PDK RED 2 Quick Start Manual

1. Package Contents
Red 2
Two Door Controller (1)
Battery Leads (1)
4. Input A / DPS Connection
B
A
DPS Contact
Double DPS
Contact
A
DPS (Door Position Switch) - The DPS is mounted on the door frame in the
desired location with a 22/2 wire running from the DPS to the controller.
Wire the DPS to the controller as shown above. When using two DPS sensors
for double doors you will wire them in series with only two conductors
running back to the controller for connection.
B
AUX Input - A rule can be setup to trigger events or outputs based on this
input trigger.
Key Lock (1)
Jumpers (4)
Diodes (2)
PORT1
-
+
BUS
B
REX
A
Maglock
Exit) at the door for free egress. Run an 18/2 wire from the Maglock to the
Door Controller, connecting to the Maglock as shown.
B
REX (Request to Exit)
18/5 wire ran from the REX to the controller. Wire the REX to the controller
and maglock as shown above. If reporting is not needed in the system , simply
eliminate the green labeled wire.
C
Jumper - Use the designated jumper(s) to energize the relay output NO and
NC to utilize the output as a wet contact.
2. Mounting Controller
POWER
HEART
LINK
ETHERNET
ACTIVITY
POE OUT
POE IN
PORT1
PORT2
-
+ BUS
+ BUS - BATTERY
+ - + -
0 1 L - 0 1 L - 12VDC
A B NC C NO A B NC C NO
+ GND
Mount -
Mount the Red 2 enclosure securely to a wall.
5. Input B / REX Connection
C
If using a powered REX,
run to any 12VDC
output on controller. A
Maglock
- When installing a Maglock it is typical to install a REX (Request to
- The REX is mounted in the desired location with an
3. Reader Connection
A
Reader
C
D
A
Main Reader - The main reader is mounted at the door with a 22/5 or 22/6
wire ran to the door controller. Wire the reader to the controller as shown
above. Be sure to check polarity and voltage prior to powering controller.
B
Secondary Reader - Wire the second reader to the controller as shown
above. Be sure to check polarity and voltage prior to powering the controller.
C
OSDP - Place jumper(s) to enable OSDP (see OSDP reference guide at the
end of this guide for more info)
D
Piezo - Can be connected to available relay and configured with software
6. Locking Relay
C
B
OR
A
A
Diode - The provided diode must be installed when using a strike. Install at
the strike with the grey stripe of diode on positive and the black on negative.
B
NC - Used for maglocks (or strikes in fail-safe configuration). Connect the
negative (-) of the maglock or strike to NC on the door controller.
C
NO - Used for strikes in fail-secure configuration. Connect the negative (-) of
the strike to NO on the door controller.
D Jumper - Use the designated jumper(s) to energize the relay output NO and
NC to utilize the output as a wet contact.
Red 2 Controller
+ -
0 1 L
B
OSDP
Wiring
PORT1
D
-
+
BUS
