Operating and installation instructions Refrigerator with PerfectFresh zone and DynamicCooling K 14827 SD K 14827 SD ed/cs (-1) en - AU, NZ To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time.
Guide to the appliance a On/Off sensor e Temperature display b SuperCool sensor f "Cooling" symbol c Sensor for setting a lower g Sensor for setting a higher temperature (X) temperature (Y) d Safety lock indicator light h Alarm off sensor (only visible when Safety lock is (only visible when the door alarm activated)
Page 5
Guide to the appliance a DynamicCooling fan b Ceiling lighting c Butter and cheese compartment d Universal container e Egg tray/Condiment tray f Bottle rack g Active charcoal filter holder h Adjustable shelves i Bottle shelf j Bottle divider k Condensate channel and drain hole l PerfectFresh zone, dry compartment m Control for setting the moisture level...
Caring for the environment Disposal of the packing Disposing of your old material appliance The transport and protective packing Electrical and electronic appliances has been selected from materials which often contain materials which, if are environmentally friendly for disposal handled or disposed of incorrectly, and can normally be recycled.
They contain important notes on the installation, safety, operation and care of the appliance. Miele cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.
Page 8
Furthermore, the appliance must not be operated in areas where explosions may occur. Miele cannot be held liable for damage resulting from improper or incorrect use of the appliance. This appliance is not intended for use by persons (including...
Page 9
In the event of any damage: – avoid any flames or anything which creates a spark, – switch off at the mains and unplug the appliance, – ventilate the room where the appliance is located for several minutes, and – call Miele.
Page 10
If the connection cable is faulty, it must only be replaced by a Miele approved service technician to protect the user from danger. Do not connect the appliance to the mains electricity supply by a multi-socket unit or an extension lead.
Page 11
Repairs and other work by unqualified persons could be dangerous. Installation work and repairs to electrical appliances must only be carried out by a Miele approved service technician. The manufacturer's warranty will be invalidated if the appliance is not repaired by a Miele approved service technician.
Page 12
Follow the instructions given on the food manufacturer's packaging regarding storage conditions and "use by" dates. Use only Miele Original spare parts. If spare parts or accessories from other manufacturers are used, the warranty will be invalidated, and Miele cannot accept liability.
Page 13
Warning and Safety instructions The following applies to stainless steel appliances: Do not place sticky notes, adhesive tape, masking tape or any other adhesive agent on the treated surface of the door. The coating will become damaged and lose its protective properties against soiling.
Page 14
Warning and Safety instructions Disposal of your old appliance Before disposing of an old appliance, first make the door lock unusable. This way you will prevent children from accidentally locking themselves in and endangering their lives. Be careful not to damage any part of the pipework whilst awaiting disposal, e.g.
How to save energy Normal energy Increased energy consumption consumption Installation/Maint- In a ventilated room. In an enclosed, enance unventilated room. Protected from direct In direct sunlight. sunlight. Not situated near a heat Situated near a heat source source (radiator, oven). (radiator, oven).
Page 16
How to save energy Normal energy Increased energy consumption consumption Do not change the arrangement of the drawers and shelves as when delivered. Only open the door when Frequent opening of the door necessary and for as short a for long periods will cause a time as possible.
^ Touch the On/Off sensor until the strips and frames. temperature display comes on. ^ Also apply the Original Miele care The appliance will start to cool, and the product for stainless steel to the side interior lighting will come on when the panels after removing the protective door is opened.
Switching on and off Switching off Settings mode Certain settings on the appliance can only be selected in the settings mode. How to select the settings mode and how to change the settings is ^ Touch the On/Off sensor until all of described in the relevant section of the indicators go out.
Switching on and off Switching the sensor tones on/off Activating or de-activating the safety lock The sensor tone which sounds each time a sensor is touched can be The safety lock can be activated to deactivated. prevent the appliance being switched off inadvertently.
Switching on and off You have now left the settings mode. The safety lock indicator will light up in the temperature display when the safety lock has been activated. Switching off for longer periods of time If the appliance is not going to be used for a longer period of time, e.g.
The correct temperature DynamicCooling It is very important to set the correct temperature for storing food in the The DynamicCooling fan automatically appliance. Micro-organisms will cause switches on when the cooling system food which is not stored at the correct for the refrigerator switches on.
The correct temperature – Leaving a finger on the sensor, adjusts the temperature continuously. When the highest or lowest ^ Touch and leave your finger on the X temperature in the range is reached, the X or Y sensor disappears. sensor.
The correct temperature ^ Leave your finger on the X sensor for § 5 is the default setting for the another 5 seconds until c appears in PerfectFresh zone. If a setting of § 1 the display. to § 4 is selected, the temperature ^ Touch the X sensor repeatedly until d can fall below 0°C.
