J5530K Screw (5x15) x 2 Center Screw (5x20) x 8 Speaker Cable x 6 Front x 2 Stand x 2 Stand Base x 2...
Getting Started HT-J5550WK Screw (5x15) x 4 Front x 2 Screw (5x20) x 16 Centre Stand Base x 4 SURROUND SPEAKERS OUT SPEAKER IMPEDANCE : 3Ω ID SET Wireless Receiver Surround x 2 Stand x 4 Subwoofer Speaker Cable x 6 Module (SWA-7000) - English...
Internet or stop the content you are playing on the TV, and then select the BD/DVD mode. ✎ Plug the microphone jack before using Karaoke function. Rear Panel * In case of HT-J5500K/J5530K/J5550K AUX IN SURROUND * FM ANTENNA SURROUND...
Getting Started Remote Control Tour of the Remote Control Press to select Home Theater's Turn the product on and off. mode. (BD/DVD, D. IN, AUX, etc.). FUNCTION To open and close the disc tray. VOLUME MUTE Adjust the volume. Cut off the sound temporarily. Press numeric buttons to operate options.
Connections This section describes various methods of connecting the product to other external components. Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Connecting the Speakers Position of the product Place it on a stand or cabinet shelf, or under the TV stand.
Connections Installing the Speakers on the Tallboy Stand * HT-J5530K only - Front Speakers Stand Base HT-J5550K/J5550WK only - Front/Surround Speakers Turn the Stand Base upside-down and connect it to the Stand. Stand Use the driver to fasten the screws (5x20) on the 4 marked holes.
Page 11
SURROUND SURROUND Front Speaker (R) Subwoofer * Refer to page 5 for the speakers of HT-J5500K/J5550K. ✎ If you place a speaker near your TV set, the screen color may be distorted because of the magnetic field. | CAUTION |...
Page 12
Connections HT-J5550WK Front Speaker (L) Centre Speaker Wireless Receiver Module Subwoofer SURROUND SPEAKERS OUT SPEAKER IMPEDANCE : 3 ID SET Front Speaker (R) Surround Surround Speaker (L) Speaker (R) * This product should be connected with the SWA-7000 only. ✎ If you place a speaker near your TV set, the screen colour may be distorted because of the magnetic field.
Connecting to a TV and External Devices SURROUND SURROUND White Method 1 Method 2 External Devices AUDIO OUT OPTICAL OUT HDMI IN (ARC) Connecting to a TV Connect an HDMI cable from the HDMI OUT jack on the back of the product to the HDMI IN jack on your TV. If the TV supports ARC, you can hear the audio from your TV through the home theater with only this cable connected.
IP router is currently being used by policies may prevent the product from accessing another device nearby, it will result in interference Samsung's software update server. If this occurs, and communication failure. contact your Internet Service Provider (ISP) for ✎...
16:9 Full - For widescreen TVs. Displays ✎ If you use an HDMI cable to connect the product to an Anynet+ (HDMI-CEC)-compliant Samsung widescreen pictures in their original 16:9 format TV and 1.) You have set the Anynet+ (HDMI-CEC) and expands 4:3 pictures to fill the 16:9 screen.
Settings The Home Screen at a Glance 8 Function Use for switching to an external device, and for radio and mode switching for a Bluetooth connection. You can use the remote control’s FUNCTION PLAY DISC PHOTOS VIDEOS MUSIC button and the main unit’s button for mode switching.
When you connect a Samsung product setting. and a Samsung TV with BD Wise to each other EXIT via HDMI, and BD Wise is on in both the product Button : Press to exit the current menu.
Page 18
Settings HDMI Color Format Speaker Selection Lets you set the color space format for the HDMI Lets you select which speakers you want active, output to match the capabilities of the connected either the TV's speakers or the home theater's device (TV, monitor, etc).
Page 19
Lets you test the Internet Protocol setup to see if it the Anynet+ feature and lets you control those is working correctly. products with one Samsung TV remote. To operate Network Status this function, you must connect this product to an Anynet+ Samsung TV using an HDMI cable.
STEREO and MONO. For more information about this function, see page ~ In a poor reception area, select MONO for a clear, interference-free broadcast. Contact Samsung Presetting Stations Provides contact information for assistance with Example : Presetting FM 89.10 into memory.
