SERVICE MANUAL

MODEL
KD-32NX200U
COMMANDER
DEST
CHASSIS NO.
RM-939
UK
SCC-Q84L-A
KD-32NX200U
- 1 -
AE-6D
CHASSIS
RM-939

Advertisement

Table of Contents
loading

Related Manuals for Sony KD-32NX200U

Summary of Contents for Sony KD-32NX200U

  • Page 1: Service Manual

    SERVICE MANUAL AE-6D CHASSIS MODEL COMMANDER DEST CHASSIS NO. KD-32NX200U RM-939 SCC-Q84L-A KD-32NX200U RM-939 - 1 -...

  • Page 2: Table Of Contents

    TANCE CRITIQUE POUR LA SÈCURITÈ DU FONCTIONNEMENT, PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE NE LES REMPLACER QUE PAR DES COMPSANTS SONY DONT THESE COMPONENTS WITH SONY PARTS WHOSE PART LE NUMÈRO DE PIÈCE EST INDIQUÈ DANS LE PRÈSENT NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN MANUEL OU DANS DES SUPPLÈMENTS PUBLIÈS PAR SONY.

  • Page 3: Caution

    Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com - 3 -...
  • Page 4 l l a ° 2 . s l . s l . s l . s l . s l e i l i n i WARNING (UK Models only) The flexible mains lead is supplied connected to a B.S. 1363 fused plug having a fuse of 5 AMP rating.

  • Page 5: Connectors

    21 pin connector Pin No Signal Signal level Audio output B Standard level : 0.5V rms (right) Output impedence : Less than 1kohm* Audio input B Standard level : 0.5V rms (right) Output impedence : More than 10kohm* Audio output A Standard level : 0.5V rms (left) Output impedence : Less than 1kohm*...

  • Page 6: Self Diagnostic Software

    AE-6D SELF DIAGNOSTIC SOFTWARE The identification of errors within the AE-6D chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flashing LED) and then communicate with each device in turn to establish if a device is faulty.
  • Page 7 Error Detection Monitor Device acknowledge is used to check IIC errors. Device acknowledge is checked by sending an IIC start sequence during CRT power on. Each device is checked three times, if there is no acknowledge after each attempt, it will be regarded as an error. There are three steps to check for errors.
  • Page 8 2. Error Reader Display The error reader display is connected to the service connector to read actual error codes. The part number for the error reader display is S-188-900-10. Once an error has been detected it will then be displayed on the two digit error reader. The errors displayed refer to the following table.

  • Page 9: General

    SECTION 1 GENERAL - 9 -...
  • Page 10 - 10 -...
  • Page 11 - 11 -...
  • Page 12 - 12 -...
  • Page 13 - 13 -...
  • Page 14 - 14 -...

  • Page 15: Disassembly

    SECTION 2 DISASSEMBLY 2-1. Rear Cover Removal 2-2. Speaker Box Removal => => => => => => Screws Remove the rear cover fixing screws indicated and pull the To remove the speaker box assembly remove the two screws rear cover backwards away from the set. circled and unplug the speaker lead from connector CN1202 on the ‘A’...

  • Page 16: G1 Board Removal

    2-4. G1 Board Removal 2-5. G Board Removal Screw Clips Clips Clips To remove the G Board first remove the G1 bracket by removing the screw circled and releasing the four clips (two To remove the G1 board release the three clips circled and on each side of the bracket).

  • Page 17: Service Position

    2-8. Service Position 2-9. Wire Dressing 1 To place the chassis in the service position, remove the speaker assembly box (see 2-2.), remove the G1 and D2 brackets and position on the side of the main bracket as shown above. Insert the main bracket firmly into the T-slot located on To avoid damage to the ground interconnecting leads from the the left corner of the beznet as indicated (see inset).
  • Page 18 2-12. Picture Tube Removal WARNING: BEFORE REMOVING THE ANODE CAP High voltage remains in the CRT even after the power is disconnected. To avoid electric shock, discharge CRT before attempting to remove the anode cap. Short between anode and CRT coated earth ground strap.
  • Page 19 - 19 -...

  • Page 20: Set-Up Adjustments

    SECTION 3 SET-UP ADJUSTMENTS • When complete readjustment is necessary or a new picture tube Carry out the adjustments in the following order : is installed, carry out the following adjustments. 3-1. Beam Landing and Geometry. • Unless there are specific instructions to the contrary, carry out 3-2.

  • Page 21: Convergence

    Fig.3-4 Align both Purity Purity magnets Purity control magnets magnets to the vertical position Align pips on each magnet 3-2. Convergence (1) Screen centre convergence [Static convergence] Input a dot pattern signal from the pattern generator. GREEN Normalize the picture setting. [Moving vertically], adjust the V.STAT magnet so that the BLUE vertical red, green and blue dots coincide at the centre of the...
  • Page 22 Correction for HMC [Horizontal mis-convergence] and VMC HTIL correction can be performed by adding a THL correction [Vertical mis-convergence] by using the BMC [Hexapole] assembly to the Deflection yoke. magnet. a). HMC correction by BMC [Hexapole] magnet and movement of the electron beam.

  • Page 23: Focus Adjustment

    Layout of each control 3-3. Focus Adjustment Receive a cross hatch pattern from a video generator. Adjust the focus control located on the flyback transformer to the best level at the centre of the screen. Purity magnet Check left and right x-axis vertical line thickness and adjust to BMC (Hexaploe) magnet V STAT convergence magnet make them as thin as possible.

  • Page 24: Circuit Adjustments

    SECTION 4 CIRCUIT ADJUSTMENTS Initialising Menu 4-1. Electrical Adjustments Service adjustments to this model can be performed using the supplied remote Commander RM-939. s i l Programming the Remote Commander for Operation in Service Mode Press the VCR/TV/DVD button until the TV LED lights.
  • Page 25 Basic Setting t l i f a l i a l i a l i a l i Table.4-2 Feature Setting Table.4-5 Table.4-3 Device Register Setting c t i l r t l r t Table.4-4 Table.4-6 - 25 -...
  • Page 26 Table.4-7 Table.4-8 - 26 -...
  • Page 27 Table.4-9 t l i . f f Table.4-10 . f f . f f . f f l v l " 6 Table.4-11 Table.4-12 - 27 -...

