Sony SLV-SE210B Service Manual

Hide thumbs Also See for SLV-SE210B:
Table of Contents

Advertisement

Quick Links

QQ
3 7 63 1515 0
SERVICE MANUAL
System
TE
Channel coverage
L 13942296513
PAL (I): (SLV-SE210G)
UHF B21 to B69
PAL (B/G)
(SLV-SE210B/SE210D/SX110B/
SX110A):
VHF E2 to E12
Italiens VHF A to H
UHF E21 to E69
CATV S01 to S05, S1 to S20
HYPER S21 to S41
SECAM (L)
(SLV-SE210B/SX110B):
VHF F2 to F10
UHF F21 to F69
CATV B to Q
HYPER S21 to S41
RF output signal
(SLV-SE210G/SE210D/SX110D)
UHF channels 21 to 69
Aerial out
75-ohm asymmetrical aerial socket
Tape speed
SP: PAL
23.39 mm/s
(recording/playback)
NTSC 33.35 mm/s
(playback only)
SECAM
(SLV-SE210B/SX110B)
23.39 mm/s
(recording/playback)
www
.
http://www.xiaoyu163.com
SLV-SE210B/SE210D/SE210G/
LP: PAL (SLV-SE210G)
Maximum recording/playback time
10 hrs. in LP mode (with E300 tape)
(SLV-SE210G)
5 hrs. in SP mode (with E300 tape)
Rewind time
Approx. 60 sec. (with E180 tape)
Inputs and outputs
AV1 (EURO AV)
21-pin
Video input: pin 20
Audio input: pins 2 and 6
Video output: pin 19
Audio output: pins 1 and 3
AV2 IN (SLV-SE210B/SE210D)
21-pin
Video input: pin 20
Audio input: pins 2 and 6
x
ao
u163
y
i
http://www.xiaoyu163.com
2 9
8
Photo: SLV-SE210
SPECIFICATIONS
MESECAM
Q Q
(SLV-SE210B/SE210D/SX110B/
3
6 7
1 3
SX110D)
23.39 mm/s
(recording/playback)
11.70 mm/s
(recording/playback)
NTSC (SLV-SE210G)
16.67 mm/s
(playback only)
VIDEO CASSETTE RECORDER
.
SX110A/SX110B
9 4
2 8
RMT-V257D/V257E
France Model
SLV-SE210B/SX110B
Italy Model
Germany Model
North Europe Model
SLV-SE210D/SX110A
UK Model
TS-10 MECHANISM
Refer to the SERVICE MANUAL of VHS
MECHANICAL ADJUSTMENT MANUAL
VII for MECHANICAL ADJUSTMENTS.
(9-921-790-11)
General
Power requirements
1 5
0 5
8
2 9
9 4
240 V: (SLV-SE210G)
230 V: (SLV-SE210B/SE210D/
SX110A/SX110B)
AC, 50 Hz
Power consumption
15 W
3 W (ECO. MODE is set to ON,
Standby mode)
Operating temperature
5 C to 40 C
Storage temperature
–20 C to 60 C
Dimensions
Approx. 360 × 94 × 255 mm (w/h/d)
including projecting parts and controls
Mass
Approx. 2.8 kg (SLV-SE210G)
Approx. 2.6 kg (SLV-SE210B/
SE210D/SX110A/SX110B)
Supplied accessories
Remote commander (1)
R6 (size AA) batteries (2)
Aerial cable (1)
PERITEL cable (1)
(SLV-SE210B/SX110B)
Design and specifications are subject to
change without notice.
m
co
9 9
SLV-SE210G
2 8
9 9
