REPAIR INSTRUCTION HR1871/00 /05 / HR1873/00 1. Remove the Bottom First you have to remove the anti slip ring. Open all 4 screws (T15) to remove the Bottom. Anti slip ring 2. Change the driving shaft First you have to remove the bottom (see point 1.) Remove the cap, use a small screw driver.
Page 6
REPAIR INSTRUCTION HR1871/00 /05 / HR1873/00 4. Remove the safety switch When you open both fl aps you can remove the safety switch. 5. Remove the locking arm Remove on each side the springs. Open the screw on both sides.
Page 7
REPAIR INSTRUCTION HR1871/00 /05 / HR1873/00 Circuit diagram High Voltage Version (without brake) Circuit SC7303 breaker 15µH 100R@25MHz Safety 10A/250VAC Switch RS2006M 220 - 240 V DD-30R 10D471 560k 224/275VAC 474/275VAC G5T22 15µH 100R@25MHz Locking Arm Switch 104/400V 51 T1210T-61...
