Haier AS24GS1ERA Service Manual

Wall mounted type dc inverter ek&em-series
Hide thumbs Also See for AS24GS1ERA:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual , Installation Manual
AS24GS1ERA
indoor unit and remote controller(W)
AS24GS2ERA
indoor unit and remote controller(HD)
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or
repair the product or products dealt with in this service information by anyone else could result in serious injury or death

SERVICE MANUAL

DC Inverter
Model No.
WARNING
All right reserved .Unauthorized copying and distribution is a violation of law
Haier Group

Wall mounted Type

EK&EM-Series
AS24GS1ERA
AS24GS2ERA
1U24GS1ERA
1U24GS1ERA outdoor unit
©2011 (Qingdao Haier Air Conditioner General corp.,Ltd)
Order No.$&69

Advertisement

Table of Contents
loading

Related Manuals for Haier AS24GS1ERA

Summary of Contents for Haier AS24GS1ERA

  • Page 1: Service Manual

    ©2011 (Qingdao Haier Air Conditioner General corp.,Ltd) All right reserved .Unauthorized copying and distribution is a violation of law...

  • Page 2: Table Of Contents

    AS24GS1/2ERA 1U24GS1ERA-SM 1. Introduction..................... 1 2. List of Functions..................6 3. Specifications................... 7 4. Printed Circuit Board Connector Wiring Diagram......... 9 5. Functions and Control................14 5.1 Main functions and control specifications of indoor nit......14 5.2 The control system of outdoor unit............21 5.3 Value of thermistor...................
  • Page 3 AS24GS1/2ERA 1U24GS1ERA-SM 9.9 Removal of Outdoor panel..............102 9.10 Removal of Electrcal Box..............104 9.11 Removal of the Side panel..............105 9.12 Removal of Fan Motor................. 107 9.13 Removal of Compressor and Heat Exchanger........111 10. Wiring Diagrams................... 115 10.1 Indoor Unit................... 115 10.2 Outdoor Unit..................

  • Page 4: Introduction

    AS24GS1/2ERA 1U24GS1ERA-SM Introduction 1. Introduction 1.1 Safety Cautions Be sure to read the following safety cautions before conducting repair work. The caution items are classified into “Warning” and “Caution”. The “Warning” items are especially important since they can lead to death or serious injury if they are not followed closely. The “Caution” items can also lead to serious accidents under some conditions if they are not followed.

  • Page 5: Cautions Regarding Products After Repair

    AS24GS1/2ERA 1U24GS1ERA-SM Introduction Warning Do not repair the electrical components with wet hands. Working on the equipment with wet hands can cause an electrical shock. Do not clean the air conditioner by splashing water. Washing the unit with water can cause an electrical shock.
  • Page 6 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Warning Be sure to use an exclusive power circuit for the equipment, and follow the technical standards related to the electrical equipment, the internal wiring regulations and the instruction manual for installation when conducting electrical work. Insufficient power circuit capacity and improper electrical work can cause an electrical shock or fire. Be sure to use the specified cable to connect between the indoor and outdoor units.

  • Page 7: Inspection After Repair

    Introduction AS24GS1/2ERA 1U24GS1ERA-SM Caution Installation of a leakage breaker is necessary in some cases depending on the conditions of the installation site, to prevent electrical shocks. Do not install the equipment in a place where there is a possibility of combustible gas leaks. If a combustible gas leaks and remains around the unit, it can cause a fire.
  • Page 8 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Caution Check to see if the parts and wires are mounted and connected properly, and if the connections at the soldered or crimped terminals are secure. Improper installation and connections can cause excessive heat generation, fire or an electrical shock. If the installation platform or frame has corroded, replace it.

  • Page 9: List Of Functions

    AS24GS1/2ERA 1U24GS1ERA-SM Functions Category AS24GS1/2ERA 1U24GS1ERA make your room full of an abundance natural negative ions. Healthy negative ion Avoid the child's wrong operation on the remote controller Child lock The 3D airflow is able to deliver the airflow horizontally and vertically. 3D air flow Use the timer function to set on,or off,or from on to off,or from off to on 24Hour timer...

  • Page 10: Specifications

    AS24GS1/2ERA 1U24GS1ERA-SM 3 Specification AS24GS1ERA AS24GS2ERA 6.80(2.2~7.0) 7.10(2.3~7.3) 6.80(2.2~7.0) 7.10(2.3~7.3) 23200(7500-23900) 23900(7850-24900) 23200(7500-23900) 23900(7850-24900) 6536(1032~8170) 6536(1032~8170) 5848(1892-6020) 5848(1892-6020) 2120(600~2150) 2120(600~2150) 1970(595~2000) 1970(595~2000) 3.21 3.21 φ 9.52 9.52 15.88 15.88 16.7 17.3 16.7 17.3 14.6 15.4 14.6 15.4 13.5 12.5 13.5 12.5...
  • Page 11 AS24GS1/2ERA 1U24GS1ERA-SM SNB130FGYM2 FV50S 0.50 R410a 1.60 51.7 51.7 1823.8 1823.8 2120 1970 860x308x730 995X420X815 48.2 52.2...