  • Page 28: Volume Electrical Adjustments

    4-2. Volume Electrical Adjustments Deflection System Adjustment Enter into the service mode and select ‘Deflection’ from the Sub Colour Adjustment menu. The ‘Deflection’ adjustment menu will be displayed. Select and adjust each item to obtain the optimum image. Input a PAL colour bar signal. Connect an oscilloscope to CN9001 pin 5 located on the C1 Board.

  • Page 29: Test Mode

    4-3. TEST MODE 2: Is available by pressing the ‘TEST’ button twice, OSD ‘TT’ appears. The functions described below are available by selecting the two numbers. To release the ‘Test mode 2’, press 0 twice, press the TV button or switch the TV set into Stand-by mode. Pressing the two Local Control buttons (+ and -) during power ON will also switch into ‘TT’...
  • Page 30 Memo - 30 -...

  • Page 31: Block Diagrams

    5-1. BLOCK DIAGRAMS (1) IC1801 IC1804 IC1808 IC1811 DQP- IC1402 PHASE AC-AMP DQP-PHASE DF-DRIVE CN1803 VM-OUT DQP-DC-LEVEL CN2000 VM BOARD DPIC CN5602 DPDT-OFF ANALOGUE Y100 G BOARD Y-IN TU1001 TUNER CN6006 U100 CB-IN V100 CN1602 CR-IN IC1950 MAIN RY CN1804 R-OUT ROTATION (N/S) R-OUT...

  • Page 32: Block Diagrams

    5-1. BLOCK DIAGRAMS (2) CN4472 IC4403 VP100 OUT VP-100 HP100 OUT HP-100 IC4402 IC4203 DIGITAL REALITY IC4201 IC3100 IC4401 IC4600 IC4602 CREATION (DRC-MF) 16Mb SDRAM DIGITAL CHROMA DECODER DIGITAL NOISE REDUCTION (DNR) FBIN BUFFER CGEN DICO(0) XCAS XCAS D(31) D(31) SDDAT31 AIN6 LIEN...

  • Page 33: Block Diagrams

    5-1. BLOCK DIAGRAMS (3) VG(L) CN9002 Q6804, C1 ( Q6805 T6800 R.G.B. OUT D1 BOARD VG(H) CN8614 CN6801 200V J9002 SS RESET OVERSHOOT AFC PULSE PULSE Q6814, DETECT V SENSE PROJECT Q6813 Q6802, Q6801 Q6816, Q6817 IC9001 IC6800 CN9001 RED-VIDEO-OUT R DRV V-IN V-OUT...

  • Page 34: Block Diagrams

    5-1. BLOCK DIAGRAMS (4) CN4601 CN4602 IC401 TO G BOARD RELAY KICK VCC ACT PWR RELAY TO A BOARD QUAD HIGH SPEED SWITCH Q4600 CN402 DIFFERENTIAL RECEIVER CN6013 CN1604 MS-BS+ AC IN T4601 MS-BS- D4600 MS-SDIR+ CN100/1 IC103 CN4600 DIR+ CS DISABLE CS DISABLE AGC-MON...

