SERVICE MANUAL
Revised-1
System
Laser: Semiconductor laser
Channel coverage:
PAL/SECAM (B/G, D/K, I, L)
VHF: E2 to E12, R1 to R12, F1 to F10, Italian
A to H, Ireland A to J, South Africa 4 to 13/
UHF: E21 to E69, R21 to R69, B21 to B69,
F21 to F69/CATV: S01 to S05, S1 to S20,
France B to Q/HYPER: S21 to S41
The above channel coverage merely ensures the
channel reception within these ranges. It does not
guarantee the ability to receive signals in all
circumstances.
Video reception: Frequency synthesizer system
Audio reception: Split carrier system
Aerial out: 75-ohm asymmetrical aerial socket
Timer: Clock: Quartz locked/Timer indication:
24-hour cycle (digital)/Power back-up
duration: 1 hour
Video recording format: MPEG Video
Audio recording format/applicable bit rate:
Dolby Digital/2 ch, 256 kbps
When you play PCM sound tracks with a 96 kHz
sampling frequency, the output signals from the
DIGITAL OUT (OPTICAL or COAXIAL) jack
are converted to 48 kHz sampling frequency.
Inputs and outputs
LINE 2 OUT
(AUDIO): Phono jack/2 Vrms/10 kilohms
(VIDEO): Phono jack/1.0 Vp-p
(S VIDEO): 4-pin mini DIN/Y:1.0 Vp-p, C: 0.3
Vp-p (PAL)
LINE 2 IN/LINE 4 IN
(AUDIO): Phono jack/2 Vrms/more than 22
kilohms
(VIDEO): Phono jack/1.0 Vp-p
(S VIDEO): 4-pin mini DIN/Y:1.0 Vp-p, C: 0.3
Vp-p (PAL)
RDR-HX900
SPECIFICATIONS
LINE 1 -TV: 21-pin
CVBS IN/OUT
S-Video/RGB OUT (upstream)
LINE 3/DECODER: 21-pin
CVBS IN/OUT
S-Video/RGB IN
S-Video OUT (downstream)
Decoder
DV IN: 4-pin/i.LINK S100
DIGITAL OUT (OPTICAL): Optical output
jack/–18 dBm (wave length: 660 nm)
DIGITAL OUT (COAXIAL): Phono jack/0.5
Vp-p/75 ohms
COMPONENT VIDEO OUT
(Y, P
/C
, P
B
B
Phono jack/Y: 1.0 Vp-p, P
P
/C
: 0.7 Vp-p
R
R
General
Power requirements: 220-240 V AC, 50/60 Hz
Power consumption: 54 W
Dimensions (approx.): 430 × 89 × 346 mm
(width/height/depth) incl. projecting parts
Hard disk drive capacity: 160 GB
Mass (approx.): 5.9 kg
Operating temperature: 5 ºC to 35 ºC
Operating humidity: 25 % to 80 %
Supplied accessories:
Audio/video cord (1)
Mains lead (1)
Aerial cable (1)
Remote commander (remote) (1)
R6 (size AA) batteries (2)
Specifications and design are subject to change
without notice.
RMT-D206P
AEP Model
UK Model
/C
):
R
R
/C
: 0.7 Vp-p,
B
B

DVD RECORDER

Advertisement

Table of Contents
loading

Summary of Contents for Sony RDR-HX900

  • Page 1: Dvd Recorder

    RDR-HX900 RMT-D206P SERVICE MANUAL AEP Model UK Model Revised-1 SPECIFICATIONS System LINE 1 -TV: 21-pin CVBS IN/OUT Laser: Semiconductor laser S-Video/RGB OUT (upstream) Channel coverage: LINE 3/DECODER: 21-pin PAL/SECAM (B/G, D/K, I, L) CVBS IN/OUT VHF: E2 to E12, R1 to R12, F1 to F10, Italian...