  • Page 12: Printed Circuit Board Connector Wiring Diagram

    AS24GS1/2ERA 1U24GS1ERA-SM Connector Wiring Diagram 4.Printed Circuit Board Connector Wiring Diagram 4.1 Indoor unit Connectors &RQQHFWRUV 3&%  &RQWURO 3&% )RU +80+&5 '% 1) CN26 Connector for fan motor 2) CN1 Connector for heat exchanger thermistor and Room temperature thermistor 3) CN11 Connector for UP&DOWN STEP motor 4) CON2 Connector for power N wire 5) CON1 Connector for power L 6) CN32 Connector for display board...
  • Page 13 AS24GS1/2ERA 1U24GS1ERA-SM Connector Wiring Diagram 3&%  CN26 CN11 CN32 CN20 CON6 CON1 CON9 CON2 CON6 CON7 CN34 Domestic Air Conditioner...
  • Page 14 AS24GS1/2ERA 1U24GS1ERA-SM Connector Wiring Diagram 4.2: outdoor unit &RQQHFWRUV 3&%  &RQWURO 3&% 1) CN1,CN2 Connector for power N and L 2) CN3 Connector for ground 3) CN6 CN7 Connector for terminal to indoor unit 4) CN25 Connector for DC POWER 15Vand 5V to the module board 5) CN9,CN10 Connector for CN2,CN1 on the module board 6) CN12 Connector for AC fan motor 7) CN11 Connector for four way valve coil...
  • Page 15 AS24GS1/2ERA 1U24GS1ERA-SM Connector Wiring Diagram 3&%  CN28 CN25 CN22 CN23 CN22 CN21 CN20 CN19 CN18 CN17 CN47 CN16 CN15 CN45 CN12 CN11 CN36 CN10 Domestic Air Conditioner...
  • Page 16 AS24GS1/2ERA 1U24GS1ERA-SM Connector Wiring Diagram 3&%  CN10 CN11 Domestic Air Conditioner...

  • Page 17: Functions And Control

    AS24GS1/2ERA 1U24GS1ERA-SM Function and Control )XQFLWLRQV DQG &RQWURO 5.1 Main functions and control specification of indoor unit 5.1.1 Automatic operation When the running mode is turned to automation after starting the system, the system will first determine the running mode according to the current room temperature and then will run according to the determined mode.
  • Page 18 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 5.1.3 Demoisture mode. * temperature control range: 16---30 * temperature difference: Control feature: send the demoisture signal to the outdoor system. When Tr>Ts+2 , the compressor will be turned on, the indoor fan will opera te at the set speed. When Tr is between the Ts and Ts+2 , the outdoor system will operate at the high demoisture frequency for 10 minutes and then at the low demoisture mode for six minutes.
  • Page 19 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control mode. *Indoor fan control manual control: You can choose high, medium, low and automatic speed control. Automatic: When Tr<Ts, high speed. When Ts=<Tr=<Ts+2 , medium speed. When Tr> Ts+2 , low speed. When the airflow speed has no delay from the high to low switching, the speed should be delayed for 3 minutes (remain at high speed for 3 minutes.) before the next switch.
  • Page 20 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control Entering ‘mute’, you can have normal operation or signal control such as timing to finish the strength operation. When the system is at the automatic option ,There is no strength/ mute function,. 5.1.6 Mute operation the system enters the mode after receiving the ‘mute signal’.
  • Page 21 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control temperature will be raised for 1 centigrade after 1 hour’s operation and will be raised for 1 centigrade 1 hour later. The system will keep this status for 6 hours and then close. 2.2 Under the heating mode, after the setting of the dormant operation, the et temperature will fall 2 centigrades after 1 hour’s operation and will fall 2 centigrades 1 hours later.
  • Page 22 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control malfunction will be stored in the malfunction resume and will not be revealed. 5.1.12 High load protection control The outdoor system will be stopped if the coil temperature is above 65 for 2 minutes. The indoor fan will be controlled by the thermostat.
  • Page 23 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control according to the original status, the malfunction code will not be revealed or processed. WUDQVPLVVLRQ DEQRUPDOLW\ If the indoor system can’t receive the outdoor system for 8 minutes, the communication abnormality can be confirmed and reported and the outdoor system will be stopped. 5.1.16 Single indoor system operation * Enter condition: First, Heating operation mode, set the high speed airflow and 30 centigrade set temperature, then press the dormant keys for 6 times within 7 seconds, the system will feedback with...

  • Page 24: The Control System Of Outdoor Unit

    AS24GS1/2ERA 1U24GS1ERA-SM Function and Control heating signal to the outdoor system. Meanwhile, you can fix the indoor system at high speed mode, the location of the airflow directin board can be switched to the maximal position. c. Quitting condition: The fixed frequency heating can be quitted after receiving the remote signal, and the system will enter the remote setting status.
  • Page 25 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 58Hz,88Hz for one minute (the overheating protection of the outdoor unit air-blowing temperature, immediately decrease the frequency when the compressor is overflowing and releasing the pressure) then it can be operated towards the target frequency. When the machine runs normally, there’s no such process.
  • Page 26 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control ΔT <1 >=4 The percentage of the 100% 120% 140% rated frequency P Heating mode ΔT <1 >=4 The percentage of the 100% 140% 140% rated frequency P K=∑Ki/the number of running machines The indoor set Breeze Medium High...
  • Page 27 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control The temperature of the outdoor Airflow speed Ta 22 Ta<22 Keeping the speed Ta<22 Medium Ta<16 Keeping the speed Ta<14 High 5.2.3 The control of the outdoor electronic expansion valve When starting the compressor: the opening size of the valve must be guaranteed to have entered into the standard opening size, and then the compressor can be started.

