Your new dryer Intended use
Congratulations - you have chosen to buy a modern, high-quality Bosch For domestic use only.
domestic appliance.
Only to be used for drying fabrics that have been
The condensation dryer with heat pump and automatic cleaning of the washed with water.
heat exchanger is outstanding in terms of efficient energy consumption
and low maintenance requirements page 6.
Keep children younger than 3 years old away from
Every dryer which leaves our factory is carefully checked to ensure that the dryer.
it functions correctly and is in perfect condition.
Do not let children make the cleaning and
Should you have any questions, our after-sales service will be pleased to maintenance work on the dryer without supervision.
help. Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.
The dryer can be operated by children 8 years old
Environmentally-responsible disposal
and older, by persons with reduced physical,
This appliance is labelled in accordance with European Directive
sensory or mental abilities and by persons with
2012/19/EU concerning used electrical and electronic appliances
insufficient experience or knowledge if they are
(waste electrical and electronic equipment - WEEE). The guideline
supervised or have been instructed in its use by
determines the framework for the return and recycling of used appliances
a responsible adult.
as applicable throughout the EU.
For further information about our products, accessories, spare parts and
services, please visit: www.bosch-home.com
Observe the safety instructions on page 13.
Read these instructions and the separate
Energy-saving mode instructions before
Additional Display status/
switching on the dryer.
functions service Programme selector
Contents
Page
Preparation . . . . . . . . . . . . . . . . . . . . . . 2
Setting the programmes . . . . . . . . . . . . . 2
Drying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
Notes on laundry . . . . . . . . . . . . . . . . . . 5
Button signals . . . . . . . . . . . . . . . . . . . . . 5
Fine adjustment of the drying result. . . . . 6
Important Information . . . . . . . . . . . . . . . 6
Overview of programmes . . . . . . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . 8
Frost protection / Transport . . . . . . . . . . . 8
Signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Care and cleaning . . . . . . . . . . . . . . . . . . 9
Technical data . . . . . . . . . . . . . . . . . . . 10 Container Empty the condensate container.
Optional accessories . . . . . . . . . . . . . . . 10
Clean the filter in the condensate container if necessary
Normal noises . . . . . . . . . . . . . . . . . . . . 11
Clean Rinse the fluff filters under running water
What to do if ... / After-sales service . . . 12
Safety instructions . . . . . . . . . . . . . . . . 13
Fine adjustment of The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3) for the
the drying result Cottons, Easy-Care and
Reduced temperature for delicate fabrics that require a longer Low heat
drying time; e.g. polyacrylics, polyamide, elastane, acetate silk. programmes has been finely adjusted, the setting is retained for the others.
Further information page 6.
1
Preparation Drying
Installation page 8
Never start the dryer if it is damaged.
Inspecting the
Inform your after-sales service.
dryer
Make sure your hands are dry. Connecting the
condensate container with filter
Hold the plug only.
mains plug
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
See programme overview on page 7.
See also separate instructions for "basket for woollens"
(depending on the model)
Selecting and adjusting the programme
1
Select the drying programme ...
2
... and adapt to individual requirements
All buttons are sensitive and only
need to be touched lightly.
Press the Start/Stop button
3
Drum
Two-part
fluff filter
Only use the dryer with the fluff filter
inserted.
Air inlet
page 9.
page 4.
Drying
0, 1, 2, 3
SuperQuick 40' programmes presetting = 0. After one of these
Do not pull out/empty the condensate container
when drying is in progress.
2
Emptying condensation
Information on laundry ...
Empty the container after each drying cycle, not during drying.
1. Remove the condensate container and hold it level.
2. Pour out the condensation.
3. Always push container in fully until it clicks into place.
If the Container indicator lamp flashes despite the container having been
emptied Filter in condensate container, page 9.
Cleaning the fluff filter
Control panel
Clean fluff filters reduce energy consumption.
The fluff filter consists of two parts. Clean the inner
and outer filter after every drying cycle:
1. Open the door. Remove fluff from the door/door area.
2. Pull out both parts of the fluff filter.
3. Remove fluff from the edge of the shaft. Fluff should not fall
into the open shaft.