  • Page 35: Block Diagrams

    5-1. BLOCK DIAGRAMS (5) 5-2. CIRCUIT BOARD LOCATION Reference Information RESISTOR : METAL FILM : SOLID C1 Board FPRD : NON FLAMMABLE CARBON FUSE : NON FLAMMABLE FUSIBLE : NON FLAMMABLE METAL OXIDE VM Board D1 Board D2 Board MS2 Board : NON FLAMMABLE CEMENT H3 Board M2 Board...
  • Page 36 ~ A Printed Wiring Board Conductor side A ~ - 36 -...
  • Page 37 ~ A Printed Wiring Board Conductor side B ~ - 37 -...
  • Page 38 A Board Location Table (A Side) ~ A Board Waveforms ~ 10us/div 10us/div 10us/div 2ms/div 750 mVp-p (H) 650 mVp-p (H) 600 mVp-p (H) 2.8 Vp-p (V) 10us/div 10us/div 20us/div 10us/div A Board Location Table (B Side) ~ 5.2 Vp-p (H) 800 mVp-p (H) 700 mVp-p (H) 580 mVp-p (H)
  • Page 39 A..-32NX200U R1274 C1273 100p 6.8k R1276 L1271 Q1271 JR1245 Q1270 2SC2412K-R C1275 C1276 2SC2412K-R JR1232 XX 0.01 R1290 L1272 3.9k FL1270 JR1233 CF1270 R1275 100uH CHIP Q1272 R1272 R1273 6.5MHZ 2SC2412K-R JR1234 R1270 6.8k C1274 JR1238 JR1235 CHIP JR1236 R1289 R1279 R1288 C1283...
  • Page 40 A..-32NX200U C1505 R_MB BACKEND R_PJE R1521 R_MB R_TXT B_PJE G_TXT R1520 B_TXT G_PJE RGB_TXT IC1502 A 1/9 B_MB G_MB R1522 G_MB R1523 C1506 XX L1401 Q1405 R1435 10uH 2.2k R1404 R1407 BLK_MB BLK_TXT C1402 R1419 R1439 L1403 R1471 10uH R1513 PRE-RGB R1431 C1444...
  • Page 41 A..-32NX200U COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL R1131 C1837 R1854 470k 0.01 R1898 R1861 R1855 1/10W 4.7k D1811 3.3k R1807 C1807 C1802 R1826 RN-CP DAN202K-T-146 RN-CP R1882 100k D1807 2.2k R1849 C1818 D1803 R1806 DAN202K-T-146 DAN202K C1822 0.47 C1803...
  • Page 42 A..-32NX200U ROTA A 3/9 DF_PARA MP_PARA DEFLECTION, PICTURE ROTATION A 3/9 HC_PARA H_DRIVE TO D BOARD AFC_PULSE CN8500 R1133 X_RAY ZOOM_COMP R1199 CN1805 R1862 C1823 R1857 R1902 Q1807 C1838 R1198 9VDEFLECTION R1924 R1868 C1847 R1918 R1903 R1858 R1863 R1871 R1132 R1933 R1936 R1872...
  • Page 43 A..-32NX200U COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL INTERFACE +5V_STBY D1016 UDZS-5.6B D1015 D1NL20U-TR AOPP 3.3V_STBY A 6/9 D1017 IC1012 D1NL20U-TR A 7/9 BA033T D1012 +5V_STBY FL1010 UDZSTE-174.7B VIDEO 2.5V SCL-TV SDA-TV A 7/9 C1053 C1047 C1049 C1052 R1041 D1007...
  • Page 44 TO G BOARD CN6006 CN2000 CN1602 A..-32NX200U +5V_STBY R1068 4.7k Q1012 R1059 2SC2412K-R AC_ON/OFF R1057 4.7k 6.8k D1019 R1060 C1014 ACT5V 0.22 ACT7V R1069 IC1013 IC1011 5V_JACT 4.7k PS1012 BA05T PS1011 BA05T Q1011 L1013 R1058 10UH 2SC2412K-R +5V_STBY 3.3V_STBY C1050 C1051 C1059 C1060...
  • Page 45 A..-32NX200U AOPP +5V_STBY D1003 A 5/9 DAN202K IC1201 A 6/9 5V_1 R1014 TDA7482 R1027 AUDIO AMPLIFIER WOOFER POWER-OFF-MUTE CHIP 4.7k CHIP Q1001 R1079 AUDIO PROTECTION R1021 D1201 2SC2412K DAN202K CHIP Q1003 Q1007 5V_1 DTA144EKA 2SC2412K C1205 R1205 Q1002 2200 D1004 2SC2412K CHIP DAN202K...
  • Page 46 TO N BRD CN3501 CN4000 A..-32NX200 ACT3.3V R4087 C4021 0.22 N-RESET FL4000 FL4001 FL4003 FL4004 FL4002 ACT5V ACT12V D.CVBS ACT5VD ACT3.3V ACT2.5V C4046 ACT5VD ACT5VD IC4005 R4078 TC74HC4066AF(EL) VSYNC V_SYNC D4002 HSYNC N-SDA(TV) R4039 H_SYNC DAN202K-T-146 FB4008 ACT3.3V R4079 CONTROLsw 1/16W CHIP R4081...
  • Page 47 A..-32NX200U C4077 ACT9V 100p C4004 FB4011 C4010 ACT5VD R4002 R4015 10uH 10uH C4016 IC4000 R4024 L4001 TC74HC4066AF(EL) L4002 R4027 33VFE CHIP 10uH 10uH 33VFE_T C4000 CHIP R4022 I/PA TU4000 L4000 Q4001 CHIP D4000 22uH DTC144EKA ACT33V O/PA CONT A C4008 0.01 C4015 R4023...
  • Page 48 ~ B5 Printed Wiring Board Conductor side A ~ ~ B5 Location Table A Side ~ ~ B5 Printed Wiring Board Conductor side B ~ ~ B5 Location Table B Side ~ - 48 -...

