Samsung SGH-X530 Service Manual

Samsung mobile phone service manual
Hide thumbs Also See for SGH-X530:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
GSM TELEPHONE
SGH-X530
GSM TELEPHONE
CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts list
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Flow Chart of Troubleshooting
10. Reference data

Advertisement

Table of Contents
loading

Related Manuals for Samsung SGH-X530

Summary of Contents for Samsung SGH-X530

  • Page 1 GSM TELEPHONE SGH-X530 GSM TELEPHONE CONTENTS 1. Safety Precautions 2. Specification 3. Product Function 4. Array course control 5. Exploded View and Parts list 6. MAIN Electrical Parts List 7. Block Diagrams 8. PCB Diagrams 9. Flow Chart of Troubleshooting...

  • Page 2: Table Of Contents

    Contents 1. Safety Precautions 1-1. Repair Precaution ................1-1 1-2. ESD(Electrostatically Sensitive Devices) Precaution ......1-2 2. Specification 2-1. GSM General Specification ..............2-1 2-2. GSM TX power Level ..............2-2 3. Product Function 4. Array course control 4-1. Downloading Binary Files .............4-2 4-2. Pre-requsite for Downloading ............4-2 4-3.
  • Page 3 Contents 9. Flow Chart of Troubleshooting 9-1. Baseband ................9-1 9-1-1. Power ON ................9-1 9-1-2. Initial ................9-4 9-1-3. SIM Part ................9-6 9-1-4. Microphone Part ..............9-7 9-1-5. Speaker Part_1(MP3, SPEAKER PHONE) ........9-8 9-1-6. Speaker Part_2(RECEIVER) ..........9-10 9-1-7. Charging Part ..............9-11 9-2. RF ..................9-13 9-2-1.

  • Page 4: Safety Precautions

    ● Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 5: Esd(Electrostatically Sensitive Devices) Precaution

    ● You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 6: Specification

    2. Specification 2-1. GSM General Specification GSM900 E G S M 9 00 DCS1800 PC S1 90 0 P ha se 1 Ph ase 2 Ph ase 1 Freq. Band[MHz] 890~915 880~915 1710~1785 1850~1910 Uplink/Downlink 935~960 925~960 1805~1880 1930~1990 0~124 & ARFCN range 1~124 512~885...
  • Page 7 Speclflcation 2-2. GSM Tx Power Class TX Power TX Power TX Power GSM900 DCS1800 PCS1900 control level control level control level 33±2 dBm 30±3 dBm 30±3 dBm 31±2 dBm 28±3 dBm 28±3 dBm 29±2 dBm 26±3 dBm 26±3 dBm 27±2 dBm 24±3 dBm 24±3 dBm 25±2 dBm...

  • Page 8: Product Function

    3. Product Function Main Function - Speed dial - SDN(Service Dialling Numbers) - Network services - Read SMS or MMS message - Voicemail - SOS messages SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 9: Array Course Control

    4. Array course control Test Jig (GH80-03307A) Test Cable (GH39-00127A) RF Test Cable (GH39-00283A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 10: Downloading Binary Files

    •Swift Model firmware is composed of 2 files –*.s3 : Main source code binary. 4-2. Prerequisite •Downloader program(Optiflash.exe) •X530 Moblie Phone •Data Cable •Binary Files SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 11: S/W Downloader Program

    -> “Settings” -> “Generic” -> “Specify hardware platform”. Choose hardware platform for the downloader file setting. Set the everything else as the default values which are shown below SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 12 OptiFlash will use to communicate with the phone. However, Optiflash will use a slower speed if either the PC’s or the phone’s serial hardware is incapable of handling the selected speed. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 Set the directory path and choose the latest S/W binary, for example "gsmstack.s3", for the downloader binary setting. And Check "Reserved Memory Regions" - 0x00008000 - 0x0001ffff 5. 1st. Press “Flash”. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 14 8. Confirm the downloaded version name by key-string( *#1234# Memory reset will be done by pressing the following key-strings. Full Reset : “ ” will reboot the phone automatically. *2767*3855# SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 15: Exploded View And Parts List