  • Page 28: Protection Function

    AS24GS1/2ERA 1U24GS1ERA-SM Function and Control defrostings is 45 minutes (the time interval which is in 57 digits in EEPROM can be adjusted When the result of C×TA α is in the scope of C×TA α<-15 , the time interval between two defrostings is 65 minutes.
  • Page 29 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control Increasing the frequency (1HZ/10second) Increasing the frequency 1HZ/1second TTC>=110 lasts for 20 seconds. Overheating protection of air-blowing, alarm malfunction to the indoor, others don’t last. 5.2.6.2 TC high temperature-preventing control of the indoor heating unit Tpg_indoor is the highest value of the effective indoor unit (start it and it is in accord with the running state).
  • Page 30 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control frequency of the compressor increases at the speed of no faster than 0.1HZ/second. 5.2.6.4 The protection function of AC current: During the starting process of the compressor, if the AC current is greater than 10.5A, the frequency of the compressor decreases at the speed of 1HZ/second.
  • Page 31 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 5.2.6.6 The frequency limitation of modification rate In the field which is controlled by high frequency, if the modification rate is not high enough, the control-driven on chip will enter into weak magnetic control, this will help to relieve the problem of modification rate.

  • Page 32: Value Of Thermistor

    AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 5.3 Value of Thermistor 5.3.1 intdoor Unit Room sensor and Pipe Sensor R25 =10KΩ±3% B25 /50 =3700K±3% Temp.(( )) Max.(KΩ) Normal(KΩ) Min.(KΩ) Tolerance( ) 165.2170 147.9497 132.3678 -1.94 1.75 155.5754 139.5600 125.0806 -1.93 1.74 146.5609 131.7022 118.2434 -1.91...

  • Page 33: Function And Control

    AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 50.8956 47.1666 43.6714 -1.54 1.44 48.3178 44.8454 41.5851 -1.51 1.42 45.8860 42.6525 39.6112 -1.49 1.40 43.5912 40.5800 37.7429 -1.47 1.39 41.4249 38.6207 35.9739 -1.45 1.37 39.3792 36.7676 34.2983 -1.43 1.35 37.4465 35.0144 32.7108 -1.41 1.33 35.6202 33.3552 31.2062...
  • Page 34 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 7.2546 6.9673 6.6854 -1.06 1.04 6.9852 6.7008 6.4222 -1.10 1.07 6.7273 6.4459 6.1707 -1.13 1.11 6.4803 6.2021 5.9304 -1.17 1.14 6.2437 5.9687 5.7007 -1.21 1.18 6.0170 5.7454 5.4812 -1.25 1.22 5.7997 5.5316 5.2712 -1.29 1.25 5.5914 5.3269 5.0704...
  • Page 35 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 1.6409 1.5051 1.3794 -2.97 2.75 1.5923 1.4592 1.3360 -3.02 2.80 1.5454 1.4149 1.2942 -3.07 2.84 1.5000 1.3721 1.2540 -3.12 2.88 1.4562 1.3308 1.2151 -3.17 2.93 1.4139 1.2910 1.1776 -3.22 2.97 1.3730 1.2525 1.1415 -3.27 3.01 1.3335 1.2153 1.1066...
  • Page 36 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control Ambient Sensor, Defrosting Sensor, Pipe sensor R25 =10KΩ±3% B25 /50 =3700K±3% Temp.( ) Max.(KΩ) Normal(KΩ) Min.(KΩ) Tolerance( ) 165.2170 147.9497 132.3678 -1.94 1.75 155.5754 139.5600 125.0806 -1.93 1.74 146.5609 131.7022 118.2434 -1.91 1.73 138.1285 124.3392 111.8256 -1.89 1.71...
  • Page 37 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 19.1149 18.2270 17.3646 -1.08 1.05 18.2580 17.4331 16.6305 -1.06 1.03 17.4442 16.6782 15.9315 -1.03 1.01 16.6711 15.9601 15.2657 -1.01 0.99 15.9366 15.2770 14.6315 -0.98 0.96 15.2385 14.6268 14.0271 -0.96 0.94 14.5748 14.0079 13.4510 -0.93 0.92 13.9436 13.4185 12.9017...
  • Page 38 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 3.4195 3.2085 3.0079 -1.91 1.82 3.3060 3.0989 2.9021 -1.95 1.85 3.1969 2.9935 2.8005 -2.00 1.89 3.0919 2.8922 2.7029 -2.04 1.93 2.9909 2.7948 2.6092 -2.08 1.97 2.8936 2.7012 2.5193 -2.13 2.01 2.8000 2.6112 2.4328 -2.17 2.05 2.7099 2.5246 2.3498...
  • Page 39 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 0.8983 0.8088 0.7275 -4.07 3.69 0.8741 0.7863 0.7067 -4.12 3.74 0.8507 0.7646 0.6867 -4.18 3.78 0.8281 0.7436 0.6672 -4.23 3.83 0.8061 0.7233 0.6484 -4.29 3.88 0.7848 0.7036 0.6303 -4.34 3.92 0.7641 0.6845 0.6127 -4.40 3.97 0.7441 0.6661 0.5957...
  • Page 40 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 4738.4141 4032.7098 3429.0191 -2.73 2.34 4451.4586 3795.3910 3233.1039 -2.72 2.33 4183.5548 3573.4260 3049.5312 -2.70 2.32 3933.3289 3365.7336 2877.4527 -2.69 2.31 3699.5139 3171.3148 2716.0828 -2.67 2.30 3480.9407 2989.2460 2564.6945 -2.66 2.29 3276.5302 2818.6731 2422.6139 -2.64 2.28 3085.2854 2658.8058 2289.2164...
  • Page 41 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 420.1431 383.7151 350.1301 -1.97 1.81 400.3242 366.1295 334.5542 -1.95 1.80 381.5350 349.4341 319.7460 -1.93 1.78 363.7176 333.5801 305.6645 -1.90 1.76 346.8176 318.5216 292.2709 -1.88 1.75 330.7839 304.2151 279.5286 -1.86 1.73 315.5682 290.6199 267.4031 -1.84 1.71 301.1254 277.6976 255.8620...
  • Page 42 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 62.3423 60.1906 58.0609 -0.95 0.94 59.9821 57.9770 55.9885 -0.92 0.92 57.7223 55.8552 53.9998 -0.90 0.89 55.5583 53.8210 52.0912 -0.87 0.87 53.4856 51.8706 50.2591 -0.85 0.84 51.5000 50.0000 48.5000 -0.85 0.84 49.7063 48.2057 46.7083 -0.85 0.85 47.9835 46.4842 44.9911...
  • Page 43 AS24GS1/2ERA 1U24GS1ERA-SM Function and Control 14.5599 13.5942 12.6811 -2.36 2.23 14.1376 13.1879 12.2909 -2.41 2.27 13.7294 12.7955 11.9144 -2.45 2.31 13.3347 12.4165 11.5510 -2.50 2.35 12.9531 12.0503 11.2003 -2.54 2.39 12.5840 11.6965 10.8617 -2.58 2.43 12.2270 11.3545 10.5348 -2.63 2.47 11.8817 11.0240 10.2191...