  • Page 49: B5 Board Schematic

    B5..-32NX200U CN4472 POWER_INT POWER_INT R4447 PICTURE DECODER, DRC, DIGITAL NOISE REDUCTION IC4402 TC7SET04F(TE85R) INVERTER +3.3V FL4405 D3.3V-AD +3.3V HP_100_OUT D3.3V-AD L4411 C4459 R4428 R4427 R4426 R4425 R4424 R4423 C4429 10uH R4484 FB4403 4.7k 2.2k 4.7k 2.2k 0.01 1/10W 1/10W 1/10W 1/10W VP100_OUT IC4403...
  • Page 50 B5..-32NX200U COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL DIYD[0-7],DICD[0-7],W13ID,IHDD,IVDD DDTB FL4202 B5 1/8 R4239 Q4200 +1.8V C4206 C4208 0.01 FL4201 R4245 R4246 R4238 D3.3V-1 C4207 C4209 C4217 C4219 +3.3V 0.01 0.01 0.01 C4225 R4235 C4221 C4226 0.01 0.01 0.01 W13ID...
  • Page 51 CN4501 B5..-32NX200U CPLD B5 1/8 HSYNCOUT R4573 R4440 R4571 HSYNCIN C4514 A5V-1 C3237 0.01 PDACY R4915 R4916 R4917 CHIP CHIP CHIP D3.3V-DCD FL4902 Y_100_OUT Q4903 RB4503 RB4504 2SA1037AK V_100_OUT R4574 R4912 R4570 R4572 U_100_OUT 2.2K RN-CP PDACU C4909 100p R4913 2.2K RN-CP Q4904...
  • Page 52 B5..-32NX200U C4629 ADD, DATA, WE, RAS, CAS, CS R4698 C4627 B5 5/8 0.01 0.01 C4630 C4628 0.01 0.01 Q4600 2PD601AR-115 BUFFER VDOCIN7 SDADR3 D[16] VP_SUB_IN R4601 VDOCIN6 SDDAT16 D[17] CHIP VDOCIN5 SDDAT17 R4600 D[18] 3.3k VDOCIN4 CHIP SDDAT18 D[19] VDOCIN3 R4602 SDDAT19 C4626...
  • Page 53 B5..-32NX200U ADD, DATA, WE, RAS, CAS, CS B5 4/8 SDDQM0 FL4607 D3.3V-MID IC4602 C4635 C4636 C4637 MT48LC2M32B2TG-7 0.01 0.01 64M_MEMORY 6.3V RB4612 DQ15 D[0] D[15] VCCQ VSSQ D[1] D[14] DQ14 D[2] D[13] DQ13 D[3] D[12] VSSQ VCCQ RB4624 DQ12 RB4613 DQ11 D[4] D[11]...
  • Page 54 B5..-32NX200U DCDB B5 1/8 C3116 C3121 C3125 C3119 0.01 0.01 0.01 0.01 C3131 C3122 C3127 0.01 C3120 0.01 0.01 0.01 C3117 C3126 0.01 0.01 C3114 C3129 0.01 0.01 A5V-ADC C3149 C3150 Q3117 0.01 2PD601AR-115 BUFFER R3168 R3152 R3156 C3134 CHIP 5.6k DVD-14 DVS-7...
  • Page 55 B5.-32NX200U CN4474 MS_CLK VCLK VCLK MS_VS MS_HS MS_C[7] VUV7 MS_C[6] VUV6 MS_C[5] VUV5 MS_C[4] D3.3V VUV4 MS_C[3] VUV3 MS_C[2] VUV2 MS_C[1] IC4603 VUV1 MS_C[0] SN65LVDS31DR VUV0 QUAD LOW VOLTAGE MS_Y[7] DIFFERENTIAL SIGNALLING MS_Y[6] MS_Y[5] MS_Y[4] C4644 FB4614 MS_Y[3] MS_Y[2] DIN1 MS_Y[1] C4653 C4648...
  • Page 56 B5..-32NX200U VDMID HDMID CK54_OUT1 R4310 CHIP DS_OUT B5 2/8 FB4303 SCL-MID C4348 C4347 C4346 0.01 0.01 0.01 SDA-MID FB4302 C4349 0.01 IP[0-7] IP_PORT R4342 R4340 B5 2/8 R4341 ADD_VSS2 R4311 IOPORT9 ADD_VDD4 CHIP IOPORT8 DRCVSOUT VDMID1 IP[7] R4337 IOPORT7 HDMID1 DRCHSOUT IP[6] R4336...
  • Page 57 ~ C1 Printed Wiring Board Conductor side ~ ~ C1 Board Waveforms ~ ~ MS2 Printed Wiring Board Conductor side A ~ 10us/div 10us/div 2.0 Vp-p (H) 2.2 Vp-p (H) 5us/div 10us/div 20.0 Vp-p (H) 2.2 Vp-p (H) 10us/div 5us/div 20.0 Vp-p (H) 20.0 Vp-p (H) 5ms/div...

  • Page 58: C1 Board Schematic

    C1..-32NX200U CN9009 FV FOCUS CN9002 R9046 IC9001 OPEN 200V TDA6120Q/N2/S1 NL9002 R9056 C9031 C9032 R9092 4700p 680p 1/2W TO D1 BOARD RED-VIDEO-OUT CHIP R,G,B OUT L9001 CN8614 L9006 5.0MM CN9003 R9037 R9031 1.5k C9048 R9028 R9103 180k CHIP CN9004 R9001 C9015 Q9007 2SC3624A...

  • Page 59: H Board Schematic

    ~ MS2 Board Schematic Diagram [ Memory Stick ] ~ ~ H Board Schematic Diagram [ AV Link Processor ] ~ H..-32NX200U COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL CN301 AV LINK PROCESSOR +5V_STBY 3.3V_STBY +5V_STBY TO A BOARD CN1702 SIRCS R323...
  • Page 60 ~ D1 Printed Wiring Board Conductor side ~ ~ D1 Board Waveforms ~ ~ D1 Board Location Table ~ ~ D1 Board Semiconductor Voltages ~ 10us/div 10us/div 10us/div 4.0 Vp-p (H) 20.0 Vp-p (H) 4.0 Vp-p (H) 10us/div 10us/div 10us/div ~ D1 Board IC Voltages ~ 20.0 Vp-p (H) 20.0 Vp-p (H)

  • Page 61: D1 Board Schematic

    C8201 CN8614 PS8401 C8210 H_DRIVE HORIZONTAL OUTPUT STAGE REF’s 81XX 250V Q8805 C8801 R8826 +200V Q8102 T8100 R8825 R8820 R8821 2SC5698-SONY-CA UPPER H-OUT TO C1 BOARD C8202 R8202 CN9002 R8101 R8201 R8109 470p L8201 R8100 3.3k 1/2W 100k 500V 1/2W 0.47...

  • Page 62: G1 Board Schematic

    G1..-32NX200U D4612 D1NL20U-TA2 STD-BY +6V TO G BOARD CN6013 DIGITAL POWER SUPPLY AND TIMER RECORD FUNCTION RELAY KICK VCC Q4600 D4611 Q4601 CN4601 DTA144ESA 1SS133 2SC1740S-RT JL009 R4614 C4624 R4613 1/4W 2.2M 1/4W R4615 4.7k 1/4W RY4601 C4600 CN4602 4700p 250V D4607 FB4604...
  • Page 63 ~ G1 Printed Wiring Board Conductor Side~ ~ D2 Printed Wiring Board Conductor Side~ ~ D2 Board IC Voltages ~ ~ D2 Board Location Table ~ ~ D2 Board Semiconductor Voltages ~ - 63 -...

  • Page 64: D2 Board Schematic

    D2..-32NX200U C6852 0.01 R6865 SS RESET C6849 470p HV OVERSHOOT PROTECT 1608 DYNAMIC PICTURE STABLISING CIRCUIT Q6813 2SB709A-QRS-TX R6862 R6897 470k R6870 R6867 D6820 220k R6885 MTZJ-7.5B 1/10W 1/10W 1/10W CHIP Q6817 CHIP CHIP 2SB709A-QRS Q6812 R6896 C6848 R6882 R6869 R6868 R6863 1/10W...
  • Page 65 ~ M2 Board IC Voltages ~ ~ M2 Board Semiconductor Voltages ~ ~ M2 Printed Wiring Board Conductor side A ~ ~ M2 Printed Wiring Board Conductor side B ~ - 65 -...

