• Do not incinerate or dispose of in fire. • Do not handle damaged or leaking lithium ion batteries. • Be sure to charge the battery pack using a genuine Sony battery charger or a device that can charge the battery pack.
For Customers in Europe Notice for the customers in the countries applying EU Directives The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or guarantee matters please refer to the addresses given in separate service or guarantee documents.
Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.
Identifying parts H Speaker I LCD screen (Playback) button K For shooting: W/T (Zoom) button For viewing: (Playback zoom) button/ (Index) button L Hook for wrist strap M Mode switch (Delete) button O MENU button P Control button Menu on: v/V/b/B/z Menu off: DISP/ Q Battery insertion slot R Battery eject lever...
• When charging is finished, disconnect the power cord (mains lead) from the wall outlet (wall socket), and remove the battery pack from the battery charger. • Be sure to use the battery pack or the battery charger of the genuine Sony brand.
• The number of images that can be recorded is when shooting under the following conditions: – Using Sony “Memory Stick PRO Duo” (Mark2) media (sold separately). – When a fully charged battery pack (supplied) is used at an ambient temperature of 25 °C (77 °F).
Inserting the battery pack/a memory card (sold separately) Ensure the notched corner Eject lever faces correctly. Open the cover. Insert the memory card (sold separately). • With the notched corner facing as illustrated, insert the memory card until it clicks into place. Insert the battery pack.
Memory cards that you can use Memory Card For still images For movies Memory Stick PRO Duo Memory Stick PRO-HG Duo Memory Stick Duo — SD memory card SDHC memory card • In this manual, products in A are collectively referred to as “Memory Stick Duo” media.
Setting the date and time Date & Time setting is displayed when you press the ON/OFF (Power) button for the first time. ON/OFF (Power) Control button Select items: Set: Press the ON/OFF (Power) button. Date & Time setting is displayed when you press the ON/OFF (Power) button for the first time.
Shooting still images/movies Shutter button W: zoom out T: zoom in Mode switch : Still image : Movie Shooting still images: Press the shutter button halfway down to focus. When the image is in focus, a beep sounds and the z indicator lights. Press the shutter button fully down.
Viewing images W: zoom out T: zoom in (Playback) Control button (Delete) Select images: B (next)/b (previous) Set: z Press the (Playback) button. Selecting next/previous image Select an image with B (next)/b (previous) on the control button. Press z in the center of the control button to view movies.
List of icons displayed on the screen (When shooting still images) Display Indication AE/AF lock ISO400 ISO number Shutter speed F2.8 Aperture value +2.0EV Exposure Value AF range finder frame Display Indication indicator Battery remaining Low battery warning Image size Display Indication Scene Selection...
Introduction of other functions Other functions used when shooting or playing back can be operated using the Control button or MENU button on the camera. This camera is equipped with a Function Guide that allows you to easily select from the functions. While displaying the guide, try the other functions.
White Balance Adjust color tones of an image. Focus Select the focus method. Select the metering mode that sets which part of the Metering Mode subject to measure to determine the exposure. Smile Detection Set the Smile Shutter function sensitivity for detecting Sensitivity smiles.
Format/Create REC. Folder/Change REC. Folder/Delete Memory Card REC. Folder/Copy/File Number Tool * Area Setting/Date & Time Setting Clock Settings * If a memory card is not inserted, (Internal Memory Tool) will be displayed and only [Format] and [File Number] can be selected. Number of still images and recordable time of movies The number of still images and recordable time may vary depending on the...
Notes on using the camera Changing the language setting The screen language setting, press the MENU button, then select (Settings) t (Main Settings) t [Language Setting]. On use and care Avoid rough handling, disassembling, modifying, physical shock, or impact such as hammering, dropping or stepping on the product. Be particularly careful of the lens.
Page 21
No compensation for damaged content or recording failure Sony cannot compensate for failure to record or loss or damage of recorded content due to a malfunction of the camera or recording media, etc. Cleaning the camera surface Clean the camera surface with a soft cloth slightly moistened with water, then wipe the surface with a dry cloth.
Specifications Camera [Input and Output connectors] (USB)/A/V OUT terminal: [System] Video output Image device: Audio output (Monaural) 7.76 mm (1/2.3 type) color CCD, USB communication Primary color filter USB communication: Hi-Speed USB Total pixel number of camera: (USB 2.0) Approx. 14.5 Megapixels Effective pixel number of camera: [LCD screen] Approx.
Page 23
BC-CSN/BC-CSNB battery Trademarks charger • The following marks are trademarks of Sony Corporation. Power requirements: AC 100 V to , “Cyber-shot,” 240 V, 50 Hz/60 Hz, 2 W “Memory Stick PRO Duo,” Output voltage: DC 4.2 V, 0.25 A “Memory Stick PRO-HG Duo,”...