  • Page 44: System Configuration

    AS24GS1/2ERA 1U24GS1ERA-SM 6.2.1 The Instruction For AS24GS1ERA...

  • Page 45: Parts And Functions

    AS24GS1/2ERA 1U24GS1ERA-SM Introduction Parts and Functions Indoor Unit Remote controller 9. LOCK display 10. SWING display 11. Mode display Operation mode AUTO COOL HEAT ON/OFF Remote controller 12. TEMP display 13. SIGNAL SENDING 14. TIMER OFF display MODE 15. TIMER ON display SWING 16.
  • Page 46 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Operation Base Operation Emergency operation and test operation Emergency Operation: ON/OFF Use this operation only when the remote controller is defective or lost, and with function of emergency running, air conditoner Remote controller can run automatically for a while. When the emergency operation switch is pressed, the "...
  • Page 47 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Operation Sleep Operation In AUTO mode The unit operaters in corresponding sleep mode adapted to the automatically selected operation Before going to bed,you can simply press the SLEEP mode. button and unit will operate in SLEEP mode and bring 4.
  • Page 48 AS24GS1/2ERA 1U24GS1ERA-SM Introduction parliament, herewith we inform the consumer about the dis- Operation posal requirements of the electrical and electronic products. DISPOSAL REQUIREMENTS: Timer On/Off On-Off Operation Your air conditioning product is marked with this symbol.This means that electrical and electronic Set clock correctly before starting TIMER operation.
  • Page 49 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Indoor Unit Installaion Necessary Tools for Installation Power Source Torque wrench Driver Before inserting power into receptacle, check the voltage (17mm,22mm,26mm) Nipper without fail. Pipe cutter Hacksaw The power supply is the same as the corresponding nameplate. Flaring tool Hole core drill Install an exclusive branch circuit of the power.
  • Page 50 Introduction AS24GS1/2ERA 1U24GS1ERA-SM Indoor Unit Installation 1. Insert the drain hose into the dent of heat insulation materials of Fitting of the Mounting Plate and Positioning of the wall Hole indoor unit. 2. Insert the indoor/outdoor electric cable from backside of indoor unit, and pull it out on the front side, then connect them.
  • Page 51 F aulty connector c onnection; m alfunction F aulty therm istor; H eat-exc hange Model AS18GS1ERA AS24GS1ERA F aulty P C B ; s e n s o r failure 4G0.75mm 4G0.75mm F aulty E E P R O M data;...
  • Page 52 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Maintenance For Smart Use of The Air Conditioner Remote Controller Indoor Body Setting of proper room Do not block the air inlet temperature or outlet Proper wipe the air conditioner by using a temperature soft and dry cloth.For serious stains, use a neutral detergent diluted with Do not usewater,wipe the controller water.Wring the water out of the...
  • Page 53 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Cautions WARNING Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. WARNING Check proper When abnormality such as burnt-small found, Use an exclusive immediately stop the operation button and installation of the...
  • Page 54 Are there too much heat sources or too many people in the room during cooling operation? Haier Group Address:No.1 Haier Road,Hi-tech Zone,Qingdao 266101 P .R.China Contacts: TEL +86-532-8893-6943;FAX +86-532-8893-1010 Website: www.haier.com Domestic air conditioner...