Network Setup ✎ To delete all Preset FM stations at once, press the TITLE MENU button for about 5 seconds in FM Manual mode until DEFAULT PRESET appears When you connect this product to a network, you on the display. can use network based applications and functions Recording FM Radio such as BD-LIVE and upgrade the product's software...
Settings Wireless - Automatic Network Settings Ğ Ğ Follow the Steps 1 to 3 in "Configuring Your Network Wired network connection failed. Connection". (See page 21) MAC Address XX:XX:XX:XX:XX:XX In the Network Settings screen, change IP Address 0. 0. 0. 0 Subnet Mask 0.
Page 23
✎ You can get the Network parameter values from Enter your wireless network or wireless router's name. your Internet provider. 11. When finished, select Return ( ' ), and then ~ Enter numbers directly using the number press the v button. The Security Key screen buttons on your remote control.
Settings Wi-Fi Direct When you have completed the procedure, you should see a pop-up on your TV screen saying that a device that supports Wi-Fi Direct has The Wi-Fi Direct function allows you to connect Wi- requested to connect. Confirm that the device Fi Direct devices to the product and each other using that is making the request is your device, select Yes in the pop up, and then press the v...
By USB Upgrading Software Visit Samsung's website on a computer and The Software Upgrade menu allows you to upgrade download the update package to a USB device. the product’s software for performance improvements ✎ Save the update package in the USB device's or additional services.
Settings Auto Upgrade Notification If your product is connected to the network and you set Auto Upgrade Notification on, the product will notify you if a new software version is available with a pop-up message. Turn on the product. In the Software Upgrade menu, set Auto Upgrade Notification to On.
Playing Content Your home theater can play content located on Press the ^ button to close the disc tray. Blu-ray/DVD/CD discs, USB devices, PCs, smart Playback starts automatically. phones, tablets, and in Apps. If playback does not start automatically, press To play content located on your PC or a mobile the 6 button on the remote.
Playing Content A screen appears listing the contents of the disc. If necessary, use the ▲▼◄► buttons to select a Depending on how the contents are arranged, folder, and then press the v button. you will see either folders, individual files, or Select a file to view or play, and then press the both.
Controlling Video Playback 2 Using the disc menu, title menu, popup menu, and title list You can control the playback of video content located DISC MENU on a Blu-ray/DVD disc, USB device, mobile device, FUNCTION or PC. Depending on the disc or contents, some of During playback, press this button to display the VOLUME MUTE...
Playing Content Using the TOOLS Menu Menu selections that appear only when a BD/DVD disc plays TOOLS During playback, press the button. Title Chapter If there is more than one title on a disk or device, Lets you move to a chapter that you want to lets you move to or select a desired title.
Creating a Video Playlist Buttons on the Remote Control used FUNCTION for Music Playback You can create a playlist of video files in nearly the VOLUME MUTE same way you create a playlist of music files. See page 32 for instructions. Select video files instead of music files.
Page 32
Playing Content Creating a Music Playlist Ripping If you are playing music from a commercial CD Insert a USB device into the USB jack on the RETURN or DVD, press the 5 or button. The front of the product. Music List Screen appears. If you are creating With the Playback screen displayed, use the ▲▼...
Playing Photo Content Using Karaoke You can play photo content located on a DVD, USB, You can enjoy the Karaoke with music. mobile device, or PC. Connect the microphone on the front of the Using the Tools Menu product. In the Home menu, select the Settings, and then TOOLS During playback, press the button.
Playing Content To Connect the Home Theater to a Bluetooth Using Bluetooth Device You can use a Bluetooth device to enjoy music with high quality stereo sound, all without wires! ~ Pairing distance : max. 2M, Connect Operating distance : max. 10M ~ Actual Bluetooth performance may differ depending on your environment, even if you use your Bluetooth device within the specified...
Using the Bluetooth Quick Start - If the Bluetooth device is turned off, not in place, or malfunctions. When the home theater is turned off, connecting Note that such devices as microwave ovens, wireless your smart device to the product via a Bluetooth LAN adapters, fluorescent lights, and gas stoves use connection can turn the home theater on.
Page 36
Playing Content Use TV SOUND: Ğ 1) When you want to listen to the TV's audio through the home theater speakers. 2) When you want to listen to the audio from a USB device plugged into the TV through the home theater speakers.
