Enclosures
3
Installation
For enclosure details, see the following figure:
Figure 3.1: AE2 and AE4 enclosure features
3.1
Installing enclosure
To install an enclosure, follow these instructions:
1.
2.
3.
Bosch Security Systems, Inc.
1 Top enclosure mounting holes (2 per
enclosure)
3 ICP-EZTS Tamper Switch mounting
holes (3)
5 Grounding pin for connecting
transformer to base
7 Support post assembly
9 Screw to connect mounting clip or
mounting clip and printed circuit
board to enclosure
11 Mounting location for lockset
13 Knockouts for wiring
Knock out the desired wire entrances on the enclosure.
Using the enclosure as a template, mark the top mounting holes on the mounting surface.
Start installing the mounting hardware (as determined by surface and weight of
enclosure, modules, and batteries) for these two holes.
2 Control panel\module mounting
4 Grounding pins for connection
6 Transformer mounting holes
8 Possible printed circuit board
10 AE2/AE4 Enclosure standoff
12 Battery mounting location (two 7 Ah,
14 Bottom enclosure mounting holes (2
Installation Manual
Installation | en
locations
enclosure cover to base
mounting locations
12 Ah, or 18 Ah batteries)
per enclosure)
2016.06 | 02 | F.01U.282.190