  • Page 66: M2 Board Schematic

    CN104 M2..-32NX200U +2.5VCORE +3.3V R213 R214 R215 R216 R217 R187 4.7k R188 +3.3V 3.3k R100 R101 R189 3.3k C113 Q120 Q118 IC101 Q116 DTC114YKA R102 C101 PST6001MT DTC114YKA RB111 RB113 Q100 DTC114YKA IC104 R124 M24C32-WMN6T(A) R248 3.3k /RESET Q119 DTC114YKA C100 C150 R249...

  • Page 67: G Board Schematic

    ~ G Board Schematic Diagram [ Power Supply ] ~ - 67 -...
  • Page 68 ~ G Board IC Voltages ~ ~ G Board Semiconductor Voltages ~ ~ G Board Semiconductor Location Table ~ ~ G Printed Wiring Board Conductor side ~ ~ VM Printed Wiring Board Conductor side ~ ~ VM Board Waveforms ~ ~ VM Board Semiconductor Voltages ~ 500ns/div 500ns/div...

  • Page 69: Vm Board Schematic

    VM..-32NX200 +135V F3..-32NX200 C5420 C5413 C5414 R5415 250V 1/2W POWER SWITCH, SIRCS RECEIVER C5400 C5401 R5401 R5403 R5404 Q5402 R5428 AND STAND-BY LED INDICATOR CN5402 L5400 3.3k 1.8k 2SC1740S-RT C5417 0.18uH 1/4W 1/4W 1/4W BUFFER 1/4W R5413 F2601 R5430 1/4W R5416 CN2601 CN2603...
  • Page 70 ~ J3 Printed Wiring Board Conductor side A ~ ~ J3 Printed Wiring Board Conductor side B ~ ~ J3 Board Location Table A side ~ ~ J3 Board Location Table B side ~ ~ F3 Printed Wiring Board Conductor side ~ ~ H3 Printed Wiring Board Conductor side ~ - 70 -...

  • Page 71: H3 Board Schematic

    TO H BOARD CN300 CN907 CN909 C906 D903 MTZJ-9.1B R906 C907 470k D904 1/4W C902 C903 MTZJ-6.8A 1000p 1000p R909 D902 MTZJ-9.1B 470k S905 S904 S901 S903 S902 S900 1/4W C909 L903 10uH R905 100p R903 R904 R910 470k 470k 1/4W L902 1/4W...

  • Page 72: J3 Board Schematic

    J3..-32NX200U COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL J3 2/2 Q9211 CHIP IMZ1A-T109 R8817 R9258 R9256 CHIP V_M[2] RGB-SEL R9257 R9252 R9247 CHIP CHIP R9248 CHIP R9174 C9192 C9096 CHIP C9095 C9189 CHIP FL8811 C9094 C8992 C8991 C8990 C9099 C9097...
  • Page 73 J3..-32NX200U R8931 R_TV[1] R8937 CHIP CHIP CN8805 R_TV[1] R8934 C8914 4700p R9177 R8938 R8932 CHIP 3.3k SCARTS R9121 RN-CP J3 1/2 CHIP R_IN[2] J3 1/2 BLK[5] F BLK C8913 R8936 L_TV[3] H- PULSE 1000p 470k R8939 CHIP R8933 Y_M[3] V PULSE IN CHIP L_TV[3] (CV02)VIDEO OUT...

  • Page 74: Semiconductors

    NJM3403AM 2SC2785-HFE MCZ3001D UPC4558G2 LA6500-FA 3 GND STV9379A ( TOP VIEW ) TLC2932IPWR TLC2933IPWR-12 CXA1875AM-T4 L7809CV/LSY STP5NB40FP PQ1CG2032FZ STP5NB40(030Y) 2SC5698-CA 2S5696-SONY-CA TCET1103G LM318P LM358D LM393DT LM393N M24C32-WMN6T(A) ( TOP VIEW ) BA12T BAO33T IRFI644G-LF36 IRF614-005 IRF720-LF49 IRF620 CXA1855Q SPA07N60C2-E8152 2SA1837...
  • Page 75 2SB733-34 DAP202K GS1B460/45 D1NL20U D1NL20U-TR D1NL40-TA2 2SC2688(5)-LK D1NS4 EGP20G EL1Z GP08D L-59SRSGC-CC RGP10GPKG23 UF4005PKG23 CATHODE ANODE ERA22-08 RD15ES-B2 BAS316-115 RD18ES-B2 ERA85-009 DTZ-TT11-6.8B HZS9.1NB2 RD5.1ESB2 MMDL914T1 MA3062M-TX RD5.6ESB2 MTZJ-13B UDZS-TE17-12B RD5.1M-B2 MTZJ-33B RD6.8ESB2 UDZSTE-174.7B MTZJ-3.6A RD8.2ESB3 UDZSTE-175.1B 1SS119-25 MTZJ-30C UDZSTE-175.6B MTZJ-7.5B 1SS133T-77 UDZSTE-176.2B MTZJ-T-77-15B...

  • Page 76: Ic Block Diagrams

    5-5 IC BLOCK DIAGRAMS J3 BOARD IC8810 TDA8601T DECODING SELECTABLE CLAMP SELECTABLE 3-STATE CLAMP SELECTABLE CLAMP SELECTABLE 3-STATE CLAMP SELECTABLE CLAMP SELECTABLE 3-STATE CLAMP 3-STATE G BOARD IC6001 MCZ3001D D2 BOARD IC6800 MCZ3001D Remote Internal DVLD Driver ref 5v Sel=34v Reg.
  • Page 77 A BOARD IC1231 MSP3411G SBUS Interface I2C Interface DEMODULATOR IDENT SCART Switching Facilities G BOARD IC6003 SE135N-LF4 A BOARD IC1801/IC1804/IC1808 LM393DT A BOARD IC1701 STV9379 A BOARD IC1802 LM358 FLYBACK GENERATOR POWER AMPLIFIER THERMAL PROTECTION - 77 -...
  • Page 78 A BOARD IC1002/IC1003/IC1006/IC1007/IC1010 PQ1CG2032FZ Vout ON/OFF PWM COMP ON/OFF ERROR AMP Oadj Vref A BOARD IC1012/IC1812 BA033T/BA12T D2 BOARD IC6801/IC6802 NJM2903/NJM2904 REFERENCE VOLTAGE D2 BOARD IC6803/IC6807 TLV431 Cathode Vref Anode - 78 -...