  • Page 55: Display Board

    AS24GS1/2ERA 1U24GS1ERA-SM Introduction 6.2.2 The Instruction For AS24GS2ERA Remote controller Indoor Unit Additional functions display Supplemented electrical Operation mode QUITE SLEEP HEALTH POWER heating Inlet Air Purifying Filter Remote controller (inside) 9. QUIET button 10. HEAT button 11. COOL button Inlet grille 12.
  • Page 56 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Operation Base Operation Emergency operation and test operation Emergency Operation: Use this operation only when the remote controller is defective or lost, and with function of emergency running, air conditoner Remote controller can run automatically for a while. When the emergency operation switch is pressed, the "...
  • Page 57 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Operation Sleep Operation 4. In FAN mode It has no SLEEP function. Press button to enter additional options, when 5.Set the wind speed change when sleeping cycle display to will flash. And then press If the wind speed is high or middle before setting for the enter to sleep function.
  • Page 58 AS24GS1/2ERA 1U24GS1ERA-SM Introduction EUROPEAN REGULATIONS Operation CONFORMITY FOR THE MODELS Timer On/Off On-Off Operation All the products are in conformity with the following European provision: 1.After unit starts, select your desired operation mode. - Low Voltage Directive 73/23/EEC 2.Press TIMER button to change TIMER mode. Every - Low Voltage Directive 2006/95/EC time the button is pressed, display changes as follows: -Electomagnetic CompatibilitY 89/336/EEC...
  • Page 59 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Indoor Unit Installaion Necessary Tools for Installation Power Source ● Torque wrench ● Driver ● Before inserting power into receptacle, check the voltage (17mm,22mm,26mm) ● Nipper without fail. ● Pipe cutter ● Hacksaw ● The power supply is the same as the corresponding nameplate. ●...
  • Page 60 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Indoor Unit Installation · [ Left Left-rear piping ] Fitting of the Mounting Plate and Positioning of the wall Hole ● In case of left side piping, cut away, with a nipper, the lid for left piping. ●...
  • Page 61 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Correct Incorrect When connecting the cable after installing the indoor unit 1. Insert from outside the room cable into left side of the wall Lean Damage of flare Partial Too outside Crack hole, in which the pipe has already existed. 2.
  • Page 62 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Maintenance For Smart Use of The Air Conditioner Remote Controller Indoor Body Setting of proper room Do not block the air inlet temperature or outlet Proper wipe the air conditioner by using a temperature soft and dry cloth.For serious stains, use a neutral detergent diluted with Do not usewater,wipe the controller water.Wring the water out of the...
  • Page 63 AS24GS1/2ERA 1U24GS1ERA-SM Introduction Cautions WARNING Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. WARNING Check proper When abnormality such as burnt-small found, Use an exclusive immediately stop the operation button and installation of the...
  • Page 64 Are there too much heat sources or too many people in the room during cooling operation? Haier Group Address:No.1 Haier Road,Hi-tech Zone,Qingdao 266101 P.R.China Contacts: TEL +86-532-8893-6943;FAX +86-532-8893-1010 Website: www.haier.com Domestic air conditioner...

  • Page 65: Error Codes And Description

    AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7 Service Diagnosis 7.1 Caution for Diagnosis The operation lamp flashes when any of the following errors is detected. 1.When a protection device of the indoor or outdoor unit is activated or when the thermistor malfunctions, disabling equipment operation.
  • Page 66 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.Error Codes and Description indoor display Code indication Reference Outdoor Description Page indoor (LED1 flash times) Indoorand Outdoor Communication fault between indoor and Page .72 outdoor units Room temperature sensor failure Page .64 Indoor Malfunction Heat-exchange sensor failure Page .64 Indoor EEPROM error Page .71...
  • Page 67 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.1Thermistor or Related Abnormality (indoor unit) (: Room temperature sensor failure ,QGRRU 'LVSOD\ (: Heat-exchange sensor failure 0HWKRG RI the temperatures detected by the thermistors are used to determine thermistor errors 0DOIXQFWLRQ 'HWHFWLRQ 0DOIXQFWLRQ when the thermistor input is more than 4.92V or less than 0.08V during compressor 'HFLVLRQ operation.
  • Page 68 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.4.2 Indoor fan motor malfunction ,QGRRU 'LVSOD\ 0HWKRG RI The rotation speed detected by the Hall IC during fan motor operation is used to determine 0DOIXQFWLRQ abnormal fan motor operation 'HWHFWLRQ 0DOIXQFWLRQ when the detected rotation feedback singal don’t receiced in 2 minutes 'HFLVLRQ &RQGLWLRQV 6XSSRVHG &DXVHV...