Network Services On your home theater, select Change Device. Using BD-LIVE™ Use the ▲▼ button to select your PC in the Device List. Connect the product to your network. Select the kind of file you want to view or play, PHOTOS, VIDEOS, or MUSIC and then press (See page 14) Configure the network settings.
Network Services Using Apps Using Opera TV Store The first time you access any one of the apps, the At the Opera TV Store, you will find high-quality home theater displays two agreements. You must Internet video streaming, social network, and music accept both agreements to download and use any streaming services.
Deleting Apps from MY APPS The TV displays a connecting message (for example, Connecting to Android_92gb...) and Highlight the MENU button on the top of the My then displays the connected message. Apps screen, and then press the v button on In a few moments, the screen of your device your remote.
~ This function is not available if the HDMI cable does not support CEC. ~ Depending on the disc type, some aspect ratios ~ If your Samsung TV has an Anynet+ logo, then it may not be available. supports the Anynet+ function.
Playing JPEG files Speaker Settings ~ When Speaker Selection is set to TV Speaker, ~ You can’t enlarge the subtitle and PG graphics in the full screen mode. audio is produced by the TV speakers. Playing Content HDMI audio Using the TOOLS button while playing pictures ~ When HDMI audio is output to the TV speakers, it is...
Please note that this is not a defect in the product. do not match, the disc will not play. ✎ Samsung cannot guarantee that this product will The Region Number for this product is displayed on the play every disc bearing the Blu-ray Disc, DVD, or CD rear panel of the product.
~ "x.v.Color" is a trademark of Sony Corporation. HDD manufacturer. ~ "AVCHD" and the AVCHD logo are trademarks of ~ SAMSUNG is not responsible for any data file damage Matsushita Electronic Industrial Co., Ltd. and Sony or data loss. Corporation.
Page 44
Appendix Video File Support File Extension Container Video Codec Audio Codec Resolution DivX 3.11/4/5/6 MP3, Dolby Digital, DTS, *.avi MP4v3 WMA, PCM H.264 BP/MP/HP VC-1 AP, DivX 5/6 *.mkv MP3, Dolby Digital, DTS H.264 BP/MP/HP VC-1 AP *.wmv 1920x1080 (wmv9) VC-1 SM MP4 (mp4v) *.mp4...
Page 45
Digital Output Selections Bitstream Bitstream Bitstream Setup (Re-encoded (Unprocessed) (Re-encoded DTS) Dolby D) Connection HDMI supported AV receiver Up to PCM 7.1ch Dolby Digital Dolby Digital Dolby Digital Dolby Digital Plus Plus Audio Dolby TrueHD Dolby TrueHD Re-encoded Stream on DTS re-encoded Dolby Digital * Up to PCM 5.1ch...
Refer to the table below when this product does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off the product, disconnect the power cord and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom Check/Remedy You cannot eject the disc.
Page 47
Symptom Check/Remedy Dolby Digital 5.1 CH ~ Is there "Dolby Digital 5.1 CH" mark on the disc? Dolby Digital 5.1 CH Surround Surround Sound is not Sound is produced only if the disc is recorded with 5.1 channel sound. produced. ~ Is the audio language correctly set to Dolby Digital 5.1-CH in the information display? The remote control does...
Page 48
Appendix Symptom Check/Remedy "Not Available" appears on ~ The feature is unavailable or the action cannot be completed at this time because: screen. 1. The Blu-ray/DVD disc's software restricts it. 2. The Blu-ray/DVD disc's software doesn’t support the feature (e.g., angles) 3.
Subwoofer speaker output 170W (3Ω) Amplifier Frequency response 20Hz~20kHz (±3dB) S/N Ratio 70dB Channel separation 60dB Input sensitivity (AUX) 500mV HT-J5500K Speaker Weights Dimensions (W x H x D) Impedance Frequency range Rated input (Unit : mm) system (Unit : kg) Front 83.4 x 170.5 x 101.0...
Page 50
6.50 ✎ Network speeds equal to or below 10Mbps are not supported. ✎ Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. ✎ Weight and dimensions are approximate. ✎ Design and specifications are subject to change without prior notice.
Licenses Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, DTS-HD, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS-HD Master Audio | Essential is a trademark of DTS, Inc.