4. Open the filter and remove all the fluff.
5. Rinse both parts under running water and dry thoroughly.
6. Close the inner and outer filter, put them back together
and reinsert them into the appliance.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
Your dryer is equipped with an automatic reduced ironing function. The drum is moved at specific time
intervals for 60 minutes once the programme has ended. The laundry stays loose and fluffy
(or 120 minutes if the additional Less ironing function is selected (depending on model)).
End of programme
as soon as the Anti-Crease/End indicator lamp
lights up.
Interrupt programme
Adding or removing laundry.
The drying operation can be interrupted briefly to add or remove laundry. However, it must then be
continued until it has finished.
1. Open the door. The drying process is interrupted.
2. Add or remove laundry then close the door.
3. If required, select a new programme and additional functions.
4. Press the Start /Stop button.
3 4 4
Fine adjustment of the drying result
Adjustment of the levels of dryness
Labelling of fabrics
Follow the manufacturer's care information.
Dry at normal temperature.
Dry at low temperature in addition, select Low Heat .
Do not machine dry.
Turn to 1 x to the
Off right
Always observe the safety instructions on page 13.
Do not tumble-dry the following fabrics, for example:
– Non-breathable fabrics (e.g. rubber-coated). Drying , Iron Dry , Cupboard Dry , Anti-Crease/End
– Delicate materials (silk, curtains made from synthetic material) these may crease.
are displayed in sequence.
– Oil-stained laundry. Short signal when changing from level 3 to 0, otherwise long
signal .
Drying tips
– To ensure an even result, sort the laundry by fabric type and drying programme.
– Always dry very small fabrics (e.g. baby socks) together with large items of laundry
(e.g. towels).
– Close zips, hooks and eyelets, and button up covers. Tie fabric belts, apron strings, etc.
Important Information
together
– Do not over-dry easy-care laundry Risk of creasing. Allow laundry to finish drying in the air.
– Do not dry woollens in the dryer. They may, however, be refreshed page 7 Wool finish
Your dryer is designed to be particularly energy efficient. Its technical features include
programme (depending on model).
a refrigeration circuit, which uses energy efficiently in a similar way to a refrigerator.
– Do not iron laundry immediately after drying; fold items up and leave for a while residual The dryer's heat exchanger is cleaned automatically during drying.
moisture will then be distributed evenly.
The fluff filters and filter in the condensate container must be cleaned regularly.
– The drying result depends on the type of water used during washing. Fine adjustment of
the drying result page 6.
– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.
Do not use the Extra Dry programme.
– The drying of starched laundry should be limited. Starch leaves behind a coating that Never operate the dryer without the fluff filters and without filter in condensate container.
impairs drying.
– When washing laundry that is to be tumble-dried afterwards, use the correct amount of fabric
softener as specified in the manufacturer's instructions.
– For pre-dried, multi-layered fabrics or small, individual items of laundry, use the Timed
Fluff filters
programme. Also suitable for subsequent drying.
Environmental protection / Energy-saving tips During drying, fluff and hair from the laundry is trapped by the fluff filter. Blocked fluff filters
may impair the heat exchange process.
– Before drying, spin the laundry thoroughly in the washing machine the higher the spin
The fluff filters must therefore be cleaned after every drying cycle. Rinse regularly under
speed, the shorter the drying time will be, thus less energy is consumed. Also spin easy-care
running water page 4.
laundry.
– Use the maximum recommended capacity, but do not exceed it Programme overview
page 7.
– Make sure the room is well ventilated during drying.
Filter in the condensate container
– Do not cover or seal the air inlet.
The filter in the condensate container cleans the condensation. This condensation is required
Button signals
for the automatic cleaning process. The filter should be cleaned regularly under running
water. Empty the condensate container before cleaning the filter
Setting the volume for button signals
Fabrics
Do not dry any fabrics that have come into contact with solvents, oil, wax, grease or paint:
e.g. hair styling products, nail varnish remover, stain remover, cleaning solvent. etc.
Press Start/Stop until the
Turn to 1 x to the Press and hold Low Heat Turn to Empty all pockets.
Off right and turn 2 x to the right required volume is reached Off Do not dry non-breathable fabrics.
Avoid drying items that produce a lot of fluff.
Selectable values: off, quiet, medium, loud, very loud.
Woollens should be refreshed only, using the woollens programme.
5
Press and hold Low Heat Press Low Heat until Turn to
and turn 5 x to the right the required level is reached
Off
page 4/9.