  • Page 79: Exploded Views

    SECTION 6 EXPLODED VIEWS NOTE : Items with no part number and no description are not Items marked “*” are not stocked stocked because they are seldom required for routine since they are seldom required for service. routine service. Some delay should The construction parts of an assembled part are indicated be anticipated when ordering these with a collation number in the remarks column.

  • Page 80: Picture Tube

    6-2. PICTURE TUBE REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK X-4039-981-2 CABINET ASSY 52-57 4-087-586-01 CABINET 4-087-528-01 M/S GUIDE LIGHT 4-087-533-01 MULTI BUTTON 4-087-527-01 POWER BUTTON 4-204-426-01 SPRING 4-087-530-01 GUIDE, LIGHT 4-083-848-02 DAMPER, DOOR 4-087-552-11 DOOR X-4039-980-2 BEZEL ASSY £...

  • Page 81: Electrical Parts List

    SECTION 7 ELECTRICAL PARTS LIST PARTS LISTING TABLE OF CONTENTS Page D1 BOARD COMPLETE Parts List : ..................82 D2 BOARD COMPLETE Parts List : ..................84 B5 BOARD COMPLETE Parts List : ..................86 G BOARD COMPLETE Parts List : ..................
  • Page 82 H6 D1 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C8817 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V * A-1300-281-A DI Board, Complete C8820 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V 4-382-854-01 SCREW (M3X8), P, SW (+) C8821 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C8822 1-136-479-11 FILM...
  • Page 83 PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK Q8101 8-729-048-47 TRANSISTOR 2SC2688(5)-LK R8308 1-216-841-11 METAL CHIP 1/10W Q8102 8-729-056-16 TRANSISTOR 2SC5698-SONY-CA R8309 1-216-841-11 METAL CHIP 1/10W Q8103 8-729-056-17 TRANSISTOR 2SC5696-SONY-CA R8317 1-215-473-00 METAL 150K 1% 1/4W Q8105 8-729-050-48 TRANSISTOR IRF614-005 R8318...
  • Page 84 D1 D2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C6836 1-136-165-00 FILM 0.1UF 5.00% 50V R8844 1-215-469-00 METAL 100K 1% 1/4W C6837 1-136-103-00 FILM 0.1UF 5.00% 200V R8845 1-215-469-00 METAL 100K 1% 1/4W C6840 1-130-495-00 MYLAR 0.1UF 5.00% 50V R8848 1-216-845-11 METAL CHIP 100K 5%...
  • Page 85 F4 D1 D2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < IC > R6825 1-218-912-11 METAL CHIP 510K 0.5% 1/10W R6827 1-218-883-11 METAL CHIP 0.5% 1/10W IC6800 8-759-670-30 IC MCZ3001D R6828 1-218-895-11 METAL CHIP 100K 0.5% 1/10W IC6801 8-759-700-07 IC NJM2903M R6829 1-216-841-11 METAL CHIP 1/10W...
  • Page 86 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R8957 1-218-847-11 METAL CHIP 0.5% 1/10W C3128 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V R8988 1-260-123-11 CARBON 100K 5% 1/2W C3129 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V R8989 1-249-429-11 CARBON 1/4W C3130 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V R8990 1-216-845-11 METAL CHIP...
  • Page 87 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4209 1-124-779-00 ELECT CHIP 10UF 20.00% 16V C4431 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C4210 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C4432 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C4211 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C4433 1-126-206-11 ELECT CHIP...
  • Page 88 M B5 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4513 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V < CONNECTOR > C4514 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V C4515 1-164-156-11 CERAMIC CHIP 0.1UF CN4472 *1-816-448-11 CONNECTOR, BOARD TO BOARD 50P C4516 1-164-156-11 CERAMIC CHIP 0.1UF CN4473 *1-816-550-11 CONNECTOR, BOARD TO BOARD 20P...
  • Page 89 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK FL4406 1-234-177-21 FERRITE L4408 1-469-522-91 INDUCTOR FL4407 1-234-177-21 FERRITE L4409 1-469-522-91 INDUCTOR FL4408 1-234-177-21 FERRITE L4410 1-469-522-91 INDUCTOR FL4409 1-234-177-21 FERRITE L4411 1-469-525-91 INDUCTOR 10UH FL4410 1-234-177-21 FERRITE L4412 1-412-026-11 INDUCTOR FL4411 1-234-177-21 FERRITE L4601 1-419-370-21 INDUCTOR...
  • Page 90 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < RESISTOR > R3151 1-216-815-11 METAL CHIP 1/10W R3152 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W R3100 1-216-864-11 SHORT CHIP R3153 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W R3101 1-216-864-11 SHORT CHIP R3154 1-216-818-11 METAL CHIP 1/10W R3102 1-216-813-11 METAL CHIP...
  • Page 91 H5 D2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4212 1-216-833-11 METAL CHIP 1/10W R4334 1-216-809-11 METAL CHIP 1/10W R4213 1-216-833-11 METAL CHIP 1/10W R4335 1-216-809-11 METAL CHIP 1/10W R4214 1-216-833-11 METAL CHIP 1/10W R4336 1-216-809-11 METAL CHIP 1/10W R4215 1-216-864-11 SHORT CHIP R4337...
  • Page 92 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4491 1-216-864-11 SHORT CHIP R4611 1-216-864-11 SHORT CHIP R4492 1-216-864-11 SHORT CHIP R4612 1-216-864-11 SHORT CHIP R4495 1-216-864-11 SHORT CHIP R4613 1-216-864-11 SHORT CHIP R4498 1-216-864-11 SHORT CHIP R4626 1-216-801-11 METAL CHIP 1/10W R4499 1-216-864-11 SHORT CHIP...