  • Page 69: Ipm Protection

    AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis Turn off power supply and rotate fan by hand Does fan rotate Replace fan motor smoothly? Turn power ON and operate fan Turn off power supply and disconnect fan motor connector,then turn power ON Does it rotate? Check output of fan motor connector I s m o t o r p o w e r v o l t a g e D C 3 1 0 V...
  • Page 70 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis RXWGRRU GLVSOD\ LED1 flash 2 times: ,QGRRU 'LVSOD\ ) 0HWKRG RI IPM protection is detected by checking the compressor running condition and so on. 0DOIXQFWLRQ 'HWHFWLRQ 0DOIXQFWLRQ The system leads to IPM protection due to over current 'HFLVLRQ The compressor faulty leads to IPM protection &RQGLWLRQV...
  • Page 71 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.4 The IPM and outdoor PCB don’t communicate or Related Abnormality RXWGRRU GLVSOD\ LED1 flash 4 times Indoor Display 0HWKRG RI Communication is detected by checking the IPM module and the outdoor PCB 0DOIXQFWLRQ 'HWHFWLRQ 0DOIXQFWLRQ The outdoor PCB broken leads to communication fault 'HFLVLRQ The IPM module broken leads to communication fault...
  • Page 72 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.5 Thermistor or Related Abnormality(outdoor unit) )URVWUHPRYLQJ WHPSHUDWXUH VHQVRU IDLOXUH ,QGRRU GLVSOD\ RXWGRRU GLVSOD\ LED1 flash 10 times: ([KDXVW WHPSHUDWXUH VHQVRU IDLOXUH ,QGRRU GLVSOD\: RXWGRRU GLVSOD\: LED1 flash 13 times: $PELHQW WHPSHUDWXUH VHQVRU IDLOXUH ,QGRRU GLVSOD\: RXWGRRU GLVSOD\: LED1 flash 12 times: 0HWKRG RI...
  • Page 73 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.6 Overheat Protection For Exhaust Temperature ,QGRRU GLVSOD\ RXWGRRU GLVSOD\ LED1 flash 8 times 0HWKRG RI the exhaust temperature control is checked with the temperature being detected 0DOIXQFWLRQ by the exhaust pipe thermistor 'HWHFWLRQ 0DOIXQFWLRQ when the compressor discharge temperature is above 117 'HFLVLRQ &RQGLWLRQV 6XSSRVHG...
  • Page 74 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis Pull out the exhaust sensor and measure its The sensor is damaged. Replace the sensor resistance standard temperatures with a new one. according to the resistance-temperature table The sensor is damaged. Replace the sensor the results deviate with a new one.
  • Page 75 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.8 Communication error between the indoor and outdoor units ,QGRRU GLVSOD\ 2XWGRRU: GLVSOD\ LED1 flash 15 times 0HWKRG RI The date received from the another unit in indoor unit-outdoor unit signal transmission is 0DOIXQFWLRQ checked whether is normal Detection Malfunction When the date sent from the another unit cannot be received normally,or when the content...
  • Page 76 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis Check the status of LED1 on the indoor mainboard. If the LED1 blinks measure voltage between Jumpers 3 and 4 of IC8 on the indoor mainboard with a multimeter. Test the outdoor power supply (230VAC and +310VDC) with a multimeter.
  • Page 77 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.10 Power Supply Over or under voltagve fault ,QGRRU GLVSOD\ RXWGRRU GLVSOD\ LED1 flash 6 times 0HWKRG RI An abnormal voltage rise or fall is detected by checking the specified voltage detection FLUFXLW 0DOIXQFWLRQ 'HWHFWLRQ 0DOIXQFWLRQ An voltage signal is fed from the voltage detection circuit to the microcomputer 'HFLVLRQ &RQGLWLRQV...
  • Page 78 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.11 Loop of the station detect error 2XWGRRU 'LVSOD\ /(' IODVK  WLPHV ,QGRRU 'LVSOD\ /(' IODVK  WLPHV ,QGRRU 'LVSOD\ 0HWKRG RI the position of the compressor rotor can not detected normally 0DOIXQFWLRQ 'HWHFWLRQ 0DOIXQFWLRQ when the The wiring of compressor is wrong or the connection is poor;...
  • Page 79 AS24GS1/2ERA 1U24GS1ERA-SM Service Diagnosis 7.3.12 Over-current of the compressor 2XWGRRU 'LVSOD\ LED1 flash 3 or 24 or 25 times 0HWKRG RI The current of the compressor is too high 0DOIXQFWLRQ 'HWHFWLRQ 0DOIXQFWLRQ when the IPM Module is damaged 'HFLVLRQ RU the compressor is damaged &RQGLWLRQV power supply.

