Summary of Contents for Samsung WA13V9
-
Page 1: Washing Machine
WA13V9 WA10V9 Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register WA10V9-02604G-02_EN.indd 1 2011-03-23 5:20:40... -
Page 2: Features
features 1. Air Turbo Drying System Air Turbo technology spins hard and fast so you can spend less time drying. Time Saving AIR TURBO saves your time, ensuring your clothes are dried 30%-40% faster than line drying alone. Especially during the rainy season and in high-humid weather, laundry that once took days to drip-dry, such as heavy jeans, bulky sweaters, and thick blankets are dried more rapidly. -
Page 3: Safety Instructions
safety instructions Please note that the following precautions for safety intend to prevent unpredictable danger and damage by helping the proper use in safety. When using hot water in washing, please make sure that the water should not exceed 50°C. - Plastic parts may be deformed or damaged, and an electric shock or a fire may take place. - Page 4 safety instructions CAUTIONS There might be a slight injury or damage when you violate this instruction. • Don’t install it in the area with moisture or outdoor where it has rain or snow. − An electric shock or a fire may take place. • Please unplug the power supply cord when you do not use it.
-
Page 5: Table Of Contents
contents setting up your washer Description of part Checking before washing and caring for garments How to wash automatically depends on the laundry Control Panel Fuzzy program Blanket program Wool program Memory program Easy program Quick program Super Clean ECO+ program Delay Start Air Turbo manual functions... -
Page 6: Setting Up Your Washer
setting up your washer DeSCRIPTION OF PART The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Be sure to keep the lid closed during washing and spinning. filter water supply hose (hot) water supply hose (cold) Drain hose (pump) Lint will be collected in the filter... -
Page 7: Checking Before Washing And Caring For Garments
CHeCKING BeFORe WASHING AND CARING FOR GARMeNTS Must follow the checkpoints in order to avoid machine problems or damages on garments. • If the below problems are caused by customer’s faults, separate service fee will be charged. checkpoints before starting washing Check if the clothes are bleaching or not. -
Page 8: Caring For Clothes Before Washing
setting up your washer CARING FOR CLOTHeS BeFORe WASHING take out personal belongings from pockets. • Caution, Check the pockets! Hairpins and coins cause damages to clothes and washing machine. They make noise and problems to the machine. Must check the pocket. if pants zippers are open while washing, the spin basket may be damaged. -
Page 9: How To Wash Automatically Depends On The Laundry
HOW TO WASH AUTOMATICALLy DePeNDS ON THe LAUNDRy before starting washing, check the following; • Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose. Washing for the first time Before washing clothes for the first time, you must run a complete cycle without clothes. -
Page 10: Control Panel
setting up your washer CONTROL PANeL For more details, see control panel of your washing machine. Press this button once to turn the power on. power button Press it again to turn the power off. Press to pause and restart programs. start/pause To change the washing procedure during an operation, press this button to button... -
Page 11: Fuzzy Program
remaining time, The display shows the remaining wash time, the reserved delayed start Delay start time, time and error messages. error Display Press this button to finish the wash at a specified time. Turn your washer off Delay start to cancel a previously delayed start time. button You can set the delayed start time from between 3 to 18 hours. -
Page 12: Wool Program
Then, the changes are stored. easy program If you choose EASY, you will enjoy full access to all of Samsung Washing Machine’s userfriendly functions at your fingertips. When selecting this program, Air Turbo is selected automatically. -
Page 13: Quick Program
Quick program The Quick program is good for light or slightly stained laundry. 1. Press the power button to turn the washer “On”. 2. Press the program select button. 3. Press the start/pause button. The water level is selected automatically. 4. -
Page 14: Air Turbo
setting up your washer Air Turbo This program saves you valuable time, ensuring that your clothes dry faster than from line drying. 1. Press the power button to turn the washer “On”. 2. Press the air turbo button. Each time the Air Turbo button is pressed, the operations are performed in the following order: 30 Min ... -
Page 15: Manual Functions
manual functions Possible to select the function for each program. (Example) For a simple washing as the little dirt program : Power Select the little dirt program Wash Start/Pause wash only Press the power button. Press the wash button. Press the start/pause button. -
Page 16: Installation & Maintenance
installation & maintenance The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. eNVIRONMeNT Leave some space Maintain at least 10cm between the washer and the wall. Place the washer on a sturdy flat surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs. -
Page 17: Connecting The Water Supply Hose
CONNeCTING THe WATeR SUPPLy HOSe 1. Remove the adaptor from the water supply hose. 2. First, using a “+” type screw driver, loosen the four screws on the adaptor. Next, take the adaptor and turn part(b) following the arrow for gap about 5 mm between them. 3. -
Page 18: How To Connect The Drain Hose
installation & maintenance HOW TO CONNeCT THe DRAIN HOSe IN CASe OF PUMP-DRAINeD WASHeR cap-hose Take out the cap-hose and connect the Be sure to join tightly the drain hose into the outlet-hose. drainoutlet on the back of the machine. Be sure to join tightly the drain hose into the Install the drain hose in the position of about drain-outlet on the side of the machine. -
Page 19: Assembling The Rat Protection Panel
ASSeMBLING THe RAT PROTeCTION PANeL Label 1. Insert the rat protection panel to the 2. For easy to insert the protection panel assembling hole on back side to the end. should push to in front a little.Next,insert the rat protection panel from back side to the end. -
Page 20: Cleaning The Filter
installation & maintenance CLeANING THe FILTeR Clean the filter net often to keep the washer clean. 1. Push the upper part of the Magic filter 2. Open the cover as shown in the figure. and pull in. 3. Clean the Magic filter. 4. -
Page 21: Troubleshooting
troubleshooting problem check Washing machine won’t work - Is the water tap opened? - Is the washer plugged in? - Is the power cut off? - Is there enough water? Water dose not drain - Is the drain hose down?(No pump) - Is the drain hose frozen? - Is the drain hose clogged? - If the water dose not drain in 15 minutes, a buzzer will sound,... -
Page 22: Washing Machine Won't Work
washing machine won’t work? problem check & solution The power is cut off. Is the electric voltage normal? Is the washer plugged in? Plug in the electric cord. Water does not drain. Is the drain hose down? Put the drain hose down. Is the drain hose folded? Unfold the drain hose. -
Page 23: Specification
EXTRA LOW 43 l 0.05~0.78 MPa WATER PRESSURE WATER USAGE 212 l (0.5 ~ 8.0 kg f/cm WASHING TYPE SPIN SPEED Stirring Type 720 rpm wa13V9 WASH 470 W HIGH 83 l POWER CONSUMPTION SPIN 280 W 76 l STANDARD DIMENSIONS(mm) - Page 24 QUESTIONS OR COMMENTS? country call or Visit us online at SOUTH AFRICA 0860-SAMSUNG(726-7864 ) www.samsung.com Code No. DC68-02604G-02_EN WA10V9-02604G-02_EN.indd 24 2011-03-23 5:20:43...