  • Page 93 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK RB4205 1-239-409-11 NETWORK RESISTOR (CHIP) 47 C6003 £ 1-119-898-51 CERAMIC 2200PF 20.00% 250V RB4206 1-239-409-11 NETWORK RESISTOR (CHIP) 47 C6004 £ 1-119-898-51 CERAMIC 2200PF 20.00% 250V RB4207 1-239-409-11 NETWORK RESISTOR (CHIP) 47 C6005 1-126-965-91 ELECT 22UF...
  • Page 94 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK CN6010 *1-564-511-11 PLUG, CONNECTOR 8P < PHOTOCOUPLER > CN6013 *1-564-506-11 PLUG, CONNECTOR 3P CN6014 1-695-915-11 TAB (CONTACT) PH6001 £ 8-749-016-21 IC TCET1103G CN6015 1-695-915-11 TAB (CONTACT) < TRANSISTOR > < DIODE > Q6003 8-729-010-29 TRANSISTOR MSD601-RST1 D6001...
  • Page 95 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R6042 1-216-295-91 SHORT CHIP < CONNECTOR > R6045 1-216-639-11 METAL CHIP 0.5% 1/10W R6047 1-216-681-11 METAL CHIP 0.5% 1/10W CN401 *1-816-104-12 CONNECTOR, MEMORY STICK R6048 1-215-481-00 METAL 330K 1% 1/4W CN402 *1-816-124-11 PIN, CONNECTOR (FOR PWB) 18P R6049 1-208-805-11 METAL CHIP 9.1K 0.5% 1/10W...
  • Page 96 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R404 1-216-801-11 METAL CHIP 1/10W < RESISTOR > R405 1-218-692-11 METAL CHIP 0.5% 1/16W R406 1-216-809-11 METAL CHIP 1/10W R903 1-249-406-11 CARBON 1/4W R407 1-216-809-11 METAL CHIP 1/10W R904 1-249-406-11 CARBON 1/4W R408 1-216-809-11 METAL CHIP 1/10W...
  • Page 97 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C9048 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V < RESISTOR > C9049 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V C9050 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V R9001 1-216-633-11 METAL CHIP 0.5% 1/10W C9051 1-535-303-00 LEAD, JUMPER (5.0MM) R9003 1-535-303-00 LEAD, JUMPER (5.0MM) R9006...
  • Page 98 C1 H REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R9072 1-247-807-31 CARBON 1/4W < RESISTOR > R9073 1-216-049-11 RES-CHIP 1/10W R9092 1-216-295-91 SHORT CHIP R300 1-216-833-11 METAL CHIP 1/10W R9094 1-216-295-91 SHORT CHIP R301 1-216-809-11 METAL CHIP 1/10W R9095 1-216-295-91 SHORT CHIP R302 1-216-809-11 METAL CHIP...
  • Page 99 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < FUSE > C8864 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V C8865 1-164-156-11 CERAMIC CHIP 0.1UF F2601 £ 1-576-232-21 FUSE (H.B.C.) 5A/250V C8866 1-165-908-91 CERAMIC CHIP 1UF £ 1-533-725-11 HOLDER, FUSE (F2601) C8867 1-164-156-11 CERAMIC CHIP 0.1UF C8868 1-164-156-11 CERAMIC CHIP 0.1UF...
  • Page 100 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C8920 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V C9186 1-164-156-11 CERAMIC CHIP 0.1UF C8921 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V C9188 1-104-665-11 ELECT 100UF 20.00% 25V C8922 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V C9189 1-104-665-11 ELECT 100UF...
  • Page 101 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < FERRITE BEAD > < RESISTOR > FB8800 1-469-869-21 FERRITE R8109 1-249-389-11 CARBON 1/4W R8110 1-249-389-11 CARBON 1/4W < FILTER > R8115 1-216-029-00 RES-CHIP 1/10W R8116 1-216-029-00 RES-CHIP 1/10W FL8808 1-236-071-11 ENCAPSULATED COMPONENT R8117 1-216-029-00 RES-CHIP 1/10W...
  • Page 102 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R8911 1-216-113-00 RES-CHIP 470K 5% 1/10W R8970 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W R8912 1-216-843-11 METAL CHIP 1/10W R8971 1-216-809-11 METAL CHIP 1/10W R8913 1-216-843-11 METAL CHIP 1/10W R8972 1-216-801-11 METAL CHIP 1/10W R8914 1-218-885-11 METAL CHIP...
  • Page 103 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R9090 1-216-797-11 METAL CHIP 1/10W R9197 1-216-091-00 RES-CHIP 1/10W R9094 1-216-809-11 METAL CHIP 1/10W R9198 1-216-837-11 METAL CHIP 1/10W R9095 1-216-833-11 METAL CHIP 1/10W R9199 1-216-817-11 METAL CHIP 1/10W R9099 1-216-809-11 METAL CHIP 1/10W R9200 1-216-817-11 METAL CHIP...
  • Page 104 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C1052 1-126-935-11 ELECT 470UF 20.00% 16V * A-1401-417-A A Board, Complete C1053 1-126-964-11 ELECT 10UF 20.00% 50V C1054 1-126-964-11 ELECT 10UF 20.00% 50V 4-201-023-01 SPACER, INSULATING 4-202-373-01 SPRING, IC C1055 1-164-156-11 CERAMIC CHIP 0.1UF C1056 1-164-156-11 CERAMIC CHIP 0.1UF *4-206-387-11 SHIELD BASE, N...
  • Page 105 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C1238 1-115-340-11 CERAMIC CHIP 0.22UF 10.00% 25V C1424 1-126-963-11 ELECT 4.7UF 20.00% 50V C1239 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V C1425 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V C1242 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V C1426 1-115-340-11 CERAMIC CHIP 0.22UF...