Page 54
使用 3D 功能 將配件 (電池等) 安全地貯藏在兒童夠不著的 位置。 3D 圖片的重要健康和安全資訊。使用 3D 功能 不要將產品安裝在不平穩的位置 (例如搖搖 之前,請閱讀並理解以下安全資訊。 晃晃的架子或傾斜的地板) 或會震動的位 有些觀眾觀看 3D 電視機時可能會遇到不 置。 適,例如頭暈,噁心和頭疼。如果您遇到任 不要使產品摔到地上,也不要敲擊產品。 如 何這類症狀,請停止觀看 3D 電視機,摘下 果產品受損,請拔下電源插頭並與服務中心 3D 有源眼鏡並休息。 聯絡。 長時間觀看 3D 影像可能導致眼睛疲勞。如 若要清潔本裝置,請從牆上插座拔下電源插 果您感到眼睛疲勞,請停止觀看 3D 電視, 頭,然後用柔軟,乾燥的布料擦拭產品。不 摘下 3D 有源眼鏡並休息。 要使用任何化學品,例如蠟,苯,酒精,稀...
Page 56
使用入門 音箱組件 HT-J5500K 前置音箱 x 2 環繞音箱 x 2 音箱纜線 x 6 中置音箱 重低音音箱 HT-J5530K 螺釘 (5x15) x 2 音箱纜線 x 6 螺釘 (5x20) x 8 中置音箱 前置音箱 x 2 支架 x 2 支架基座 x 2 環繞音箱 x 2 重低音音箱...
Page 57
使用入門 HT-J5550WK 螺釘 (5x15) x 4 前置音箱 支架基座 x 4 螺釘 (5x20) x 16 中置音箱 SURROUND SPEAKERS OUT SPEAKER IMPEDANCE : 3Ω ID SET 環繞音箱 支架 x 4 音箱纜線 x 6 無線接收器模組 重低音音箱 (SWA-7000) - 繁體中文...
Page 58
放影片,必須在光碟功能表中選擇 Play Movie (播放影片) 或 Start (開始),然後按 鍵。 ✎ 如果您正在使用互聯網或正在電視上透過家庭影院播放 USB 裝置中的內容,則無法透過 FUNCTION (功能) 按鈕選取 BD/DVD 模式。若要選取 BD/DVD 模式,請退出互聯網或停 止正在電視上播放的內容,然後選取 BD/DVD 模式。 ✎ 使用卡拉 OK 功能之前插入咪高風。 背面板 * HT-J5500K/J5530K/J5550K SURROUND 外部模擬音頻輸入 * FM 天線 SURROUND 冷卻風扇 HDMI 輸出 外部數位音訊輸入 (光學) LAN 接線端...
Page 59
使用入門 遙控器 遙控器按鍵說明 按下可選取家庭影院的模 開啟或關閉本產品。 式。(BD/DVD,D. IN, FUNCTION AUX 等)。 打開和關閉光碟托架。 VOLUME MUTE 調整音量。 暫時切斷聲音。 按下數位鍵進行選擇。 DISC MENU TITLE MENU 用於進入快顯功能表 / 標題 按該鍵可檢視光碟功能表。 POPUP 功能表。 按該鍵可前後跳動。 按該鍵可前後搜尋。 按下可播放光碟或檔案。 按下可暫停播放。 按下可停止播放光碟或檔案。 KARAOKE HOME REPEAT 按該鍵可使用卡拉 OK 功能。 允許您重複標題,章節, (咪高風音量, 迴聲, 音調控制) 曲目或光碟。...
Page 68
DISC MENU TITLE MENU POPUP 遙控器上用於設定功能表的鍵 設定功能表功能 KARAOKE HOME REPEAT 圖像 3D 設定 TOOLS INFO 設定 3D 相關功能。 3D Blu-ray 播放模式: 選擇是否在 3D 模 EXIT RETURN 式下播放包含 3D 內容的 Blu-ray 光碟。 如果在 3D 模式中移至首頁功能表,產品 TUNER MEMORY MO/ST HOME 將自動切換至 2D。 (首頁) 鍵:按該鍵可移至主螢...