Alarm To switch off the door alarm Your appliance has been fitted with an alarm to avoid energy being wasted if whilst the door is still open the door is left open and to prevent If you want to keep the door open stored food becoming too warm.
SuperCool The SuperCool function The SuperCool function can be used to rapidly reduce the temperature in the refrigerator to its lowest setting (depending on the room temperature). Switching on SuperCool SuperCool is particularly recommended for the faster chilling of large amounts of fresh food or drink.
Using the refrigerator efficiently Different storage zones – pre-packed vegetables and other fresh food with a label stating it Due to the natural circulation of the air should be kept at a temperature of in the appliance, there are different approx.
Using the refrigerator efficiently Food which should not be Storing food correctly stored in a refrigerator Food should generally be stored covered or packaged in the refrigerator Not all food is suitable for refrigeration at section (there are some exceptions to temperatures below 5 °C.
Using the PerfectFresh zone Food is stored in the PerfectFresh zone The closer the storage humidity is to the at lower temperature than in the moisture content of the food, the crisper conventional refrigerator section. The and fresher the food remains over a humidity in the PerfectFresh zone can longer period, as the water content of be regulated to provide the correct...
Using the PerfectFresh zone Setting , = low humidity. Always keep these foods covered or wrapped. The regulator opens the openings to Exception: Meat (The surface of the the compartment and the air within is meat dries out slightly, helping to able to escape.
Page 30
Using the PerfectFresh zone Examples of fruit and vegetables which produce a large amount of this natural gas are: Apples, apricots, pears, nectarines, peaches, plums, avocados, figs, blueberries, melons and beans. Examples of fruit and vegetables which react strongly to the natural gases given off by other types of fruit and vegetables are: Kiwis, broccoli, cauliflower, Brussels...
Page 31
Using the PerfectFresh zone If you are not satisfied with the results of your stored food (e.g. food loses firmness and wilts shortly after placing in the appliance), keep in mind the following instructions: ^ Only place fresh food in the appliance as the initial condition of the food is crucial to maintaining freshness.
Adjusting the interior fittings Moving the shelves To move the split shelf: ^ Take both halves of the split glass The shelves can be adjusted according to the height of the food. shelf out, ^ Raise the shelf, and pull it forwards slightly until the notch at the side is in line with the shelf support.
Adjusting the interior fittings PerfectFresh zone Adjusting the condiment compartments tray/bottle shelf ^ Lift the tray/shelf up and out of the The compartments in the PerfectFresh zone are on telescopic rails, and can stainless steel frame to remove. be removed for filling, emptying or ^ Push up the stainless steel frame, cleaning purposes.
Adjusting the interior fittings Universal container Moving the bottle divider (depending on model) The bottle divider can be moved to the left or right to ensure that bottles are The universal container can be used held securely in position when the door both to store and serve food.
Automatic defrost Refrigerator section and PerfectFresh zone The refrigerator section and the PerfectFresh zone defrost automatically. Condensate and frost can build up on the back wall of the refrigerator section and the PerfectFresh zone whilst in use. You do not need to remove this, as it will defrost and evaporate automatically with the warmth generated by the appliance.
– dirt erasers, special coating that is not susceptible to soiling. – sharp metal scrapers. Do not apply the Original Miele care product for stainless steel to the Before cleaning doors as visible smearing will occur. ^ Switch off the appliance.
Cleaning and care To remove the stainless steel panel from the lid of the butter and cheese compartment, proceed as follows: ^ Take out the entire butter and cheese compartment. ^ Open the lid. The stainless steel panel is fitted ^ Take hold of the dividing plate with tightly to the plastic lid and needs to both hands and slide it out.
Original Miele care product for high quality surface coating. It protects stainless steel. against soiling and facilitates cleaning ^ Apply the Original Miele care product and care. for stainless steel each time you clean the appliance. Do not use the following on the...
Miele care product for stainless steel. appliance (heat exchanger) should be dusted at least once a year. A build-up ^ Apply the Original Miele care product of dust will increase the energy for stainless steel to the side panels consumption of the appliance.
If you do not have new active charcoal filters, you can order them from your Miele Chartered Agent or from the Miele Spare Parts Department. You can switch off the Change active charcoal filter indicator early if you would prefer not to have the red indicator showing.
Page 41
(in holders) in the appliance. Active charcoal filters and holders ^ At the same time, briefly touch the can be obtained from your Miele Chartered Agent or from the Miele On/Off sensor (without letting go of the X sensor).
If this is the case, contact a qualified ^ Check that the door closes properly. electrician or Miele..the compressor runs . . . the appliance does not get cool continuously.
Page 43
. . . the floor of the refrigerator is wet. The LED lighting may only be repaired The condensate drain hole is blocked. or changed by a Miele service ^ Clean the condensate channel and technician because there are live parts drain hole.