  • Page 80: Installations

    Installation AS24GS1/2ERA 1U24GS1ERA-SM 8 Installation Installation Manual of Room Air Conditioner IMPORTANT INFORMATION REGA- EUROPEAN REGULATIONS RDING THE REFRIGERANT USED CONFORMITY FOR THE MODELS Contains fluorinated greenhouse gases covered by the Kyoto Protocol All the products are in conformity with the following R410A European provision: - Low Voltage Directive 73/23/EEC...
  • Page 81 Installation AS24GS1/2ERA 1U24GS1ERA-SM The models adopt HFC free refrigerant R410A. For installation of the indoor units,refer to the installation manual which was provided with the units. (The diagram shows a wall-mounted indoor unit.) Attention must be paid to the rising up of drain hose more than 15cm Optional parts for piping Non-adhesive tape...
  • Page 82 Installation AS24GS1/2ERA 1U24GS1ERA-SM WARNING CAUTION Domestic air conditioner...
  • Page 83 Installation AS24GS1/2ERA 1U24GS1ERA-SM Domestic air conditioner...
  • Page 84 Installation AS24GS1/2ERA 1U24GS1ERA-SM Precautions for Handling Units for Use with R410A Caution Do not use the existing refrigerant piping Use a vacuum pump with a reverse-flow check valve. The old refrigerant and refrigerator oil in the existing piping If other types of valves are used, the vacuum pump oil will flow back into the refrigerant cycle and cause the refrigerator contain a large amount of chlorine, which will cause the refrigerator oil in the new unit to deteriorate.
  • Page 85 Installation AS24GS1/2ERA 1U24GS1ERA-SM Before Installing (Relocating) the Unit or Performing Electric Work Caution Ground the unit. Do not spray water on the air conditioners or immerse the Do not connect the grounding on the unit to gas pipes,water air conditioners in water. pipes, lightning rods, or the grounding terminals of Water on the unit presents a risk of electric shock.
  • Page 86 Installation AS24GS1/2ERA 1U24GS1ERA-SM Domestic air conditioner...
  • Page 87 Installation AS24GS1/2ERA 1U24GS1ERA-SM Domestic air conditioner...
  • Page 89 Installation AS24GS1/2ERA 1U24GS1ERA-SM Air outlet Wind direction Cushion rubber 4.Installation dimension(Unit:mm) Domestic air conditioner...
  • Page 90 Installation AS24GS1/2ERA 1U24GS1ERA-SM 1U07BS1ERA 1U09BS1ERA 1U12BS1ERA 1U18FS1ERA 1U24GS1ERA Connection of pipes To bend a pipe, give the roundness as large as possible not to crush the pipe , and the bending radius should be 30 to 40 mm or longer. Connecting the pipe of gas side first makes working easier.
  • Page 91 AS24GS1/2ERA 1U24GS1ERA-SM Installation Domestic air conditioner...
  • Page 92 Installation AS24GS1/2ERA 1U24GS1ERA-SM (e.g.1U18FS1ERA) Domestic air conditioner...
  • Page 93 Installation AS24GS1/2ERA 1U24GS1ERA-SM 1U07BS1ERA 1U09BS1ERA 1U12BS1ERA 1U18FS1ERA 1U24GS1ERA T 25A/250V. FOR 18K 24K FOR 07K 09K 12K Outdoor unit Outdoor unit 1U07BS1ERA Model 1U09BS1ERA 1U18FS1ERA 1U24GS1ERA To Indoor unit 1U12BS1ERA To Indoor unit Connecting wiring 4G0.75mm 4G0.75mm 4G0.75mm POWER Power cable 3G1.5mm 3G2.5mm 3G4.0mm...

  • Page 94: Outdoor Unit Troubleshooting

    When the The wiring of compressor is wrong or Suction temperature sensor failure the connection is poor Lack of refrigerant Check if there is leakage in the unit. Haier Group Address:No.1 Haier Road,Hi-tech Zone,Qingdao 266101 P.R.China Contacts: TEL +86-532-8893-6943;FAX +86-532-8893-1010 Website: www.haier.com Domestic air conditioner...

  • Page 95: Removal Procedure

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9 Removal of Procedure 9.1 Removal of Front panel Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step 1. Remove the front panel. Open the front panel to the horizontal position.

  • Page 96: Removal Of Air Filter

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Lift an air filter upwards slightly and then pull it out downwards. Insert the air filters along grooves when installing. When installing, insert 2 hooks of the air filter completely. Domestic air conditioner...

  • Page 97: Removal Of Horiaontal Blade And Front Grill

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.3 Removal of Horizontal Blade and Front Grill Step Loosen the marked f ive screws Release the marked four hooks. When assembling, install the front grille horizontally so as not to stuff the flap inside. When assembling, make sure the three hooks are caught prop erly.
  • Page 98 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 2. Remove the horizontal The horizontal blade is blade. single. Release the center pivot.

  • Page 99: Removal Of Drain Pan

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points Pull the front grille out horizontally and remove When assembling, install the front grille horizontally so as not to stuff the flap inside. When assembling, make sure the three hooks are caught properly. Domestic air conditioner...
  • Page 100 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.4 Removal of Drain Pan Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the front grille. Remove the assembly of the reduction motor.