    QLC01 QCR17 QMO01 QSP01 QMP01 QME01 QME02 QPC01 QAN05 QMI01 QFL01 QAN02 QSH01 QSC01 QCR54 QRF03 QCR49 QRE01 QCR04 QVO01 QMI03 QIF01 QBA01 QCR05 QBA00 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 16: Cellular Phone Parts List

    QFR01 ASSY COVER-FRONT GH98-02237A QRE01 　 ASSY COVER-REAR GH98-02240A 　 QIF01 PMO-COVER IF GH72-34193A 　 QMI03 RMO-RUBBER MIC GH73-08289A 　 QRF03 PMO-COVER EAR JACK GH72-34192A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 17 MPR-VINYL BOHO WINDOW GH74-28851A MPR-TAPE BGA B GH74-28856A MPR-TAPE MAIN FPCB HOLD GH74-28942A MPR-SPONGE PCB GH74-28944A MPR-ELEC TAPE PCB A GH74-28946A MPR-VINYL BOHO FRONT GH74-29101A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 18: Disassembly

    2) Disjoint the FPCB by DESOLDERING. 1) Be careful for the damage on the WIRE or ※ caution RUBBER. 1) Be careful for the FPCB's crack SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 19 3) Take off the receiver from the Upper plastic. 2) Disjoint the FPCB with DESOLDERING. ※ caution ※ caution 1) Be careful for the Cammera's crack. 1) Be careful for the FPCB's crack SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 20 1) Insert the MAIN FPCB like the picture below. 1) Be careful for scratch ※ caution 2) Be careful for the FPCB's crack 1) Be careful for the FPCB's crack SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 21 2) Put the PBA first, and then MOT, SPK. put the MIC. ※ caution ※ caution 1) Be careful the wire. 1) Be careful the rubber's folding. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 22 ※ caution ※ caution 1) Be careful for the damage of plastic. 1) Be careful for the damage of plastic. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 23 Exploded View and Parts List 1) Joint 5 screws with the prop. ※ caution 1) Be careful for the damage of plastic. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 24: Main Electrical Parts List

    IC-MELODY 1205-003116 U101 IC-TRANSCEIVER 1209-001712 U201 IC-SENSOR 1405-001082 V100 VARISTOR 1405-001082 V102 VARISTOR 1405-001082 V103 VARISTOR 1405-001082 V205 VARISTOR 1405-001082 V206 VARISTOR 1405-001082 V306 VARISTOR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 25 R-CHIP 2007-000162 R211 R-CHIP 2007-000164 R206 R-CHIP 2007-000164 R318 R-CHIP 2007-000168 R325 R-CHIP 2007-000170 R212 R-CHIP 2007-000170 R303 R-CHIP 2007-000171 R313 R-CHIP 2007-000171 R314 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 26 R-CHIP 2007-008045 R103 R-CHIP 2007-008137 R121 R-CHIP 2007-008419 R122 R-CHIP 2007-008419 R124 R-CHIP 2007-008419 R125 R-CHIP 2007-008419 R126 R-CHIP 2007-008419 R127 R-CHIP 2007-008419 R128 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 R-CHIP 2203-000233 C222 C-CER,CHIP 2203-000233 C316 C-CER,CHIP 2203-000254 C204 C-CER,CHIP 2203-000254 C205 C-CER,CHIP 2203-000254 C206 C-CER,CHIP 2203-000254 C207 C-CER,CHIP 2203-000254 C209 C-CER,CHIP 2203-000254 C210 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 28 C-CER,CHIP 2203-002668 C164 C-CER,CHIP 2203-005344 C216 C-CER,CHIP 2203-005344 C323 C-CER,CHIP 2203-005344 C337 C-CER,CHIP 2203-005395 C163 C-CER,CHIP 2203-005482 C335 C-CER,CHIP 2203-005482 C338 C-CER,CHIP 2203-005682 C102 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 C-CER,CHIP 2203-006048 C317 C-CER,CHIP 2203-006048 C319 C-CER,CHIP 2203-006048 C324 C-CER,CHIP 2203-006048 C326 C-CER,CHIP 2203-006048 C330 C-CER,CHIP 2203-006048 C342 C-CER,CHIP 2203-006048 C345 C-CER,CHIP 2203-006048 C349 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 30 C-CER,CHIP 2203-006556 C136 C-CER,CHIP 2203-006556 C157 C-CER,CHIP 2203-006556 C158 C-CER,CHIP 2203-006556 C159 C-CER,CHIP 2203-006556 C160 C-CER,CHIP 2203-006556 C161 C-CER,CHIP 2203-006556 C162 C-CER,CHIP 2203-006562 C143 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 31 INDUCTOR-SMD 2703-002858 L103 INDUCTOR-SMD 2703-002858 L104 INDUCTOR-SMD 2801-003856 OSC200 CRYSTAL-SMD 2801-004455 OSC100 CRYSTAL-SMD 2801-004573 OSC300 CRYSTAL-SMD 2904-001592 F100 FILTER-SAW 2904-001599 F101 FILTER-SAW 2904-001600 F102 FILTER-SAW SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 32 3709-001384 SIM300 CONNECTOR-CARD EDGE 3710-001611 IFC101 CONNECTOR-INTERFACE 3711-006228 BTC104 HEADER-BATTERY 3722-002067 EAR300 JACK-EAR PHONE 4302-001130 BAT300 BATTERY-LI(2ND) GH09-00036A UCP201 IC MICOM-SGHX480 GH13-00036A U301 IC ASIC-SGHX670 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 33: Block Diagrams

