MJX HYPER GO 16207 User Manual

1:16 rc high speed car
Hide thumbs

Advertisement

Quick Links

Download this manual
14+
No.16207
1:16 RC HIGH SPEED CAR
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYPER GO 16207 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MJX HYPER GO 16207

Summary of Contents for MJX HYPER GO 16207

  • Page 1 No.16207 1:16 RC HIGH SPEED CAR USER MANUAL...

  • Page 2: Warnings And Cautions

    The instruction sheet for this product is just for your reference. We reserve the right to make changes or adjustments on the product without prior notification. Please refer to the official information. Warning: Choking hazard! This product contains small parts. NOT suitable for children under 3 years. Contains electrical components and should be kept dry at all times.
  • Page 3 ●Be sure to read thoroughly ●Cutters, nippers and ●As the product contains the manual before you screwdrivers need careful small and sharp parts, begin. Fresh user should handling. assemble and store this seek advice from people product only in places having rich experience in out of the reach of children.
  • Page 4 FCC PART 15 B Notice: CAUTION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: Power Switch

    Power Switch 1. Turn on the power switch of the transmitter, the signal indicator light of transmitter flashes. 2. Press the power button of high speed car, which is on the side of the ESC; the indicator light of high speed car flashes.
  • Page 6 E45A Brushless ESC Please Do Not forcible/reversely insert all sockets. E45A Indicator Meanings light situation Indicator Stays on Signaled Power switch a. No signal Flash quickly VCC/BVD b. Pull the trigger Heat sink Flash slowly Low voltage Over heat Flash twice protection Yellow wire A Stuck protection...
  • Page 7 ③Power/Speed switch ④Indicator light Stays on Working well Flash quickly Frequency mating Flash slowly Low battery of transmitter 100% (70% Throttle) (100% Throttle) ⑤CH1: ST (Steering) Middle Turn left Turn right ⑥CH2: TH (Throttle) Forward Backward Push Brake: When the car is going forward, pull the transmitter trigger back, Pull Pull forward...
  • Page 8 Install the Head Wheels Fix the head wheels into the rear of the car via 3 screws. Install the Tail Install the tail to the body, lock with 2 screws. Install the Transmitter’s Battery Open the transmitter’s battery cover, insert 2 AA batteries according to the indicated positive and negative direction, close the battery cover.
  • Page 9 Install Battery and Charge Battery Install the battery ①Turn the battery lock knob and flip up the cover; ②Connect the receiver plug to the battery; ③Put the battery into the battery holder and make sure it is in place; ④Flip back the cover and turn the knob to lock it. Charge High speed car battery: 11.1V 1050mAh 25C.
  • Page 10 Install Car Shell 1. Aline the 3 holes of the car shell with holders, then install it. 2. Insert the 3 clips into the holes to lock the car body.
  • Page 11 16200 Front Swing Set Screw: Q1601 M26124 2.6x12.5mm 2PCS 16210 M26124 Countersunk flat head screws 16230 R168Z 16200 Bearing: R168Z 2PCS Ball bearing R168Z 16220 Pivot balls: Q1601 2PCS Q1601 M26124 Steering pivot balls 16202 Rear Swing Set Screw: 16240B M23124 2.3x12mm 1PCS...
  • Page 12 16420 Metal Gears Diff Assembly Screw: Bearing: R1810 2PCS M2123 2x12mm 4PCS R1810 Countersunk flat Ball bearing head screws M2525 2.5x2.5mm 1PCS Hexagon socket machine screw M2525 R1810 M2123 16420 M2123 16700 Servo Assembly Screw: M26126 2.6x12mm 1PCS 16701 Screws 16700 M26126 16702...

  • Page 13: Motor Assembly

    Motor Assembly Screw: M25845 2.5x8mm 2PCS (16393) 16397C Countersunk flat head screws M31256 M3066 3x6mm 2PCS (16393B) Countersunk flat head screws 16395C M31256 3x12.5mm 2PCS Machine screws M3030 3x3mm 1PCS Hexagon socket machine screw B2845 B284C & 16397C 16392B 16393/16393B M3030 M25845/M3066 16430S Steering Assembly...
  • Page 14 High Speed Car Assemble Screw: M26104 M23104 M2384 2.3x8mm 4PCS M23104 Round head screws M26104 16190 M2664 2.6x6mm 2PCS Round head screws 16160 M26104 2.6x10mm 10PCS Round head screws M23104 2.3x10mm 6PCS Round head screws 16400 16420 16420 M2684 2.6x8mm 4PCS Round head screws M26104...
  • Page 15 -14-...
  • Page 16 -15-...
  • Page 17 High Speed Car Assemble Iron shaft: M20101 1PCS (4PCS) Wheel hex pins 16440 1PCS (4PCS) Wheel hex Nut: 1PCS (4PCS) M4 Wheel lock nut 16440 M20101 16300C -16-...

  • Page 18: Spare Parts

    Spare Parts 1601G 1610A 1611A 16120S Front Bumper Assembly Body Rear Bumper (Metal) Wheelie Bar Assembly (Metal) 1612B 16130 16140 16150 Tail Chassis Parts Battery Clip Chassis 16160 16170 16180 16282 Front Upper Gearbox Front Shock Tower Rear Shock Tower F/R Body Pillars Covers 16190...
  • Page 19 Spare Parts 16240B 16250 16260 M25425 Rear Upper Suspension Rear Lower F/R Lower Suspension Rear Hubs Arms Suspension Arms Arms Hinge Pins (Including Ball Head) M1640A 16300C 16410 M20101 Wheel Assembly Metal F/R CVD Shafts Wheel Hex Pins Rear Reinforced Sheet (2PCS) (2 Sets) (8PCS)
  • Page 20 Spare Parts B284C B2845 16392B 16393/16393B Motor Assembly Brushless Motor Motor Pinions Motor Guard 16395C 16397C 16420 16400 Metal Gears Diff Metal Gears Main Motor Heatsink Motor Fan Assembly Driving Set 16401 16402 16403 E45A Brushless ESC Spur Gear Assembly Drive Gear Centre Drive Shaft (Metal)
  • Page 21 Spare Parts M26124 M23124 M2523 M26364 Countersunk Flat Head Countersunk Flat Head Rear Fixing Pin Step Flat Screws Screws Screws (12PCS) (12PCS) (4PCS) (12PCS) M2384 M2664 M26104 M23104 Round Head Screws Round Head Screws Round Head Screws Round Head Screws (12PCS) (12PCS) (12PCS)
  • Page 22 Spare Parts B3105 P3050 P812 M3294 Round Head Half Battery USB Charging Cable Hexagonal Wrench Thread Screws (12PCS) M26154 M2665 M001 P810 Countersunk Flat Head Step Flat Screws Body Clips Screwdriver Screws (12PCS) (12PCS) (12PCS) -21-...
  • Page 23 MADE IN CHINA Instructions must be retained since it contains important information.
