product introduction

CABLE SELECTION

Item
Power (DC12V)
1
DC Power Product
Wiegand I/O
2
Product Controller connected
External Reader Product
Signal I/O
3
£
Controller Product
RS-485 Cable
£
4
Converter Host PC
£
Converter Product
10_
product introduction
Cable Type
Belden #9409, 18 AWG 2 Conductor, Unshielded Belden #9409, 18 AWG 2 Conductor, Unshielded
Belden #9512, 22 AWG 4 Conductor, Shielded
Belden #9514, 22 AWG 8 Conductor, Shielded
Belden #9512, 22 AWG 4 Conductor, Shielded
Belden #9514, 22 AWG 8 Conductor, Shielded
Belden #9829, 24 AWG 2-twisted pair, Shielded
