KDC-C467/Y/FM/FMA,C667/Y COMPONENT DESCRIPTION 3 7 63 1515 0 GCD PLAYER UNIT (X32-5090-0X) Ref.No. Component Name Application/Function Operation/Condition/Compatibility RF amplifier built in digital servo and data processor IC. Focusing, tracking, sled and spindle servo processing. Detection of dropout, anti-shock, track crossing and off-track conditions.
Page 4
KDC-C467/Y/FM/FMA,C667/Y COMPONENT DESCRIPTION 3 7 63 1515 0 GRF MODULATOR UNIT Ref.No. Component Name Application/Function Operation/Condition/Compatibility UPC7805AHF BU 5V AVR While BACKUP is applied, AVR outputs +5V. LC72329-9274 System MI-COM. System control NJM78L05UA 5V AVR Power supply for FM modulator and RF amplifier IC101 NJM2060M Isolation amp.
KDC-C467/Y/FM/FMA,C667/Y MICROCOMPUTER'S TERMINAL DESCRIPTION 3 7 63 1515 0 GIC7 (CD PLAYER UNIT : X32-5090-0X) Pin No. Pin Name Description Processing Operation NOR/RW CD-DA/CD-RW Switching Not used(N.C.) TSTB CD-TEXT parameter strobe P-CON P-CON output Not used(N.C.) Focus OK input "Hi" : Focus OK...
Page 6
KDC-C467/Y/FM/FMA,C667/Y MICROCOMPUTER'S TERMINAL DESCRIPTION 3 7 63 1515 0 Pin No. Pin Name Description Processing Operation DATAC Data output from the changer HCLK I/O Communication clock input/output with H/U RECQC Communication request to H/U "Lo" : Communication requested CHMUTE Audio mute request to H/U "Lo"...
Page 7
KDC-C467/Y/FM/FMA,C667/Y MICROCOMPUTER'S TERMINAL DESCRIPTION 3 7 63 1515 0 GIC2 (RF MODULATOR UNIT) Pin No. Pin Name Description Processing Operation Main clock resonator connection terminal TEST2 Test mode terminal 2 for test mode Not used(pull down to GND lines.) 3, 4 PG3, PG2 Not used(pull down to GND lines.)
Page 8
KDC-C467/Y/FM/FMA,C667/Y MICROCOMPUTER'S TERMINAL DESCRIPTION 3 7 63 1515 0 Pin No. Pin Name Description Processing Operation HOLD Hold input "Lo" : Microprocessor stop Not used(pull up to +5V lines.) Not used(pull down to GND lines.) HCTR Not used(pull down to GND lines.) LCTR Not used(pull down to GND lines.)
Page 9
KDC-C467/Y/FM/FMA,C667/Y ADJUSTMENT 3 7 63 1515 0 RF MODULATOR UNIT 1. DC balance adjustment (VR301) While observing the waveform with an oscilloscope at pin 13 of IC301, adjust VR301 to minimize the waveform level. 2. PLL control voltage adjustment (VC301) First set the transmission frequency to ∗87.9...
PC BOARD (COMPONENT SIDE VIEW) 3 7 63 1515 0 X13-9840-00 (J74-1100-02) X16-1010-00 (J74-1153-01) MGND LOESW 8/12SW L 13942296513 (FOIL SIDE VIEW) X13-9840-00 (J74-1100-02) X16-1010-00 (J74-1153-01) MGND u163 LOESW 8/12SW Refer to the schematic diagram for the values of resistors and capacitors.
Page 14
(X32-5090-0X) 3 7 6 3 1 5 1 5 0 72(X92-) MGSW AVREF0 NO SW R129 RESET RESET IC CHRST EJSW 5.0V (X13-9840-00) OUT 1 5.0V ARMSW 14.4V REQH RESET CH CON CHCON BU14V BU+14V CH-CON BU+14V CH MUTE CH-RST A GND Q6,7 R-ch...
Page 15
C205 SAGND MODEL C73, CP10, UNIT No. UNIT No. IC11 R157 NAME SD5V SA5V KDC-C667(K,M,E) ELEVATOR X32-5090-00 X92-4310-00 KDC-C667Y(E) ELV+ KDC-C467(K,E) KDC-C467Y(E) X32-5090-01 X92-4310-01 KDC-C467FM(K,E) KDC-C467FMA(E) 2.5V ELV- 9.1K ELVD+ ELVD- 120K 3.2V 3.5V 2.0V 2.0V SIGNAL LINE GND LINE 5.0V...
Page 16
1 6 3 ∗ C208 R212 C211 1u50 KDC-C467/Y/FM/FMA, (2/3) KDC-C667/Y CAUTION : For continued safety, replace safety critical components only with manufacturer's recommended parts (refer to parts • DC voltages are as measured with a high impedance voltmeter. Values list).
Page 17
3 7 63 1515 0 DISPLAY UNIT DATA IN R5 2.2K DATA OUT R4 100 R3 2.2K RESET R2 2.2K R1 2.2K REMO LCD RESET 680P PLAY/ TRACK TRACK POWER PAUSE P4/S4 DISC UP DISC DWN REPEAT RAMDOM LCD DRIVER RESET 10u16 C4 0.022...
KDC-C467/Y/FM/FMA,C667/Y EXPLODED VIEW (UNIT) 3 7 63 1515 0 M4x17.3 N09-4186-25 or N09-4383-05 SILVER φ2x4 N89-2004-46 φ2.6x6 (BLK) N89-2606-45 L 13942296513 BROWN (X13-9840-00) u163 Parts with the exploded numbers larger than 700 are not supplied.
Page 20
KDC-C467/Y/FM/FMA,C667/Y EXPLODED VIEW (RF MODULATOR) 3 7 63 1515 0 L 13942296513 LCD1 φ3x6 (BLK) N09-4207-08 φ3x8 (BLK) N09-4206-08 u163 φ2x4 (BLK) N79-2040-45 φ2x8 (BLK) N79-2080-45 Parts with the exploded numbers larger than 700 are not supplied.
L 13942296513 Display Unit ........0.125kg (0.28lbs) Hide-away Unit ......... 0.6kg (1.3lbs) KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice. KENWOOD CORPORATION 14-6, Dogenzaka 1-chome, Shibuya-ku, Tokyo 150-8501 Japan KENWOOD SERVICE CORPORATION KENWOOD ELECTRONICS ITALIA S.p.A.