Page 27
認識各部件 H 揚聲器 I LCD螢幕 (播放)按鈕 K 用來拍攝:W/T (變焦)按鈕 用來觀看: (播放變焦) 按鈕/ (索引)按鈕 L 腕帶掛鉤 M 模式開關 N (刪除)按鈕 O MENU按鈕 P 控制按鈕 功能表開啟:v/V/b/B/z 功能表關閉:DISP/ Q 電池插入插槽 R 電池彈出控制桿 S 三腳架安裝孔 • 請使用螺絲長度小於5.5 mm的 三腳架。否則,您將無法固 定住相機,並有可能損壞相 機。 T 電池/記憶卡蓋 U 存取指示燈 V 記憶卡插槽...
Page 46
各部分介绍 H 扬声器 I LCD液晶屏 (播放)按钮 K 用于拍摄:W/T (变焦)按钮 用于查看: (播放变焦)按 钮/ (索引)按钮 L 腕带挂钩 M 模式开关 N (删除)按钮 O MENU按钮 P 控制按钮 菜单开启:v/V/b/B/z 菜单关闭:DISP/ Q 电池插槽 R 电池退出杆 S 三脚架安装孔 • 使用螺丝长度小于5.5 mm的三 脚架。否则,将无法牢牢固定 相机,且可能会造成相机损 坏。 T 电池/存储卡盖 U 存取指示灯 V 存储卡槽...
• Jauhkan baterai dari jangkauan anak kecil. • Jagalah baterai agar tetap kering. • Ganti hanya dengan jenis yang sama atau yang ekivalen yang dianjurkan oleh Sony. • Buanglah baterai yang sudah digunakan segera seperti dijelaskan dalam instruksi. Pengisi daya baterai Meskipun lampu CHARGE tidak menyala, pengisi daya baterai tetap dialiri daya AC selama terpasang ke stopkontak.
• Pengisi baterai BC-CSN/BC-CSNB (1) • Kabel power (tidak tersedia di Amerika Serikat dan Kanada) (1) • Baterai isi ulang NP-BN1 (1) • Kabel USB khusus (Sony Corporation 1-837-597-) (1) • Tali pergelangan (1) • CD-ROM (1) – Perangkat lunak aplikasi Cyber-shot –...
Mengenali bagian-bagian H Speaker I Layar LCD J Tombol (Pemutaran) K Untuk memotret: Tombol W/T (Pembesaran) Untuk melihat: Tombol (Zoom pemutaran)/Tombol (Indeks) L Kait untuk tali pergelangan M Tombol mode N Tombol (Hapus) O Tombol MENU P Tombol kontrol Menu aktif: v/V/b/B/z Menu non aktif: DISP/ Q Celah masukan baterai R Tuas pelepas baterai...
• Hubungkan pengisi baterai ke outlet dinding terdekat. • Bila pengisian selesai, lepaskan sambungan kabel power dari outlet dinding, dan keluarkan baterai dari pengisi baterai. • Pastikan untuk menggunakan baterai atau pengisian baterai dengan merek asli Sony.
Page 66
Angka bisa lebih sedikti tergantung sekeliling. • Jumlah gambar yang dapat direkam adalah bila memotret dalam kondisi berikut: – Menggunakan "Memory Stick PRO Duo" (Mark2) dari Sony (dijual terpisah). – Bila baterai (tersedia) yang diisi penuh digunakan pada suhu kamar 25°C.
Memasukkan baterai/kartu memori (dijual terpisah) Pastikan ujung tumpul Tuas pelepas menghadap arah yang benar. Buka penutup. Masukkan kartu memori (dijual terpisah). • Dengan ujung tumpul menghadap ke bawah seperti gambar, masukkan kartu memori hingga berbunyi. Masukkan baterai. • Sejajarkan baterai dengan tanda panah di dalam celah masukan baterai. Lalu, masukkan baterai hingga tuas pelepas baterai masuk di tempatnya.
Page 68
Kartu-kartu memori yang dapat anda gunakan Kartu Memori Untuk gambar foto Untuk film Memory Stick PRO Duo Memory Stick PRO-HG Duo Memory Stick Duo — Kartu memori SD Kartu memori SDHC • Dalam buku petunjuk, produk dalam A secara bersama-sama disebut sebagai "Memory Stick Duo".
Menset tanggal dan waktu Pengaturan Tanggal & Waktu ditampilkan bila anda menekan tombol ON/ OFF (Power) untuk pertama kali. ON/OFF (Power) Tombol kontrol Memilih komponen: Set: Tekan tombol ON/OFF (Power). Pengaturan Tanggal & Waktu ditampilkan bila anda menekan tombol ON/OFF (Power) untuk pertama kali. •...
