This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
CS-MRE7PKE
CS-MRE9PKE
CS-MRE12PKE
WARNING
PRECAUTION OF LOW TEMPERATURE
Order No: PAPAMY1301063CE

Air Conditioner

Indoor Unit
© Panasonic Corporation 2013
Outdoor Unit
CU-2RE15PBE
CU-2RE18PBE
Destination
Europe