    7. Block Diagrams VBAT Current Charging D[0:15] A[1:23] VBAT VCCA_2.9V VCCB_2.9V VRF_2.9V VCCD_2.9V VCCD_1.8V JIG ON RX_EN VBAT SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 34: Pcb Diagrams

    TP_INTRQ UCP201 VCORE TP_CP_OEN CP_TMS DSP_INT TR300 U201 SIM300 U103 BTC104 V307 V306 ZD101 ZD100 U104 BAT300 MIC301 IFC101 TP103 TP105 TP102 TP101 TP100 CN100 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 PCB Diagrams ZD302 V205 CN103 V206 V207 V208 V202 V201 V204 LED210 LED208 V203 V200 SHARP STAR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 36: Flow Chart Of Troubleshooting

    Flow Chart of Troubleshooting 1. Baseband 9-1-1. Power ON 'Power ON' does not work check the current consumption Download again >= 100mA Check the Voltage of the Battery Charge the battery >= 3.3V Check the pin C311, Check C312, C314, C315 "Power On Download again with jig box"...
  • Page 37 Flow Chart of Troubleshooting UP_CLK SIMCLK UP_RST SIMRST VRTC_3V UP_IO SIMDATA SIM_IO SIM_IO SIM_RST SIM_RST SIM_CLK SIM_CLK VSIM VSIM VRTC LED2_DRV KEY_BL2 VCCB_2.9V VRF_2.9V VCCD_1.8V LED1_DRV KEY_BL1 VCCA_2.9V VCCD_2.9V RING_DRV VIB_DRV R301 VLDO_7 VLDO_6 VL5S_B C9 VL5S_A VLDO_5 VL4S_B BAND_SEL2 VL4S_A BAND_SEL1 VLDO_4...

  • Page 38: Initial

    Flow Chart of Troubleshooting 9-1-2. Initial Initial Failure check the pin RSTB of UCP201 Check UCP201 is LOW? check the pin CKI Check of UCP201 is R101, C105 13Mhz? Check the clock signal check at pin #3 of OSC100 OSC100 Freq=26Mhz? Check the pin #9 of U101 is HIGH and pin #11,...
  • Page 39 Flow Chart of Troubleshooting VCCD_1.8V VCCD_1.8V VCCD_2.9V VCCD_2.9V VRTC_3V R204 C215 C216 C217 C218 VCORE VREF CLK13M_TR TR_RST TDO F12 TR_RST TRST CKO/IACK/ERAMHI IOBIT[2]/VEC[3]/EROMHI CHG_OFF IOBIT[1]/VEC[4]/PLLTOA DSP_INT DSP_INT INT#0 DSP_IO UCP201 DSP_RWN DSP_AB(8:0) DSP_AB(8) AB#8 DSP_AB(7) AB#7 DSP_AB(6) AB#6 DSP_AB(5) AB#5 DSP_AB(4) AB#4...

  • Page 40: Sim Part

    Flow Chart of Troubleshooting 9-1-3. Sim Part "Insert SIM" is displayed on the LCD The voltage is 2.8V Check the UCP300 at the pin#1 of Is there any signal Check the UCP201 & UCP300 pin #2,3,4 of SIM300? Check the SIM Card SIM300 R300 VSIM...