  • Page 101: Removal Of Vertical Blades And Swing Motor

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.5 Removal of Vertical Blade and Swing Motor Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Loosen the marked screws Push the hooks on the back of the vertical blades and remove.

  • Page 102: Removal Of Electrical Box

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.6 Removal of Electrical Box Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work.

  • Page 103: Removal Of Heat Exchanger

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.7 Removal of Heat Exchanger Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points You can detach the indoor unit without removing the assembly of the outlet grille.

  • Page 104: Removal Of Fan Rotor And Fan Motor

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.8 Removal of Fan and Fan Motor Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Loosen the 6 screws. Remove the right side plate.

  • Page 105: Removal Of Outdoor Panel

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.9 Removal of Outdoor panel Step Procedure Points 1. Features Loosen the service Be careful not to cover screw and remove the service cover. Domestic air conditioner...
  • Page 106 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points 2. Remove the panels. Loosen the 4 screws and lift the top panel Loosen the screws of the panel. Pull and remove the front panel. Domestic air conditioner...
  • Page 107 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.10 Romoval of Electrcal Box Step Procedure Points screws, then lift the electrical box Domestic air conditioner...
  • Page 108 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.11 Romoval of the Side panel Step Procedure Points screws and remove the side panel. Domestic air conditioner...
  • Page 109 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points Remove the screws and remove the side panel. Domestic air conditioner...

  • Page 110: Removal Of Fan And Fan Motor

    Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM 9.12 Removal of fan and fan motor Step Procedure Points Put the lead wire Loosen the of motor when remove the fan the propeller fan) Domestic air conditioner...
  • Page 111 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points screws and lift the fan motor. Domestic air conditioner...
  • Page 112 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points screws, then lift the Domestic air conditioner...
  • Page 113 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points screws, then lift the proof plate. Domestic air conditioner...
  • Page 114 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points Cut down the and pull out the compressor and remove the Domestic air conditioner...
  • Page 115 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points Domestic air conditioner...
  • Page 116 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points Domestic air conditioner...
  • Page 117 Removal of procedure AS24GS1/2ERA 1U24GS1ERA-SM Step Procedure Points Remove the Domestic air conditioner...

  • Page 118: Wiring Diagrams

    AS24GS1/2ERA 1U24GS1ERA-SM :LULQJ 'LDJUDPV 10.Wiring Diagrams 10..1. Indoor unit Domestic Air Conditioner...

  • Page 119: Outdoor Unit

    AS24GS1/2ERA 1U24GS1ERA-SM 10.2.Outdoor unit Domestic Air Conditioner...

  • Page 120: Circuit Diagrams

    AS24GS1/2ERA 1U24GS1ERA-SM &LUFXLW 'LDJUDPV 11.Circuit Diagrams 11.1.Indoor unit CN32' CN32'' urgent switch Note3 R53,R6,R16,R18,R17,R21 EEPROM Comment: 10K select accoding to diaplay SRCK SWITCH For change 0.1uF JTP1288LA Comment: 1K SW1' write online Comment: 0.1uF CHECK/S_TIME TSVC-1 TEST DIGH CN48 MODE DIGL MODE 0.1uF...
  • Page 121 AS24GS1/2ERA 1U24GS1ERA-SM &LUFXLW 'LDJUDPV 11.2.Outdoor unit 11.2.1 Control Board Circuit Diagrams CN10 CN48 CN49 4-WAY VALVE 2-SPEED-AC-MOTOR AC-L OUT AC-N OUT AC-N OUT AC-L OUT Comment: HEAT1 HEAT2 3-SPEED-AC-MOTOR CN14 CN13 FUSE1 PTC1 T1A/250V AC-L 2U/450V FUSE2 T25A 250VAC 470N AC-L AC-N 100/1W...
  • Page 122 AS24GS1/2ERA 1U24GS1ERA-SM &LUFXLW 'LDJUDPV CN26 250 Connector 220K/2W 105/275VAC 680U/400V/450V 680U/400V/450V LED2 POWER 250 Connector CN24 11.2.2 Module Board Circuit Diagram 5. 2MH/15A D207 FFA30U60DN PS21965-AT C405 C404 C406 AC -L SGH40N60UF 104/275V 474/275V 680U/400V*2 104/275V R215 D25B X60B 0. 015/5W 0.

  • Page 123: Description Of Coding Rules Of Unit Model

    Appendix AS24GS1/2ERA 1U24GS1ERA-SM Description of coding rules of unit model Apply to T1;220~240V 50HZ 1ph DCInverter Heat pump&R410 refrigerant version number Super-match range Platform of indoor units: G(EK Platform) Nominal cooling capacity (24000BTU/h) Type of indoor unit: S(wall-mounted) Indoor unit Apply to T1;220~240V 50HZ 1ph DCInverter Heat pump&R410 refrigerant...
  • Page 124 AS18GS1ERA 1U18FS1ERA-SM The end Sincere Forever Haier Group Zhao Ni Zhang Fei Yang Bifei 86 532 88936935 Wu Hongjin...
