Philips 150S4FG/00 Service Manual

15" tft lcd colour monitor
Hide thumbs Also See for 150S4FG/00:
Table of Contents

Advertisement

Quick Links

15" TFT LCD Colour Monitor
Service
Service
Service
Description
Important Safety Notice..................................2
Installation & Accessories...............................6
Clock & Phase Adjustments............................7
Advanced Control of OSD...............................8
OSD Attention Signal.....................................10
Troubleshooting............................................11
Failure Mode of LCD Panel............................ 12
Flat Panel Adjust (FP Adjust)..........................13
Definition of Pixel Defects..............................14
Wiring Diagram..............................................15
Mechanical Instructions.............................. ...16~18
Electrical Instructions.....................................19
Factory Adjustment........................................ 20
Safety Test Requirements...............................21
DDC Instructions............................................22~28
DDC Data.......................................................29~31
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Published by BCU Monitor
Printed in Taiwan

TABLE OF CONTENTS

Page
Description
Repair Flow Chart...........................................32~34
Colour Adjustment..........................................35~41
Repair tips......................................................42
Input DVI & D-SUB Diagram............................44
ROM Diagram.................................................45
Scaler Diagram...............................................46
Power Diagram...............................................47
Power board Diagram .....................................48
Power board_B Diagram..................................49
Power board C.B.A..........................................51
Scaler board C.B.A.........................................52~53
Exploded View.................................................55
Recommended Parts List.................................56
Spare Parts List..............................................57~58
General product Specification..........................59~78
Different Parts List -................. . ........................79
SAFETY NOTICE
Copyright reserved
Subject to modification
HUDSON 3
150S4FG/00(Hannstar)
Horizontal frequencies
Dec 15 2002
M
30 - 61 kHz
Page
GB
3138 106 10255

Advertisement

Table of Contents
loading

Related Manuals for Philips 150S4FG/00

Summary of Contents for Philips 150S4FG/00

  • Page 1: Table Of Contents

    15" TFT LCD Colour Monitor HUDSON 3 Service Service Service 150S4FG/00(Hannstar) Horizontal frequencies TABLE OF CONTENTS 30 - 61 kHz Page Description Description Page Important Safety Notice........2 Repair Flow Chart...........32~34 Technical Data & Power Management .....3~4 Colour Adjustment..........35~41 Description of Controls Connection to PC..5 Repair tips............42...
