- Page 1 Operating Instructions EB-GD70 Digital Cellular Telephone Main Kit Before operating this equipment please read these instructions completely.
-
Page 3: Table Of Contents
Before You Start ....1 Symbols Used, Safety Information, Fitting/Removing the SIM, Fitting/Removing the Battery Your Telephone ....4 Location of Controls, Display Basic Operation . -
Page 4: Before You Start
Thank you for purchasing this Panasonic GD70 digital cellular telephone. This telephone is designed to operate on the Global System for Mobile Communications (GSM), GSM900 or GSM1800. These operating instructions detail use of the equipment contained in the Main Kit. Some services are network dependent or may only be available on a subscription basis. -
Page 5: Fitting The Sim
You are advised not to use the equipment at a refuelling point. You are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants or where blasting operations are in progress. Never expose the battery pack to extreme temperatures (in excess of 60°C) or charge the battery pack for much longer than recommended. - Page 6 Fitting/Removing the Battery Fit a fully charged battery pack. If the battery pack is not fully charged then it must be charged as shown in “Charging the Battery” – see page 28. Fitting the Battery Removing the Battery...
-
Page 7: Your Telephone
Location of Controls Antenna Speaker Display Microphone External connector Your Telephone g Navigation key – pressing up/down scrolls through options in the main area of the display or adjusts the volume. Pressing left/right scrolls through options in the Incoming/charging option area of the display (see Display below) indicator B Select key –... - Page 8 Display Menu Location area - indicates Option area - shows options menu number, location that can be selected by B key number, or alpha mode Following some operations the display will automatically clear after three seconds or after pressing any key. Y lights when you are registered to a non-home network - roaming t lights when call divert is enabled...
-
Page 9: Basic Operation
Power on/off F E and hold to switch power on A greeting will be displayed. F E and hold to switch power off Making a Call Make sure that the telephone is switched on and the signal strength meter is displayed. 1 F area code and telephone number 2 F D Emergency Calls... -
Page 10: International Dialling
International Dialling Using the Automatic International Access Code “+” you will be able to dial international numbers without having to know the code for the international exchange. 1 F 0 and hold until a “+” appears 2 F country code or e to scroll through the abbreviated international names 3 F area code and telephone number 4 F D... -
Page 11: Calling Line Identification
Calling Line Identification This feature allows you to identify incoming calls and accept or reject them. The caller’s telephone number, and name if stored in Phonebook, will be displayed. NOTE: Call Line Identification may not always be available. Adjusting Volume Earpiece Volume Four levels of earpiece volume are available. -
Page 12: Automatic Redial
Automatic Redial When a call is unsuccessful the telephone will ask if you want to redial the telephone number again automatically. F B when “OK” is displayed in the option area Auto Redial will countdown the display to the next redial To stop redialling, F B when “Cancel”... -
Page 13: Advanced Operation
Concept of Operation There is a close relationship between the select key, navigation key and the display. Pressing e scrolls through the main area of the display. Pressing f scrolls through options at the bottom right of the display. To choose the option, press B. Desktop Handsfree Desktop Handsfree allows you to hold a conference call, whereby more than one person can listen to the call at a time. -
Page 14: Voice Memo
Answering a call Handsfree F D and hold, will allow the call to be answered Handsfree. Voice Memo You can record a conversation for approximately 50 seconds during a call. If a different SIM is installed any recorded message will be lost. CAUTION: Security of a recorded message is your responsibility. -
Page 15: Dtmf Tones
Erase F B twice during playing DTMF Tones DTMF tones can be sent during conversation. These are often used to access voice mail, paging and computerised home banking. For example, you may need to input a number to remotely access voice mail messages. Send DTMF Tones During a Call F digits (0 to 9, # and *) Pause Dial... - Page 16 Making a Second Call 1 F telephone number, or recall from Phonebook – see “Retrieving a Telephone Number” page 17 2 F D The first call will be placed on hold. Receiving a Second Call A second call can be received, if call waiting is switched on – see “Call Service” page 24. It is not possible to have more than one fax or data call.
-
Page 17: Operation During Two Calls
Operation During Two Calls Swap Between Calls F B when “Swap” is displayed in the option area End Current Call 1 F f to display “End” in the option area 2 F B The held call will remain held. End Both Calls Held call Current call 00:34... -
Page 18: Stored Numbers
Note Pad During a call you can enter numbers which you may wish to dial when the call has ended. During a call:F telephone number When the call has ended press D to call that number To store in Phonebook, press A while the number is displayed – see “Phonebook” page 22. Recent Numbers Recently dialled telephone numbers will be stored in “Last Dialled”. -
Page 19: Returning An Unanswered Call
Calling the Last Dialled Number To redial your last called telephone number F D D Returning an Unanswered Call When the display shows that you have received calls but not answered them. 1 F B The last caller’s telephone number will be displayed. 2 F e to point at the telephone number you wish to dial 3 F D Phonebook... -
Page 20: Overwrite Protection
Automatic Location The telephone number can be stored automatically at the first available location. This can be done instead of entering a location number. F B when “Any” is displayed in the option area of the display Overwrite Protection If a location is occupied you will be asked if you wish to overwrite the current information. F B to overwrite the selected location F C to choose another location number Retrieving a Telephone Number... - Page 21 View This is used to review the telephone number and name together or just the name. F B when “View” is displayed in the option area Recall 1 F f to display “Recall” in the option area 2 F B Dialling When the desired telephone number or name is displayed Editing...