Noises Normal noises What causes them Humming noise made by the motor (compressor). This noise can Brrrrr ... get louder for brief periods when the motor is switching on. Blubb, blubb..A gurgling noise can be heard when coolant is circulating through the pipes.
In the event of a fault which you cannot correct yourself, please contact: – Miele. You will find the address and telephone number of Miele on the back cover of the manual. When contacting Miele, please quote the model and serial number of your appliance.
Information for Chartered Agents Demonstration mode The old setting lights up, and your newly selected setting flashes. The appliance can be displayed in the ^ Touch the On/Off sensor to confirm demonstration mode. When this is activated, the controls and lighting are the new setting.
Electrical connection All electrical work should be carried out Do not connect the appliance to the by a suitably qualified and competent mains electricity supply by an extension person in strict accordance with current lead or a plug adapter. Extension leads local and national safety regulations.
This condensation can cause Miele or your Chartered Agent will be corrosion on the outer walls of the able to advise you on which models appliance. are suitable to being installed...
Installation Appliance with supplied wall Climate range spacers The appliance is designed for use within certain climate ranges (ambient The wall spacers, which are temperatures), and should not be used supplied with some appliances, outside this range. The climate range of need to be used for the appliance to the appliance is stated on the data achieve its declared energy...
Installation Installation On stainless steel appliances ^ Remove the cable clip from the back of the appliance. ^ Check that all parts at the back of the appliance are unhindered. Carefully remove any hindrance. ^ Carefully push the appliance into position.
Installation Appliance dimensions K 14827 SD 1850 mm 600 mm 630 mm* K 14827 SD ed/cs (-1) * Depth without wall spacers fitted. If wall spacers are fitted, the appliance depth is increased by approx. 35 mm.
Changing the door hinging The appliance is supplied with Removing the door handle right-hand door hinging. If left-hand door hinging is required, the hinging must be changed. To change the door hinging, you will need the following tools: Two people are needed to change the door hinging.
Page 53
Changing the door hinging ^ Fit restraining clip b (supplied with Removing the SoftClose door the appliance) onto SoftClose mechanism mechanism c. The SoftClose door mechanism is at the bottom of the door. The restraining clip stops the hinge from snapping shut. Do not remove the ^ Open the appliance door.
Page 54
Changing the door hinging Changing over the door Remove any food from the door shelves. ^ Close the appliance door. ^ Slide SoftClose mechanism bracket f as far as it will go towards the handle side of the door, and undo screws g on the SoftClose mechanism.
Page 55
Changing the door hinging ^ Then separate retaining plate f from cover e by pushing it slightly to the left. Then pull the cover forwards and off. ^ Rotate retaining plate f by 180°. ^ Then fit cover e from the front over retaining plate f, and slide it over to the right.
Page 56
Changing the door hinging ^ Screw hinge plate f into position on Changing the bearing the opposite side using the two outer Important! The height of the long slots only. Do not use the appliance door can be adjusted on middle screw because you will not this stainless steel appliance.
Page 57
Changing the door hinging ^ Unscrew bearing i from hinge plate ^ Screw hinge plate g into position on g, rotate it by 180° and refit into the the opposite side using the two outer hole on the opposite side of the hinge long slots only.
Page 58
Changing the door hinging Fitting the appliance door Replacing the SoftClose door mechanism ^ Place the door onto hinge pin c. ^ Close the appliance door. ^ Remove cover a from panel b, rotate it by 180° and refit it on the other side.
Page 59
Changing the door hinging The screw holes on the left and right must line up perfectly. ^ First screw the SoftClose mechanism onto the appliance side, then onto the handle side c, pushing it firmly towards the appliance. ^ Replace panel b onto the SoftClose mechanism from above, clicking it back into place first at the bottom and then at the top.
Page 60
Changing the door hinging Refitting the handle It is important to check that the side section of the handle d does not Please make sure you follow the instructions below carefully when come into contact with the door seal you refit the handle. The door seal when opening the door as this would will be damaged if the handle is damage the door seal permanently.
Aligning the appliance door The appliance door can be For appliances with height adjustable retrospectively aligned to the housing doors (stainless steel appliances) using the outer long slots in the lower The height of the appliance door can hinge plate. be retrospectively adjusted on the outer, lower hinge plate.
Building in the appliance The appliance can be installed in a kitchen run. To match the height of the rest of the kitchen, the appliance can be fitted with a suitable top box a. A ventilation gap of at least 50 mm depth must be allowed for behind the appliance across the entire width of the top box for air to circulate.
Page 64
Alteration rights reserved / 0813 M.-Nr. 09 432 270 / 00 K 14827 SD, K 14827 SD ed/cs (-1)