Memotret gambar foto/film Tombol rana W: memperkecil T: memperbesar Tombol mode : Gambar foto : Film Memotret gambar foto: Tekan tombol rana setengahnya ke bawah untuk memfokus. Bila gambar sedang berada dalam fokus, ada nada bip berbunyi dan indikator z menyala. Tekan tombol rana seluruhnya ke bawah.
Melihat gambar W: memperkecil T: memperbesar (Pemutaran) Tombol kontrol (Hapus) Memilih gambar: B (berikut)/b (sebelum) Set: z Tekan tombol (Pemutaran). Memilih gambar berikut/sebelum Pilih sebuah gambar dengan B (berikut)/b (sebelum) pada tombol kontrol. Tekan z pada bagian tengah tombol kontrol untuk melihat film. Menghapus gambar 1 Tekan tombol (Hapus).
Daftar ikon yang ditampilkan pada layar (Saat sedang memotret gambar foto) Tampilan Indikasi ISO400 Nomor ISO Kecepatan rana F2.8 Nilai apertur +2.0EV Nilai Pencahayaan Indikator bingkai pencari jangkauan AF Tampilan Indikasi Sisa baterai Tampilan Indikasi Peringatan baterai rendah Folder perekaman Ukuran gambar Jumlah gambar rekaman Pilihan Pemandangan...
Pengenalan fungsi lainnya Fungsi lainnya yang digunakan saat memotret atau memutar ulang dapat dioperasikan dengan menggunakan tombol Kontrol atau tombol MENU pada kamera. Kamera ini dilengkapi dengan Panduan Fungsi sehingga anda dapat memilih dari fungsi-fungsi dengan mudah. Saat sedang menampilkan panduan, cobalah fungsi lainnya.
Page 74
Mengatur pencahayaan secara manual. Mengatur sensitivitas cahaya. Keseimbangan Mengatur tone warna gambar. Putih Fokus Memilih metode fokus. Memilih mode pengukuran cahaya yang menset bagian Mode Pengukuran mana dari subjek untuk diukur untuk menentukan Cahaya pencahayaan. Sensitiv. Deteksi Menset sensitivitas fungsi Rana Senyuman untuk Senyuman mendeteksi senyuman.
Komponen pengaturan Bila anda menekan tombol MENU saat sedang memotret atau selama pemutaran, (Pengaturan) disediakan sebagai pemilihan akhir. Anda dapat mengubah pengaturan default pada layar (Pengaturan). Garis Kotak/Resolusi Tampilan/Zoom Digital/Phlg Efek P’aturan Mata Mrh/Tnd Mata Tertutup Pemotretan Bip/Language Setting/Panduan Fungsi/Warna tampilan/ Hemat Daya/Inisialisasikan/Video Out/Sambungan Pengaturan Utama USB/Pengaturan LUN...
Film Tabel di bawah menunjukkan perkiraan waktu perekaman maksimum. Ini adalah total waktu untuk semua file film. Ukuran file film yang dapat direkam adalah sampai sekitar 2 GB untuk setiap file. (Satuan: jam : menit : detik) Kapasitas Memori internal Kartu memori Sekitar 28 MB 2 GB...
Page 77
Jangan menggunakan/menyimpan kamera di tempat-tempat berikut • Di tempat yang sangat panas, dingin atau lembab Di tempat seperti di dalam mobil yang diparkir di bawah matahari, bodi kamera dapat berubah bentuk dan hal ini dapat menyebabkan kegagalan fungsi. • Di bawah sinar matahari langsung atau dekat pemanas Bodi kamera dapat berubah warna atau bentuk, dan hal ini dapat menyebabkan kegagalan fungsi.
Page 78
Perekaman materi-materi tersebut yang tidak resmi bertentangan dengan undang-undang hak cipta. Tidak ada ganti rugi untuk isi yang rusak atau kegagalan merekam Sony tidak dapat mengganti rugi kegagalan merekam atau kehilangan atau kerusakan isi rekaman akibat kegagalan fungsi kamera atau media perekaman, dll.
Page 79
Spesifikasi Kamera [Konektor Input dan Output] Terminal (USB)/A/V OUT: [Sistem] Output video Peralatan gambar: Output audio (Monaural) 7,76 mm (tipe 1/2,3) warna CCD, Komunikasi USB Filter warna primer Komunikasi USB: Hi-Speed USB Jumlah total piksel kamera: (USB 2.0) Sekitar 14,5 Megapiksel Jumlah piksel efektif kamera: [Layar LCD] Sekitar 14,1 Megapiksel...
Pengisi baterai BC-CSN/ Merek dagang BC-CSNB • Tanda berikut ini adalah merek dagang milik Sony Corporation. Kebutuhan power: AC 100 V hingga , "Cyber-shot", 240 V, 50 Hz/60 Hz, 2 W "Memory Stick PRO Duo", Tegangan output: DC 4,2 V, 0,25 A "Memory Stick PRO-HG Duo",...
