Sony TRINITRON CPD-110GS Service Manual

SERVICE MANUAL
REVISED
MICROFILM
CPD-110GS/110EST
SPECIFICATIONS
CRT 0.25 mm aperture grille pitch
15 inches measured diagonally
90-degree deflection
Approx. 285 × 214 mm (w/h)
Viewable image size
(11
14.0" viewing image
Resolution Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
Approx. 270 × 202 mm (w/h)
Standard image area
(10
Deflection frequency* Horizontal: 30 to 70 kHz
Vertical: 48 to 120 Hz
AC input voltage/current 100 to 240 V, 50 – 60 Hz, 1.6 – 0.8 A
Power consumption Max. 105 W
Approx. 368 × 393 × 389 mm (w/h/d)
Dimensions
(14
Mass Approx. 14 kg (30 lb 14 oz)
Plug and Play DDC1/DDC2B
Supplied accessories See page 6
* Recommended horizontal and vertical timing condition
• Horizontal sync width should be more than 1.0 µsec.
• Horizontal blanking width should be more than 3.6 µsec.
• Vertical blanking width should be more than 500 µsec.
Design and specifications are subject to change without notice.
TRINITRON
®
Canadian Model
X-110
1 × 8 1
/ / inches)
4 2
× 8 inches)
3
/
4
× 15 × 15
1 1 3
/ / / inches)
2 2 8
COLOR COMPUTER DISPLAY
CPD-110GS
US Model
Chassis No. SCC-L27A-A
CPD-110EST
AEP Model
Chassis No. SCC-L27B-A
CHASSIS