  • Page 106 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C1807 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V C4025 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V C1808 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V C4026 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V C1814 1-126-947-11 ELECT 47UF 20.00% 35V C4027 1-162-974-11 CERAMIC CHIP 0.01UF...
  • Page 107 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < DIODE > D1808 8-719-914-43 DIODE DAN202K D1809 8-719-987-87 DIODE ERA85-009 D1001 8-719-500-70 DIODE D5S4M D1810 8-719-991-33 DIODE 1SS133T-77 D1002 8-719-500-70 DIODE D5S4M D1811 8-719-914-43 DIODE DAN202K D1003 8-719-914-43 DIODE DAN202K D1813 8-719-063-73 DIODE D1NL20U-TR D1004 8-719-914-43 DIODE DAN202K...
  • Page 108 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < FILTER > L1003 1-414-934-21 INDUCTOR 10UH L1004 1-412-525-31 INDUCTOR 10UH FL1010 1-233-736-21 FILTER, EMI L1005 1-412-525-31 INDUCTOR 10UH FL1011 1-239-899-21 FERRITE L1006 1-419-249-11 INDUCTOR 15UH FL1231 1-236-071-11 ENCAPSULATED COMPONENT L1007 1-419-249-11 INDUCTOR 15UH FL1232 1-236-071-11 ENCAPSULATED COMPONENT...
  • Page 109 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK Q1006 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R < RESISTOR > Q1007 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R JR1006 1-216-864-11 SHORT CHIP Q1008 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R JR1007 1-216-864-11 SHORT CHIP Q1009 8-729-028-28 TRANSISTOR 2SK2036(TE85L) JR1238 1-216-295-91 SHORT CHIP Q1010 8-729-028-28 TRANSISTOR 2SK2036(TE85L) R1001 1-216-829-11 METAL CHIP...
  • Page 110 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R1050 1-216-809-11 METAL CHIP 1/10W R1137 1-216-864-11 SHORT CHIP R1051 1-218-837-11 METAL CHIP 0.5% 1/10W R1144 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1052 1-218-847-11 METAL CHIP 0.5% 1/10W R1145 1-216-650-11 METAL CHIP 0.5% 1/10W R1053 1-218-837-11 METAL CHIP...
  • Page 111 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R1256 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1460 1-216-809-11 METAL CHIP 1/10W R1260 1-216-809-11 METAL CHIP 1/10W R1461 1-216-809-11 METAL CHIP 1/10W R1261 1-216-809-11 METAL CHIP 1/10W R1462 1-216-809-11 METAL CHIP 1/10W R1270 1-216-815-11 METAL CHIP 1/10W...
  • Page 112 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R1721 1-216-844-11 METAL CHIP 1/10W R1900 1-216-864-11 SHORT CHIP R1722 1-216-833-11 METAL CHIP 1/10W R1905 1-218-756-11 METAL CHIP 150K 0.5% 1/10W R1723 1-216-836-11 METAL CHIP 1/10W R1906 1-208-782-11 METAL CHIP 0.5% 1/10W R1801 1-216-841-11 METAL CHIP 1/10W...
  • Page 113 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4009 1-469-564-11 FERRITE R4102 1-216-864-11 SHORT CHIP R4010 1-469-564-11 FERRITE R4103 1-216-864-11 SHORT CHIP R4011 1-216-805-11 METAL CHIP 1/10W R4104 1-216-864-11 SHORT CHIP R4012 1-469-564-11 FERRITE R4105 1-216-864-11 SHORT CHIP R4013 1-216-864-11 SHORT CHIP R4106 1-216-864-11 SHORT CHIP R4014...
  • Page 114 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C105 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V < FERRITE BEAD > C107 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C108 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V FB103 1-414-766-22 FERRITE C109 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V FB104 1-414-766-22 FERRITE...
  • Page 115 J3 M2 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R123 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R190 1-216-801-11 METAL CHIP 1/10W R124 1-216-864-11 SHORT CHIP R191 1-216-801-11 METAL CHIP 1/10W R125 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R192 1-216-801-11 METAL CHIP 1/10W R126 1-216-833-11 METAL CHIP...
  • Page 116 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK RB119 1-239-621-11 NETWORK RESISTOR (CHIP) 22 < TRANSISTOR > RB120 1-234-524-21 RES, CHIP NETWORK 33 RB121 1-234-524-21 RES, CHIP NETWORK 33 Q5400 8-729-119-78 TRANSISTOR 2SC2785-HFE RB122 1-234-524-21 RES, CHIP NETWORK 33 Q5401 8-729-119-78 TRANSISTOR 2SC2785-HFE RB123 1-234-524-21 RES, CHIP NETWORK 33...
  • Page 117 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D4611 8-719-991-33 DIODE 1SS133T-77 * A-1636-052-A G1 Board, Complete D4612 8-719-063-70 DIODE D1NL20U 4-202-373-01 SPRING, IC 4-382-854-01 SCREW (M3X8), P, SW (+) < FERRITE BEAD > < CAPACITOR > FB4602 1-410-396-41 FERRITE 0.45UH FB4603 1-410-396-41 FERRITE...
  • Page 118 VM G1 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4616 1-216-366-00 METAL OXIDE 0.56 5% MISCELLANEOUS R4617 1-249-415-11 CARBON 1/4W R4618 1-249-420-11 CARBON 1.8K 5% 1/4W £ 1-571-433-21 SWITCH, PUSH (AC POWER) 1-424-855-11 COIL, CHOKE 29MMH < RELAY > £...
  • Page 119 • User programmable Functional Check through Infrared • Fast and documented Test Mode setting of all Sony TV chassis Additional features such as Adjustments and Troubleshooting are available in chassis-dependent software modules. Please contact your local Sony Service organisation for the latest information.
