INVERTER MULTI
AIR CONDITIONER
WALL MOUNTED
Models
Indoor unit
ASYA07LACM
ASYA09LACM
ASYA12LACM
ASYA07LACM
ASYA09LACM
ASYA12LACM
CONTENTS
. . . . . . . . . . . . . . . . . . . . 1
OUTLINE AND DIMENSIONS
. . . . . . . . . . . . . . . . . . . 6
. . . . . . . . . . . . . . . . .14
. . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . 19
type
Outdoor unit
AOYA18LAT3
AOYA24LAT3
. . . . . . . . . . . 3
. . . . . 5
. . . . . . . 8
. . . .11
. . . . . . . . . . 22
Advertisement
Table of Contents
Related Manuals for Fujitsu ASYA07LACM
Summary of Contents for Fujitsu ASYA07LACM
-
Page 1: Table Of Contents
INVERTER MULTI AIR CONDITIONER WALL MOUNTED type Models Indoor unit Outdoor unit ASYA07LACM AOYA18LAT3 ASYA09LACM ASYA12LACM ASYA07LACM AOYA24LAT3 ASYA09LACM ASYA12LACM CONTENTS ....1 SPECIFICATIONS . -
Page 2: Specifications
SPECIFICATIONS INDOOR UNIT ELECTRICAL DATA COOL & HEAT TYPE INDOOR UNIT ASYA07LACM ASYA09LACM ASYA12LACM COOLING CAPACITY 2.3 kW 2.7 kW 3.5 kW HEATING CAPACITY 2.7 kW 3.3 kW 4.0 kW 0.8 L/hr 1.0 L/hr 1.2 L/hr MOISTURE REMOVAL AIR CIRCULATION HIGH... - Page 3 OUTDOOR UNIT ELECTRICAL SPECIFICATIONS TYPE Colling & heating multi Colling & heating multi MODEL NAME AOYA18LAT3 AOYA24LAT3 COOLING CAPACITY 5.4 kW 6.8 kW HEATING CAPACITY 6.8 kW 8.0 kW POWER SUPPLY (220V) - 230V - (240V) (220V) - 230V - (240V) FREQUENCY 50 Hz 50 Hz...
- Page 4 DIMENSIONS INDOOR UNIT (unit : mm) 2007.04.18...
- Page 5 OUTDOOR UNIT (Unit : mm) Air Flow 2007.04.18...
-
Page 6: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM OUTDOOR UNIT Discharge thermistor Heat exchanger Mufller Compressor Receiver tank Pressure Heat exchanger switch (A) 4-way valve Strainer Accumulator Pressure switch (B) Distributor Expansion Expansion Expansion valve valve valve Pipe Pipe Pipe Pipe Pipe Pipe Thermistor Thermistor Thermistor Thermistor Thermistor... -
Page 7: Circuit Diagram
CIRCUIT DIAGRAM INDOOR UNIT CN201 WHITE WHITE WHITE WHITE CN10 WHITE WHITE ORANGE YELLOW STEP MOTOR PINK BLUE BLUE YELLOW BLACK WHITE PIPE TEMPERATURE BLACK BLACK FAN MOTOR THERMISTOR BLACK ROOM TEMPERATURE BLACK THERMISTOR SWITCH POWER CIRCUIT GRAY GRAY VARISTOR GREEN THERMAL FUSE 102... -
Page 8: Outdoor Unit Circuit Diagram
OUTDOOR UNIT 4-WAY VALVE CONSTRUCTION CHECK SWITCH SW150 CN37 CN30 PRESSURE SWITCH 1 COMPRESSOR WHITE FAN MOTOR CURRENT WHITE CN36 PRESSURE SWITCH 2 SWITCHING WHITE WHITE 3 2 1 BROWN BLUE CN27 EXPANSION VALVE A ORANGE YELLOW WHITE F4 FUSE 2-WAY VALVE BLACK THERMISTOR A... -
Page 9: Indoor Pcb Circuit Diagram
INDOOR PCB CIRCUIT DIAGRAM CONTROL UNIT ASYA07LACM : EZ-0070HSE ASYA09LACM : EZ-0071HSE TERMINAL ASYA12LACM : EZ-0072HSE BLACK WHITE OUTDOOR UNIT SERIAL EARTH EARTHING TERMINAL GREEN BLACK WHITE B3B-XASK THERMAL FUSE BS5P-SHF-1AA CN8-1 CN8-2 CN8-3 TEST CN8-4 CN8-5 CN201 S7B-ZR-3.4 ZHR-07... -
Page 10: White-
INDOOR UNIT CONTROLLER PCB ASSEMBLY ASYA07LACM : K06AT-0700HSE-C1 ASYA09LACM : K06AT-0701HSE-C1 ASYA12LACM : K06AT-0702HSE-C1 THERMAL FUSE THERMISTOR CURCUIT RESET CURCUIT 5V POWER SUPPLY CN7 B3B-XASK OUTDOOR UNIT 13.5V I C6 1.0K NJM7805 <1/10W> <1/10W> 10K <1/10W> x 2 R42 49.9K... -
Page 11: White-
INDOOR UNIT INDICATOR PCB ASSY K02CB-0300HSD-D0 D204 SLR-325 < ORANGE> D203 SLR-325 CN201 <GREEN> D202 SLR-325 07 JB/ZHR 1061 <GREEN> D201 SLR-325 <RED> C201 <F> R201 <1/4W> C202 I C201 GP1UM261R 2006.09.27... -
Page 12: Outdoor Pcb Circuit Diagram
OUTDOOR PCB CIRCUIT DIAGRAM INVERTER ASSEMBLY AOYA18LAT3 : EZ-006KHUE AOYA24LAT3 : EZ-0068HUE CHOKE COIL L=0.3MH 30A UL1015 UL1015 AWG14 AWG14 F201 BLACK BLACK TLC 25A-250V, B UL1015 TERMINAL AWG14 (250V 25A) HP-T4005-21 BLACK UL1015 UL1015 UL1015 UL1015 AC230V AWG14 AWG14 BLACK AWG14 AWG14... -