  • Page 41: Microphone Part

    Flow Chart of Troubleshooting 9-1-4.Microphone Part * Call with Sim before testing. MicroPhone does not work Check the soldered Resolder microphone status of microphone Check the reference Check voltage on mic path C346,R328,R332,C358,R330,R331,C349, R326 ≒ 2.0V C355,C348,R327,R333 Check UCP300 Is microphone OK? VCCA_2.9V R326 C348...
  • Page 42 Flow Chart of Troubleshooting...

  • Page 43: Speaker Part_2(Receiver)

    Flow Chart of Troubleshooting 9-1-5. Speaker Part There is no sound from speaker Check the connection reconnect speaker status at speaker pad Are there any signal at Replace the speaker module the speaker pad?
  • Page 44 Flow Chart of Troubleshooting 9-1-6. LCD backlight Backlight does not work Backlight ON "TIME" Select backlight "15 sec" mode mode in the menu? Check conecting between PBA and LCD Check FPCB conector Check the U102 on the LCD PCB...
  • Page 45 Flow Chart of Troubleshooting 9-2. RF 9-2-1. GSM Rx CONTINOUS RX ON RF INPUT : 62CH AMP : -50dbm Normal condition Check ANT, R102, R105, R135 catch the channel ? Check U100 Resolder or change pin 12 ≥ -65 RFS601, C110,L106,L103,L104 dbm ? Check U100 Resolder or change...
  • Page 46 Flow Chart of Troubleshooting 9-11...

  • Page 47: Dcs Rx

    Flow Chart of Troubleshooting 9-2-2. DCS Rx CONTINOUS RX ON RF INPUT : 698CH AMP : -50dbm Normal condition catch the Check ANT, R102, R105, R135 channel ? Check U100 Resolder or change pin 12 ≥ -65 RFS601, C110,L106,L103,L104 dbm ? Check U100 Resolder or change pin 18 ≥...
  • Page 48 Flow Chart of Troubleshooting 9-13...

  • Page 49: Pcs Rx

    Flow Chart of Troubleshooting 9-2-3. PCS Rx CONTINOUS RX ON RF INPUT : 660CH AMP : -50dbm Normal condition catch the Check ANT, R102, R105, R135 channel ? Check U100 Resolder or change pin 12 ≥ -65 RFS601, C110,L106,L103,L104 dbm ? Check U100 Resolder or change pin 20 ≥...
  • Page 50 Flow Chart of Troubleshooting 9-15...
  • Page 51 Flow Chart of Troubleshooting RFS601 F100 C101 GSM_LNA_IN_N FEEDING L101 C103 C106 GSM_LNA_IN_P R102 L103 L104 R135 L106 C109 R105 F101 ANT_GND C110 C111 DCS_LNA_IN_N L108 C112 C113 DCS_LNA_IN_P F102 C114 PCS_LNA_IN_N L109 C115 C117 PCS_LNA_IN_P VCC2 21 GND5 U100 19 GND4 L110 VCC1...
  • Page 52 Flow Chart of Troubleshooting 9-2-4. GSM Tx CONTINUS TX ON CONDITION TX POWER DAC : 554 CODE Check U101 Check and Check U101 APPLIED pin 15 : about change pin 6 : 2.8V ? CH : 62ch 2~3 dbm? UCP201,UCP300 RBW : 100KHz VBW : 100KHz SPAN : 10MHz...

  • Page 53: Pcs Tx

    Flow Chart of Troubleshooting 9-2-5. DCS/PCS Tx CONTINUS TX ON CONDITION TX POWER DAC : 560 CODE Check U100 Check U101 APPLIED Check and pin 16 : about pin 6 : 2.8V ? CH : 698CH(DCS), change 2~3 dbm? 660CH(PCS) UCP201,UCP300 RBW : 100KHz VBW : 100KHz...

  • Page 54: Reference Data

    PS : Pilot Symbol QPSK: Quadrature Phase Shift Keying RS : Reed-Solomon SI : Service Information TDM : Time Division Multiplexing TS : Transport Stream 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 55 ⓒ This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2006. 11. Rev.1.0...