Page 72
✎ 如需同時刪除所有預設 FM 電台,在 網絡設定 FM 手動模式下按 TITLE MENU (標題功 能表) 鍵 5 秒,直至螢幕顯示 DEFAULT 當將本產品連接至網絡時,您可以使用網絡 PRESET (預設)。 型應用程式和 BD-LIVE 等功能,還可以透過 錄製 FM 廣播 網絡連線升級產品的軟件。 您可以在插入的 USB 儲存裝置上錄製您最 設定您的網絡連線 愛的廣播節目。 要開始設定您的網絡連線,請執行以下步 將 USB 裝置插入產品正面的 USB 插 驟: 孔。 FUNCTION 在主螢幕中,選擇 設定,然後按 v (功能) 鍵以選擇...
Page 79
播放內容 如有必要,請使用 ▲▼◄► 按鈕選擇資 將會出現一個列出光碟內容的畫面。視 內容的排列方式而定,您將會看到資料 料夾,然後按下 v 鍵。 夾,個別檔案或兩者。 選擇要檢視或播放的檔案,然後按下 如有必要,請使用 ▲▼◄► 按鈕選擇資 v 鍵。 RETURN 料夾,然後按下 v 鍵。 按下 鍵結束資料夾,或者按 EXIT 使用 ▲▼◄► 按鈕選擇要檢視或播放的 下 鍵返回主螢幕。 檔案,然後按下 v 鍵。 請參閱第 29~33 頁,以瞭解如何控制播 RETURN 放 USB 裝置上的相片,視頻和音樂。 按下一次或多次 鍵以結束目 前的畫面,結束資料夾或返回主螢幕。...
Page 80
控制視訊播放 2 使用光碟功能表,標題功能表,快顯 功能表和標題清單 FUNCTION 您可以控制位於 Blu-ray/DVD 光碟,USB 裝 DISC MENU (光碟功能表) VOLUME MUTE 置,手機裝置或 PC 上的視訊檔案之播放。 本說明書中介紹的一些功能可能不可用,具 在播放過程中,按此鍵可顯示光碟功能表。 體取決於光碟或內容。 TITLE MENU (標題功能表) 遙控器上用於播放視訊的按鍵 在播放過程中,按此鍵可顯示標題功能表。 綠色 (B) DISC MENU TITLE MENU 如果光碟中有播放清單,按 按 POPUP 鈕可移至播放清單。 POPUP MENU (快顯功能表) 在播放過程中,按此鍵可顯示快顯功能 KARAOKE HOME REPEAT 表。...
Page 100
環繞音箱輸出 170W (3Ω) 重低音音箱輸出 放大器 20Hz~20kHz (±3dB) 頻率回應 70dB 訊噪比 聲道分離度 60dB (AUX) 500mV 輸入靈敏度 HT-J5500K 尺寸(寬 x 高 x 厚) 重量 音箱系統 阻抗 頻率範圍 額定輸入 (單位 : 毫米) (單位 : 千克) 83.4 x 170.5 x 101.0 0.45 前置音箱 165W 200Hz ~ 20kHz 83.4 x 129.0 x 101.0...
Page 101
268.8 x 87.6 x 101.0 0.58 中置音箱 170W 20Hz ~ 200Hz 220.6 x 380.6 x 364.7 6.50 重低音音箱 不支援網速小於或等於 10Mbps。 Samsung Electronics Co., Ltd 保留隨時變更規格的權利,恕不另行通知。 重量和尺寸為估計值。 設計和規格如有變更,恕不提前通知。 如需電源和功耗的詳細資訊,請參閱本產品隨附的標籤。 SWA-7000 (僅適用 HT-J5550WK) 0.73 千克 165W x 2 CH 重量 輸出...
Page 102
授權 根據 Dolby Laboratories 的許可證製造。Dolby, Pro Logic 和雙 D 符號是 Dolby Laboratories 的商標。 如需 DTS 專利,請造訪 http://patents.dts.com。在 DTS Licensing Limited 的 授權下製造。DTS,DTSHD,符號以及 DTS 和符號一起是 DTS, Inc. 的註冊 商標,DTS-HD Master Audio | Essential 是 DTS, Inc. 的商標。 DTS, Inc. 版權 所有。 此...
Page 103
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. 在全球範圍內聯絡三星 如果您有任何關於三星產品的問題或建議,請聯絡三星客戶服務中心。 Area Contact Centre Web Site ` Asia Pacific AUSTRALIA 1300 362 603 www.samsung.com/au/support NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com/nz/support...