-
Page 22: Fixed Dial
Speed Dial a Stored Number 1 F location number – leading zeros may be left out 2 F # 3 F D Fixed Dial The Fixed Dial Store is part of Phonebook, but with additional security. When the security feature Fixed Dial is switched on it is only possible to make calls with telephone numbers that are in the Fixed Dial Store. -
Page 23: Service Numbers
Service Numbers Your Service Provider may program some special telephone numbers into the Service Dial area of the Phonebook. It is not possible to modify the telephone numbers stored in the Service Dial part of the Phonebook. F A and hold F g to browse through the Service Dial list of telephone numbers The telephone number pointed to can only be recalled or dialled. -
Page 24: Alpha Entry
Alpha Entry is used to enter alphanumeric characters into Phonebook, Short Messages, Price Per Unit and the Greeting Message. Character entry type Normal Greek Space“@,.;:!¡?¿()’&%+-/<>=£$¥¤§ ABCabc DEFdef GHIghi JKLjkl Each time a key is pressed it will display the next character. When another key is pressed or no key is pressed for a short time the cursor will move to the next position. -
Page 25: Additional Features
When the word “Menu” is in the option area of the display pressing the B will display a menu of telephone features. To select a feature press e so that the pointer is showing next to the feature that you require then press B. A quick way of selecting a feature is to press the menu number shown in the bottom left of the display. - Page 26 Messages Messages Receive List Send List Create Review Parameters Broadcasts Receive Message List Topics Languages You can receive, display, edit and/or send short text messages, of up to 160 characters. Before you can send a message you must enter the Message Centre number into the Parameters.
-
Page 27: Call Service
When your message has been delivered a confirmation can be received if Report is set to “Yes”. The Message Centre may be able to convert the message to the format specified by Protocol. Broadcasts Broadcast can display information about your current area such as traffic or weather information. -
Page 28: Call Divert
Using Withhold ID it is possible to check if you send Calling Line Identification information when you make a call. When checking the Status of Withhold ID the telephone must be registered with a network. Call Charge will set the cost of each unit for call charge information and the required currency in which call charge is displayed. - Page 29 enabled the lock icon (O) is displayed. To restore normal operation, enter your lock code. Call Bar is used to restrict certain outgoing and/or incoming calls. Call Bar is controlled by a security Password that is supplied by your Service Provider. When updating or checking the Status of Call Bar the telephone must be registered with a network.
- Page 30 Personalise Personalise Language Tones All Tones Keep Alive Ring Volume Auto Answer Ring Type Greeting Key Volume Backlight Warning Tone DTMF Length Defaults Hot Key Dial The Language that the telephone will use for display messages can be changed. In Tones, the telephone key, ring and warning tones (except low battery warning), can be switched off.
-
Page 31: Battery Information
Low Battery When the battery power is low a warning tone will sound and a LOW BATTERY message will flash. The power will automatically shut off shortly after the warning tone. Fully charge the battery pack or replace it with a fully charged one. During conversation finish your call immediately. -
Page 32: Care And Maintenance
Care and Maintenance Pressing any of the keys may produce a loud tone. Avoid holding the telephone close to the ear while pressing the keys. Extreme temperatures may have a temporary effect on the operation of your telephone. This is normal and does not indicate a fault. Do not disassemble the equipment. -
Page 33: Other Information
Glossary of Terms Dual Tone Multi-Frequency tones allow you to communicate with computerised telephone DTMF Tones systems, voice mailboxes etc. Global System for Mobile Communications. The name given to the advanced digital technology that your telephone uses. Home country The country where your home network operates. Home network The GSM network on which your subscription details are held. -
Page 34: Trouble Shooting
Glossary of Terms continued PIN/PIN2 Unblocking Key. Used to unblock the PIN/PIN2. Supplied by your Service Provider. PUK/ PUK2 If the PUK/PUK2 is entered incorrectly 10 times, the PUK/PUK2 will be blocked. The act of locking on to a GSM network. This is usually performed automatically by your Registration telephone. - Page 35 Extremely short The network you are using and battery life for a new the condition of the battery battery pack. pack can affect battery life. Short battery life for The battery pack was worn an old battery pack. out. The life of the battery pack is Short battery life for affected by improper charging, Ni-MH battery pack.
-
Page 36: Important Error Messages
Trouble Shooting continued Calls cannot be made from Fixed Dial Store The telephone is not switched Calls cannot be Incoming calls are barred. received. The telephone is not registered to a network. Emergency calls You are not in a GSM cannot be made. - Page 37 Network not Roaming with the selected network is not allowed. Allowed Security The network has detected authentication failure because your SIM is not registered with that Failure network. Contact your Service Provider. The SIM is blocked because the wrong PUK has been entered ten times. Contact your Service SIM Blocked Provider.
-
Page 38: Specifications
Telephone GSM900 Class 4 Type GSM1800 Class 1 Temperature range Charging +5°C to +35°C Storage -20°C to +60°C Battery – Attached to telephone Battery Pack (EB-BSD70) Weight 134g Dimensions 132 x 45.5 x 19.5mm Height x Width x Depth Supply Voltage 3.6V DC, 860mAh Li-Ion Standby time (h) Up to 100... - Page 39 The Serial Number can be found on the outside of the telephone under the battery. For your convenience we recommend that you note the following details as a record of your purchase. Part Number Serial Number Dealer Name Purchase Date BULL CP8 PATENT ©...
- Page 40 Printed in UK 990119...