Page 13: White-
CONTROLLER PCB ASSEMBLY AOYA18LAT3 : K04AW-0605HUE-C1 AOYA24LAT3 : K04AW-0602HUE-C1 MAIN CURRENT YELLOW R200 R201 C201 C202 C203 C116 ZPR0RCH400A250 220K 600/ 600/ 600/ D101 <2W> 450V 450V 450V <HCP> 195K <RN - 1/2W> x 6 D25XB60 0.033 <2W> x 8 R111 C115 BLACK... - Page 14 OUTDOOR UNIT POWER SUPPLY PCB ASSEMBLY K04BA-0505HUE-P0 TM100 N200500K1D7C-01 RCV2515-010PF05 RCV2515-010PF05 TM101 VA101 C104 BLACK 470V 0.033 C107 C111 C101 <TNR> <YE> POWER SOURCE VA102 C105 <LE> <LE> <LE> 230V 0.033 470V 50Hz <TNR> <YE> TM102 C106 WHITE SA100 <LE> RA-302M BLACK TO INDOOR UNIT...
-
Page 15: Error Contents
ERROR CONTENTS INDOOR UNIT Error display Indoor unit LED Error contents OPERATION TIMER AIR CLEAN COIL DRY or QUIET (Red) (Green) (Green) (Orange) 2 - 5 Communication error Indoor unit - Outdoor unit flashes Room temp. sensor error 2 flashes 2 flashes Indoor unit temperature error Heat exchanger temp. - Page 16 OUTDOOR UNIT LEDS LED A LED B LED C Communication error (indoor unit A to outdoor unit) 1 time Communication error (indoor unit B to outdoor unit) 1 time Communication error (indoor unit C to outdoor unit) 1 time Discharge pipe temperature sensor 2 times Outdoor heat exchanger temperature sensor 3 times...
-
Page 17: Parts (Indoor Unit)
PARTS INDOOR UNIT Front panel assy INVERTER Ref. Description Part number Front Panel Assy 9313130169 Intake Grille Assy 9313131128 Air Filter 9309997011 Front Panel 9309999053 Clamper (Grille) 9306755010 Air Clean Filter Assy 9312152018 Electric Filter Holder 9306602017 Remote Control Unit 9315027030 Remote Control Holder 9305642045... - Page 18 INDOOR UNIT Casing assy Ref. Description Part number Casing Assy 9311354116 Casing Cover B 9314160011 Casing Cover F 9309987005 Louver Holder 9309993013 Drain Hose Assy 9314147029 Drain Cap Assy 9316177017 Louver U Assy 9312368020 Louver Z Assy 9312369027 2007.04.17...
- Page 19 INDOOR UNIT Ref. Description Part number Gear A 9309994003 Crossflow Fan Assy 9307836015 Clamp (Motor) 9310102008 Shaft Holder C Assy 9306628017 Wire Clamper 9313944018 Holder (Room Thermistor) 9311948018 Cover (Switch) 9313943011 Evaporator Total Assy 9313099039 Joint Pipe Assy 9313104016 Insulation (Pipe) E 9304607007 Holder (Evaporator) L 9309982017...
-
Page 20: Parts (Outdoor Unit)
OUTDOOR UNIT Ref. Description Part number Top Panel Sub Assy 9374417049 Front Panel 9374094080 Fan Guard 9374330010 Grip Side 9374173013 Service Panel Sub Assy 9374415045 Right Panel 9374599042 Grip 9374172016 Valve Cover Sub Assy 9374827015 Propeller Fan Assy 9366378020 Fan Motor 9601882015 Condencer A Assy 9374433179... - Page 21 OUTDOOR UNIT Connector : RED Connector : WHITE Ref. Description Part number Ref. Description Part number Separate Wall Assy 9375226022 Coil (Expansion Valve) (A=Red) 9900057084 Coil. Choke 9900366018 Coil (Expansion Valve) (B=White) 9900057053 Compressor Assy 9315297037 Coil (Expansion Valve) (C=Green) 9900057060 4-Way Valve Assy 9374425136...
- Page 22 OUTDOOR UNIT Inverter assy Ref. Description Part number Inverter Box A 9374603015 Inverter Box B Assy 9374625024 Inverter Box C 9375140014 Inverter Box Duct 9374609017 Inverter Box Cover 9375139018 Heat Sink A 9375138011 Inverter Box D 9374606023 Terminal (6P) 9900016036 Terminal (3P) 9306489045 Fuse Holder (Big)
-
Page 23: Standard Accessories
STANDARD ACCESSORIES INDOOR UNIT Name and Shape Q'ty Part No. Wall hook For indoor unit installation bracket 9310001004 Remote Use for air conditioner INVERTER control unit operation 9315027030 Battery (penlight) For remote control unit 0600185527 Cloth tape For indoor unit installation 9310519004 Remote control Use as remote control unit... - Page 24 0703G3212...
