Contents Getting started Headset overview ..................55 Button functions ..................56 Charging the headset ................57 Wearing the headset ................59 Using your headset Turning the headset on or off..............61 Using voice prompts ................61 Pairing and connecting the headset ............64 Pairing via the Active pairing feature .............68 Using call functions................69 Using music control functions ..............73 Resetting the headset................74...
Page 55
Samsung Electronics. Trademarks • SAMSUNG, and the SAMSUNG logo are registered trademarks of Samsung Electronics. ® • Bluetooth is a registered trademark of the Bluetooth SIG, Inc.
Do not disassemble, modify, or repair your device. Any changes or modifications to your device can void your manufacturer’s warranty. If your device needs servicing, take your device to a Samsung Service Centre. • Do not bite or suck the device. Children or animals can choke on small parts.
Getting started This section explains the basic parts and functions of your Bluetooth headset. Headset overview 3.5 mm audio jack Mode button Microphone Volume button Indicator light Power switch Control button Talk button Multifunction jack • Make sure you have the following items: Travel adapter, headset, 3.5 mm stereo headphone, and user manual.
Button functions Button Function Power • Slide up or down to turn the headset on or off. Switch • Press to make or answer a call. Talk • Press to end a call. • Press and hold to enter Pairing mode. •...
Charging the headset The headset has a rechargeable internal battery which is non-removable. Make sure the headset is fully charged before using it for the first time. To check the battery level, see page 58. Connect the charger to the multifunction jack (see below images). Plug the charger in to the wall outlet.
• Use only Samsung-approved chargers. Unauthorised or Non-Samsung chargers could cause damage to the headset or in extreme circumstances an explosion, it could also invalidate any warranty on the product. • To save energy, unplug the travel adapter when not in use.
Indicator Battery level Voice prompt light colour Above 80% Blue “Headset battery level is high” 80 ~20% Violet “Headset battery level is medium” Below 20% “Headset battery level is low” Wearing the headset Use the supplied 3.5 mm stereo headphone. Connect the headphone to the headset.
Using your headset This section explains how to turn the headset on or off, pair and connect the headset to the phone, and use various functions. • Activated functions and features may differ depending on the phone type. • Some devices, especially those that are not tested or approved by the Bluetooth Special Interest Group (SIG), may be incompatible with your headset.
The headset provides following these languages: English, Spanish, French, German and Chinese. The default setting is English. If the headset is turned on for the first time, you will hear “Thank you for using the Samsung Bluetooth headset. Press both volume buttons simultaneously to confirm language.”...
Turning the voice prompt on or off To turn voice prompts on In Pairing mode, press and hold the Volume up button for 4 seconds. You will hear “Voice prompt is on.” To enter Pairing mode, see page 64. To turn voice prompts off In Pairing mode, press and hold the Volume down button for 4 seconds.
Page 65
Status Voice prompt When you turn the voice “Voice prompt is on” or prompt on or off “Voice prompt is off” When you turn Multi-point “Multi-point mode is on” or feature on or off “Multi-point mode is off” When you connect the “Device is connected”...
Even though the voice prompt feature has been turned off, you can always hear the following voice prompts. • “Language name selected” • or “Voice prompt is off” “Voice prompt is on” Pairing and connecting the headset Pairing means unique and encrypted wireless connection between two Bluetooth devices when they agree to communicate with each other.
Activate the Bluetooth feature on your phone and search for the headset (see your phone’s user manual). Select the headset (HS3000) from the list of devices found by your phone. If requested, enter the Bluetooth PIN 0000 (4 zeros) to pair and connect the headset to your phone.
Page 68
Activate the Bluetooth feature on the second Bluetooth phone and search for the headset (see your phone’s user manual). Select the headset (HS3000) from the list of devices found by the second Bluetooth phone. If requested, enter the Bluetooth PIN 0000 (4 zeros) to connect the headset to the second Bluetooth phone.
Connecting the headset with a music device You can also pair and connect your headset with a music device such as an MP3 player. The way is same as phones. When the phone and the music device are connected with the headset, you can make or answer a call while you are listening to music from the music device.
Pairing via the Active pairing feature With the Active pairing feature, your headset automatically look for a Bluetooth device and try to make a connection with it. This feature is available for mobile phones, but the phone’s Bluetooth visibility option must be set to on. In Pairing mode, press and hold the Talk button to enter Active pairing mode.
Using call functions Available call functions may differ from phone to phone. Making a call Redialling the latest number To redial the latest number on the primary phone, press the Talk button. To redial the latest number on the secondary phone, press the Talk button twice. For some phones, pressing the Talk button opens the call log list.
Answering a call Press the Talk button to answer a call when you hear incoming call tones. • If you receive calls on both connected devices at the same time you can only answer the call on the primary phone. •...
Page 73
Options available during a call You can use the following functions during a call. Adjusting the volume Press the Volume up or down button to adjust the volume. You will hear a beep when the volume level of the headset reaches it’s lowest or highest level.
Page 74
Answering a second call • Press the Talk button to end the first call and answer a second call on the same phone when you hear call waiting tones. • Press and hold the Talk button to place the first call on hold and answer a second call on the same phone when you hear call waiting tones.
Using music control functions Listening to music Control playback with the following buttons: BUTTON FUNCTION Play/ • Press to start or pause or resume playback on Pause the primary device. • Press twice to start or pause or resume playback on the secondary device.
Applying a sound effect (SoundAlive) You can apply appropriate sound effects for music during listening to music. To apply a sound mode, such as Normal, Vocal, or Instrument, press the mode button while listening to music. You can also switch between the sound modes pressing the mode button.
Appendix Frequently asked questions Will my headset work Your headset will work with devices that support with laptops, PCs, your headset’s Bluetooth version and profiles. and PDAs? For specifications, see page 78. Will anything cause Appliances such as cordless phones and wireless interference with networking equipment may cause interference with my conversation...
Page 78
Can other Bluetooth When you pair your headset to your Bluetooth phone users hear phone, you are creating a private link between my conversation? only these two Bluetooth devices. The wireless Bluetooth technology used in your headset is not easily monitored by third parties because Bluetooth wireless signals are significantly lower in radio frequency power than those produced by a typical mobile phone.
Warranty and parts replacement Samsung warrants this product as free of defects in material, design and workmanship for the period of one year from the original date of purchase. If during the period of warranty this product proves defective under normal use and service you should return the product to the retailer from whom it was originally purchased or a qualified service centre.
Specifications Item Specifications and description Bluetooth version Support profile Headset Profile, Hands-Free Profile, Advanced Audio Distribution Profile Operating range Up to 33 feet (10 metres) Standby time Up to 170 hours* Talk time Up to 7 hours* Play time Up to 6 hours* Charging time Approximately 2 hours* * Depending on the phone type and usage, the actual time may differ.
